Sony PCS-XG100 User manual

LAN1-ALERT-LAN2 ONLINE
CAMERA
1080 60P
I
N
O
U
T
HDMI
DVI-I OUT ISDN UNIT AUX CONTROL MAINTENANCE
REC OUT
LRLRLRLR
AUDIO OUTAUDIO 2 INAUDIO 1 IN
MIC(A1)
1(R) 2(R) 3(R) 4(L) 5(L)
2
6(L)
DVI-I 1 DVI-I 2(PC)
HDMI-2
HDMI-1
1
DVI cable 5) HDMI
cable 5)
to DC 12V
Camera cable 1)
to HDMI to VISCA
IN
to DVI-I 2
(PC) IN
to HDMI INto CAMERA
4-455-814-13 (1)
HD Visual Communication System
PCS-XG100/XG77/XG100S/XG77S
Installation Guide
© 2013 Sony Corporation Printed in China
Connections
Continued on
reverse side
Notes
Be sure to turn off all the equipment before making any connections.ˎ
Do not connect/disconnect the camera cable, interface cable, or penˎ
tablet with the power on. Doing so may damage the camera unit,
Communication System, or ISDN unit.
For safety, do not connect the 1000BASE-T connector to a networkˎ
that will apply excess voltage to this connector.
When used with an ISDN unit for the first time,ˎthe
Communication System may automatically upgrade the software
of the connected equipment. Follow the instructions on the
monitor screen to upgrade the software. Do not turn off the
Communication System or disconnect the cable during upgrade.
Doing so may cause a malfunction of the system.
ISDN support is planned for version 2.0.ˎ
SRG-120DH
HD Camera Unit 3)
TV monitor 5) 6)
ISDN unit 5)
Interface
cable
(supplied
with ISDN
unit)
1) Supplied
2) Supplied (two PCS-A1 microphones are supplied with the
PCS-XG100/XG100S, and one is supplied with the PCS-XG77/XG77S)
3) Supplied with the PCS-XG100/XG77
4) Supplied (Japan only)
5) Not supplied
6) Output to HDMI monitors under default settings. When outputting to a non-HDMI monitor,
refer to the“To change the ‘Monitor Output’ setting”section on the reverse side.
PCSA-B384S 5)
to ISDN 1 to 3
or
PCSA-B768S 5)
to ISDN 1 to 6
ISDN modular cable 5)
to DC 19.5 V
Power cord 4)
Computer
Projector, etc.
HDMI cable 1)
to HDMI IN UTP cable (category 6,
straight) 5)
VCR, etc.
to MIC (A1) 1 (R) / 4 (L)
PCS-A1 microphone 2)
Connecting two microphones allows pickup
of stereo sound.
LAN
Notes
The PCS-XG77/XG77S is not equipped with the following connectorsˎ
and indicators:
HDMI IN, HDMI-2 OUT, and 2 connectors, and LAN 2 ALERT indicator
On the PCS-XG77/XG77S, theˎ1 connector is named the
connector, and the LAN 1 ALERT indicator is named the LAN ALERT
indicator.
Normally, connect the UTP cable to theˎ1 connector (indicated in
green). If the UTP cable is connected to the 2 connector, some of the
functions of the system may be restricted.
For details, refer to the Operating Instructions supplied with the system.
The REC OUT jack is used to make an audio recording of aˎ
communication, for example. It is not used during regular
communication.
We recommend using Sony’s HDMI cable.ˎ
ISDN
line
Front Rear
to power outlet
to 1
AC adaptor 1)
to TERMINAL
to ISDN UNITto DVI-I
OUT
to HDMI-1
OUT
to
(USB) port
DVI cable 5)
Pen tablet 5)
(Wacom)

Changing the “Monitor Output” and
“Frequency” Settings with the Remote
Commander
If the “Monitor Output” and “Frequency” settings in the Video setup menu are configured incorrectly, pictures
will not be displayed on the monitor. In such cases, use the (power) switch on the Communication System
and the buttons on the Remote Commander to configure the correct settings.
To change the “Monitor Output” setting
After verifying that the (power) switch indicator on the system is lit, perform the following.
Press the (power) switch on the Communication System.
Within five seconds after you pressed the switch, press the buttons on the
Remote Commander as follows, based on the desired “Monitor Output.”
Desired “Monitor Output” On the Remote Commander, press:
HDMI 1 VIDEO INPUT button (once) Number button 3 (three times)
DVI-I OUT VIDEO INPUT button (once) Number button 4 (three times)
The“Monitor Output”setting is changed, and the picture appears on the monitor connected to the system.
To change the “Frequency” setting
After rebooting the system and verifying that the (power) switch indicator changes from blinking to
remaining steadily lit, perform the following.
Press the (power) switch on the Communication System.
Within five seconds after you pressed the switch, press the buttons on the
Remote Commander as follows, based on the desired “Frequency.”
Desired “Frequency” On the Remote Commander, press:
60 Hz VIDEO INPUT button (once) Number button 1 (three times)
50 Hz VIDEO INPUT button (once) Number button 2 (three times)
The “Frequency” setting is changed, and the system reboots.
Note
The Remote Commander cannot be paired with cameras. “IPELA” and are trademarks of Sony Corporation.
