Siemens SINAMIC S120 Technical Document

SINAMICS
S120
Air
-Cooled Chassis Power Units -
supplement to Motor Module
6SL3320-1TG41-5AA3
Equipment Manual
10/2020
A5E50422764A
Introduction
1
Fundamental safety
instructions
2
Motor Module Chassis
6SL3320-1TG41-5AA3
3
DC link components
4
Cabinet design and EMC
5
Maintenance and service
6
Appendix
A

Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
A5E50422764A
Ⓟ
10/2020 Subject to change
Copyright © Siemens AG 2020.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication
may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
Equipment Manual, 10/2020, A5E50422764A 3
Table of contents
1 Introduction........................................................................................................................................... 5
1.1 The SINAMICS converter family ............................................................................................ 5
1.2 Usage phases and their documents/tools (as an example)..................................................... 8
1.3 Where can the various topics be found? ............................................................................... 9
1.4 Training and support.......................................................................................................... 10
1.5 Directives, standards, certificates ....................................................................................... 10
1.6 Additional information....................................................................................................... 11
1.7 General Data Protection Regulation.................................................................................... 12
2 Fundamental safety instructions......................................................................................................... 13
2.1 General safety instructions................................................................................................. 13
2.2 Handling electrostatic sensitive devices (ESD)..................................................................... 18
2.3 Industrial security .............................................................................................................. 19
2.4 Residual risks of power drive systems ................................................................................. 20
3 Motor Module Chassis 6SL3320-1TG41-5AA3...................................................................................... 21
3.1 Description ........................................................................................................................ 21
3.2 Safety information............................................................................................................. 23
3.3 Interface description.......................................................................................................... 25
3.3.1 Overview........................................................................................................................... 25
3.3.2 Connection example.......................................................................................................... 26
3.3.3 DC link/motor connection .................................................................................................. 27
3.3.4 X9 terminal strip................................................................................................................ 28
3.3.5 DCPS, DCNS....................................................................................................................... 28
3.3.6 X41 EP terminal / temperature sensor connection............................................................... 28
3.3.7 X42 terminal strip.............................................................................................................. 30
3.3.8 X46 Brake control and monitoring...................................................................................... 30
3.3.9 DRIVE-CLiQ interfaces X400, X401, X402 ........................................................................... 31
3.3.10 Meaning of the LEDs on the Control Interface Module in the Motor Module........................ 32
3.4 Technical data ................................................................................................................... 33
3.4.1 General technical data ....................................................................................................... 33
3.4.2 Current derating as a function of the ambient temperature and installation altitude ........... 35
3.4.3 Motor Modules, 675 ... 1035 V DC (line voltage 3 AC 500 ... 690 V).................................... 36
3.4.4 Overload capability ............................................................................................................ 38
3.4.5 Current de-rating depending on the pulse frequency.......................................................... 39
4 DC link components............................................................................................................................. 41
4.1 Braking Module ................................................................................................................. 41
4.1.1 Description ........................................................................................................................ 41
4.1.2 Safety information............................................................................................................. 43

Table of contents
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
4Equipment Manual, 10/2020, A5E50422764A
4.1.3 Interface description.......................................................................................................... 44
4.1.3.1 Braking Module for frame size JX ....................................................................................... 44
4.1.3.2 Connection example.......................................................................................................... 45
4.1.3.3 Braking resistor connection................................................................................................ 45
4.1.3.4 X21 digital inputs/outputs.................................................................................................. 46
4.1.3.5 S1 Threshold switch........................................................................................................... 47
4.1.4 Installing the Braking Module in a Motor Module, frame size JX.......................................... 48
4.1.5 Technical specifications ..................................................................................................... 49
4.2 Braking resistors ................................................................................................................ 51
4.2.1 Description........................................................................................................................ 51
4.2.2 Safety information............................................................................................................. 51
4.2.3 Dimension drawing............................................................................................................ 53
4.2.4 Electrical connection.......................................................................................................... 54
4.2.5 Technical data ................................................................................................................... 54
5 Cabinet design and EMC...................................................................................................................... 57
5.1 Notes ................................................................................................................................ 57
5.1.1 General ............................................................................................................................. 57
5.1.2 Safety information............................................................................................................. 57
5.1.3 Directives .......................................................................................................................... 59
5.2 EMC-compliant design and control cabinet configuration ................................................... 59
5.3 Notes on control cabinet climate control ............................................................................ 60
5.3.1 General ............................................................................................................................. 60
5.3.2 Ventilation......................................................................................................................... 61
6 Maintenance and service .................................................................................................................... 65
6.1 Chapter content................................................................................................................. 65
6.2 Maintenance ..................................................................................................................... 66
6.3 Service .............................................................................................................................. 67
6.3.1 Installation device.............................................................................................................. 68
6.3.2 Using crane lifting lugs to transport power blocks............................................................... 69
6.4 Replacing components....................................................................................................... 70
6.4.1 Safety information............................................................................................................. 70
6.4.2 Messages after replacement of DRIVE-CLiQ components..................................................... 70
6.4.3 Replacing the power block, Motor Module, frame size JX.................................................... 72
6.4.4 Replacing the Control Interface Module, Motor Module, frame size JX ................................ 74
6.4.5 Replacing the fan, Motor Modules, frame size JX................................................................ 76
6.4.6 Replacement of the fan fuses
............................................................................................. 78
6.5 Forming the DC link capacitors........................................................................................... 78
6.6 Recycling and disposal ....................................................................................................... 82
A Appendix ............................................................................................................................................. 83
A.1 Cable lugs.......................................................................................................................... 83
A.2 List of abbreviations........................................................................................................... 85
Index.................................................................................................................................................... 95

Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
Equipment Manual, 10/2020, A5E50422764A 5
Introduction
1
1.1 The SINAMICS converter family
With the SINAMICS converter family, you can solve any individual drive task in the low-
voltage, medium-voltage and DC voltage range. From converters to motors and controllers,
all Siemens drive components are perfectly matched to each other and can be easily
integrated into your existing automation system. With SINAMICS you are prepared for
digitization. You benefit from highly efficient engineering with a variety of tools for the entire
product development and production process. And you also save space in the control cabinet
– thanks to the integrated safety technology.
You can find additional information about SINAMICS at the following address
(http://www.siemens.com/sinamics).
SINAMICS documentation
The SINAMICS documentation is organized in the following categories:
•General documentation/catalogs
•User documentation
•Manufacturer/service documentation
Standard scope
The scope of the functionality described in this document can differ from that of the drive
system that is actually supplied.
•Other functions not described in this documentation might be able to be executed in the
drive system. However, no claim can be made regarding the availability of these functions
when the equipment is first supplied or in the event of service.
•The documentation can also contain descriptions of functions that are not available in a
particular product version of the drive system. Please refer to the ordering documentation
only for the functionality of the supplied drive system.
•Extensions or changes made by the machine manufacturer must be documented by the
machine manufacturer.
For reasons of clarity, this documentation does not contain all of the detailed information
about all of the product types, and cannot take into consideration every conceivable type of
installation, operation and service/maintenance.
Target group
This documentation is intended for machine manufacturers, commissioning engineers, and
service personnel who use the SINAMICS drive system.

Introduction
1.1 The SINAMICS converter family
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
6Equipment Manual, 10/2020, A5E50422764A
Benefits
This manual provides all of the information, procedures and operator actions required for the
particular usage phase.
Siemens MySupport/Documentation
You can find information on how to create your own individual documentation based on
Siemens content and adapt it for your own machine documentation at the following address
(https://support.industry.siemens.com/My/ww/en/documentation).
Additional information
You can find information on the following topics at the following address
(https://support.industry.siemens.com/cs/de/en/view/108993276):
•Ordering documentation / overview of documentation
•Additional links to download documents
•Using documentation online (find and search in manuals/information)
Questions relating to the technical documentation
Please send any questions about the technical documentation (e.g. suggestions for
improvement, corrections) to the following email address
(mailto:docu.motioncontr[email protected]).
FAQs
You can find Frequently Asked Questions under Product Support
(https://support.industry.siemens.com/cs/de/en/ps/faq).
Siemens Support for on the move
With the "Siemens Industry Online Support" app, you can access more than 300,000
documents for Siemens Industry products – any time and from anywhere. The App supports
you in the following areas:
•Resolving problems when executing a project
•Troubleshooting when faults develop
•Expanding a system or planning a new system
Further, you have access to the Technical Forum and other articles that our experts have
drawn-up:
•FAQs
•Application examples
•Manuals
•Certificates
•Product announcements and much more
The App "Siemens Industry Online Support" is available for Apple iOS and Android.

Introduction
1.1 The SINAMICS converter family
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
Equipment Manual, 10/2020, A5E50422764A 7
Data matrix code data on the rating plate
The data matrix code on the rating plate contains the specific device data. This code can be
read-in with any Smartphone and technical information for the appropriate device can be
displayed via the "Industry Online Support" Mobile App.
Web sites of third-party companies
This document includes hyperlinks to web sites of third-party companies Siemens accepts no
responsibility for the content of these web sites, nor does it use these web sites and their
content for its own use, as Siemens cannot check these web sites and is also not responsible
for the content and information provided on them. The user uses these web sites at his own
risk.

Introduction
1.2 Usage phases and their documents/tools (as an example)
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
8Equipment Manual, 10/2020, A5E50422764A
1.2 Usage phases and their documents/tools (as an example)
Usage phase
Tools
Orientation
SINAMICS S sales documentation
Planning/engineering •SIZER engineering tool
•SINAMICS Low Voltage Configuration Manual
•Configuration manuals, motors
Decision mak-
ing/ordering
SINAMICS S120 catalogs
•SINAMICS S120 and SIMOTICS (Catalog D 21.4)
•SINAMICS Converters for Single-Axis Drives – Built-In Units (D 31.1)
•SINAMICS S120 Chassis Format Units and Cabinet Modules, SINAMICS S150 Converter Cabinet
Units (catalog D 21.3)
Configur-
ing/installation •SINAMICS S120 Equipment Manual for Control Units and Supplementary System Components
•SINAMICS S120 Equipment Manual for Booksize Power Units
•SINAMICS S120 Equipment Manual for Booksize Power Units C/D Type
•SINAMICS S120 Equipment Manual for Air-Cooled Chassis Power Units
•SINAMICS S120 Equipment Manual for Liquid-Cooled Chassis Power Units
•SINAMICS S120 Equipment Manual water-cooled chassis power units for common cooling
circuits
•SINAMICS S120 Equipment Manual for AC Drives
•SINAMICS S120M Equipment Manual for Distributed Drive Technology
Commissioning
•STARTER Commissioning Tool
•SINAMICS S120 Getting Started
•SINAMICS S120 Commissioning Manual
•SINAMICS S120 Function Manual Drive Functions
•SINAMICS S120 Safety Integrated Function Manual
•SINAMICS S120 Communication Function Manual
•SINAMICS S120/S150 List Manual
Using/operating •SINAMICS S120 Commissioning Manual
•SINAMICS S120 Function Manual Drive Functions
•SINAMICS S120/S150 List Manual
Maintenance/Service
•SINAMICS S120 Commissioning Manual
•SINAMICS S120/S150 List Manual
List of references •SINAMICS S120/S150 List Manual

Introduction
1.3 Where can the various topics be found?
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
Equipment Manual, 10/2020, A5E50422764A 9
1.3 Where can the various topics be found?
Software
Manual
Alarms
Described in order of ascending num-
bers
SINAMICS S120/S150 List Manual
Parameters Described in order of ascending num-
bers
SINAMICS S120/S150 List Manual
Function block
diagrams
Sorted according to topic
SINAMICS S120/S150 List Manual
Described in order of ascending num-
bers
Drive functions
SINAMICS S120 Function Manual Drive Functions
Communication topics
SINAMICS S120 Function Manual Communication
2)
Safety Integrated
Basic and Extended Functions
SINAMICS S120 Safety Integrated Function Manual
Basic Functions
SINAMICS S120 Function Manual Drive Functions
Commissioning Of a simple SINAMICS S120 drive with
STARTER
Getting Started1)
Commissioning
With STARTER
SINAMICS S120 Commissioning Manual
1)
Commissioning
Of a simple SINAMICS S120 drive with
Startdrive
Getting Started
2)
Commissioning
With Startdrive
SINAMICS S120 Commissioning Manual
2)
Web server
SINAMICS S120 Function Manual Drive Functions
Hardware
Manual
Control Units and expansion components
SINAMICS S120 Equipment Manual for Control Units and
Supplementary System Components
Booksize power units
SINAMICS S120 Equipment Manual for Booksize Power Units
Power units, booksize C/D type format
SINAMICS S120 Equipment Manual for Booksize Power Units
C/D Type
Chassis power units SINAMICS S120 Equipment Manual for Chassis Power Units,
air, liquid or water cooled
AC drive components
SINAMICS S120 Equipment Manual for AC Drives
S120 Combi components
SINAMICS S120 Equipment Manual Combi
Diagnostics via
LEDs
STARTER
SINAMICS S120 Commissioning Manual
1)
Startdrive
SINAMICS S120 Commissioning Manual
2)
Meaning of the LEDs
Equipment Manuals
High Frequency Drive components
SINAMICS S120 System Manual High Frequency Drives
1)
Up to firmware version 5.1 SP1
2) From firmware version 5.2

Introduction
1.4 Training and support
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
10 Equipment Manual, 10/2020, A5E50422764A
1.4 Training and support
Training
At the following address (http://www.siemens.com/sitrain), you can find information about
SITRAIN (Siemens training on products, systems and solutions for automation and drives).
Technical support
Country-specific telephone numbers for technical support are provided in the Internet at the
following address (https://support.industry.siemens.com/cs/ww/en/sc/4868) in the "Contact"
area.
1.5 Directives, standards, certificates
Relevant directives and standards
You can obtain an up-to-date list of currently certified components on request from your local
Siemens office. If you have any questions relating to certifications that have not yet been
completed, please ask your Siemens contact person.
Certificates for download
The certificates can be downloaded from the Internet:
Certificates (https://support.industry.siemens.com/cs/de/en/ps/13206/cert)
EC declaration of conformity
You can find the EC Declaration of Conformity for the relevant directives as well as the
relevant certificates, prototype test certificates, manufacturers declarations and test
certificates for functions relating to functional safety ("Safety Integrated") on the Internet at
the following address (https://support.industry.siemens.com/cs/ww/en/ps/13231/cert).
The following directives and standards are relevant for SINAMICS S devices:
•European Low Voltage Directive
SINAMICS S devices fulfil the requirements stipulated in the Low-Voltage Directive
2014/35/EU, insofar as they are covered by the application area of this directive.
•European Machinery Directive
SINAMICS S devices fulfil the requirements stipulated in the Low-Voltage Directive
2006/42/EC, insofar as they are covered by the application area of this directive.
However, the use of the SINAMICS S devices in a typical machine application has been
fully assessed for compliance with the main regulations in this directive concerning health
and safety.

Introduction
1.6 Additional information
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
Equipment Manual, 10/2020, A5E50422764A 11
•Directive 2011/65/EU
SINAMICS S devices comply with the requirements of Directive 2011/65/EU on the
restriction of the use of certain hazardous substances in electrical and electronic devices
(RoHS II).
•European EMC Directive
SINAMICS S devices comply with the EMC Directive 2014/30/EU.
•Quality systems
Siemens AG employs a quality management system that meets the requirements of ISO
9001 and ISO 14001.
Standards that are not relevant
China Compulsory Certification
SINAMICS S devices do not fall in the area of validity of the China Compulsory Certification
(CCC).
1.6 Additional information
Ensuring reliable operation
The manual describes a desired state which, if maintained, ensures the required level of
operational reliability and compliance with EMC limit values.
Should there be any deviation from the requirements in the equipment manual, appropriate
actions (e.g. measurements) must be taken to check/prove that the required level of
operational reliability and compliance with EMC limit values are ensured.
Spare parts
Spare parts are available on the Internet at the following address
(https://support.industry.siemens.com/sc/de/en/sc/2110).
Product maintenance
The components are subject to continuous further development within the scope of product
maintenance (improvements to robustness, discontinuations of components, etc).
These further developments are "spare parts-compatible" and do not change the article
number.
In the scope of such spare parts-compatible further developments, connector/connection
positions are sometimes changed slightly. This does not cause any problems with proper use
of the components. Please take this fact into consideration in special installation situations
(e.g. allow sufficient clearance for the cable length).

Introduction
1.7 General Data Protection Regulation
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
12 Equipment Manual, 10/2020, A5E50422764A
Use of third-party products
This document contains recommendations relating to third-party products. Siemens accepts
the fundamental suitability of these third-party products.
You can use equivalent products from other manufacturers.
Siemens does not accept any warranty for the properties of third-party products.
Ground symbols
Table 1- 1 Symbols
Icon
Meaning
Connection for protective conductor
Ground (e.g. M 24 V)
Connection for function potential bonding
1.7 General Data Protection Regulation
Compliance with the General Data Protection Regulation
Siemens respects the principles of data protection, in particular the data minimization rules
(privacy by design).
For this product, this means:
The product does not process neither store any person-related data, only technical function
data (e.g. time stamps). If the user links these data with other data (e.g. shift plans) or if he
stores person-related data on the same data medium (e.g. hard disk), thus personalizing
these data, he has to ensure compliance with the applicable data protection stipulations.

Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
Equipment Manual, 10/2020, A5E50422764A 13
Fundamental safety instructions
2
2.1 General safety instructions
WARNING
Electric shock and danger to life due to other energy sources
Touching live components can result in death or serious injury.
•Only work on electrical devices when you are qualified for this job.
•Always observe the country-specific safety rules.
Generally, the following steps apply when establishing safety:
1. Prepare for disconnection. Notify all those who will be affected by the procedure.
2. Isolate the drive system from the power supply and take measures to prevent it being
switched back on again.
3. Wait until the discharge time specified on the warning labels has elapsed.
4. Check that there is no voltage between any of the power connections, and between any of
the power connections and the protective conductor connection.
5. Check whether the existing auxiliary supply circuits are de-energized.
6. Ensure that the motors cannot move.
7. Identify all other hazardous energy sources, e.g. compressed air, hydraulic systems, water.
Switch the energy sources to a safe state.
8. Check that the correct drive system is completely locked.
After you have completed the work, restore the operational readiness in the inverse
sequence.
WARNING
Electric shock if there is no ground connection
For missing or incorrectly implemented protective conductor connection for devices with
protection class I, high voltages can be present at open, exposed parts, which when
touched, can result in death or severe injury.
•Ground the device in compliance with the applicable regulations.

Fundamental safety instructions
2.1 General safety instructions
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
14 Equipment Manual, 10/2020, A5E50422764A
WARNING
Electric shock due to connection to an unsuitable power supply
When equipment is connected to an unsuitable power supply, exposed components may
carry a hazardous voltage that might result in serious injury or death.
•Only use power supplies that provide SELV (Safety Extra Low Voltage) or PELV-
(Protective Extra Low Voltage) output voltages for all connections and terminals of the
electronics modules.
WARNING
Electric shock due to equipment damage
Improper handling may cause damage to equipment. For damaged devices, hazardous
voltages can be present at the enclosure or at exposed components; if touched, this can
result in death or severe injury.
•Ensure compliance with the limit values specified in the technical data during transport,
storage and operation.
•Do not use any damaged devices.
WARNING
Electric shock due to unconnected cable shield
Hazardous touch voltages can occur through capacitive cross-coupling due to unconnected
cable shields.
•As a minimum, connect cable shields and the cores of power cables that are not used
(e.g. brake cores) at one end at the grounded housing potential.
WARNING
Arcing when a plug connection is opened during operation
Opening a plug connection when a system is in operation can result in arcing that may
cause serious injury or death.
•Only open plug connections when the equipment is in a voltage-free state, unless it has
been explicitly stated that they can be opened in operation.
WARNING
Electric shock due to residual charges in power components
Because of the capacitors, a hazardous voltage is present for up to 5 minutes after the
power supply has been switched off. Contact with live parts can result in death or serious
injury.
•Wait for 5 minutes before you check that the unit really is in a no-voltage condition and
start work.

Fundamental safety instructions
2.1 General safety instructions
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
Equipment Manual, 10/2020, A5E50422764A 15
NOTICE
Damage to equipment due to unsuitable tightening tools.
Unsuitable tightening tools or fastening methods can damage the screws of the equipment.
•Be sure to only use screwdrivers which exactly match the heads of the screws.
•Tighten the screws with the torque specified in the technical documentation.
•Use a torque wrench or a mechanical precision nut runner with a dynamic torque sensor
and speed limitation system.
NOTICE
Property damage due to loose power connections
Insufficient tightening torques or vibration can result in loose power connections. This can
result in damage due to fire, device defects, or malfunctions.
•Tighten all power connections to the prescribed torque.
•Check all power connections at regular intervals, particularly after equipment has been
transported.
WARNING
Spread of fire from built-in devices
In the event of fire outbreak, the enclosures of built-in devices cannot prevent the escape of
fire and smoke. This can result in serious injury or property damage.
•Install built-in units in a suitable metal cabinet in such a way that personnel are
protected against fire and smoke, or take other appropriate measures to protect
personnel.
•Ensure that smoke can only escape via controlled and monitored paths.
WARNING
Active implant malfunctions due to electromagnetic fields
Converters generate electromagnetic fields (EMF) during operation. Electromagnetic fields
may interfere with active implants, e.g. pacemakers. People with active implants in the
immediate vicinity of systems are at risk.
•As the operator of an EMF-emitting installation, assess the individual risks of persons
with active implants.
•Observe the data on EMF emission provided in the product documentation.

Fundamental safety instructions
2.1 General safety instructions
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
16 Equipment Manual, 10/2020, A5E50422764A
WARNING
Unexpected movement of machines caused by radio devices or mobile phones
Using radio devices or mobile telephones in the immediate vicinity of the components can
result in equipment malfunction. Malfunctions may impair the functional safety of machines
and can therefore put people in danger or lead to property damage.
•Therefore, if you move closer than 20 cm to the components, be sure to switch off radio
devices or mobile telephones.
•
Use the "SIEMENS Industry Online Support App" only on equipment that has already been
switched off.
WARNING
Damage to motor insulation due to excessive voltages
When operated on systems with grounded line conductor or in the event of a ground fault
in the IT line system, the motor insulation can be damaged by the higher voltage to ground.
If you use motors that have insulation that is not designed for operation with grounded line
conductors, you must perform the following measures:
•IT system: Use a ground fault monitor and eliminate the fault as quickly as possible.
•TN or TT systems with grounded line conductor: Use an isolating transformer on the line
side.
WARNING
Fire due to inadequate ventilation clearances
Inadequate ventilation clearances can cause overheating of components with subsequent
fire and smoke. This can cause serious injury or even death. This can also result in increased
failures and shorter service lives for devices/systems.
•Ensure compliance with the specified minimum clearance as ventilation clearance for the
respective component.
NOTICE
Overheating due to inadmissible mounting position
The device may overheat and therefore be damaged if mounted in an inadmissible position.
•Only operate the device in admissible mounting positions.

Fundamental safety instructions
2.1 General safety instructions
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
Equipment Manual, 10/2020, A5E50422764A 17
WARNING
Unrecognized dangers due to missing or illegible warning labels
Dangers might not be recognized if warning labels are missing or illegible. Unrecognized
dangers may cause accidents resulting in serious injury or death.
•Check that the warning labels are complete based on the documentation.
•Attach any missing warning labels to the components, where necessary in the national
language.
•Replace illegible warning labels.
NOTICE
Device damage caused by incorrect voltage/insulation tests
Incorrect voltage/insulation tests can damage the device.
•Before carrying out a voltage/insulation check of the system/machine, disconnect the
devices as all converters and motors have been subject to a high voltage test by the
manufacturer, and therefore it is not necessary to perform an additional test within the
system/machine.
WARNING
Unexpected movement of machines caused by inactive safety functions
Inactive or non-adapted safety functions can trigger unexpected machine movements that
may result in serious injury or death.
•Observe the information in the appropriate product documentation before
commissioning.
•Carry out a safety inspection for functions relevant to safety on the entire system,
including all safety-related components.
•Ensure that the safety functions used in your drives and automation tasks are adjusted
and activated through appropriate parameterizing.
•Run a function test.
•Only put your plant into live operation once you have guaranteed that the functions
relevant to safety are running correctly.
Note
Important safety instructions for Safety Integrated functions
If you want to use Safety Integrate
d functions, you must observe the safety instructions in
the Safety Integrated manuals.

Fundamental safety instructions
2.2 Handling electrostatic sensitive devices (ESD)
Air-Cooled Chassis Power Units - supplement to Motor Module 6SL3320-1TG41-5AA3
18 Equipment Manual, 10/2020, A5E50422764A
2.2 Handling electrostatic sensitive devices (ESD)
Electrostatic sensitive devices (ESD) are individual components, integrated circuits, modules
or devices that may be damaged by either electric fields or electrostatic discharge.
NOTICE
Damage through electric fields or electrostatic discharge
Electric fields or electrostatic discharge can cause malfunctions through damaged individual
components, integrated circuits, modules or devices.
•Only pack, store, transport and send electronic components, modules or devices in their
original packaging or in other suitable materials, e.g conductive foam rubber of
aluminum foil.
•Only touch components, modules and devices when you are grounded by one of the
following methods:
–Wearing an ESD wrist strap
–Wearing ESD shoes or ESD grounding straps in ESD areas with conductive flooring
•Only place electronic components, modules or devices on conductive surfaces (table
with ESD surface, conductive ESD foam, ESD packaging, ESD transport container).
