SitOnit Seating Switchback Home Edition User manual

C6515 Rev C
SWITCHBACK
HOME EDITION
ASSEMBLY INSTRUCTIONS
Sit. Stand. Or switch it up (back and forth). Personalize your workspace with Switchback, the
height-adjustable table that lets you change up your workday in a ash. Built with premium
industry-leading features at an unmatched value, you’ve got one great modern oce essential.

To report any issues with this product, call our customer experience team at [phone] or
email [email protected]. For more information, visit www.sitonit.net
SWITCHBACK – HOME EDITION ASSEMBLY INSTRUCTIONS
REQUIRED TOOLSCOMPONENT LIST
COMPONENTS
1:1 SCALE
2
2-LEG 3-STAGE SWITCHBACK
Cordless Drill / Driver
(Do not overtighten screws.)
5 mm Hex L-Key
(Included)
#2 Phillips
Screwdriver or Bit
Top Supports ⅜" × ⅝" ScrewsController #8 × ⅞" Screws
5 mm L-Key
Feet
Frame
#10 × ¾" Screw
#10 × ¾" Screws
⅜" × ⅝" Screw#8 × ⅞" Screw
• Frame (1)
• Top Support (2)
• Foot (2)
• Controller (1)
• #10 × ¾" Screw (18)
• #8 × ⅞" Screw (2)
• ⅜" × ⅝" Screw (8)

To report any issues with this product, call our customer experience team at [phone] or
email [email protected]. For more information, visit www.sitonit.net
SWITCHBACK – HOME EDITION ASSEMBLY INSTRUCTIONS
STEPS
1
2
3
3
1. Rotate the columns into the upright position.
2. Install top supports into columns.
3. Tighten the four socket screws (already in place) on each side that secure the motor housing for each of the columns
using the 5 mm hex L-key provided.
Note: Ensure that the four additional pre-installed socket screws, to the left or right of the indicated socket screws, are
also rmly tightened.
Column
Motor Housing
Socket Screw

To report any issues with this product, call our customer experience team at [phone] or
email [email protected]. For more information, visit www.sitonit.net
SWITCHBACK – HOME EDITION ASSEMBLY INSTRUCTIONS
STEPS
45
6
4
4. Using the provided 5mm hex L-key, install table feet using four ⅜" × ⅝" screws per leg.
5. Place the frame/foot assembly onto the underside of the tabletop and extend the frame to the length indicated by the
pilot holes. Start by lining up the pilot holes on the center supports and once they are in position, the end brackets
should line up with a set of pilot holes (Note: There may be an extra set of pilot holes on each end of the top, these
can be ignored). Getting the frame extended to the proper length may require loosening the set screws in the base
assembly using the provided 5 mm hex L-key. Once the legs are situated, center the U-pipe and tighten the set
screws as shown in the illustration.
6. Connect the controller to the control box. Tuck the control box cord through the frame notch. Note: This must be
done before securing the base to the top.
Set Screw
U-Pipe
Control Box
Center Support

To report any issues with this product, call our customer experience team at [phone] or
email [email protected]. For more information, visit www.sitonit.net
SWITCHBACK – HOME EDITION ASSEMBLY INSTRUCTIONS
STEPS
7
5
8 9
7. Attach the frame/foot assembly to the tabletop using the #10 × ¾" screws.
8. Attach the controller to the front of the tabletop with the two #8 × ⅞" crews.
9. Attach power cord. Tuck all excess cords into the frame.
10. With the help of another person, ip the table to the normal position and reset it before the rst use.

To report any issues with this product, call our customer experience team at [phone] or
email [email protected]. For more information, visit www.sitonit.net
SWITCHBACK – HOME EDITION ASSEMBLY INSTRUCTIONS
STEPS
6
To reset the table:
Press and hold the up and down buttons at the same time for 3 seconds. Continue pressing until the columns are in
the lowest position. When nished resetting, the control box will make a sound and the buttons can be released. Now
the system is operational.
10

To report any issues with this product, call our customer experience team at [phone] or
email [email protected]. For more information, visit www.sitonit.net
SWITCHBACK – HOME EDITION SAFETY INFORMATION
WARNING
7
RISK OF DEATH AND SERIOUS INJURY
Raising or lowering the table can trap, pinch, or crush body parts or property.
Read all instructions before using this equipment.
1"
1"
1"
1"
1"
1"
KEEP AWAY FROM CHILDREN
This table system is designed for adult use and is not
intended to be used by children. Children should be
supervised to ensure that they do not play with or near the
table system or its controls.
DO NOT OPERATE THIS EQUIPMENT
UNLESS PROPERLY TRAINED
Do not operate this equipment unless properly trained.
This table system is not intended for use by adults with
reduced physical, sensory, or mental capabilities or
children. Only adults who have appropriate understanding
of the operating instructions and warnings should operate
this equipment.
USE CARE AT ALL TIMES TO PREVENT THE
TABLE SYSTEM FROM TIPPING OVER
Before moving the table system, clear all objects and
equipment from the table to reduce the risk of tipping over.
Do not lift the table system by the tabletop. Adjust the table
to its lowest height before moving. In order to avoid risk of
tipping or collapse, make sure corded objects will not be
pulled o the table or cause other objects to fall.
KEEP AT LEAST ONE INCH OF
CLEARANCE AROUND THE DESK
TO ENSURE NOTHING IS IN THE
TABLE SYSTEM'S PATH
In order to avoid risk of serious injury due to
pinch points, conrm that the surroundings
on all sides of the table system are clear.
Body parts and property can be caught
between the moving top and immovable
obstacles such as shelves, furniture,
windowsills, or walls.
Make sure the power cord moves freely as
desk moves up and down. Do not place
feet, legs, or other body parts on objects
placed under table top.
This product has been evaluated by UL for commercial use. it has not been evaluated for environments where children or others
who may not recognize and comprehend the risks inherent with moving parts are unsupervised.
7

To report any issues with this product, call our customer experience team at [phone] or
email [email protected]. For more information, visit www.sitonit.net
SWITCHBACK – HOME EDITION SAFETY INFORMATION
WARNING
8
RISK OF DEATH AND SERIOUS INJURY
Raising or lowering the table can trap, pinch, or crush body parts or property.
Read all instructions before using this equipment.
8
DO NOT OVERLOAD TABLE
Make sure the table system is not overloaded by the weight of the tabletop and objects on table. Evenly distribute load;
excess loads near the edges can reduce stability and lead to tip-over. Do not exceed maximum load of 250 lb (including
top). Do not exceed maximum edge load of 25 lb when positioning monitors or mounting accessories. Never sit or stand on
the table.
KEEP BASE DRY
Keep all electrical components away from water and humidity. This equipment is approved for indoor use only and should
not be used outdoors. Always unplug electrical components before cleaning. Follow all cleaning guidelines provided by the
manufacturer.
INSPECT REGULARLY
Inspect table system regularly and immediately stop using the product if it is damaged or has loose parts.
GROUNDING INSTRUCTIONS
This product is equipped with a cord that has an
equipment-grounding conductor and a grounding
plug. Use only the cord provided. Make sure that
the product is connected to an outlet that has the
same conguration as the plug and is properly
installed and grounded in accordance with all local
codes and ordinances.
Do not modify the plug provided with the product.
If it will not t the outlet, have a proper outlet
installed by a qualied electrician.
No adapters are to be used with this product.
Keep cord away from heated surfaces.
Grounded Outlet Box
Grounding
Pin
Grounded
Outlet

To report any issues with this product, call our customer experience team at [phone] or
email [email protected]. For more information, visit www.sitonit.net
SWITCHBACK – HOME EDITION USER GUIDE
99
CONTROLLER
INITIALIZATION / RESET
Simultaneously ress the or buttons for three seconds. Continue pressing until both columns are in the lowest
position. When the reset is nished, the control box makes a beep sound and the buttons can be released.
Reminders:
When reset is being conducted, the display shows “E00” in last 5mm stroke.
• When reset is nished, the display shows starting height.
• Users must conduct reset when the desk is operated at the rst time.
CONTROLLER OPERATION
Press the or button until the desk reaches the preferred height.
SETTING THE MEMORIZED POSITION
Switchback supports, at most, four memory positions.
How to set memorized positions:
Adjust the desk to the desired height.
1. Press the preferred memory button (1 ,2 ,3 or 4), with either or for 2 seconds. Once the display shows P1 or
P2 or P3 or P4, the position is memorized.
2. Press and hold button 1, 2, 3 or 4 to move the desk to memorized position.
SWITCHING BETWEEN METRIC AND IMPERIAL
3. Press memory buttons 1, 2 and 4 for ve seconds.
4. The digital display will show "C-I" or "C-E". If no other buttons are pushed within ve seconds, the system will return to
normal operation.
5. Press the 3 button for imperial units. The display will show "E" or "I" for inches. Press the 2 button to choose metric
units. The display will show "C" for centimeters .
USER INTERFACE GUIDE
042
3-digit display
(shows height
of the desk)
memory setting
buttons

To report any issues with this product, call our customer experience team at [phone] or
email [email protected]. For more information, visit www.sitonit.net
SWITCHBACK – HOME EDITION USER GUIDE
1010
HEIGHT ADJUSTMENT GUIDE
SETTING THE UPPER AND LOWER HEIGHT LIMITS
Setting upper height limit:
1. Adjust the desk to the preferred height of upper limit.
2. Press or buttons together and then release button within 3 seconds.
3. Re-press more than 3 times in a slow pace.
4. A beeping sound will notify you that the process has completed.
PRESETTING THE DESK STARTING HEIGHT
This setting can be used to reset the displayed table height if required. This setting may be helpful if the table base is above or
below oor level.
1. Press button until the desk reaches its lowest position and then release button.
2. Re-press button again for ve seconds and the digital display will start to ash.
3. Adjust the starting height with the or button and release the button when the preferred starting height is reached.
4. After 10 seconds, the display will stop ashing and this will conrm that you have successfully set the starting height.
Disable upper height limit:
1. Move the desk to the upper limit height being set.
2. Repeat steps 2–4 above to disable the upper limit settings.
Disable lower height limit:
1. Move the desk to the lower limit height being set.
2. Repeat steps 2–4 above to disable the lower limit settings.
Setting lower height limit:
1. Adjust the desk to the preferred lower limit height.
2. Press or buttons together and then release button within 3 seconds.
3. Re-press more than three times in a slow pace.
4. A beeping sound will notify you that the process has completed.

To report any issues with this product, call our customer experience team at [phone] or
email [email protected]. For more information, visit www.sitonit.net
SWITCHBACK – HOME EDITION USER GUIDE
1111
ERROR CODES AND POWER SAVING
The digital display shows the error code below to suggest the issues that users may encounter during the operation.
Error Code Description
000 Resetting
E00 Not reset completely
E01 Overuse protection
E02 Unbalance protection
E03 Anti-collision
E04 T-touch protection
E11 M1 Motor over-current protection
E12 M2 Motor over-current protection
E13 M3 Motor over-current protection
E21 No hall sensor from M1
E22 No hall sensor from M2
E23 No hall sensor from M3
E31 No current from M1
E32 No current from M2
E33 No current from M3
POWER SAVING FUNCTION
To wake up the control:
• When no button has been pressed for 25 seconds, display goes o. Press any button to light up the display again.
• When no button has been pressed for 30 seconds, the system goes to <0.1W standby mode. Long press any button to
wake the system up. The digital display will show desk height again.
