Snom Mass Deployment V3.4 Instruction Manual
F REQUENTLY
A SKED
Q UESTION
Conguring snom phones
for Mass Deployment V3.4
Date: Sept-17-2004
Author: Sven Fischer
Document: faq-04-03-26-v3.4-sf
2 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 3
[ F REQUENTLY A S K E D Q U E S T I O N ]
As stated in the FAQ „How can I update a snom phone?”, it is possible to congure your
snom phone with cong les, which consist of the following settings.
This release v3.4 is describing rmware settings beginning with version 3.4 ! In case you
are using an older rmware version please refer to v2.0 of this document.
Phone settings
Settings are non-volatile name/value pairs that are stored in the ash of the phone. They
include registration information, dialled numbers, network settings and other information that
should be available after rebooting. Settings can be made read only on a per setting basis.
This is useful in environments where an operator sets up the phones and wants to avoid users
changing settings that affect the stability of the phone. In this way, expensive trouble ticket
searching can be reduced and the total cost of ownership of the phone be minimized.
Settings Files
Setting les are ASCII-based les containing lines (terminated with newline or carriage
return/newline pairs). Comments start with a # or a < character. The < and > characters allow
easy integration of html tags. Names may consist of the characters a-z, A-Z, 0-9 and _.
Appending a name with an “!” character means that this setting becomes writable by the
user. Appending the name with an “&” states that the setting is read only (this is the default).
If a setting is marked writable, the value in the settings le is only written to the phone if
that setting has not yet been set up at the phone. In order to overwrite such settings, do not
append the setting name with “!”.
A sample le looks like this:
<html>
<pre>
#This is a settings le
#
phone_name: testphone
dns_domain: intern.snom.de
dns_server1!: 192.168.0.9
</pre>
<html>
Downloading procedure
Settings are downloaded from web servers. HTTP is a very powerful way to get conguration
information from anywhere in the world. The location of a le is described as a URL, i.e. it
begins with http://.
This is how the Settings are set up:
1. The settings that were stored in the ash memory are read.
2. Network and DNS is set up. This allows the phone to get settings from internet URLs.
3. It then checks the setting "setting_server” and loads the settings stored in the URL (e.g.
http://www.snomag.de/snom200/snom200.htm) provided. For a small description of
2 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 3
[ F REQUENTLY A S K E D Q U E S T I O N ]
the le format, see below. The setting_server URL can also consist of a {mac} statement
like http://www.snomag.de/snom200/snom200.php?mac={mac}. The MAC address is a
unique identication ID of Ethernet devices. snom devices have the form 000413xxxxxx,
where xxxxxx is a hexadecimal number identifying the snom device. The MAC address
is automatically replaced from the phone with its own mac address before using the
URL. So phone specic settings can be provided for each phone via this mechanism. The
“setting_server” setting can be set manually via webinterface or automatically via DHCP
(options 66 and 67) and through snom4S SIP proxy.
4. The de facto settings are added. These settings may differ from what has been set up
because DHCP may have changed them. The settings include:
• the IP address of the device,
• the net mask,
• the IP gateway,
• the hostname,
• the DNS domain, rst and second DNS server,
• the UTC offset in seconds,
• the time server,
• DHCP on or off
Each setting is described by its ‚Name:‘ which should be added to the cong le followed
by a colon and its specic value. Name is followed by ‚Valid values:‘ where the valid values are
described. Each possible value is bracketed in <>.The braces must be left out if you are using
the values stored in a cong le. ‚Default:‘ shows the value which is set by default after you
have removed all of the setting with a manual update or a reset values! Lastly, ‚Description’
gives brief details of each setting. See also the snom4S SIP proxy manual for PNP conguration
via the proxy. And see the FAQ “How to update a snom phone” for further details regarding the
update process.
4 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 5
[ F REQUENTLY A S K E D Q U E S T I O N ]
Redirection
redirect_event
Valid values: <all>, <busy>, <none>,
<time> Default: none Description: Event
that causes redirection. <all> redirects
always, <none> never, <busy> when
the phone is in use and <time> after a
timeout.
redirect_time
Valid values: e.g. <15>
Default: blank
Description: Number of seconds after
which the phone will redirect the incoming
call.
redirect_number
Valid values: e.g. <tb,sf> or <sip:tb@sn
om.de;q=0.8,[email protected];q=0.9>.
Default: blank
Description: The redirection target. If the
proxy executes the redirection, this may
be a comma-separated list of alternate
destinations (including probabilities).
redirect_busy_number
Valid values: e.g. <tb,sf> or <sip:tb@sn
om.de;q=0.8,[email protected];q=0.9>.
Default: blank
Description: The redirection target when
the redirect_event is set to busy.
Basic
language
Valid values: <English>, <English(UK)>,
<Deutsch>, <Francais>, <Italiano>,
<Espanol>, <Cestina>, <Nederlands>,
<Polski>, <Portugues>, <Slovencina>,
<Suomi>, <Svenska>, <Dansk>,
<Japanese>, <Chinese>
Default: English
Description: Selects the language.
web_language
Valid values: <English>, <Deutsch>,
<Nederlands>, <Suomi>, <Dansk>
Default: English
Description: Selects the language for the
webinterface.
display_method
Valid values: <full_contact>, <display_
name>, <user_name>
Default: full_contact
Description: Selects the display style of
SIP URLs.
call_completion
Valid values: <true>, <false>
Default: false
Description: With <true> the phone
offers after a “busy” the option to wait
for the other party to become free again
and inform the user to make a new call
attempt.
auto_dial
Valid values: <off>, <2> , <5>, <10>,
<15>
Default: off
Description: Phone begins after 2, 5,
10 or 15 seconds to dial the number
already typed in.
block_url_dialing
Valid values: <true>, <false>
Default: false
Description: With <true> the user is not
anymore able to change the inputtype
for editing chars, it will remain numbers
only.
challenge_response
Valid values: <true>, <false>
Default: true
Description: <true> turns on displaying
challenge request on the display to the
user.
4 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 5
[ F REQUENTLY A S K E D Q U E S T I O N ]
broadsoft_call_control
Valid values: <true>, <false>
Default: false
Description: <true> turns on broadsoft
call control feature support.
cmc_feature
Valid values: <true>, <false>
Default: false
Description: When this setting (CMC -
Client Matter Code) is turned on, the user
is offered a softkey during a call; its use
sends a unique code to the server using
the INFO message in SIP. This code can
later be used for billing or book keeping
along with the call ID of that call.
call_waiting
Valid values: <true>, <false>
Default: false
Description: If call waiting indication
(CWI) is on (<true>), during a call
parallel incoming calls are signaled with
a knocking sound and the caller hears a
free signal. In case of <false> only one
incoming call in parallel can be handled
and the caller hears a busy signal.
cw_dialtone
Valid values: <true>, <false>
Default: false
Description: In case of holding a party
you will hear a free tone <true> or
nothing <false>
conf_hangup
Valid values: <true>, <false>
Default: false
Description: Someone maybe wants the
hookswitch to not cancel a call, then it
should be set to <false>.
transfer_on_hangup
Valid values: <true>, <false>
Default: true
Description: to switch off “transfer on
hook” functionality, set it to <false>.
contrast
Valid values: Between <0> and <15>
Default: 8
Description: Determines the display
contrast, but should not be used,
because each phone reacts differently
to it dependend by example from the
temperature etc. Its better to set it
manually.
use_backlight
Valid values: <true>, <false>
Default: true
Description: In case your phone has a
backlit display (snom105/220) the light
can be switched off completely with
<false>.
image_src
Valid values: <true>, <false>
Default: false
Description: The pictures for the internal
web interface are taken from the phone
(<false>) or loaded via the Internet
(<true>). Thus if you have a slow
connection to the remote phone, <true>
will signicantly speed up the displaying
of the phone‘s webpages.
guess_number
Valid values: <true>, <false>
Default: true
Description: Number guessing or auto
completion while typing in numbers to
dial.
deny_all_feature
Valid values: <true>, <false>
Default: true
Description: If set to <true>, the “Deny
All” option is offered on incoming calls.
Otherwise it is disabled.
6 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 7
[ F REQUENTLY A S K E D Q U E S T I O N ]
admin_mode
Valid values: <true>, <false>
Default: true
Description: Administrator mode
(all settings are accessible) or user
mode (only a few basic settings are
accessible).
admin_mode_password
Valid values: Numbers and character
strings of unspecied length, e.g.
<1234>, <0fg5gju>, <nhcndeve>
Default: 0000
Description: The password for entering
the Administrator mode on the snom
phone.
callpickup_dialoginfo
Valid values: <true>, <false>
Default: false
Description: If your phone should be able
to get informed of calls to be picked up
via the dialoginfo SIP message and to
pickup calls, set this setting to <true>.
SIP Line Settings
The SIP stack on the phone supports
seven lines, which are identied with
the numbers 1 through 7. Line-specic
settings are appended with the line
number.
user_realname[1-7]
Valid values: e.g. <Jim Testa>
Default: blank
Description: This is the real name of the
user that is displayed for line x.
user_name[1-7]
Valid values: e.g. for <sip:
abc@company.de>, the user_name[1-7]
would be abc.
Default: blank
Description: The account name for line x.
This is a mandatory setting to set up a
SIP line!
user_host[1-7]
Valid values: e.g. for <sip:
abc@company.de> the user_host would
be <company.de>.
Default: blank
Description: The registrar for line x. This
is also a mandatory setting to set up an
SIP line!
user_pass[1-7], user_hash[1-7]
Valid values:
e.g. <company, 456876, answerIs42, a6
4bd7c29de0f23ba64bd7c29de0f23b0>
Default: blank
Description: A setting for registrar
authentication. The username and the
password can usually be set up on the
proxy and registrar, user_hash is a MD5
encrypted password, which can be used
instead of user_pass.
user_q[1-7]
Valid values: Values between <0.0> and
<1.0>
Default: 1.0
Description: The probability of the
registration for line x. This probability
is used by some proxies to call the
registered phones one by one (sequential
and parallel forking proxy).
user_dp_str[1-7]
Valid values: dialplan regular expression,
see snom4S proxy manual
Default: blank
Description: dialplan per line
user_transport[1-7]
Valid values: <auto>, <udp>, <tcp>,
<tls> Default: auto Description:The IP
protocol which should be used for this
line.
6 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 7
[ F REQUENTLY A S K E D Q U E S T I O N ]
user_expiry[1-7]
Valid values: <60>, <600>, <3600>,
<7200>, <28800>, <86400>
Default: 86400 (one day)
Description: The proposed expiry time of
the registration in seconds for line x.
user_mailbox[1-7]
Valid values: e.g. <abc> or <sip:
Default: Blank
Description: The SIP url of the mailbox
associated with line x.
user_ice[1-7]
Valid values: <true>, <false>
Default: false
Description: Offer ICE <true> or not
<false> associated with line x.
user_ringer[1-7]
Valid values: <Ringer1>, <Ringer2>,
<Ringer3>, <Ringer4>, <Ringer5>,
<Ringer6>, <Ringer7>
Default: Ringer1
Description: The ring tone to be used
if a call comes to that specic line. See
“ring_source” also.
user_moh[1-7]
Valid values: e.g. <sip:[email protected]>,
<mh>, <192.168.0.40>
Default: blank
Description: SIP Address of music on
hold server of that specic line. The
music is automatically played if this line
is on hold.
user_stream[1-7]
Valid values: e.g.
<http:// www.radioxyz.de>, <http:
//192.168.0.40> Default: blank
Description: HTTP URL of a music
streaming server of that specic line. The
music is automatically played if this line
is on hold.
user_srtp[1-7]
Valid values: <true>, <false>
Default: false
Description: Use SRTP for audio
connections <true> or don’t <false>.
This option is valid for snom190 only.
active_line
Valid values: [1-7]
Default: 1
Description: Number of the active SIP
line. This is the line that is used as the
originator of an outgoing call.
SIP Stack Settings
sip_postx
Valid values: e.g. <proxy.company.de>
Default: blank
Description: Register postx, which is
automatically chosen as registrar if the
logon wizard is used to logon an SIP user
and the registrar has not been set up
through the logon wizard.
user_outbound[1-7]
Valid values: e.g. <proxy.company.de>,
<192.168.0.24>
Default: blank
Description: Address or path of the
outbound proxy per SIP line that is
used for calling.
route_proxy
Valid values: <true>, <false>
Default: false
Description: Treat as initial route
(<true>), <false> for address only
8 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 9
[ F REQUENTLY A S K E D Q U E S T I O N ]
nat_detection
Valid values: <auto>, <upnp>,
<stunclient>, <static>, <off>
Default: auto
Description: NAT detection according to
your network.
stun_server
Valid values: e.g. <217.115.141.99:
5062>
Default: blank
Description: IP address of a STUN server
(hostname:port) if you have one.
stun_binding_interval
Valid values: Integer values e.g. 5, 10.
Default: blank
Description: STUN binding interval in
seconds.
rtp_port_start
Valid values: Valid port numbers.
Default: blank
Description: First dynamic RTP port
rtp_port_end
Valid values: Valid port numbers.
Default: blank
Description: Last dynamic RTP port
network_id_name
Valid values: Valid name.
Default: blank
Description: Network identity
(hostname)
network_id_port
Valid values: Valid port number.
Default: blank
Description: Network identity (port)
use_nw_port
Valid values: <true>, <false>
Default: false
Description: Use local SIP port (<false>)
or network port (<true>)
sip_retry_t1, sip_retry_t2
Valid values: Integer values, e.g.
<500>.
Default: 500, 4000
Description: The time for resending SIP
messages in milliseconds. They should be
set to 500 and 4000 respectively.
session_timer
Valid values: Integer values, e.g.
<2400>, <3200>.
Default: 3600
Description: Default time for session
timer in seconds. 0 disables the session
timer, 3600 is a reasonable value.
dirty_host_ttl
Valid values: Integer values, e.g. <60>,
<120>.
Default: 0
Description: Time in seconds until the
phone waits before it repeats a non
answered request again.
max_forwards
Valid values: Integer values, e.g. <40>,
<60>.
Default: 70
Description: The maximum number of
hops allowed for an SIP request/
response.
enum_sufx
Valid values: e.g. <e164.arpa>
Default: e164.arpa
Description: Route domain for ENUM,
8 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 9
[ F REQUENTLY A S K E D Q U E S T I O N ]
see FAQ “ENUM on snom phones”
tcp_threshold
Valid values: <auto>, <tcp>, <udp>
Default: auto
Description: Set transport layer for
SIP messages either to TCP, UDP or
automatic.
trace
Valid values: <true>, <false>
Default: true
Description: Enable tracing output of the
current protocol stack.
logon_wizard
Valid values: <true>, <false>
Default: false
Description: Logon wizard and mobility
features available in snom key menu.
user_phone
Valid values: <true>, <false>
Default: true
Description: Use user=phone in SIP
signalling.
use_mapped
Valid values: <true>, <false>
Default: true
Description: Use mapped address.
publish_presence
Valid values: <true>, <false>
Default: false
Description: Publish presence information
on <true>.
refer_policy
Valid values: <auto>, <refer>, <bye>
Default: Auto
Description: Choose between REFER
and BYE/Also method for initiating
a transfer. Auto makes an automatic
selection depending on the capabilities
indicated by the other party.
refer_brackets
Valid values: <true>, <false>
Default: false
Description: In case you want to have
your REFER framed with brackets set it
to <true>.
require_prack
Valid values: <true>, <false>
Default: true
Description: In case PRACK is required,
set to <true>, else <false>.
symmetrical_rtp
Valid values: <true>, <false>
Default: true
Description: Switch off symmetrical RTP
support with <false>, else <true>.
offer_gruu
Valid values: <true>, <false>
Default: true
Description: This setting is used to toggle
the support for GRUU (Globally Routable
User agent URL’s) in SIP.
offer_mpo
Valid values: <true>, <false>
Default: false
Description: Using this setting the user
can turn the Media Path Optimization on
or off.
challenge_dialog
Valid values: <true>, <false>
Default: false
Description: Turning this setting on
<true> enables a challenge response for
dialog messages.
10 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 11
[ F REQUENTLY A S K E D Q U E S T I O N ]
challenge_reboot
Valid values: <true>, <false>
Default: false
Description: This setting enables/disables
a challenge response for remote reboot
request.
challenge_checksync
Valid values: <true>, <false>
Default: false
Description: Turning this setting on
<true> enables a challenge response for
Check-Sync.
H.323 Settings
user_h323_e164_number1
Valid values: e.g. <3884576>
Default: Blank
Description: E164 number assigned to
the phone.
user_h323_id1
Valid values: e.g. <kitchen>
Default: blank
Description: H.323 ID assigned to the
phone.
user_h323_url_id1
Valid values: e.g. tx@company.de
Default: blank
Description: H.323 URL ID assigned to
the phone.
user_gkgw_mode1
Valid values: <auto>, <gatekeeper>,
<gateway>, <none>
Default: auto
Description: Gatekeeper or gateway mode.
Can be <auto> (automatic discovery
of Gatekeeper) or <gatekeeper> for
explicitly using the gatekeeper mode,
<gateway> for gateway mode and
<none> for autonomous operation.
user_h323_gateway1
Valid values: e.g. <192.168.0.9>,
<gtk.company.de>
Default: blank
Description: IP address of the gatekeeper
or the gateway, depending on gkgw_
mode (see above). This eld will be
automatically set to the discovered
gatekeeper‘s IP Address if <auto> mode
is selected in “gkgw_mode”.
user_h323_ttl1
Valid values: e.g. <600>
Default: 600
Description: Time-to-live for Gatekeeper
registration. Very low values result in
more frequent refreshes of registration
but also cause additional network trafc.
Very high values result in large intervals
of disconnection from the Gatekeeper
before getting back online if the
gatekeeper reboots without sending any
un-registration request to the phone.
user_early_start1
Valid values: <true>, <false>
Default: true
Description: The early start option
allows the H.245 channel to be set up
earlier, and hence speeds up the call
setup. When early start is turned on, the
H.245 channel address is also supplied
in the Setup message. This speeds up
the call because the H.245 channel
negotiations can proceed in parallel
to H.225.
user_fast_start1
Valid values: <true>, <false>
Default: false
Description: Fast start sends encoded
OpenLogicalChannel messages within the
Setup messages and hence eliminates
the need for a separate H.245 channel
for Codec capability negotiation. This
10 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 11
[ F REQUENTLY A S K E D Q U E S T I O N ]
will only work if the other party is also
supporting fast start. This feature in H.323
is optional, meaning it can be ignored by
an endpoint not supporting this feature,
hence making the snom phone revert to
the normal H.245 signalling on a separate
channel. Note that if Fast Start is being
used, Out of band DTMF might not work
because the DTMF info is relayed on the
H.245 channel.
user_h323_h245_tunneling1
Valid values: <true>, <false>
Default: false
Description: H.245 Tunnelling option
sends tunnelled H.245 messages within
an H.225 pdu. This also accelerates
connection setup if both parties are
supporting this feature.
trace
Valid values: <true>, <false>
Default: true
Description: Enable tracing output of the
current protocol stack.
user_h323_h4501
Valid values: <true>, <false>
Default: false
Description: If ag is set to <true>,
H.450 supplementary services are used,
otherwise (<false>) it is facility-based.
Gateway prexes (H.323 only)
user_external_line_prex1
Valid values: e.g. <0>, <111>
Default: blank
Description: Prex used for reaching
outside numbers via an H323 gateway.
This prex will be replaced by the
gateway_prex in a dialled number for
calling outside numbers (see gateway_
prex).
user_gateway_prex1
Valid values: e.g. <*5>
Default: blank
Description: Prex with which an ISDN
gateway is registered at the gatekeeper.
The phone will replace this prex with the
external_line_prex in a dialled number if
it is starting with the external_line_prex
(see external_line_prex).
Hence the user doesn’t have to dial
numbers like 5*1234567 but can instead
dial 01234567 with the same effect.
PBX key codes (H.323 only)
key_seq_hold_on
Valid values: For example <*1>
Default: blank
Description: Key code that is sent by
the phone to the PBX if it is set and the
“R” (hold on) key is pressed on the
phone.
key_seq_hold_off
Valid values: For example <*2>
Default: blank
Description: Key code that is sent by
the phone to the PBX if it is set and the
“R” (hold off) key is pressed on the
phone.
key_seq_transfer_blind
Valid values: e.g. <*60#>
Default: blank
Description: Key code that is sent by the
phone to the PBX if it is set and the “Xfer”
key is pressed on the phone for a blind
transfer.
key_seq_transfer_consultation
Valid values: e.g. <*6>
Default: blank
Description: Key code that is sent by
the phone to the PBX if it is set and the
“Xfer” key is pressed on the phone for a
12 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 13
[ F REQUENTLY A S K E D Q U E S T I O N ]
consultation transfer. The phone needs
to have 2 active calls in order to use this
feature.
key_seq_divert
Valid values: For example <*3>
Default: blank
Description: Key code that is sent by the
phone to the PBX if it is set and redirection
is active with a redirection number.
key_seq_conf_on
Valid values: For example <*3>
Default: blank
Description: Key code that is sent by
the phone to the PBX if it is set and the
“Cnf.On” key is pressed on the phone.
key_seq_conf_off
Valid values: e.g. <*30>
Default: blank
Description: Key code that is sent by
the phone to the PBX if its set and the
“Cnf.Off” key is pressed on the phone.
key_seq_pickup
Valid values: e.g. <#11>
Default: blank
Description: Key code that is sent by the
phone to the PBX to pick up an alerting
call. This is activated by pressing the
‘pickup’ key when the key_seq_pickup
is set.
key_seq_end
Valid values: e.g. <#>
Default: blank
Description: The end symbol that is
automatically appended to the above key
codes before they are sent to the PBX.
The end symbol marks the end of a key
code sequence.
key_single_call_mode
Valid values: <true>, <false>
Default: true
Description: Set to <true> the phone
simulates a simple analog phone which is
able to handle one call in parallel only.
Codec and DTMF settings
codec[1-5]_name[1-7]
Valid values: 0 (ulaw), 8 (alaw), 3 (gsm),
2 (G.726-32), 18 (G.729) (also 9 (G.722),
4 (G.723) for snom190 only)
Default: 0, 8, 3, 2, 18
Description: Name of the codecs for
line1-7 to be used in preferred order
1-5.
codec_size[1-7]
Valid values: <80>, <160>, <240>,
<320>
Default: 160
Description: Packet size in bytes. Affects
only ulaw and alaw codecs (other codecs
have xed packet size). 80 (10 ms), 160
(20 ms), 240 (30 ms) and 320 (40 ms)
bytes are available per line.
dtmf_type_outofband
Valid values: <true>, <false>
Default: true
Description: Options for Out of band
DTMF. <true> forces the use of Out of
band DTMF, <false> turns it off. Its used
for H.323 only !
dtmf_type_inband
Valid values: <true>, <false>
Default: on
Description: Options for In band DTMF.
<true> forces the use of In band DTMF,
<false> turns it off. Its used for H.323
only !
dtmf_payload_type
Valid values: Integer values, e.g. <100>,
<150>.
12 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 13
[ F REQUENTLY A S K E D Q U E S T I O N ]
Default: 101
Description: Payload type for Out of band
DTMF.
Base Network Settings
ip_adr
Valid values: e.g. <192.168.0.50>
Default: Blank
Description: The IP address of the device.
This parameter is mandatory in order to
enable the ethernet connection.
netmask
Valid values: e.g. <255.255.255.0>
Default: Blank
Description: The netmask for the device.
This parameter is mandatory in order to
enable the ethernet connection.
phone_name
Valid values: e.g. <phone1>
Default: Blank
Description: Hostname of the phone.
If this parameter is available, it is
used for identifying the device in SIP
signalling.
gateway
Valid values: e.g. <192.168.0.1>,
<10.0.0.1>
Default: Blank
Description: The IP address of the default
IP gateway (not the VoIP gateway!!!). It
is the address to which the packets get
routed if the wanted packet address is
not in the current subnet. Setting up this
parameter is mandatory in order to reach
an external network.
dhcp
Valid values: <true>, <false>
Default: true
Description: Use DHCP (<true>) or do
not use DHCP (<false>).
timezone
Valid values: <USA-10>, <USA-9>,
<CAN-8>, <MEX-8>, <USA-8>, <CAN-
7>, <MEX-7>, <USA-7>, <CAN-6>,
<CHL-6>, <MEX-6>, <USA-6>, <BHS-
5>, <CAN-5>, <CUB-5>, <USA-5>,
<CAN-4>, <CHL-4>, <PRY-4>, <BMU-
4>, <FLK-4>, <CAN-3.5>, <GRL-3>,
<PRT-1>, <FRO-0>, <IRL-0>, <PRT-
0>, <ESP-0>, <GBR-0>, <ALB+1>,
<AUT+1>, <BEL+1>, <CAI+1>,
<CHA+1>, <HRV+1>, <CZE+1>,
<DNK+1>, <FRA+1>, <GER+1>,
<HUN+1>, <ITA+1>, <LUX+1>,
<MAK+1>, <NLD+1>, <NAM+1>,
<NOR+1>, <POL+1>, <SVK+1>,
<ESP+1>, <SWE+1>, <CHE+1>,
<GIB+1>, <YUG+1>, <BLR+2>,
<BGR+2>, <CYP+2>, <EGY+2>,
<EST+2>, <FIN+2>, <GAZ+2>,
<GRC+2>, <ISR+2>, <JOR+2>,
<LVA+2>, <LBN+2>, <MDA+2>,
<RUS+2>, <ROU+2>, <SYR+2>,
<TUR+2>, <UKR+2>, <IRQ+3>,
<RUS+3>, <IRN+3.5>, <ARM+4>,
<AZE+4>, <GEO+4>, <KAZ+4>,
<RUS+4>, <KAZ+5>, <KGZ+5>,
<PAK+5>, <RUS+5>, <IND+5.5>,
<KAZ+6>, <RUS+6>, <CHN+7>,
<RUS+7>, <SGP+7>, <KOR+8>,
<JPN+9>, <AUS+9.5>, <AUS+10>,
<RUS+10>, <AUS+10.5>, <NZL+12>,
<RUS+12>, <NZL+12.75>, <TON+13>
Default: Blank
Description: Timezone string, if set, it
sets utc_offset and dst automatically !
utc_offset
Valid values: e.g. in Germany it is
<+3600>.
Default: Blank
Description: Signed UTC offset in
seconds. See timezone also.
dst
Format: offset mm.ww.dd hh:mm:ss
mm.ww.dd hh:mm:ss
Valid values: e.g. for Germany <3600
14 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 15
[ F REQUENTLY A S K E D Q U E S T I O N ]
03.05.07 02:00:00 10.05.07 03:00:00>
Default: Blank
Description: Daylight saving time that
observes yearly change and leap years.
See timezone also.
ntp_server
Valid values: e.g. <192.53.103.103>
Default: 192.53.103.103
Description: Address of the NTP time
server.
Advanced Network Settings
dns_domain
Valid values: e.g. <company.com>
Default: Blank
Description: The DNS domain. This
parameter is mandatory in order to
enable DNS searching.
dns_server1, dns_server2
Valid values: e.g. <194.25.2.129>
Default: Blank
Description: Server that may be used for
DNS searches. Setting up one of these
parameters is mandatory in order to
enable DNS searching.
http_user, http_pass
Valid values: character strings, e.g.
<john>, <jh24>
Default: Blank
Description: Username and password for
accessing the embedded webserver on
the phone.
http_proxy
Valid values: IP address or url
Default: Blank
Description: Sets the http proxy for
outgoing http requests.
http_port
Valid values: e.g. <80>, <8080>
Default: 80
Description: Sets the port for http
requests.
https_port
Valid values: e.g. <80>, <8080>
Default: 443
Description: Sets the port for https
requests.
webserver_type
Valid values: <http>, <https>, <http_
https>, <off>
Default: http_https
Description: Sets the connection type of
http requests which are allowed.
webserver_cert
Valid values: base 64 encoded certicate
along with the private key
Default: empty
Description: Certicate send from the
phone to the browser in case of https.
register_http_contact
Valid values: <true>, <false>
Default: false
Description: Should the phone during a
registration request send its own URL via
which its web interface can be accessed
to the registrar <true> or don’t
<false>.
http_scheme
Valid values: <true>, <false>
Default: false
Description: Type of authentication
scheme used for web interface: Basic
<false>, Digest <true>
register_http_contact
Valid values: <true>, <false>
Default: false
Description:
14 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 15
[ F REQUENTLY A S K E D Q U E S T I O N ]
lcserver1
Valid values: e.g. <192.168.0.26>
Default: Blank (to use local LCServer on
device)
Description: IP addresses of an alternative
remote LCServer. You will not usually
need to change this setting, its for snom
internal use only.
vlan
Valid values: integers separated by a
space, e.g. <128 5>
Default: Blank
Description: VLAN ID (0..4095) and
Priority (0..7) separated by a space
Update
update_policy
Valid values: <auto_update>, <ask_
for_update>, <never_update_rm>,
<never_update_boot>, <settings_only>,
<never_update>
Default: settings_only
Description: Determines the update
behaviour of the phone. <never_update>
does not connect a server regarding
settings or updates at all, <settings_
only> loads settings only from settings
server. <auto_update> does not ask
again, if you are really sure to update.
rmware_interval
Valid values: amount in minutes
Default: 1440 (24*60)
Description: The phone polls by default
each 24 hours for a new rmware. If you
want to change that, it has to be set to
the amount of minutes after a new poll
request should be performed.
setting_server
Valid values: e.g. <http:
//www.company.com/settings/
snom200.htm>, <130.149.12.54>
Default: blank
Description: URL of the settings le.
rmware_status
Valid values: e.g. <http://
www.company.com/settings/snom200-
rmware.htm>
Default: Blank
Description: URL of the cong le that
consists of the bootloader and rmware
setting, see below.
bootloader, rmware
Valid values: e.g. <http:
/ / w w w . c o m p a n y . c o m / f i l e s /
snom200ABC.bin>, <130.149.12.54>
Default: Blank
Description: URL of the image le for
bootloader or rmware respectively.
subscribe_cong
Valid values: <true>, <false>
Default: false
Description: In case you want to subscribe
to the settings send by the proxy use
<true> otherwise (<false>) the settings
were retrieved via setting les.
Miscellaneous
preselection_nr
Valid values: Integer values & ‘+’ e.g.
<001>, <+491234567>
Default: blank
Description: If a number is entered in
this option, the phone dials this pre-
selected number automatically every
time the phone is taken off the hook. This
is particularly useful for using calling/
prepaid cards etc.
mute
Valid values: <true>, <false>
Default: false
Description: Mute <true> the
16 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 17
[ F REQUENTLY A S K E D Q U E S T I O N ]
microphone.
disable_speaker
Valid values: <true>, <false>
Default: false
Description: Disable <true> casing
speaker.
headset_device
Valid values: <none>, <external>,
<headset_rj>
Default: none
Description: Select wether you want to
use a headset with pc or rj connector
or not.
mwi_notication
Valid values: <silent>, <beep>,
<reminder>
Default: silent
Description: Do you want to get reminded
that you have messages waiting or don’t
you ?
release_sound
Valid values: <true>, <false>
Default: true
Description: Usually the phone plays a
short sound after the other party ended
the call. You can switch that off with
<false>.
Other Settings
DND_mode
Valid values: <true>, <false>
Default: False
Description: <true> means that the
phone is in “do not disturb” (DND) mode,
<false> is normal behavior.
edit_alpha_mode
Valid values: <123>, <abc>, <ABC>,
<kana>
Default: <123>
Description: Preferred or default editing
mode for typing in phone numbers/
addresses unless the user changes it
by dialing a different type of phone
number.
tone_scheme
Valid values: <AUS>, <CHN>, <GER>,
<IND>, <JPN>, <MEX>, <GBR>,
<USA>
Default: blank
Description: Country specic scheme of
phone audio signals, like free tone, busy
tone etc.
user_ringer[1-7]
Valid values: <Ringer1>, <Ringer2>,
<Ringer3>, <Ringer4>, <Ringer5>,
<Ringer6>, <Ringer7>
Default: Ringer1
Description: Default selection of the
ring tone style per SIP line that signals
incoming calls. See “ring_source”
also.
family_ring_sound, friends_ring_sound,
colleagues_ring_sound
Valid values: <Ringer1>, <Ringer2>,
<Ringer3>, <Ringer4>, <Ringer5>,
<Ringer6>, <Ringer7>
Default: Ringer1
Description: Phonebook contact type
specic ringers. Selection of the ring
tone style that signals incoming calls
dependend on the contact type of the
caller in the local phonebook. See also
“ring_source”.
ring_source
Valid values: <source>, <destination>
Default: source
Description: Denes if the local phone
(destination) or the remote phone
(source) determines the ring tone style
on an incoming call.
16 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 17
[ F REQUENTLY A S K E D Q U E S T I O N ]
ringing_time
Valid values: Between <0> and
<86400>
Default: 60
Description: Time in seconds how
long an incoming call should ring
before the phone denies him.
vol_speaker
Valid values: Between <0> and <15>
Default: 8
Description: Selection of the casing
speaker volume.
vol_headset
Valid values: Between <0> and <15>
Default: 8
Description: Selection of the headset
speaker volume.
vol_handset
Valid values: Between <0> and <15>
Default: 8
Description: Selection of the handset
speaker volume.
auto_connect
Valid values: <true>, <false>
Default: False
Description: If it is <true>, the phone will
automatically answer incoming calls.
auto_connect_type
Valid values: <auto_connect_type_
handsfree>, <auto_connect_type_
handset>
Default: auto_connect_type_handsfree
Description: If the above setting auto_
connect is <true>, auto_connect_type
determines whether the auto-answered
incoming call switches the phone to
handsfree mode or normal handset
mode.
log_level
Valid values: Between <0> and <9>
Default: 5
Description: Log level of the maintenance
web page, 9 is the most verbose
mode.
Key Mapping
fkey[0-4] ([0-64] in case of snom220 with
up to 3 extension boards)
Valid values: <line>, <dest>,
<icom>, <orbit>, <recorder>, <dtmf>,
e.g. “dest kd@company.org”
Default: line
Description: Changes the meaning of the
programmable keys. See the user/admin
manual for more info. <dtmf> is for
H323 only.
break_key
Valid values: <true>, <false>
Default: true
Description: Change the behaviour of
the key below the casing speaker key to
either break <true> or transfer <false>
functionality, valid for snom200 only.
no_dnd
Valid values: <true>, <false>
Default: false
Description: Switch off the DND
functionality at all with <true>.
Privacy
privacy_in
Valid values: <true>, <false>
Default: false
Description: Reject <true> or accept
<false> anonymous incoming calls.
18 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 19
[ F REQUENTLY A S K E D Q U E S T I O N ]
privacy_out
Valid values: <true>, <false>
Default: false
Description: Show <false> or hide
<true> your own phone number on
outgoing calls.
presence_timeout
Valid values: Between <0> and above
Default: 15
Description: This is the time after which,
if there is no activity, presence is set to
“closed”. The default is 15 minutes.
If it is set to 0, the presence stays
closed and nothing is published. In
other words, presence is disabled for
all practical purposes.
Action URLs
action_dnd_on_url
Valid values: HTTP URL
Default: empty
Description: In case the specic action
has taken place (here DND has been
switched on), a web GET to the specied
URL is performed.
action_dnd_off_url
Valid values: HTTP URL
Default: empty
Description: In case the specic action
has taken place (here DND has been
switched off), a web GET to the specied
URL is performed.
action_redirection_on_url
Valid values: HTTP URL
Default: empty
Description: In case the specic action
has taken place (here redirection always
has been activated), a web GET to the
specied URL is performed.
action_redirection_off_url
Valid values: HTTP URL
Default: empty
Description: In case the specic action
has taken place (here redirection always
has been deactivated), a web GET to the
specied URL is performed.
action_incoming_url
Valid values: HTTP URL
Default: empty
Description: In case the specic action
has taken place (here an incoming call
is ringing), a web GET to the specied
URL is performed.
action_outgoing_url
Valid values: HTTP URL
Default: empty
Description: In case the specic action
has taken place (here an outgoing call
has been started to dial out), a web GET
to the specied URL is performed.
action_setup_url
Valid values: HTTP URL
Default: empty
Description: In case the specic action
has taken place (here the end of the
setup function has been reached and
the phone is setup), a web GET to the
specied URL is performed.
action_offhook_url
Valid values: HTTP URL
Default: empty
Description: In case the specic action
has taken place (here the handset was
lifted from the hook switch), a web GET
to the specied URL is performed.
action_onhook_url
Valid values: HTTP URL
Default: empty
Description: In case the specic action
has taken place (here the handset was
put on the hook switch), a web GET to
the specied URL is performed.
18 snom technology AG
[ F REQUENTLY A S K E D Q U E S T I O N ]
Con guring snom phones for Mass Deployment V3.4 19
[ F REQUENTLY A S K E D Q U E S T I O N ]
Europe & ROW:
snom technology AG
Pascalstr. 10B
10587 Berlin, Germany
Phone: +49 (30) 39833-0
mailto:[email protected]
http://www.snom.com
India and SAARC:
snom technology (India) Pvt Ltd.
No. 417, International Trade Tower
Nehru Place, New Delhi-110019
Phone: +91 11 26234097
Fax: +91 11 26234079
http://www.snomindia.com
mailto:[email protected]
USA and Americas:
snom USA Representation
ABP International, Inc.
1203 Crestside Dr.
Coppell, Texas 75019, USA
Phone: +1-972-831-0280
mailto:[email protected]
© 2004 snom technology AG
All rights reserved.
Table of contents
Other Snom IP Phone manuals
Snom
Snom D710 User manual
Snom
Snom 300 User manual
Snom
Snom 360 Original operating instructions
Snom
Snom D345 User manual
Snom
Snom D865 Product information sheet
Snom
Snom UC edition 760 User manual
Snom
Snom 300 Original operating instructions
Snom
Snom 300 User manual
Snom
Snom 710 User manual
Snom
Snom 7 Series User manual
Popular IP Phone manuals by other brands
Cisco
Cisco SPA300 Series quick start guide
Yeastar Technology
Yeastar Technology GRANDSTREAM GXP Series Configuration guide
Matrix
Matrix SPARSH VP330 Quick installation guide
Equiinet
Equiinet EQ-F6 quick start guide
Intelbras
Intelbras TIP 300 installation guide
Polycom
Polycom VVX 3 Series Setting up and using
