Parallon
FIXED TOP T-LEG TABLE
ASSEMBLY INSTRUCTIONS
Everything to the table.
When you want cohesion in spaces large, small, shared or separate, there’s
Parallon. It’s a single collection with a singular look, oering an array of
choices for a variety of environments—and all the features to t.
Ensure design is never a distraction in the places where everyone needs to
focus. Our Parallon line of training tables provides a unied and streamlined
look from room to room.
C6568 Rev D |www.sitonit.net |1

2 |C6568 Rev D |www.sitonit.net
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Read the entire instruction manual before you start installation and
assembly. If you have any questions regarding any of the instructions or
warnings, please contact your local distributor for assistance.
To report any issues with this product, contact our customer experience
team at: [phone] or [email protected].
CAUTION
Failure to follow instructions could result in product failure or
potential injury.
Do not apply sudden weight to table.
Do not exceed 200 lb static load weight capacity.
Keep ngers clear of pinch points.

C6568 Rev D |www.sitonit.net |3
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
•Cordless Drill/Driver
•#3 Phillips Bit
•5⁄32" Hex Bit
•1⁄2" Combination Wrench
•1⁄2" Deep Well Hex Socket, ¼" Drive
•Hex Shank to ¼" Square
Drive Adapter
•¼" Drive Universal Joint
Recommended Tools
1⁄2" Deep Well Hex
Socket, ¼" Drive
Cordless
Drill/Driver
Universal Joint
¼" Drive
Hex Shank to
1⁄4" Square Drive Adapter
#3 Phillips Bit 5⁄32" Hex Bit
1⁄2" Combination
Wrench

4 |C6568 Rev D |www.sitonit.net
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
•Tabletop (1, rectangular,
half round or trapezoid)
•Top Plates (2)
•Grommet (optional)
•Pack A:
•#12 × 1" Screw (17)
•Pack C:
•¼" × 1" Screw (8)
#12 x 1" Screws 1⁄4x 1" Screws
PACK A PACK C
Parts: Top and Frame
Top
Plates
Grommets
(Optional)
•Tabletop (1, rectangular,
half round or trapezoid)
•Top Plates (2)
•Grommet (optional)
•Pack A:
•#12 × 1" Screw (17)
•Pack C:
•¼" × 1" Screw (8)
Trapezoid
Tabletop
Half Round
Tabletop
Rectangular
Tabletop
OR
OR

C6568 Rev D |www.sitonit.net |5
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Columns
Casters (Optional)
Parts: Columns and Feet
PACK B
Foot Attachment Plates 5⁄16 x 11⁄2" Bolts
5⁄16" Nuts
Feet
•Column (2)
•Foot (4)
•Caster (4, optional)
•Pack B:
•5⁄16" × 11⁄2" Bolt (4)
•5⁄16" Nut (4)
•Foot Attachment Plate (4)

6 |C6568 Rev D |www.sitonit.net
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Step 1: Attach the top plates to the columns.
1:1 HARDWARE TOOLS
5⁄32 Hex Drill Bit 1⁄4x 1" Screw (Pack C)
Column
Align the top
support and feet.
1⁄4"x 1" Screw
Top Plate

C6568 Rev D |www.sitonit.net |7
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Step 2: Attach the column assemblies to the tabletop.
Top Plate
#12 x 1" Screw
Pilot Hole
#12 x 1" Screw (Pack A) #3 Phillips Bit
1:1 HARDWARE TOOLS

8 |C6568 Rev D |www.sitonit.net
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Step 3: Slide the bolt through the foot attachment plate and column.
1:1 HARDWARE
5⁄16 x 11⁄2" Bolt (Pack B)
Foot Attachment Plate
5⁄16 x 11⁄2" Bolt
Column
Hole

C6568 Rev D |www.sitonit.net |9
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Step 4: Slide the foot over the bolt.
5⁄16 x 11⁄2" Bolt
Foot

10 |C6568 Rev D |www.sitonit.net
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Step 5: Hold the bolt in place and tighten the nut.
1:1 HARDWARE TOOLS
5⁄16 Nut (Pack B)
Universal Joint
1⁄2" Deep Well Hex Socket,
¼" Drive
Hex Shank to Square Drive Adapter
Adapter
Universal Joint
Socket

C6568 Rev D |www.sitonit.net |11
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
TOOLS
1⁄2" Combination Wrench
Step 6: Unscrew the glides to level as needed.
Alternatively, insert the optional casters into the feet and tighten the nuts.
Caster
Nut
Brake
Install the two casters
with brakes on the same
side as the pull handles.
Glide

12 |C6568 Rev D |www.sitonit.net
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Step 7: Turn the table upright with the help of another person and if
applicable, press the optional grommets into the cutouts.
Grommet
Cutout

Parallon
FIXED TOP C-LEG TABLE
ASSEMBLY INSTRUCTIONS
Everything to the table.
When you want cohesion in spaces large, small, shared or separate, there’s
Parallon. It’s a single collection with a singular look, oering an array of
choices for a variety of environments—and all the features to t.
Ensure design is never a distraction in the places where everyone needs to
focus. Our Parallon line of training tables provides a unied and streamlined
look from room to room.
C6618 Rev A |www.sitonit.net |1

2 |C6618 Rev A |www.sitonit.net
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Read the entire instruction manual before you start installation and
assembly. If you have any questions regarding any of the instructions or
warnings, please contact your local distributor for assistance.
To report any issues with this product, contact our customer experience
team at: [phone] or [email protected].
CAUTION
Failure to follow instructions could result in product failure or
potential injury.
Do not apply sudden weight to table.
Do not exceed 200 lb static load weight capacity.
Keep ngers clear of pinch points.

C6618 Rev A |www.sitonit.net |3
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
•Cordless Drill/Driver
•#3 Phillips Bit
•5⁄32" Hex Bit
•Magnetic Bit Holder
•1⁄4" Hex L-Key (Optional)
•1⁄2" Deep Well Hex Socket, ¼" Drive
•Hex Shank to ¼" Square
Drive Adapter
•Universal Joint, ¼" Drive
•1⁄2" Combination Wrench
Recommended Tools
1⁄2" Deep Well Hex
Socket, ¼" Drive
Cordless
Drill/Driver
Universal Joint,
¼" Drive
Magnetic Bit Holder
Hex Shank to
1⁄4" Square Drive Adapter
#3 Phillips Bit
5⁄32" Hex Bit
1⁄2" Combination Wrench 1⁄4" Hex L-Key

4 |C6618 Rev A |www.sitonit.net
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
•Tabletop (1, rectangular,
half round or trapezoid)
•Top Plates (2)
•Grommet (optional)
•Pack A:
•#12 × 1" Screw (17)
•Pack C:
•¼" × 1" Screw (8)
#12 x 1" Screws 1⁄4x 1" Screws
PACK A PACK C
Parts: Top and Frame
Top
Plates Trapezoid
Tabletop
Half Round
Tabletop
Rectangular
Tabletop
Grommets
(Optional)
OR
OR

C6618 Rev A |www.sitonit.net |5
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Columns
Casters
(Optional)
Parts: Columns and Feet
PACK B PACK D
Foot
Attachment Plates
Long
Feet
Short
Feet
•Column (2)
•Long Foot (2)
•Short Foot (2)
•Caster (4, Optional)
•Pack B:
•5⁄16" Nut (2)
•5⁄16" × 11⁄2" Bolt (Unused)
•Foot Attachment Plate (Unused)
•Pack D:
•Column Support (2)
•5⁄16 x 33⁄4" Screws
5⁄16"
Nuts
5⁄16 x 11⁄2"
Bolts
Column
Supports
5⁄16 x 33⁄4"
Screws

6 |C6618 Rev A |www.sitonit.net
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Step 1: Attach the top plates to the columns.
1:1 HARDWARE TOOLS
5⁄32 Hex Drill Bit 1⁄4x 1" Screw (Pack C)
Column
Align the top
support and feet.
1⁄4"x 1" Screw
Top Plate

C6618 Rev A |www.sitonit.net |7
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Step 2: Attach the column assemblies to the tabletop.
Top Plate
#12 x 1" Screw
Pilot Hole
#12 x 1" Screw (Pack A) #3 Phillips Bit
1:1 HARDWARE TOOLS

8 |C6618 Rev A |www.sitonit.net
Parallon FIXED TOP TABLE ASSEMBLY INSTRUCTIONS
Step 3: Insert the column support into the column and hold it in place.
Steps 3–5 will be repeated again on the opposite column.
1:1 HARDWARE
Column Support (Pack D)
