Snom190 Phone Configuration
Snom190 Phone Configuration
for Quadro 3.0.x Images
1 Quadro Board Configuration
The user has to manually attach the extension to the SIP line and enter the SIP user name of the phone
and the password.
2 SIP Phone Configuration
2.1 Distributors
Epygi or the other company (wholesaler, retailer) has to set up the configuration site and enter the
default values into the phone. The Snom190 phone can be configured completely manually or in an
automated way (over HTTP).
First the automated configuration for distributors and then full manual way of configuration is
described. Note that we will show the easiest possible way (from the user’s perspective) of configuring
the phone.
For a smooth interworking with Quadro the firmware version of the phone must be 3.56k.
Copyright © 2004 Epygi Technologies, Ltd. All rights reserved. 1

Snom190 Phone Configuration
Automatic (for distributors) configuration of the Snom190 using DHCP and HTTP servers:
1. By factory default DHCP is enabled. In this case it is necessary to have a DHCP server available
that will provide the IP address for the phone. An example of the server configuration is given
below:
• option tftp-server-name "http://172.29.0.116";
• option bootfile-name "ipphonescfg/snom190.htm";
Please Note: The tftp-server-name has “http” in front of it and it is also necessary to enter
correctly “option bootfile-name”. Also, filling in those fields in the DHCP configuration will narrow
the functionality of one DHCP server to configuring that one phone model.
“ipphonescfg/snom190.htm” has to be a valid path for the HTTP server located in the
172.29.0.116 server address in our case.
2. It is necessary to have the HTTP server available and to copy the configuration files and the
image provided by Epygi to the “ipphonescfg” subfolder of the root path of that server. Now it is
necessary to know the firmware version of the phone.
3. To get that version, press “MENU”, then find “Information” and press “Version”. The version will
be displayed on the LCD screen.
4. Connect the phone to the network and power on (if you need to reset the phone to factory
defaults it is necessary to press the “MENU” button, select “Configuration”, select “Reset”, and to
enter the Administrator password; it is set by default to “0”,”0”,”0”,”0”. Then press “Enter”.
Then press “Enter” again to reboot the phone.
5. The phone will boot and get its IP address, the IP address of the HTTP server via “option” 66 of
the DHCP server (option 66 is “TFTP server name”) and the setting file name over “option 67” of
the DHCP server (option 67 is the bootfile name).
The phone will automatically download the image and the configuration. Please do not turn off
the power while updating the image.
is desirable to have the DHCP server, phone and HTTP server in the same subnet.It
6. The configuration provided by Epygi will contain changes in the dial plan and set the default SIP
proxy address to 172.30.0.1.
hese were the required measures for the distributors.T
Copyright © 2004 Epygi Technologies, Ltd. All rights reserved. 2

Snom190 Phone Configuration
2.2 Manual Configuration of the Snom190 Phone using a
DHCP Server
(For testing purposes or for users who purchased the phone from a 3d party)
1. By factory default DHCP is enabled. In this case it is necessary to have a DHCP server available
that will provide the IP address for the phone.
2. Connect the phone to the network and power on (if you need to reset the phone to factory
defaults it is necessary to press the “MENU” button, select “Configuration”, select “Reset” and to
enter the Administrator password; it is set by default to “0”,”0”,”0”,”0”. Now press “Enter” and
then press “Enter” again to reboot.
3. The phone will get an IP address assigned and the user needs to know that address. Usually
during start-up the phone displays its IP address for a short time. The IP address can also be
seen by pressing “Menu”, then find “Information” and press “IPAdr”. The IP address will be
displayed on the LCD screen.
4. If you want to update firmware version of your phone you should go to embedded HTTP web
server select “Software Update” set the new image location (full http path) to “Firmware” field
and press “Load”. (You can find images on ”http://www.snom.com/support_dl_en.php” or
“http://www.snom.com/download/share/“). After pressing “Load” the phone will reboot and
upgrade firmware.
5. Using the HTTP web browser connect to the “Snom190” IP address.
6. Go to link “Line1” (or “Settings”->”SIP”->”Lines” depending on phone firmware version) then set
the LAN IP address of the Quadro board (SIP Proxy) in “Registrar” field. This should be set
“172.30.0.1” by default.
7. Set the “Dial-Plan String” field in the same page (or go to “Settings”->”SIP”->”Stack” depending
on phone firmware version) as “ |^\*([0-6]{1})|sip:*\1@\d|d |^\*([7-9]{1}[0-
9]{1})|sip:*\1@\d|d |([^#]+)#|sip:\1@\d|d”.
8. Press “Save” button on the same page.
2.3 End Users
Next step will be for end user to configure the SIP registration settings. That can be done by:
1. Go to the Snom190 IP phone embedded web server and selecting “Line1” link.
2. User needs to set the “Account” (this is sip user name), “Password” password the same as
he/she configured on the Quadro board and also optional display name.
3. User here also can change the address of SIP proxy, which by default set to 172.30.0.1).
