Spectrum Industries InVision Element Table 37128 User manual

Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 15 days of receipt. To report information regard-
ing missing parts or damage, to purchase parts or
accessories, or if you have any questions, please
contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
Owner’s Manual
0118729 Page 1 of 8
InVision Element Table™
37128

0118729 Page 2 of 8
• Read this owner’s manual before assembly or operation.
• Do not allow children to move the table.
• For indoor use only. Do not install or store the table where it will be exposed to
moisture.
• Do not block the ventilation openings.
• Do not allow anyone to sit, stand, or climb on the table.
• Use a damp, soft-cloth, or sponge, with mild soap or detergent solution to clean
dirty surfaces. Do not use harsh solvents or abrasives.
• This table is intended for institutional use. It does not have any user-serviceable
parts or user-maintenance requirements. If servicing is necessary, please
contact Spectrum Industries for assistance.
Electrical Safety:
• Keep the power switch in the OFF position before plugging or unplugging
from the wall outlet.
• Ensure total device / equipment load does not exceed 12-amps.
• Do not plug the power cord into an extension cord.
• Inspect the power cords for damage before each use. Do not use power
cords that are damaged.
• Unplug power cord from electrical outlet by gripping the cord. Do not unplug
the power cord by pulling only on the cord.
• Do not step on, drive over, drag, or place objects on the power cord.
• For added safety, plug the cart into a grounded outlet controlled by a GFI
(Ground Fault Interrupter) circuit breaker.
• Damaged electrical components can create signifi cant hazards to users and
is not covered by the warranty. Repairs should always be performed by a
qualifi ed electrician.
• Electrical devices are not toys. Children are often unaware of the hazards
associated with electrical devices. This table must always be used by adults
or with adult supervision.
Warning - Relocating audio and/or video equipment to furniture not specifi cally
designed to support audio and/or video equipment may result in death or
serious injury due to the furnishing collapsing or over turning onto a child.
Warning - Death or serious injury may occur when children climb on audio
and/or video equipment furniture. A remote control or toys placed on the
furnishing may encourage a child to climb on the furnishing and as a result the
furnishing may tip over on to the child.
Important Safety and Care Instructions

Corner Post Components
(2) 0100167
8-32 x 1/2” PH
thread-cutting screw
(44) 026064
1/4-20 x 5/8” PHMS
(4) 037779
5/16-18 Glide
0118729 Page 3 of 8
Components
T-Leg Components
(1) Cord channel-left
(1) Worksurface
(4) Post Leg
(2) T-Leg assembly
(1) Cord channel-right
(1) 0118483
End Cap
(8) 041289
1/4-20 x 1-3/4” PHMS
(2) 0100167
8-32 x 1/2” PH
thread-cutting screw
(20) 026064
1/4-20 x 5/8” PHMS
(4) 037779
5/16-18 Glide

0118729 Page 4 of 8
Assembly / Setup - Table with T-Legs
T-leg
Worksurface
1. Attach T-Legs to worksurface
1. Place the worksurface upside-down (laminate side-down) onto a at,
non-abrasive surface like another table. Figure 1A.
2. Attach the two T-legs as shown with 1/4-20 x 5/8” PHM screws.
3. Install the four glides.
Phillips
screwdriver
Tools Required
Cordless drill
with Phillips driver
(best)
or
2. Attach cord channel to worksurface
1. Attach the left and right cord channels to the worksurface as shown
with 1/4-20 x 5/8” PHM screws. Figure 1B.
2. Install the end cap with (2) 1/4-20 x 5/8” PHMS, and (2) 8-32 x 1/2”
PH thread-cutting screws and tighten securely.
Glide
Cord Channel
(left and right)
(2) 8-32 x 1/2”
PH thread-cutting
screws
End cap
Figure 1A
Figure 1B
1/4-20 x 1-3/4” PHMS
(4 per)
1/4-20 x 5/8”
PHMS
Phillips
screwdriver
Tools Required
Cordless drill
with Phillips driver
(best)
or

Assembly / Setup - Table with Post Legs
0118729 Page 5 of 8
Post leg
Worksurface
1. Attach Post legs to worksurface
1. Place the worksurface upside-down (laminate side-down) onto a at,
non-abrasive surface like another table. Figure 2A.
2. Attach each post leg as shown with (8) 1/4-20 x 5/8” PHM screws.
3. Install the four glides.
Phillips
screwdriver
Tools Required
Cordless drill
with Phillips driver
(best)
or
2. Attach cord channel to worksurface
1. Attach the left and right cord channels to the worksurface as shown
with 1/4-20 x 5/8” PHM screws. Figure 2B.
2. Install the end cap with (2) 1/4-20 x 5/8” PHMS, and (2) 8-32 x 1/2”
PH thread-cutting screws and tighten securely.
Glide
Cord Channel
(left and right)
(2) 8-32 x 1/2”
PH thread-cutting
screws
End cap
Figure 2A
Figure 2B
1/4-20 x 5/8” PHMS
(8 per)
(2) 1/4-20 x
5/8” PHMS
Phillips
screwdriver
Tools Required
Cordless drill
with Phillips driver
(best)
or

0118729 Page 6 of 8
3. Flip Table upright
1. Carefully ip the table upright-this will take 3-4 people. Figure 3.
Figure 3
CAUTION
Do not allow the legs to contact the oor until
the table is completely rotated. Side-loading
of the table legs could cause damage.
5. Wiring
1. If your worksurface has optional power module or device cutouts, install
the devices, then route and secure the cords using the wiring channel
underneath. Figure 4.
4. Display Stand
1. If you have the optional display stand, proceed with the installation at
this time. Figure 4. (Instructions included with stand.)
Figure 4
Optional
Power
module
Wiring
channel
Display
Stand

Accessories (Available separately after initial congured purchased)
0118729 Page 7 of 8
Display mount
Worksurface option with
mounting holes required-
specify when ordering
Element Display Stand - 37130
• Bolts directly to worksurface
• Integrated cable management routes and hides wires
• Adjustable (VESA-compatible) mount
• Requires worksurface mounting holes and cutout
Monitor size range: 32”-55” [81.3 cm-139.7 cm] diagonal
Weight capacity: 100 lb [45.4 kg]
Vertical adjustment
(worksurface-to-center)
• 23.5”H [59.7 cm]
• 21.5”H [54.6 cm]
• 19.5”H [49.5 cm]
• 17.5”H [44.5 cm]
• 15.5”H [39.4 cm]
(5 vertical positions
in 2” increments)
Tilting 15° range
Shipping weight: 35 lb [15.9 kg]
Mounting holes and cutouts
needed on at end of worksurface
Cove Power Module - 99044
• Two power receptacles per module
• Two USB charge ports (not data-compatible)
• Thumbscrew clamps
• Requires worksurface cutout
• ETL listed
• Available in Black or Silver
Cutout required: 5.25”W [13.3 cm] x 2”D [5.1 cm]
(mounts to surface thicknesses up to 1.5”)
Power cord: 9’ [274 cm] with 90° at plug with 45° rotation
Power receptacles: 12A, 120 VAC spill-resistant
USB charging ports: 2.1A (10.5W)
Dimensions: 6”W [15.2 cm] x 2.5”D [6.35 cm] x 3.18”H [8.1 cm]
Unit weight: 2.29 lb [1 kg]
Worksurface option with
mounting cutout required-
specify when ordering

0118729 Page 8 of 8
WE WILL MAKE IT RIGHT FOR YOU!
Spectrum is committed to provide complete customer satisfaction. Each of our products is manufactured from the best materials available and each
product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations).
We expressly warrant that Spectrum products will be of good quality and workmanship and free from defect for the period set out in the warranty table below
from the date of delivery. This warranty shall not apply to defects or damage resulting from misuse, abuse, neglect, improper care, modifi cation or repair not
authorized by Spectrum, or any other cause outside the control of Spectrum. Spectrum will, at its sole option, either repair or replace the defective product.
This warranty is exclusive; no other warranty, written or oral, is expressed or implied. This warranty is given by Spectrum to Buyer and to no other per-
son or legal entity. No Spectrum dealer, distributor, agent or employee is authorized to make any modifi cation or addition to this warranty.
NOTWITHSTANDING ANYTHING TO THE CONTRARY, SPECTRUM WILL NOT UNDER ANY CIRCUMSTANCES BE LIABLE FOR INDIRECT OR LIQUI-
DATED DAMAGES, INCLUDING CONSEQUENTIAL, INCIDENTAL AND SPECIAL DAMAGES. IN NO EVENT SHALL SPECTRUM’S LIABILITY, WHETHER
UNDER CONTRACT OR WARRANTY, IN TORT OR OTHERWISE, EXCEED THE PURCHASE PRICE RECEIVED BY SPECTRUM FOR THE PRODUCT AT
ISSUE AND “RECALL ACTION” EXPENSES. SPECTRUM SHALL NOT BE SUBJECT TO ANY OTHER OBLIGATIONS OR LIABILITIES, WHETHER ARIS-
ING OUT OF BREACH OF CONTRACT, WARRANTY, TORT (INCLUDING NEGLIGENCE AND STRICT LIABILITY) OR OTHER THEORIES OF LAW, WITH
RESPECT TO PRODUCTS SOLD OR SERVICES RENDERED BY SPECTRUM, OR ANY UNDERTAKINGS, ACTS OR OMISSIONS RELATING THERETO.
Our Customer Service Department is ready to provide immediate attention to any questions, comments or concerns. They are available to answer your calls
Monday through Friday from 7 am to 5 pm CST. In addition your product comments or concerns are welcome via e-mail at: [email protected].
Item Warranty Period
Adjustable Crank / Electric Desk Legs • 1 Year
Flat Panel Desk Gas Cylinders
Chairs
• Adjustable Height Chair Parts – including frames, gas
cylinders, wood and plastic parts, control handles, casters
• Adjustable Height Chair Upholstery
• In-Stock Upholstery
• Graded-In Fabrics and Customer Owned Material
• 7 Years
• 2 Years
• 2 Years
• No Warranty
Height Adjustable Columns and Lifts • 1 Year
General Use Casters
Electrical (including timers and LINAK actuators) • 2 Years
Keyboard / Mouse Trays • 1 Year
Flat Panel Monitor Arms
• Flat Panel Monitor Arm – General Parts
• Flat Panel Monitor Arm – Gas Cylinders
• 5 Years
• 2 Years
Desks and Lecterns
• Computer Desk Chassis
• Cart Chassis
• Lectern Chassis
• 10 Years
Warranty Table effective 1/1/2015
