Soundoff Signal EPL7PF C Series User manual

NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage.
To review our Limited Warranty Statement & Return Policy for this or any SoundO Signal product, visit our website at www.soundosignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundosignal.com.
ENHANCING SAFETY THROUGH INNOVATION
1.800.338.7337 / www.soundo󰀨signal.com
EPL7PF(x)C 0221
1
Please see reverse for Technical Specications
•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat
build-up and re. Follow crimp connector manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle
Owner’s Manual for deployment zones.
•Do NOT use system to disconnect headlights, brake lights or other safety equipment.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or re.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring
conguration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal
or local chassis ground (-) must be sized to supply at least 125% of max. current and properly fused at
power source.
•Install protective grommets when routing wire through rewall or metal.
WARNING
EPL7PF(x)C Low Bracket (shown)
EPL7PF(x)A
EPL7HF(x)C High Bracket
EPL7HF(x)A
EPL7000 MINI LIGHTBAR PERMANENT MOUNT
INSTALLATION:
1) Determine a clean, at location (typically roof) on
the vehicle to mount the PINNACLE Mini Lightbar.
The PINNACLE Mini Lightbar comes with two
(2) steel brackets which should be used to
permanently mount the light bar to a vehicle roof
or similar horizontal surface.
2) Position the bar with brackets attached and mark
hole centers. Center punch or drill pilot holes for a
1/4” sheet metal screw (customer supplied).
3) Place a locking washer over the screw and
securely fasten the brackets to the mounting
surface. The screws and holes should be caulked
with a silicone based material to prevent leakage.
DO NOT OVERTIGHTEN!
4) Make electrical connections.
Caution: Do not install this product or route any
wires in the air bag deployment zone. Refer to
your vehicle Owner’s Manual for the location of
any air bag deployment zones.
!
WARNING
This product contains high intensity LED devices.
To prevent eye damage, DO NOT stare into the
light beam at close range.

NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage.
To review our Limited Warranty Statement & Return Policy for this or any SoundO Signal product, visit our website at www.soundosignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundosignal.com.
ENHANCING SAFETY THROUGH INNOVATION
1.800.338.7337 / www.soundo󰀨signal.com
EPL7PF(x)C 0221
REPLACEMENT PARTS & ACCESSORIES
PMB3BKT- Replacement Permanent Mount Bracket (each)
PMB3BRKT- Replacement Permanent Mount Bracket (kit)
PMB3TDC- EPL7000 Replacement Clear Dome
TECHNICAL SPECIFICATIONS
Overall Dimensions: 14.25”L x 8.27”W x 2.93”H
Flash Patterns: 29 ash patterns
Input Voltage Range: 10 - 16 Vdc
Current Consumption: 2 Amps (Avg) - 4 Amps (Max)
# of LEDs: 24 Generation 3 LEDs
Operating Temperature: -40º to +65º C
Cord Length: 125.75”
Flash Patterns
Number/Name Modules Affected
1. Warp Alternating
2. Quad “
3. Quad2 “
4. Quint “
5. Double2 “
6. Warp 1, 2, 3 “
7. Progressive “
8. Q-Switch™ “
9. Intercycle “
10. Warp Whole Bar
11. Quad “
12. Quad2 “
13. Quint “
14. Double2 “
15. Warp 1, 2, 3 “
16. Progressive “
17. Warp Diagonal
18. Quad “
19. Quad2 “
20. Quint “
21. Double2 “
22. Warp 1, 2, 3 “
23. Progressive “
24. Q-Switch “
25. Intercycle “
26. Rotator “
27. Cycle 1 Random
28. Cycle 2 “
29. Cruise Whole Bar
ELECTRICAL:
PATTERN CHANGE
While the lightbar is operational, touch the
WHITE WIRE to 10-16Vdc and hold for longer
than 1.5 seconds. All light engines will steady
burn, turn off, and then start ashing the next
pattern on the list. Release the WHITE WIRE
after the bar resumes ashing. If multiple
pattern changes are required, the power must
be cycled after every change.
The PINNACLE Mini Lightbar features non-
volatile memory and will recall last pattern
used.
Selected pattern will remain the default once
turned off and can be changed by changing the
ash pattern before powering off.
ACTIVATE/DEACTIVATE CRUISE
While the lightbar is operational, touch the
WHITE WIRE to 10-16Vdc for less than one
second. The lightbar will enter cruise mode.
The lightbar will remain in cruise mode unless
power is cycled or the WHITE WIRE is touched
to 10-16vDC for less than one second again.
FOLLOW DIAGRAM BELOW FOR ELECTRICAL CONNECTIONS
RED WIRE: Connect through a switch and fuse to 10-16Vdc
BLACK WIRE: Connect to a good reliable ground (-)
WHITE WIRE: Momentary, connect to 12V (+)
EPL7000 MINI LIGHTBAR PERMANENT MOUNT
RED BLACK
WHITE
5 AMP
FUSE
+12 Vdc
PINNACLE
LIGHTBAR
