Spectrum Industries EVOLUTION Desk 36 User manual

Assembly Instructions:
36 - 72 EVOLUTION DESK
SMALL PA RTS LIST
TOOLS REQUIRED FOR ASSEMBLY:
#2 phillip s screwdriver
1ATTACHING LEGS TO WORKSUR-
FACE
Before you begin, please make sure all p art s and proper quantities are included. Any parts damaged during shipment must be
reported within 15 days of receipt. To report information regarding damages or if you have any questions, please call 1-800-235-
1/4-20 X 1-3/4”
Pan Head Machine Screw
(4) #041289 (Silver)
1/4-20 x 2”
Flat Head Machine Screw
(2) #043771
(3) for 48”,60” & 72”
Desks
Glide Wrench
(1) #025069
Glide
5/16-18 x 1-5/8”
(4) #025068
Chair Rail Bracket
(1) #051024P
for 48”60 & 72” Only
Dual Unit-to-unit
Bracket
(1) 036281
Page 1 of 2 052519QR1
1/4-20 X 5/8”
Pan Head Machine Screw
(10) #026064 (Black)
(12) for 48”,60” & 72”
Desks
(per desk)
1600 Johnson St. P.O. Box 400 Chippewa Falls, WI 54729 Ph. 1-800-235-1262 Fax. [phone]
email [email protected] www.spectrumfurniture.com
A: Position legs, attach with
4 of the 1-3/4” silver screws
(do not tighten screws
completely at this point).
See Figure 1.
For 48”,60” & 72” desks only...
B: Attach chair rail bracket
with 2 of the 5/8” screws
(Tighten these screws).
FIGURE 1
This end of leg has
a connector inside.
Flip Top Section
Rear Unit to
Unit
Bracket
(1) #052463
Chair Rail Bracket for
48”, 60”,& 72” Desks
1/4-20 x 1-3/4” Screws
1/4-20 x 1-3/4” Screws
1/4-20 x 5/8” Screws

A: Stand desk upright. Attach chair rail
using 2 of the 2” flat head screws into
the connectors in back of legs (the
countersunk holes are down and out).
See FIGURE 3 & FIGURE 4.
For 48”,60” & 72” desks only...
B: Attach chair rail to chair rail bracket
with 1 - 2” flat head screw.
(Chair rail bracket may require adjustment
for proper alignment.)
C: Tighten screws.
4ATTACHING DESKS TOGETHER
A: The unit to unit brackets secure one desk
to another, the front side is attached using
4 of the 5/8” screws for the dual unit to
unit bracket. See FIGURE 5.
B. The rear attachment is done by backing out
the leg screw part way and sliding the
rear unit to unit bracket under the
screw head and tighten.
See FIGURE 6.
2ATTACHING MODESTY
PANEL/CORD CHANNEL TO LEGS
A: Attach Modesty Panel/
Cord Channel to back of legs
as shown in FIGURE 2
with 4 of the 5/8” screws.
B: Install glides in bottom of
leg at this point.
Tighten all screws now.
FIGURE 4
FIGURE 2
NOTE: If using chair rail
bracket, slide cord channel
over bracket, then attach to
legs.
Bracket will rest inside of
cord channel.
3ATTACHING CHAIR RAIL
Page 2 of 2 052519QR1
FIGURE 3
Modesty Panel/Cord Channel
FIGURE 5
FIGURE 6
1/4-20 x5/8” screws
1/4-20 x5/8” screws
1/4-20 x 2” screw
Loosen leg screws
Slide bracket under
screw heads,
Tighten.
