Spectrum industries Starter 37372 User manual

Assembly InstructionsAssembly Instructions

ToolsTools

RequiredRequired

0192314 Page 1 of 5

Assembly InstructionsAssembly Instructions

Important

Before you begin, read and comply with all safety and operating instructions,

and ensure all parts and correct quantities are included.

Any parts damaged during shipment must be reported within 5 days of receipt.

To report information regarding missing parts or damage, to purchase parts

or accessories, or if you have any questions, please contact us.

www.spectrumfurniture.com

800-235-1262, 715-723-6750

Thank you for purchasing Spectrum products!

Acrylic Divider Panels forAcrylic Divider Panels for

Evolution Esports DeskEvolution Esports Desk

Starter - 37372Starter - 37372

Adder - 37373Adder - 37373

(2) 0159066

Side acrylic

divider 30”W

x 24”H

(2) 0159148

Bracket

(2) 0192262

Tape disk

.045” x 1.5” dia

Note: When multiple desks are attached together in

rows, the starter kit installs on the leftmost desk.

(1) 0159072

Rear acrylic

divider 44”W

x 24”H

(2) 0190174

#8 x 3/8”

PHSM

(1) 0159166

Bracket

(2) 0192262

Tape disk

.045” x 1.5” dia

(1) 0159150

Bracket

(1) 0159149

Bracket

37373 - Adder37372 - Starter

(4) 0101382

#14 x 7/8”

PHSM

(1) 0159066

Side acrylic

divider 30”W

x 24”H

(1) 0159072

Rear acrylic

divider 44”W

x 24”H

0192314 Page 2 of 5

Figure 1

Rear divider

1. Attach 0159148 bracket to worksurface1. Attach 0159148 bracket to worksurface

1. Attach the bracket to the left side of the worksurface with (2) #14 x

7/8” PHM screws as shown. Figure 1.

0159148

Bracket

(2) #14 x 7/8”

PHSM screws

Figure 2

2. Attach rear divider2. Attach rear divider

1. Loosen the (2) chair rail screws and pull the chair rail away from the

desk about 1/4”. Figure 2.

2. Set the rear divider notches over the chair rail screws in between the

chair rail and leg frames.

3. Retighten the chair rail screws to secure the divider. (Do not

overtighten screws.)

Worksurface

Figure 3

3. Attach left side divider3. Attach left side divider

1. Apply one tape disk to the left-side of the bracket. Press and hold to

the bracket for 30 seconds to secure. Figure 3.

2. Insert the left side divider tabs into the rear divider slots and push

down slightly to lock into place.

3. With the left side divider level with the worksurface, press and hold to

the tape for 30 seconds to secure.

Side divider

Tape disk

Press

here

Worksurface

0192314 Page 3 of 5

4. Attach divider at seam4. Attach divider at seam

Adder(s) and row of connected desks required - (skip to step 5 if no adders)Adder(s) and row of connected desks required - (skip to step 5 if no adders)

1. Locate the seam between two desks.

2. From under the worksurfaces, remove the existing unit-to-unit

bracket and (4) screws. Figure 4.1.

3. Place the 0159149 bracket against the worksurface with the bend

pointing downward, and re-install the unit-to-unit bracket with the

removed screws.

4. Attach the 0159150 bracket to the 0159149 bracket with (2) #8 x 3/8”

PHSM screws.

Figure 4.1

(1) 0159150

Bracket

(1) 0159149

Bracket

Existing

unit-to-unit

Bracket

(4) Existing

#14 x 7/8”

PHSM screws

(2) #8 x 3/8”

PHSM

Worksurface #1 Worksurface #2

Seam between

two desks

5. Apply one tape disk to the right side of the 0159150 and 0159166

brackets. Press and hold to each bracket for 30 seconds to secure.

Figure 4.2.

6. Insert the side divider tabs into the desk #2 rear divider slots and

push down slightly to lock into place.

7. With the side divider level with the worksurface, press and hold to the

0159150 bracket tape for 30 seconds to secure.

8. Install the 0159166 bracket into the upper rear divider slot of desk #1,

and press and hold to the side divider for 30 seconds to secure.

Note: Repeat this step for each additional desk using adder components.

Figure 4.2

Side divider

Tape disk

(1) 0159166

Bracket

Desk #1 Desk #2

(1) 0159150

Bracket

Press

here

Press

here

0192314 Page 4 of 5

Side divider

Press

here

Worksurface

Figure 5

6. Attach right side divider6. Attach right side divider

1. Insert the side divider tabs into the right rear divider slots and push

down slightly to lock into place. Figure 6.

2. With the side divider level with the worksurface, press and hold to the

tape for 30 seconds to secure.

Figure 6

5. Attach 0159148 bracket to worksurface5. Attach 0159148 bracket to worksurface

1. Attach the bracket to the right side of the worksurface with (2) #14 x

7/8” PHM screws as shown. Figure 5.

2. Apply one tape disk to the left side of the bracket. Press and hold to

the bracket for 30 seconds to secure

0159148

Bracket

(2) #14 x 7/8”

PHSM screws

Worksurface

Tape disk

7. Retighten chair rail screws7. Retighten chair rail screws

1. Retighten the chair rail screws to secure the divider.

(Do not overtighten screws.) Figure 7.

Chair rail

screws

Figure 7

Note: Do not ex or place excessive force on

the acrylic divider panels to avoid damage.

0192314 Page 5 of 5

925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM

Altuglas International03-30-20 Page 1 of 1

Cleaning Recommendations forPlexiglas® Acrylic Sheet

Altuglas International routinely provides information on CleaningPlexiglas®acrylic sheet and

the Chemical Resistance of Plexiglas®acrylic sheet to various chemicals. Altuglas

International does not provide any recommendation regarding disinfecting Plexiglas®

acrylic sheet.

Altuglas International recommends to CLEAN Plexiglas®acrylic sheet using soap and water.

Here is a link to our PLEXIGLAS® SHEET: Handling and Maintenance guidelines:

https://www.plexiglas.com/export/sites/plexiglas/.content/medias/downloads/plexiglas-expert-

pdf/Fabrication-Guidelines-Plexiglas-Handling-and-Maintenance.pdf

Wash Plexiglas® sheet with a mild soap or detergent and a lukewarm water solution. Use a clean

soft cloth or sponge and as much solution as possible. Rinse well. Dry by blotting with a damp

cloth or chamois.

Plexiglas®acrylic sheets have excellent CHEMICAL RESISTANCE to ammonia based and

chlorine based cleaners under ambient conditions for relatively short durations. Do not use

cleaners that containalcohol. The chemical resistance of Plexiglas® acrylic sheet will vary with

the stress level, temperature, reagent, duration of exposure and specific Plexiglas®acrylic sheet

used in the application. Altuglas International recommends that parts made from Plexiglas®

acrylic sheets be tested with all reagents under appropriate conditions for the end-use application.

Differences between Cleaning and Disinfectinga surface1.

Cleaningrefers to the removal of germs, dirt, and impurities from surfaces. Cleaning does not kill

germs, but by removing them, it lowers their numbers and the risk of spreading infection.

Disinfectingrefers to using chemicals to kill germs on surfaces. This process does not necessarily

clean dirty surfaces or remove germs, but by killing germs on a surface after cleaning, it can

further lower the risk of spreading infection.

1Cleaning and Disinfecting definitions copied from the CDC website: Clean & Disinfect; Interim Recommendations for US

Households with Suspected/Confirmed Coronavirus Disease2019

(https://www.cdc.gov/coronavirus/2019-ncov/prepare/cleaning-disinfection.html)March 24, 2020.Altuglas International has never

tested any procedure or productto disinfect Plexiglas® acrylic sheet and has not independently verified any information provided

on the CDC website.

The statements, technical information and recommendations contained herein are believed tobe accurate as ofthe date hereof. Sincethe

conditions and methods of use of the product and of the information referred toherein are beyond our control, Altuglas

International/Arkema expressly disclaims any and all liability as to any results obtained or arising from any use ofthe product or reliance

on such information; NO WARRANTY OFFITNESS FOR ANY PARTICULAR PURPOSE, WARRANTY OR MERCHANTABILITY

OR ANY OTHER WARRANTY EXPRESS OR IMPLIED, IS MADE CONCERNING THE GOODS DESCRIBED OR THE

INFORMATION PROVIDED HEREIN. The information provided herein relates only to the specific product designated and may not be

applicable when such product is used in combination with other materials or in any process. The user should thoroughly test any

application before commercialization. Nothing contained herein constitutes a licensetopractice under any patent and itshould notbe

construed as an inducement toinfringe any patent and the user is advised totake appropriate steps tobe surethat any proposed useofthe

product will not result in patent infringement.Plexiglas® isa registered trademark belonging toArkema.

Altuglas International – Sheet Division

Applications Development Lab

100 Route 413

Bristol, PA 19007
