Soundoff Signal GHOST EGHSTE5 B Series User manual

1.800.338.7337 / www.soundoffsignal.com
INSTALLATION:
1. Determine a clean, at location on the
vehicletomounttheGHOSTlight.
2. Usingtemplateonreverseside,markand
drillholesin4corners.HolestobeØ0.46”
(approx.Ø15/32”).
3. Carefullycutsheetmetalandensurethere
arenosharpedges.
4. Pressgasketintoopening.
5. Makeelectricalconnections.
6. Testlight.
7. Presslightintogasket.
OPERATION:
WIRE CONNECTIONS
Seesetupprocedureonsecondpage.
 ThesingleGHOSTcomesequippedwith
aninternalasherwith3userselectable
patternsthatcanbesynchronizedeither
alternatingorsimultaneouswithuptothree
otherlights.
1. ConnecttheGHOSTBLACKwiretoa
good,convenientground.
2. ConnecttheGHOSTREDwiretooneside
ofausersuppliedon/offswitch.Connectthe
othersideoftheswitch,througha5Amp
fuse,toasourceof+10-30Vdc.
3. Cruisemodeisactivatedbyapplying
powertoBROWNwirewhileREDwireis
powered.NOTE:CruisemodeisSTEADY-ON
at20%lightoutput.
4. Tosynclightsandmakepattern
selectionsseereverseside.
Please see reverse for
Technical Specications
EGHSTE5(xx)07.17
WIRE HOOK-UP TABLE
WIRECOLOR: CONNECTTO:
RED +10-30Vdc
BLACK Ground(-)
WHITE ID/PatternSelect
BROWNWIRE +10-30Vdc
!
WARNING
This product contains high intensity LED devices. To
prevent eye damage, DO NOT stare into the light
beam at close range.
GASKET
LIGHT
ASSEMBLY
Note:Lensshownis
representativeonly.
GHOST® SINGLE RECESS MOUNT LIGHT
XYLEX LENS - ECE CERTIFIED
SINGLELIGHT
EGHSTE5(x)B-EU-Black
EGHSTE5(x)W-EU-White
EGHSTE5(x)C-EU-Chrome
GHOST® SINGLE RECESS MOUNT LIGHT
ECE CERTIFIED
SINGLELIGHT
EGHSTE5(x)B-Black
EGHSTE5(x)W-White
EGHSTE5(x)C-Chrome
NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage. To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at
www.soundoffsignal.com/support/. If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. or after hours 5 p.m. to 8 p.m. EST
at 1.800338.7337 (press #4 to skip the automated message). Questions or comments that do not require immediate attention may be emailed to [email protected].
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
•HIGHCURRENTinterconnectsmustbeproperlyterminated.Poorcrimpqualitycancauseheat
build-upandre.Followcrimpconnectormanufacturerinstructions.
•DONOTinstallthisproductorrouteanywiresintheAirBagDeploymentZone.Refertovehicle
Owner’sManualfordeploymentzones.
•DoNOTusesystemtodisconnectheadlights,brakelightsorothersafetyequipment.
•Unitmaybecomehottotouchduringnormaloperation.
•Failuretoproperlyinstallconnectors,fusesorwiringmaycausevehiclefailureorre.
•Installationmustonlybeperformedbytrainedtechnician.Installermustdeterminevehiclewiring
congurationandproperintegrationofsystem.
•Useproperwiregauge.Allpowerwiresconnectingtopositive(+)ornegative(-)batteryterminal
orlocalchassisground(-)mustbesizedtosupplyatleast125%ofmax.currentandproperlyfusedat
powersource.
•Installprotectivegrommetswhenroutingwirethroughrewallormetal.
WARNING

1.800.338.7337 / www.soundoffsignal.com
TECHNICAL SPECIFICATIONS
OverallDimensions: 1.55”Hx4.67”Wx0.98”D
InputVoltageRange: 10-30Vdc
CurrentConsumption: 0.75Ampsmax/module
(ashpatterndependent)
#ofLEDs: 6Generation3LEDs
LightSyncTechnology: Yes
OperatingTemperature: -40ºto+65ºC
CruiseLightMode: Yes
EGHSTE5(xx)07.17
TheLinebelowwillprint3”long.Templatesmustbe
enlarged104.52962%fromoriginaldimensions.
4.28
1.19
R0.23
3.81
0.72
Flash Patterns
PatternName FPM
(FlashesperMinute)
1.Single 125
2.Double 125
3.Triple 123
ONE (1) LIGHT
SingleLightOperation:FollowtheIDSelectionstepsandsettheECE
GHOSTtoID#1ifitisnotalready.
TWO (2) LIGHTS
ALTERNATING:ToobtainAlternatingpatterns,followtheID
SELECTIONstepsandsetoneECEGHOSTtoID#1andtheotherto
ID#3.ThenproceedtothePATTERNSELECTIONsteps.
SIMULTANEOUS: ToobtainSimultaneouspatterns,followtheID
SELECTIONstepsandsetbothECEGHOSTlightstoID#1.Then
proceedtoPATTERNSELECTIONsteps.
SLAVE MODE
GHOSTdoesnotsupportSlaveMode.
PATTERN RESET
1.Removepower
2.PlaceWHITE(sync)wiretoground
3.Withsyncwiregrounded,re-powerREDwire
4.Maintainforonesecond(lightwilldim)
5.Removepowerandground(pattern1set)
ECE GHOST Sync Conguration Instructions
IMPORTANT! A MAXIMUM OF 4 SINGLE LIGHTS
CAN BE SYNCED TOGETHER
1. SetID#
 a. IdentifywhichpatternandsequenceyouwantandlookupID#
settingsatright.
 b. Connections
  i. RED:+12Vdc
  ii. WHT:+12Vdc(Note:youwillneedtodisconnectafter
   powerisapplied)
  iii. BLK:Ground
 c. Applypowertounit
 d. Withoutdisconnectingpowerfromunit,disconnectWHT
  wire
 e. MomentarilyconnectWHTtoGroundtochangeID#
  i. IdentifyID#bynumberofsequentialashes
  ii. PossibleID#s:1–4
 f. DisconnectpowerfromunittogetoutofIDmode.
2. SetPattern
 a. Reapplypowertounits.
 b. OnceallLightHeadID#sarecongured,makesureall 
  lightsareashingthesamepattern
 c. Connectcorrespondingcoloredwiresofallunitstogether:
  REDtoRED,etc.
 d. ChangePattern
  i. MomentarilytouchWHTwirestoGround
  ii. Observepatternchangeonalllightsconnected
 e. Insulateallwiresbytapingwithelectricaltape
3. ConnectMasterSwitchforApplication
 a. IMPORTANT!EnsureWHTPattern/SyncWiresaretied 
  together
1 Cutholeinsheetmetal
2 Pressgasketintohole
3 Makewiringconnections
4 Test
5 Installlight
NOTE:
The GHOST is a factory sealed unit that CANNOT be serviced
in the eld. Any attempt to gain access to the GHOST unit will
most likely cause permanent damage and void its warranty.
RECESS MOUNT ECE65 CERTIFIED
w/ STANDARD LENS
SINGLELIGHT
EGHSTE5(x)B-Black
EGHSTE5(x)W-White
EGHSTE5(x)C-Chrome
RECESS MOUNT ECE65 CERTIFIED
w/ XYLEX LENS
SINGLELIGHT
EGHSTE5(x)B-EU-Black
EGHSTE5(x)W-EU-White
EGHSTE5(x)C-EU-Chrome
