Sony PCS-XL55 HD Visual Communication System
The clear path to HD videoconferencing.
PCS-A1
Omnidirectional Microphone
PCSA-A3
Unidirectional Microphone
PCSA-B768S
ISDN I/F Box 768Kbps
PCSA-B384S
ISDN I/F Box 384Kbps
Optional Accessories
Dimensions
2 2 ( 5 57. 1) 4 5/8 (117)
Unit: inches (mm )
14 5/8 (370)
16 1/4 (410)
18 (456.5) 8 1/2 (214.2)
Sony Electronics Inc.
1 Sony Drive
Park Ridge,NJ 07656
ME-4031
©2011 Sony Corporation.All rights reserved.Reproduction in whole or in part without written permissions is prohibited. Features and specifications
are subject to change without notice.The values for weight and dimension are approximate.All screen images are simulated.“SONY”,“make.
believe”, Memory Stick and “IPELA” are trademarks of Sony Corporation.All other trademarks are the property of their respective owners.
CAUTION: Federal (USA) law restricts this device to sale by or on the order of a physician or other appropriately licensed medical professional.
CAUTION: See product labeling for indications, contraindications, warnings,cautions, and directions for use.
Printed in USA 6/11
PCL-XL55
VIDEO
Communication
protocol standards
H.320, H.323, IETF SIP
Compression
standard
H.261, H.263, H.263+, H.263++, H.264,
MPEG-4 video (SIP only)
Resolution 4:3 - QCIF (176 x 144), CIF (352 x 288), 4CIF (704 x 576)
16:9 - wCIF/w288p (512 x 288), w432p (768 x 432),
w4CIF (1024 x 576), 720p (1280 x 720)
Maximum frame rate Max. 60fps: H.264 - 720p
Max. 30fps: H.261 - QCIF, CIF
H.263 - QCIF, CIF
H.264 - QCIF, CIF, 4CIF, wCIF, w432p, w4CIF
Max. 10fps: H.263 - 4CIF
Bit rate IP - 64 kb/s to 4 Mb/s
ISDN - 56 kb/s to 768 kb/s (with optional PCSA-B768S),
56 kb/s to 384 kb/s (with optional PCSA-B384S)
AUDIO
Bandwidth and
coding
G.711(3.4kHz@56/64kbps),
G.722(7.0kHz@48/56/64kbps), G.728(3.4kHz@16kbps),
MPEG-4 AAC-LC/LD Mono (14kHz@48/64/96kbps),
MPEG-4 AAC-LC/LD Mono (22kHz@96kbps - IP only),
MPEG-4 AAC-LC/LD Stereo (22kHz@192kbps - IP only)
Echo cancellation ON/OFF Stereo Echo Cancelling, Auto Gain Control,
Noise Suppressor
NETWORK
Protocol TCP/IP, UDP/IP, DHCP, DNS, HTTP, TELNET, SSH, SNMP,
NTP, PPPoE, UPnP, ARP, RTP/RTCP
QoS
(Quality of Service)
Adaptive FEC (Forward Error Correction),
Real-time ARQ (Auto Repeat reQuest),
ARC (Adaptive Rate Control), IP Precedence/DiffServe
Others network
features
NAT, UDP Shaping, TCP/UDP Port Setting,
Auto Gatekeeper Discovery, URI Dialing, IPv6
STANDARDS
ITU-T (excludes
audio/video
standards)
H.221, BONDING, H.225.0, H.231, H.239, H.241 H.242,
H.243, H.245, H.350, H.460.18, H.460.19
IETF RFC2190, RFC3016, RFC3047, RFC3261, RFC3264,
RFC3550, RFC3984, RFC4573, RFC4587, RFC4629,
RFC4856, RFC4628, RFC5168
Encryption H.233, H.234, H.235 ver.3
Far end camera
control
H.224, H.281
MULTIPOINT CAPABILITY
Multipoint capability Up to 3 sites (H.320/H.323)
SCREEN LAYOUT
Screen Layout Full Screen, PinP, PandP, SideBySide
DATA SHARING
Data Sharing PC image supported up to SXGA
LIP SYNCHRONIZATION
Lip Synchronization AUTO/OFF
MIC OFF FUNCTION
Mic off Function ON/OFF
CAMERA
Image sensor 1/3.2-type 8 Megapixels CMOS image sensor
Position preset 100 positions (Saved in Main Unit)
Focus Auto / Manual
Gain Auto (Auto Gain Control)
Focal length f=2.9mm (F2.8)
Zoom ratio 3x digital zoom
Horizontal viewing
angle
Approx. 80.1°
Other features Auto White Balance, Backlight
DISPLAY
Size 22 inch wide (measured diagonally)
Aspect ratio 16:9
Resolution 1366 x 768 (WXGA)
Brightness 270 cd/m2
Response time 6.5ms
Contrast ratio 2500:1
Viewing angle 176°
Colors 16.7M colors
INTERFACE
Video Input AUX Video Input (RGB x1)
Video Output RGB x1
Audio Input AUX Mic Input L/R x1(Analog, Plug-in power,
PCS-A1/PCSA-A3), AUX Input (Mini, Stereo) x1
Audio Output Headphone Output (Mini, Stereo) x1,
REC Output (Pin, Stereo) x1
Network 10BASE-T/100BASE-TX x1, ISDN Unit Interface x1
Control RS-232C
Others Memory Stick Slot x1, Tablet Interface
GENERAL
Operating
temperature
41°F to 95°F (5°C to 35°C)
Operating humidity 20 % to 80 %
Storage temperature -4°F to +140°F (-20°C to +60°C)
Storage humidity 20 % to 80 %
Power requirements DC19.5 V supplied from AC Power Adapter
(AC100-240 V, 50/60 Hz)
Current consumption 5 A
Dimensions
(W x H x D)
22 x 18 x 8 1/2 inches (557.1 x 456.5 x 214.2 mm)
*excl. projections, including stand
Mass 18 lb 1 oz (8.2 kg)
SUPPLIED ACCESSORIES
AC Power Adaptor x1, PCS-RF1 (RF Remote Commander
Unit) x1, Manganese Battery for Remote Commander
Unit x2, CD-ROM(Operation Manuals) x1, Operation
Guide x1, Quick Connection Guide/Remote
Commander Guide x1, Worldwide Warranty Booklet x1

Stunning 720p High-definition (HD) images.
The PCS-XL55 adopts the H.264 video codec, which enables
efficient transmission of high-quality images at up to 60 frames per
second (fps) in a high-definition resolution of 1280 x 720 pixels.
Stunning HD video enhances your videoconferencing with more
lifelike images for effective communication.
Lifelike Stereo Sound.
The PCS-XL55 ensures a natural and clear sound with an
advanced echo canceller.
ITU-T H.239 Support—Presentation Data
Transferred at 30 fps.*
With support for the ITU-T H.239 (video and presentation data)
standard,the PCS-XL55 can send both the video and presentation
data displayed on your PC to videoconferencing counterparts for
more effective communication.Presentation data can be transferred
at frame rates as high as 30 fps*,providing natural and smooth
presentations even when using animation effects or showing videos
from your PC.This presentation data can also be shown from either a
projector or sub display, using the RGB output. (see Figure 1)
*These functions are available except when using the 720/60p video format.
Transportable All-in-One Design.
The PCS-XL55 is an all-in-one visual communication system that
combines a built-in high-quality camera,16:9 widescreen 22 inch
(measured diagonally) WXGA LCD, speakers,and a microphone
in one compact and sleek body that can even double as a PC
display.The unit incorporates a privacy shutter that can be closed
if you prefer not to be seen when a call comes through.
The PCS-XL55 also has a relatively wide 80.1 degree horizontal
viewing angle,making it ideal not only for use on individual desktops,
but also in small meeting spaces with a number of participants.
In addition, the PCS-XL55 is easy to transport because it is equipped
with a handle and is relatively light in weight.(see Figure 2)
Kiosk Mode.
The PCS-XL55 has a convenient Kiosk mode that can be used
to provide unattended services for applications such as remote
consulting or customized distance learning.This mode not only
provides a user-friendly interface for customers, but is also both
easy to configure and flexible. For example,up to four locations
can be preset,and customized thumbnail images can be
designed. (see Figure 3)
Video Annotation Function.**
For effective communication,the PCS-XL55 offers a useful video
annotation function. Conference participants can clearly point
out specific parts of shared data,including live images and
presentation data, by simply writing on a tablet.This function can
help you to minimize time and effort in your communications,
enabling you to deliver a clear, strong message. (see Figure 4)
** Requires an optional third-party pen tablet.
Enhanced Intelligent QoS™Functions for Stable
and Secure Videoconferencing.
To handle the transmission of large amounts of HD video data,
while maintaining high-quality and stable communication over
an IP network, the PCS-XL55 incorporates the following advanced
Quality of Service (QoS) functions:
•Adaptive FEC (Forward Error Correction)
•Real-time ARQ™(Automatic Repeat reQuest)
•ARC (Adaptive Rate Control)
These functions work in harmony for fast and consistent data
throughput during the transmission of video signals, by adapting
to any changes in network condition, and correcting any
packet loss.(see Figure 5)
Multi-Point Connection—Embedded MCU.
Using either an IP (H.323 protocol) or ISDN (H.320 protocol)
connection, the PCS-XL55 can communicate with up to
two remote videoconferencing sites (three sites in total)
simultaneously.
Simple Set-up and Easy Operation Intuitive
GUI—Simple Layer Structure/Translucent
Cascading Menus.
The PCS-XL55 was designed with an intuitive GUI,utilizing
translucent cascading menus.This simple layer structure and
easy functionality allow you to operate the videoconferencing
system, including the camera,much more easily.
One-Touch Dialing with the RF Remote
Commander Unit.
For user convenience, the PCS-XL55 adopts an RF Remote
Commander unit which you do not have to point directly towards
the system.What’s more, the PCS-XL55 has a convenient One-
Touch Dialing feature, which allows you to easily connect to any
of your registered contacts by just pushing a function button on
the RF Remote Commander unit that corresponds to a thumbnail
image on the GUI. Up to four contacts for one-touch dialing
can be shown on the home menu from a maximum of 1,000
registered contacts.
Other Features.
• Memory Stick™recording—video/presentation data (including
annotations) and audio can be recorded for later review.
• Presentation data can be sent as a single stream by selecting
the RGB input.
• Built-in streaming function for multicasting to large audiences.
• Support for IPv6.
• Support for H.460 Firewall Traversal.
• Up to 100 camera preset positions can be stored, each with
a thumbnail image for easy recall.
Key Features
Microphone
Privacy Shutter
Speakers
8 Mega pixel CMOS
21.6 inch Monitor
PCS-RF1
RF Remote Commander
Figure 1 Figure 3Figure 2 Figure 4 Figure 5
With Enhanced Intelligent QoS
Without Enhanced Intelligent QoS
Simulated image
Simulated image
Video Annotation Function.
For effective communication,the PCS-XL55 offers a useful video
annotation function. Conference participants can clearly point
out specific parts of shared data,including live images and
presentation data, by simply writing on a tablet.This function can
help you to minimize time and effort in your communications,
enabling you to deliver a clear, strong message. (see Figure 4)
enabling you to deliver a clear, strong message. (see Figure 4)
**
Requires an optional third-party pen tablet.
Enhanced Intelligent QoS
and Secure Videoconferencing
To handle the transmission of large amounts of HD video data,
while maintaining high-quality and stable communication over
an IP network, the PCS-XL55 incorporates the following advanced
Quality of Service (QoS) functions:
•Adaptive FEC (Forward Error Correction)
•Real-time ARQ
•ARC (Adaptive Rate Control)
Bringing professionals together in HD clarity.
When communicating clearly with employees, clients, or colleagues is vital to your business,
you need a videoconferencing system that lets you see, hear, speak, and be heard with the
utmost clarity, whether on or off site.That’s why so many professionals rely on Sony’s PCS-
XL55 HD Visual Communication System—an all-in-one desktop design with powerful lifelike
stereo sound and stunning 720p high- definition images.This is videoconferencing with HD
audio and video so real to life it almost feels like you’re actually there. High-definition images
provide approximately four times more details than standard-definition images, delivering
greater clarity to the visual communication experience,whether in the conference room,the
classroom,or the operating room.
Videoconferencing is a cost-effective use of resources, saving the expense of travel
and time away from your office.The Sony PCS-XL55 system allows you to attend off-site
meetings in real time,no matter where your business or facility is located.
Whether used for consulting,distance learning, meetings or training sessions, the Sony HD
Visual Communication System brings a whole new level of clarity to videoconferencing for
education, medical, government or corporate applications.
PCS-XL55
PCS-XL55
IP Network
PCS-XL55PCS-XL55
IP Network

Sony PCS-XL55 HD Visual Communication System
The clear path to HD videoconferencing.
PCS-A1
Omnidirectional Microphone
PCSA-A3
Unidirectional Microphone
PCSA-B768S
ISDN I/F Box 768Kbps
PCSA-B384S
ISDN I/F Box 384Kbps
Optional Accessories
Dimensions
2 2 ( 5 57. 1) 4 5/8 (117)
Unit: inches (mm )
14 5/8 (370)
16 1/4 (410)
18 (456.5) 8 1/2 (214.2)
Sony Electronics Inc.
1 Sony Drive
Park Ridge,NJ 07656
ME-4031
©2011 Sony Corporation.All rights reserved.Reproduction in whole or in part without written permissions is prohibited. Features and specifications
are subject to change without notice.The values for weight and dimension are approximate.All screen images are simulated.“SONY”,“make.
believe”, Memory Stick and “IPELA” are trademarks of Sony Corporation.All other trademarks are the property of their respective owners.
CAUTION: Federal (USA) law restricts this device to sale by or on the order of a physician or other appropriately licensed medical professional.
CAUTION: See product labeling for indications, contraindications, warnings,cautions, and directions for use.
Printed in USA 6/11
PCL-XL55
VIDEO
Communication
protocol standards
H.320, H.323, IETF SIP
Compression
standard
H.261, H.263, H.263+, H.263++, H.264,
MPEG-4 video (SIP only)
Resolution 4:3 - QCIF (176 x 144), CIF (352 x 288), 4CIF (704 x 576)
16:9 - wCIF/w288p (512 x 288), w432p (768 x 432),
w4CIF (1024 x 576), 720p (1280 x 720)
Maximum frame rate Max. 60fps: H.264 - 720p
Max. 30fps: H.261 - QCIF, CIF
H.263 - QCIF, CIF
H.264 - QCIF, CIF, 4CIF, wCIF, w432p, w4CIF
Max. 10fps: H.263 - 4CIF
Bit rate IP - 64 kb/s to 4 Mb/s
ISDN - 56 kb/s to 768 kb/s (with optional PCSA-B768S),
56 kb/s to 384 kb/s (with optional PCSA-B384S)
AUDIO
Bandwidth and
coding
G.711(3.4kHz@56/64kbps),
G.722(7.0kHz@48/56/64kbps), G.728(3.4kHz@16kbps),
MPEG-4 AAC-LC/LD Mono (14kHz@48/64/96kbps),
MPEG-4 AAC-LC/LD Mono (22kHz@96kbps - IP only),
MPEG-4 AAC-LC/LD Stereo (22kHz@192kbps - IP only)
Echo cancellation ON/OFF Stereo Echo Cancelling, Auto Gain Control,
Noise Suppressor
NETWORK
Protocol TCP/IP, UDP/IP, DHCP, DNS, HTTP, TELNET, SSH, SNMP,
NTP, PPPoE, UPnP, ARP, RTP/RTCP
QoS
(Quality of Service)
Adaptive FEC (Forward Error Correction),
Real-time ARQ (Auto Repeat reQuest),
ARC (Adaptive Rate Control), IP Precedence/DiffServe
Others network
features
NAT, UDP Shaping, TCP/UDP Port Setting,
Auto Gatekeeper Discovery, URI Dialing, IPv6
STANDARDS
ITU-T (excludes
audio/video
standards)
H.221, BONDING, H.225.0, H.231, H.239, H.241 H.242,
H.243, H.245, H.350, H.460.18, H.460.19
IETF RFC2190, RFC3016, RFC3047, RFC3261, RFC3264,
RFC3550, RFC3984, RFC4573, RFC4587, RFC4629,
RFC4856, RFC4628, RFC5168
Encryption H.233, H.234, H.235 ver.3
Far end camera
control
H.224, H.281
MULTIPOINT CAPABILITY
Multipoint capability Up to 3 sites (H.320/H.323)
SCREEN LAYOUT
Screen Layout Full Screen, PinP, PandP, SideBySide
DATA SHARING
Data Sharing PC image supported up to SXGA
LIP SYNCHRONIZATION
Lip Synchronization AUTO/OFF
MIC OFF FUNCTION
Mic off Function ON/OFF
CAMERA
Image sensor 1/3.2-type 8 Megapixels CMOS image sensor
Position preset 100 positions (Saved in Main Unit)
Focus Auto / Manual
Gain Auto (Auto Gain Control)
Focal length f=2.9mm (F2.8)
Zoom ratio 3x digital zoom
Horizontal viewing
angle
Approx. 80.1°
Other features Auto White Balance, Backlight
DISPLAY
Size 22 inch wide (measured diagonally)
Aspect ratio 16:9
Resolution 1366 x 768 (WXGA)
Brightness 270 cd/m2
Response time 6.5ms
Contrast ratio 2500:1
Viewing angle 176°
Colors 16.7M colors
INTERFACE
Video Input AUX Video Input (RGB x1)
Video Output RGB x1
Audio Input AUX Mic Input L/R x1(Analog, Plug-in power,
PCS-A1/PCSA-A3), AUX Input (Mini, Stereo) x1
Audio Output Headphone Output (Mini, Stereo) x1,
REC Output (Pin, Stereo) x1
Network 10BASE-T/100BASE-TX x1, ISDN Unit Interface x1
Control RS-232C
Others Memory Stick Slot x1, Tablet Interface
GENERAL
Operating
temperature
41°F to 95°F (5°C to 35°C)
Operating humidity 20 % to 80 %
Storage temperature -4°F to +140°F (-20°C to +60°C)
Storage humidity 20 % to 80 %
Power requirements DC19.5 V supplied from AC Power Adapter
(AC100-240 V, 50/60 Hz)
Current consumption 5 A
Dimensions
(W x H x D)
22 x 18 x 8 1/2 inches (557.1 x 456.5 x 214.2 mm)
*excl. projections, including stand
Mass 18 lb 1 oz (8.2 kg)
SUPPLIED ACCESSORIES
AC Power Adaptor x1, PCS-RF1 (RF Remote Commander
Unit) x1, Manganese Battery for Remote Commander
Unit x2, CD-ROM(Operation Manuals) x1, Operation
Guide x1, Quick Connection Guide/Remote
Commander Guide x1, Worldwide Warranty Booklet x1
