Southern Enterprises Hendrik End Table Trunk User manual

Page |
1
PO#:
CK171200TX
Hendrik End Table Trunk
Assembly Instructions
For assistance with assembly, contact:
Southern Enterprises Inc.
Customer Service: 1-800-633-5096
[email protected]om
www.seidal.com

Page |
2
1. Quantity
of 1
Top Panel
2. Quantity
of 1
Left Side Panel
3. Quantity
of 1
Right Side Panel
4. Quantity
of 1
Front Panel
5. Quantity
of 1
Back Panel
6. Quantity
of 1
Bottom Panel
A. Quantity
of 16
Cam Bolts
B. Quantity
of 16
Cam Locks
C. Quantity
of 8
Wood Dowels
Ø 8mm x 30mm
D. Quantity
of 1
Left-Arm Hinge
E. Quantity
of 1
Right-Arm Hinge
F. Quantity
of 15
Screws Ø 1/8” x 1/2”L
Hendrik End Table Trunk
Parts List
Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded
surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is
missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the
pictures. Using the incorrect hardware will cause damage.

Page |
3
G. Quantity
of 1
Front Knob-A
H. Quantity
of 1
Front Knob-B
I. Quantity
o f 2
Hinges
J. Quantity
o f 16
Screws Dia 1/8” x 1/2”L
K. Quantity
o f 2
Side Knobs
L. Quantity
o f 4
Bolts Dia 5/32” x 1/2”L
M. Quantity
of 2
Adhesive Pads
N. Quantity
of 8
Cotton Mats
Care and Cleaning Instructions:
Before using, wipe with a clean, dry cloth.
Periodically apply furniture wax to renew the
finish. Avoid rubbing or scratching the surface
with rough or abrasive objects.
For replacement parts or questions, please
call Customer Service at 1-800-633-5096.
Assembly Tool Required
No.2 Phillips Screwdriver
(Not Included)

Page |
4
Figure 1
Start screwing with fingers to help align
Cam Bolts.
Screw Cam Bolts (A) into holes on Front Panel
(4) and Back Panel (5).
Attach Front Panel (4) and Back Panel (5) to
Bottom Panel (6) by inserting Cam Bolts (A)
into corresponding holes.
Insert Cam Locks (B) into holes on Bottom
Panel (6).
Tighten by rotating Cam Locks (B) clockwise
with Phillips screwdriver.
Figure 2
Screw Cam Bolts (A) and insert Wood Dowels
(C) into holes on Right Side Panel (3).
Attach Right Side Panel (3) to assembled unit
by inserting Cam Bolts (A) and Wood Dowels
(C) into corresponding holes.
Insert Cam Locks (B) into holes on Bottom
Panel (6), Front Panel (4) and Back Panel (5).
Tighten by rotating Cam Locks (B) clockwise
with Phillips screwdriver.
Cover Cam Locks (B) with Cotton Mats (N) as
shown.
Hendrik End Table Trunk
Assembly Instructions

Page |
5
Figure 3
Screw Cam Bolts (A) and insert Wood Dowels
(C) into holes on Left Side Panel (2).
Attach Left Side Panel (2) to assembled unit by
inserting Cam Bolts (A) and Wood Dowels (C)
into corresponding holes.
Insert Cam Locks (B) into holes on Bottom
Panel (6), Front Panel (4) and Back Panel (5).
Tighten by rotating Cam Locks (B) clockwise
with Phillips screwdriver.
Cover Cam Locks (B) with Cotton Mats (N) as
shown.
Figure 4
Attach Hinges (I) to Back Panel (5) and Top (1)
using Screws (J) as shown.
Open Top (1) and attach Arm Hinges (D/E) to
Top (1) and trunk base using Screws (F).
Attach Front Knobs (G/H) to Front Panel (4)
and Top (1) using Screws (F).
Tighten screw with Phillips screwdriver.

Page |
6
Figure 5
Start with finger to help align Bolts.
Attach Side Knobs (K) to Side Panels (2/3)
using Bolts (L).
Tighten Bolts with Phillip screwdriver.
Place Adhesive Pads (M) on top corners of
Front Panel (4) as shown.
Close Top (1) and let it drop down slowly.
Figure 6
Now your Hendrik End Table Trunk is ready to
use!
K

Page |
7
Customer Information
Name
Address
City/State/Zip Code
Phone Number
Please indicate where you purchased this item: Store/Website/Catalog
Please indicate color/size/style number:
Style No Parts Letter Parts Description Quantity Needed
Please immediately examine this product carefully. Any request for missing parts or damage replacement must be
received within 90 days of your receipt of the product. Replacement, if available, will be honored within this time
frame. Parts will not be available for items arriving fully assembled. We do not recommend modifying product(s) and
we are not responsible for any damages due to product modification(s). If damages or missing parts are not
reported within 90 days of your receipt, we are under no obligation to provide parts or replacement merchandise.
For product issues, please contact Southern Enterprises at 800-633-5096 (toll-free) / 972-869-0111 (Dallas),
Mon-Fri 9am – 4pm CST, or email us at s[email protected]. Please ask for customer service representative for
issues involving damages or replacement parts. Please ask for technical assistance representative for any issues
with product and assembly/construction.
Please contact the retailer that you purchased from for returns.
Parts Replacement Form
Customer Service: 1-800-633-5096
[email protected]om
Southern Enterprises, Inc.
600 Freeport Parkway, Suite 200
Coppell, Texas 75019
