Spectrum Industries Masters Interactive Lectern 55250TW User manual

Owner’s Manual
0115348R3 Page 1 of 9
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 5 days of receipt. To report information regarding
missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
Masters Interactive Lectern™
55250 with CC600 worksurface cutout
55251 without worksurface cutout
55352 with Overbridge Control Console™
Masters Lectern
with CC600 cutout
55250TW
Masters Lectern
without worksurface cutout
55251TW
Masters Lectern
with Overbridge Control Console™
55352TW
shown with optional insert panel (shaded)

0115348R3 Page 2 of 9
• Read this owner’s manual before assembly or operation.
• Do not allow children to move the lectern.
• Proceed slowly and carefully when moving the lectern.
• For indoor use only. Do not install or store the lectern where it will be exposed
to moisture.
• Do not block the ventilation openings.
• Avoid uneven loading of the equipment into the lectern. Uneven weight
distribution could cause the lectern to tip when the lectern is moving.
• Do not allow anyone to sit, stand, or climb on the lectern.
• Use a damp, soft-cloth, or sponge, with mild soap or detergent solution to clean
dirty surfaces. Do not use harsh solvents or abrasives.
• This lectern is intended for institutional use. It does not have any user-
serviceable parts or user-maintenance requirements. If servicing is necessary,
please contact Spectrum Industries for assistance.
Electrical Safety:
• Do not plug the power cord into an extension cord.
• Inspect power cords for damage before each use. Do not use power cords
that are damaged.
• Unplug power cord from electrical outlet by gripping the cord. Do not unplug
the power cord by pulling only on the cord.
• Do not step on, drive over, drag, or place objects on the power cord.
• For added safety, plug the lectern into a grounded outlet controlled by a GFI
(Ground Fault Interrupter) circuit breaker.
• Electrical devices are not toys. Children are often unaware of the hazards
associated with electrical devices. This lectern must always be used by
adults or with adult supervision.
Warning - Relocating audio and/or video equipment to furniture not speci cally
designed to support audio and/or video equipment may result in death or
serious injury due to the furnishing collapsing or over turning onto a child.
Warning - Death or serious injury may occur when children climb on audio
and/or video equipment furniture. A remote control or toys placed on the
furnishing may encourage a child to climb on the furnishing and as a result the
furnishing may tip over on to the child.
Important Safety and Care Instructions

Assembly / Setup
0115348R3 Page 3 of 9
Changing rack rail position
1. Rack rails can be moved to an inner position to accommodate larger
knobs and plugs on rack-mount equipment. To move the rack rails
from the outer to inner position, remove the 1/4-20 x 5/8” PHM
screws attaching the rack rail brackets as shown in Figure 2.
2. Move the rack rails and brackets into the new position and reattach
with the screws.
Note: The rack rails are factory-installed
in the Masters in the outer position.
Phillips
Screwdriver
Tools
Required
Figure 2
inner rack rail
position
outer rack rail
position
Worksurface device installation - (lecterns with worksurface cutout only)
1. To install a worksurface device, the included cover plate will need to be removed from the worksurface.
2. From under the worksurface, remove the wing nuts and cover plate strap. Figure 1.
3. Lift off the cover plate, then refer to the device instructions for the remaining installation and setup.
Figure 1
cover plate strap
wing nut
cover plate
worksurface
underside

0115348R3 Page 4 of 9
Cord management
Figure 3A
Tools
Required
4mm Hex
wrench
Figure 3B
Lower audience-
side panel
Upper
audience-side
panel
1/4-20 JC bolts
(4 per panel)
The audience-side panels can be removed to for easy
wiring access. (Remove JC bolts with 4mm hex wrench).
Figure 4B. Replace panels when wiring is complete.
Wires and cords can be routed to different
areas of the lectern using the grommets
and pass-throughs provided. Figure 3A.
10”W x 4”D cutout
with vent cover
(4 included)
2” grommet
(2 included)
2” snap-in grommet
(2 included)
3.125” grommet
(4 included)

0115348R3 Page 5 of 9
1. To remove the insert panel, remove the (2) 1/4-20 x 35mm JC bolts with a 4mm hex
wrench and lift out the panel. Figure 4A.
2. To make cutouts in insert panel (optional):
3. Install controller(s) / electronics into panel.
4. Re-install the overbridge panel and secure with (2) 1/4-20 x 35mm JC bolts.
Note: The insert panel shown (shaded) is not included with the lectern or over-
bridge. This option needs to be ordered separately to complete the overbridge.
Figure 4A
1/4-20 x 35mm
JC bolt
Overbridge panel
1/4-20 x 35mm
JC bolt
A. Identify all location(s) and sizes for controller(s) or electronics while making sure
all devices t within the maximum cutout space available in the overbridge panel.
See Figure 4B-C.
B. Locate and mark the exact cutout area(s) on the panel. Note: Using masking
tape on cut lines will minimize laminate chipping while cutting.
C. Carefully make the cutout(s) in the overbridge panel using a jigsaw or router.
Overbridge insert panel (overbridge lecterns only)
Tools Required
4mm Hex
wrench
Jigsaw or RouterDrill
Pencil Masking
tape
Drill bit
Measuring
device

Masters overbridge panel blank
(at view)
Note: The insert panel shown (shaded) is not in-
cluded with the lectern or overbridge. This option
needs to be ordered separately to complete the
overbridge. This insert panel is horizontally sym-
metrical and can be easily removed, rotated, and
re-installed if a cutout needs to be relocated to the
opposite side of the overbridge.
Note: The Overbridge Control Console™has been
designed for many of the currently available con-
trollers on the market, however, modied cutouts
should be reviewed by Spectrum to ensure clear-
ance of brackets, keyboard slides, or other objects
under the worksurface.
Overbridge section view
2” grommet
recommended
cutout area
2” grommet
recommended
cutout area
0115348R3 Page 6 of 9
Figure 4B
Figure 4C

0115348R3 Page 7 of 9
Floor anchoring (toe kick versions only)
1. If your Masters Lectern is equipped with a toe kick, and you wish to
attach it to the oor, the toe-kick will need to be detached from the
lectern. To detach, remove the (4) 1/4-20 x 35mm JC bolts (one on each
corner) from inside the lectern. Figure 6. (Save these fasteners).
2. Carefully lift the lectern off the toe kick and set aside. This will require
several people.
3. Determine and locate the toe kick into its nal position on the oor
and mark the (4) mounting hole locations on the oor. (The toe kick
mounting holes are 1/2” dia.)
4. Drill suitable holes into the oor and anchor the toe kick with
appropriate fasteners.
5. Carefully lift the lectern back onto the toe kick and align the (4) mounting holes.
6. Re-attach the lectern to the toe kick with the previously removed JC bolts.
7. The access panel can be removed to access wiring below lectern.
Figure 6
Note: (4) fasteners are required to anchor the
toe kick to the oor. Due to the wide variety
of ooring materials and conditions possible,
anchor fasteners are not provided.
Access
panel
toe kick
Tools
Required
4mm Hex
wrench
Drill
Brake lever
Caster operation
1. To lock the caster rotation, press the brake lever. Figure 5.
2. To resume rotation, lift up on the brake lever.
Figure 5
Moving and parking the lectern
• Before moving, unplug and secure all power cords.
• Close and lock doors.
• Remove any items from the top of the worksurface.
• Unlock the casters.
• Push slowly and carefully. Do not move over uneven or irregular surfaces.
• Do not allow children to move.
• Lock the casters after moving.
• Do not park unit in areas of heavy trafc.
• Do not run power cords across hallways, classrooms, or other areas
where they will be walked on.
• Do not leave unit unattended in areas where children have access.
• Keep doors closed and locked whenever unit is unattended or parked.
• Keep casters locked whenever the lectern is unattended.
(4) 1/2” mounting
holes for oor anchors
1/4-20 x 40mm JC bolt
(access from inside lectern)
4 required

Accessories
See spectrumfurniture.com for the latest
accessories and detailed warranty information.
0115348R3 Page 8 of 9
Custom-cut logo panel
(audience-side)
36.875”W x 9”H
55252
YOUR LOGO HERE
Keyboard Drawer
with ip-down front
18.75”W x 16”D x 3.8125”H (interior height)
(max 1 per unit-keyed same as drawer and
front door)
55247
Overbridge Insert Panel
for overbridge version only-contact Spectrum to specify cutout
size(s) and location(s)-overbridge not available separately
(includes two 2” grommets with covers)
96507 - blank panel
96507mod - panel with cutout(s)
Adjustable Econo Keyboard Tray
18.375”W
(max 1 per unit)
95520 - standard lectern (17.75”D)
95531 - overbridge lectern (12”D)
Note: 95531 comes with a shorter 12”D
keyboard slide and should be specied for
overbridge version lecterns.
Note: Lectern will accommodate (one) keyboard tray or (one) keyboard drawer.
Retractable Cord Reel
15’ [457.2 cm] retractable, 12 AWG, with breaker,
(mounts horizontally inside lectern to base
panel) 10 lbs [.45 kg]
99029
Note: When installed, the
optional cord reel takes up
3RU from the bottom of the
rack rail.
The cord reel is intended to provide temporary access to electrical outlets for
Spectrum mobile lecterns. Check local electrical codes prior to installation.

0115348R3 Page 9 of 9
WE WILL MAKE IT RIGHT FOR YOU!
Spectrum is committed to provide complete customer satisfaction. Each of our products is manufactured from the best materials available and each
product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations).
We expressly warrant that Spectrum products will be of good quality and workmanship and free from defect for the period set out in the warranty table below
from the date of delivery. This warranty shall not apply to defects or damage resulting from misuse, abuse, neglect, improper care, modifi cation or repair not
authorized by Spectrum, or any other cause outside the control of Spectrum. Spectrum will, at its sole option, either repair or replace the defective product.
This warranty is exclusive; no other warranty, written or oral, is expressed or implied. This warranty is given by Spectrum to Buyer and to no other per-
son or legal entity. No Spectrum dealer, distributor, agent or employee is authorized to make any modifi cation or addition to this warranty.
NOTWITHSTANDING ANYTHING TO THE CONTRARY, SPECTRUM WILL NOT UNDER ANY CIRCUMSTANCES BE LIABLE FOR INDIRECT OR LIQUI-
DATED DAMAGES, INCLUDING CONSEQUENTIAL, INCIDENTAL AND SPECIAL DAMAGES. IN NO EVENT SHALL SPECTRUM’S LIABILITY, WHETHER
UNDER CONTRACT OR WARRANTY, IN TORT OR OTHERWISE, EXCEED THE PURCHASE PRICE RECEIVED BY SPECTRUM FOR THE PRODUCT AT
ISSUE AND “RECALL ACTION” EXPENSES. SPECTRUM SHALL NOT BE SUBJECT TO ANY OTHER OBLIGATIONS OR LIABILITIES, WHETHER ARIS-
ING OUT OF BREACH OF CONTRACT, WARRANTY, TORT (INCLUDING NEGLIGENCE AND STRICT LIABILITY) OR OTHER THEORIES OF LAW, WITH
RESPECT TO PRODUCTS SOLD OR SERVICES RENDERED BY SPECTRUM, OR ANY UNDERTAKINGS, ACTS OR OMISSIONS RELATING THERETO.
Our Customer Service Department is ready to provide immediate attention to any questions, comments or concerns. They are available to answer your calls
Monday through Friday from 7 am to 5 pm CST. In addition your product comments or concerns are welcome via e-mail at: [email protected].
Item Warranty Period
effective 1/1/2015
Adjustable Crank / Electric Desk Legs • 1 Year
Flat Panel Desk Gas Cylinders
Chairs
• Adjustable Height Chair Parts – including frames, gas
cylinders, wood and plastic parts, control handles, casters
• Adjustable Height Chair Upholstery
• In-Stock Upholstery
• Graded-In Fabrics and Customer Owned Material
• 7 Years
• 2 Years
• 2 Years
• No Warranty
Height Adjustable Columns and Lifts • 1 Year
General Use Casters
Electrical (including timers and LINAK actuators) • 2 Years
Keyboard / Mouse Trays • 1 Year
Flat Panel Monitor Arms
• Flat Panel Monitor Arm – General Parts
• Flat Panel Monitor Arm – Gas Cylinders
• 5 Years
• 2 Years
Desks and Lecterns
• Computer Desk Chassis
• Cart Chassis
• Lectern Chassis
• 10 Years
Warranty Table
Warranty
925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
© 2017 Spectrum Industries Inc., All rights reserved.
DESIGNED AND ASSEMBLED IN
CHIPPEWA FALLS
WISCONSIN.USA
