Soundoff Signal ETSSLFVBK15 User manual

1.800.338.7337 / www.soundo󰀨signal.com
ETSSLFVBK15_ ETSSLFVBK16 1122 REV B
1
AFTERSHOCK SPEAKER BRACKET (NO DRILL) FOR DODGE RAM 1500 (5TH GENERATION
ONLY) 2019 - 2023, FRAME MOUNT
NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage.
To review our Limited Warranty Statement & Return Policy for this or any SoundO Signal product, visit our website at www.soundosignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundosignal.com.
ENHANCING SAFETY THROUGH INNOVATION
ETSSLFVBK15- DRIVER SIDE
ETSSLFVBK16- PASSENGER SIDE
INTRODUCTION:
CONTAINS
ITEM# COMPONENT QTY
1 SPEAKER BRACKET 1
2 ½”-20 LOCK NUT 2
3 ½”-20 HEX HEAD BOLT 2
4 ½” FLAT WASHER 4
5 SELF DRILLING SCREWS 4
6 INSTALLATION INSTRUCTION SHEET 1
7 PRODUCT WARNING CARD 1
8 CA PROP 65 LABEL 1
•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat build-up and
re. Follow crimp connector manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle Owner’s
Manual for deployment zones.
•Do NOT use system to disconnect headlights, brake lights or other safety equipment.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or re.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring
conguration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal or local
chassis ground (-) must be sized to supply at least 125% of max. current and properly fused at power source.
•Install protective grommets when routing wire through rewall or metal.
WARNING
*Speaker and Speaker Hardware Sold Separately
ETSSLFVBK15 SHOWN WITH ETSSLF100 SPEAKER*
1
3
4
2
5

1.800.338.7337 / www.soundo󰀨signal.com
ETSSLFVBK15_ ETSSLFVBK16 1122 REV B
2
AFTERSHOCK SPEAKER BRACKET (NO DRILL) FOR DODGE RAM 1500 (5TH GENERATION
ONLY) 2019 - 2023, FRAME MOUNT
NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage.
To review our Limited Warranty Statement & Return Policy for this or any SoundO Signal product, visit our website at www.soundosignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundosignal.com.
ENHANCING SAFETY THROUGH INNOVATION
ETSSLFVBK15- DRIVER SIDE
ETSSLFVBK16- PASSENGER SIDE
INSTALLATION:
1. Remove the Universal Mounting Bracket from
the Aftershock speaker (sold separately) as this
bracket will not be used for installation.
2. Use the provided self-drilling screws (4) to attach
the speaker bracket to the rear mounting holes
of the Aftershock speaker. Tighten until screw
is fully seated, then tighten to 75 in-lbs. The
speaker should be attached to the bracket in the
orientation shown in FIG. 1. Ensure that the plug
is on the top of the speaker when in its installed
position.
3. With the speaker installed, hold the bracket
assembly in the position shown in FIG. 1 and
install by sliding the provided bolts (2) through
the existing holes in the bracket and in the
frame. Installing the top lock nut rst, tighten the
fasteners until fully seated. See FIG 2. For proper
placement.
4. Plug in the speaker and test to ensure proper
functionality.
5. Repeat steps 1-5 for the passenger side of the
vehicle.
FIG. 1
FIG. 2
ETSSLFVBK15 SHOWN WITH ETSSLF100 SPEAKER*
ETSSLFVBK15 SHOWN WITH ETSSLF100 SPEAKER*
