Soundoff Signal nFORCE Lightbar for Rear Interior User manual

1.800.338.7337 / www.soundo󰀨signal.com
NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage.
To review our Limited Warranty Statement & Return Policy for this or any SoundO Signal product, visit our website at www.soundosignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. or after hours 5 p.m. to 8 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundosignal.com.
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
nFORCE Interior Lightbar 2020-2021 Ford Utility REAR 0221
Interior Rear Lightbar
!
WARNING
This product contains high intensity LED devices.
To prevent eye damage, DO NOT stare into the
light beam at close range.
INTRODUCTION:
Design highlights for 2020 Ford PI Utility
nFORCE®Lightbar for Rear Interior:
• 6module,fullshrouddesign
• Topcoverincorporatedintothisrearinterior
lightbardesign,forimprovedlookand
installation
• Improvedwiremanagementincorporatedinto
design
• Powdercoatissmoother,lesstextured,than
traditionalSoundOffSignal®interiorlightbars
•HIGHCURRENTinterconnectsmustbeproperlyterminated.Poorcrimpqualitycancauseheat
build-upandre.Followcrimpconnectormanufacturerinstructions.
•DONOTinstallthisproductorrouteanywiresintheAirBagDeploymentZone.Refertovehicle
Owner’sManualfordeploymentzones.
•DoNOTusesystemtodisconnectheadlights,brakelightsorothersafetyequipment.
•Unitmaybecomehottotouchduringnormaloperation.
•Failuretoproperlyinstallconnectors,fusesorwiringmaycausevehiclefailureorre.
•Installationmustonlybeperformedbytrainedtechnician.Installermustdeterminevehiclewiring
congurationandproperintegrationofsystem.
•Useproperwiregauge.Allpowerwiresconnectingtopositive(+)ornegative(-)batteryterminal
orlocalchassisground(-)mustbesizedtosupplyatleast125%ofmax.currentandproperlyfusedat
powersource.
•Installprotectivegrommetswhenroutingwirethroughrewallormetal.
WARNING
NEXUS TECHNOLOGY
2020-2021 Ford PI Utility
CONTENTS
QTY COMPONENT
1 2020FORDUTILITYREARINTERIORLIGHTBARSHROUD
2 2020FORDUTILITYREARINTERIORLIGHTBARBRACKET
22020FORDUTILITYREARINTERIORLIGHTBAR
STANDOFF
2 1/4"-20THREAD2.5"LONGBUTTONSCREW
4 #8X.50TRUSSHEADPHILLIPSSHEETMETALSCREW
1 PLASTICFASCIADRILLTEMPLATE
1 DRIVERSIDEDRILLTEMPLATE
1 PASSENGERSIDEDRILLTEMPLATE
1 PRODUCTWARNINGCARD
1 INSTALLATIONINSTRUCTIONSHEET

1.800.338.7337 / www.soundo󰀨signal.com
NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage.
To review our Limited Warranty Statement & Return Policy for this or any SoundO Signal product, visit our website at www.soundosignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. or after hours 5 p.m. to 8 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundosignal.com.
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
nFORCE Interior Lightbar 2020-2021 Ford Utility REAR 0221
Interior Rear Lightbar
DRILL 1/16 PILOT HOLE
LOCATOR HOLE
LOCATOR HOLE
DRILL 1/16 PILOT HOLE
Fig.2
Fig.1
Fig.4
INSTALLATION:
1.Onthevehicletowardsthetopoftherearhatch,
thereisarectangularplasticfascia.Forreference,
placeapieceoftape,ormarker,ontheedgeofthe
fasciathatfarthestfromtheglass.Thenremovethe
fascia.
2.PlacethePlasticFasciaDrillTemplate,showninFig
1,ontotherectangularplasticfasciaremovedinthe
Step1.Topositionthetemplate,facetheDOWNside
ofthetemplate,asindicatedinFig.1,towardsthe
pieceoftape,ormarker,youplacedontheedgeof
thefasciainStep1.TheOUTsideofthetemplate,as
indicatedinFig.1,willfacetowardstheoutsideedge
ofthefascia.Tapedownthetemplate.
3.Drilla7/16hole,asindicatedinFig.1.
4.RemovePlasticFasciaDrillTemplateandrepeatStep
2andStep3forthedriver'sside.
5.Onthepassengersideofthevehicle'srearhatch,you
willseepunchedsheetmetalholes.Lineuptheholes
inthePassengerSideDrillTemplatewiththeseholes.
Tapedownthedrilltemplate,asseeninFig.2.
6.Usea1/16"drillbittodrillthepilotholesfortheDRILL
HOLESindicatedinFig.2.
7.Onthedriver'ssideofthevehicle'srearhatch,you
willseemorepunchedsheetmetalholes.Lineup
theholesintheDriverSideDrillTemplatewiththese
holes.Tapedownthedrilltemplate,asseenifFig.2.
8.Usea1/16"drillbittodrillthepilotholesfortheDRILL
HOLESindicatedinFig.2.
9.Usingthe4sheetmetalscrews,mountthe2
stainlesssteelbracketstotherearhatchusingthe
pilotholescreatedinSteps6&8.Thebrackets
shouldbefullyseated,asseeninFig.3and4.
10.Re-installtherectangularplasticfasciaremovedin
Step1.ReferenceoriginalFord®instructionsforre-
installationhelp,asneeded.
NOTE: The cut corner will face down on the rectangular
plastic fascia.
PRO TIP: The recommended torque specication for
sheet metal screws is 10 in-lb.
Fig.3
2020-2021 Ford PI Utility
AREAHATCHSHOWSTHEDRILLTEMPLATE
DRILL7/16"HOLE
NOTE:FLIPOVERTHISTEMPLATETO
LOCATETHEPASSENGERSIDEHOLE

1.800.338.7337 / www.soundo󰀨signal.com
NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage.
To review our Limited Warranty Statement & Return Policy for this or any SoundO Signal product, visit our website at www.soundosignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. or after hours 5 p.m. to 8 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundosignal.com.
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
nFORCE Interior Lightbar 2020-2021 Ford Utility REAR 0221
INSTALLATION (CONT.):
11.Connectallwiringtothe nFORCE®RearInterior
Lighbar.
12.Onceallofthewiresareconnected,insertthe shroud
standoffsandbuttonscrewsintothelightbar.Thread
screwsinthentightenuntiltorquespecication,or
untillightbarisfullyseated.
Interior Rear Lightbar
1/4"-20 X 2.5" SCREW
PLASTIC SHROUD STAND OFF
PHILLIPS HEAD SHEET METAL SCREW
SHROUD
SHROUD MOUNTING BRACKET
Fig.5
PRO TIP: The recommended torque specication for
the button screws is 15 in-lb.
2020 Ford PI Utility
