SitOnit Seating TENSOR User manual

M6x25mm Phil Button
Head Wood Screw
M8x50mm Socket Head Cap Screw
M8 Spring Lock Washer
#2 Phillips Screwdriver or Bit
Cordless Drill/Driver
(Do not over-tighten scews)
4x Leg
6mm Allen Key
2x Frame
4x M8x50mm Socket
Head Cap Screw
4x M8 Spring Lock Washer
27x M6x25mm Phil Button
Head Wood Screw
Round & Square
Versions Also Available
TENSOR - MAIN DESK ASSEMBLY INSTRUCTIONS
No. C6256 Rev. A
IMPORTANT: PLEASE READ ALL INSTRUCTIONS BEFORE STARTING ASSEMBLY.
To report any issues with this product, please contact our customer service department at [phone]
REQUIRED TOOLS
COMPONENTS
1:1 SCALE
Date: 10/24/2019
For more information, visit www.sitonit.net

Install leg onto frame per illustration. Ensure the leg is fully seated onto 1.
frame before tightening.
Install M8x50mm screw with washer using provided Allen key. 2.
Repeat step 2 for remaining legs. 3.
2
1
M8x50mm
M8 Washer
Allen Key
Steps:
Serrated Side Of
Washer Facing Up
TENSOR - MAIN DESK ASSEMBLY INSTRUCTIONS
To report any issues with this product, please contact our customer service department at [phone]
1
No. C6256 Rev. A
For more information, visit www.sitonit.net

1
Install support beam to table using appropriate number of screws determined 1.
by table length in chart above.
Small Support Beam
(For rectangular tables only; see chart below)
M6x25
Steps:
Rectangular Tables
Table Length Support Bar Type
# of M6x25
Wood Screws
36" N/A N/A
42" N/A N/A
48" Small 5
54" Small 5
60" Small 5
66" Small 5
72" Large 7
TENSOR - MAIN DESK ASSEMBLY INSTRUCTIONS
To report any issues with this product, please contact our customer service department at [phone]
2
No. C6256 Rev. A
For more information, visit www.sitonit.net

Steps:
M6x25
Align one frame assembly on 10 pilot holes (spanning the support beam when 1.
present). Install (10) M6x25mm wood screws; do not fully tighten.
Once all screws have been started and leg alignment is confirmed, fully tighten 2.
screws.
Repeat steps 1 and 2 for opposite frame assembly. 3.
1 2
3
TENSOR - MAIN DESK ASSEMBLY INSTRUCTIONS
To report any issues with this product, please contact our customer service department at [phone]
3
No. C6256 Rev. A
For more information, visit www.sitonit.net

Steps:
6mm Allen Key
Using provided 6mm Allen key, tighten (4) screws as shown 1.
Using appropriate assistance, place table upright. 2.
1
TENSOR - MAIN DESK ASSEMBLY INSTRUCTIONS
To report any issues with this product, please contact our customer service department at [phone]
4
No. C6256 Rev. A
For more information, visit www.sitonit.net

18" -LH
18" -RH
RH
LH
LH
RH
PILOT HOLE TEMPLATE
18" RECTANGULAR

24" -LH
24" -RH
RH
RH
LH
LH
PILOT HOLE TEMPLATE
24" RECTANGULAR

30"-LH
RH
RH
LH
LH
30"-RH
PILOT HOLE TEMPLATE
30" RECTANGULAR

B
A
SIZE 'A'
30 X 30 3.17"
36 X 36 3.36"
42 X 42 7.50"
48 X 48 11.64"
SIZE 'B'
42 2.94"
48 5.39"
PILOT HOLE TEMPLATE
SQUARE TOP
PILOT HOLE TEMPLATE
ROUND TOP

M6x25mm Phil Button
Head Wood Screw
M8x50mm Socket Head Cap Screw
M8 Spring Lock Washer
#2 Phillips Screwdriver or Bit Cordless Drill/Driver
(Do not over-tighten screws)
2x M8 Spring Lock Washer
Mending Plate
18x M6x25mm Phil Button
Head Wood Screw
2x M8x50mm Socket
Head Cap Screw
Frame
2x Leg
6mm Allen Key
M6 X 20
54" & 60" Returns only
TENSOR - RETURN DESK ASSEMBLY INSTRUCTIONS
No. C6257 Rev. A
IMPORTANT: PLEASE READ ALL INSTRUCTIONS BEFORE STARTING ASSEMBLY.
To report any issues with this product, please contact our customer service department at [phone]
REQUIRED TOOLS
COMPONENTS
1:1 SCALE
DATE: 10/24/2019
For more information, visit www.sitonit.net

Steps:
(Serrated side of
washer facing up)
Allen key
M8 Washer
M8x50mm
1
2
Install leg onto frame per illustration. Ensure the leg is fully seated onto 1.
frame before tightening.
Install M8x50mm screw with washer using provided Allen key. 2.
Repeat Step 2 for remaining leg. 3.
TENSOR - RETURN DESK ASSEMBLY INSTRUCTIONS
To report any issues with this product, please contact our customer service department at [phone]
1
No. C6257 Rev. A
For more information, visit www.sitonit.net

Steps:
M6x25
Align frame assembly on 10 pilot holes. Install (10) M6x25mm wood screws; 1.
do not fully tighten.
Once all screws have been started and leg alignment is confirmed, fully 2.
tighten screws.
1
3
2
To report any issues with this product, please contact our customer service department at [phone]
2
No. C6256 Rev. A
TENSOR - RETURN DESK ASSEMBLY INSTRUCTIONS
For more information, visit www.sitonit.net

6mm Allen Key
Steps:
Using provided 6mm Allen key, tighten (2) screws as shown. 1.
TENSOR - RETURN DESK ASSEMBLY INSTRUCTIONS
To report any issues with this product, please contact our customer service department at [phone]
3
No. C6257 Rev. A
For more information, visit www.sitonit.net

M6x25
Steps:
Locate the mending plate as near to the center of the return location as 1.
possible. The location may vary based on the table width.
Install mending plate (included in base carton) to the table using (4) screws 2.
provided.
Note: Use this mending plate
for returns 36", 42" and 48" long.
TENSOR - RETURN DESK ASSEMBLY INSTRUCTIONS
To report any issues with this product, please contact our customer service department at [phone]
4
No. C6257 Rev. A
For more information, visit www.sitonit.net

Steps:
Place table upright and position to accept return. 1.
Place the return in position on the mending brackets and install the remaining 2.
(4) screws with the table upright.
M6x25
TENSOR - RETURN DESK ASSEMBLY INSTRUCTIONS
To report any issues with this product, please contact our customer service department at [phone]
5
No. C6257 Rev. A
For more information, visit www.sitonit.net

M6x25
Steps:
Note: Use these mending plates
for returns 54" and 60" long.
Discard the mending plate and associated screws from the base carton and 1.
use the mending kit provided separately.
Locate the first mending plate 1" from the edge of the return location as 2.
shown. Locate the second plate as far from the first as possible.
Install mending plates to the table using (8) screws provided. 3.
TENSOR - RETURN DESK ASSEMBLY INSTRUCTIONS
To report any issues with this product, please contact our customer service department at [phone]
6
No. C6257 Rev. A
For more information, visit www.sitonit.net

M6x25
Steps:
Place table upright and position to accept return. 1.
Place the return in position on the mending brackets and install the remaining 2.
(8) screws with the table upright.
1"
TENSOR - RETURN DESK ASSEMBLY INSTRUCTIONS
To report any issues with this product, please contact our customer service department at [phone]
7
No. C6257 Rev. A
For more information, visit www.sitonit.net

24" - LH
24" - RH
RH
RH
LH
LH
PILOT HOLE TEMPLATE
24" RECTANGLE

M6x18mm Phil Button
Head Wood Screw
#2 Phillips Screwdriver or Bit Cordless Drill/Driver
(Do not over-tighten screws)
32X M6 X 18mm
4X Mending Plate
TENSOR - BRIDGE DESK ASSEMBLY INSTRUCTIONS
No. C6258 Rev. B
IMPORTANT: PLEASE READ ALL INSTRUCTIONS BEFORE STARTING ASSEMBLY.
To report any issues with this product, please contact our customer service department at [phone]
REQUIRED TOOLS
COMPONENTS
1:1 SCALE
Date: 11/15/2019
For more information, visit www.sitonit.net

M6x18
Steps:
Locate the first mending plate 1" from the edge of the bridge location as 1.
shown. Install the mending plate to the table using (4) screws.
Locate the second mending plate as far away from the first as the table 2.
frame will allow. Install the mending plate to the table using (4) screws.
Repeat Steps 1 and 2 on other table surface. 3.
Place tables upright and position to accept bridge in this position. 4.
54" and 60" Bridge Units
Add the external stiffener to the bridge unit as
near to the center of the table as the
placement of the mending brackets will allow.
In some cases, a mending bracket hole may
be covered by the table frame and the
attachment screw may be omitted.
To report any issues with this product, please contact our customer service department at [phone]
2
No. C6258 Rev. B
TENSOR - BRIDGE DESK ASSEMBLY INSTRUCTIONS
For more information, visit www.sitonit.net
