1. Assemble slide brackets
1. Attach the ‘L’ brackets to each outer slide with screws (included
with slides). The brackets need to be attached “inboard” (facing
each other). Figure 1A.
• For Freedom XRS Lecterns, multiple height positions / mounting
holes are available with the brackets-use the same hole position
on all four brackets.
• For Pivot Premiere Lecterns, use the tallest position on all four
brackets.
2. Tighten the bracket screws securely.
3. Separate the inner from the outer slides using the black levers.
4. Raise the lectern up all the way and unplug the power cord.
Note: The ‘L’ brackets can be adjusted to provide varied keyboard
heights-the keyboard tray may protrude up to a maximum of 3.9” [10
cm] below the worksurface. If the lectern is used for ADA use, a higher
adjusted worksurface will be necessary to provide ADA leg clearance.
Figure 1
Screw
(included with slides)
‘L’ Bracket
Outer slide
‘L’ Bracket
(6) 0100167
8-32 x 1/2” PH
thread-cutting
screw
(8) 037542
#8 x 5/8” PHSM
(1pr) 050092
12” Slide set
(1) 0140345
Keyboard Tray
Phillips
Screwdriver
Pull-out Keyboard Tray
55496
Tools
Required
Inner slide

0191446 Page 2 of 3
8-32 x 1/2” PH
thread-cutting screw
(3 required per slide)
Figure 2.1
Keyboard Tray
Inner
slide
2. Attach inner slides to tray
1. Attach each inner left and right slide to the keyboard tray with (3) 8-32
x 1/2” PH thread-cutting screws and tighten securely. Figure 2.1
Freedom XRS Pivot Premier
Figure 2.2
Keyboard Tray
8-32 x 1/2” PH
thread-cutting screw
(2 required per slide)
Inner
slide
1. Slides mounted in rear position. Attach each inner left and right slide
to the keyboard tray with (2) 8-32 x 1/2” PH thread-cutting screws
and tighten securely. Figure 2.1
3. Attach slide assemblies to worksurface
1. Determine the preferred position of the keyboard tray (left center right). Pre-drilled mounting holes are available for multiple mounting locations.
2. Attach each outer slide assembly to the underside of the worksurface with (4) #8 x 5/8” PHSM screws but do not tighten completely.
(Brackets face inward). Figure 3.
3. Tighten screws on one slide assembly only-leave the screws on the other slide assembly slightly loose.
Note: The lecterns have pre-drilled holes in left, cen-
ter, and right positions for keyboard tray mounting.
On Freedom XRS Lecterns, the keyboard tray should
be installed on the side opposite the equipment rack
(if equipped).
Figure 3
(4) #8 x 5/8”
PHSM
Outer slide
assembly
(4) #8 x 5/8” PHSM
Outer slide
assembly
Worksurface
Inner
slide
Inner
slide

0191446 Page 3 of 3
925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
© 2019 Spectrum Industries Inc., All rights reserved.
4. Install keyboard tray
Keyboard Tray
Assembly
Figure 4
Note: The dual-use tray can be used as a keyboard
tray, or easily ipped and used as a drawer.
1. Align the keyboard tray assembly with the installed slides and slide together. Figure 4.
2. Open and close (cycle) the tray a few times to ensure parallel and free movement.
3. With the keyboard tray pulled out, securely tighten the (4) loose worksurface slide screws from step 3.3.
Flipping keyboard tray / drawer - optional
1. To ip, pull the tray out fully and locate the plastic lever on each slide.
Figure 5.
2. Release the levers on the both slides while pulling the tray out.
3. Flip the tray over, re-align the slides, and push tray back in.
Figure 5
Push here on both
slides to release tray
