Spectrum Industries 55355 User manual

Owner’s Manual
0115923R5 Page 1 of 10
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 5 days of receipt. To report information regarding
missing parts or damage, to purchase parts or acces-
sories, or if you have any questions, please contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
Freedom One™Sit-to-Stand (S2S) Lectern
Unit-to-unit connector kit
55367
Freedom One Lectern
55368
Equipment rack
55366
55355
Freedom One Lectern
(Includes lectern, equipment rack,
and unit-to-unit connector kit)
55366 Equipment rack only
55367 Unit-to-unit connector kit
55368 Freedom One Lectern only
55355

THIS DRAWING IS THE PROPERTY OF SPECTRUM INDU
S
GENERAL AND IN DETAIL. IT SHALL NOT BE COPIED OR
PA
R
T
IE
S
W
I
T
H
O
U
T
T
H
E
EXP
R
ESS
E
D
W
R
I
T
T
E
N
C
O
N
SE
N
T
THIS DRAWING IS THE PROPERTY OF SPECTRUM INDU
S
GENERAL AND IN DETAIL. IT SHALL NOT BE COPIED OR
PA
R
T
IE
S
W
I
T
H
O
U
T
T
H
E
EXP
R
ESS
E
D
W
R
I
T
T
E
N
C
O
N
SE
N
T
(2) 0103500
2-1/2” plug
Unit-to-unit connector kit items - 55367
0115923R5 Page 2 of 10
• Read this owner’s manual before assembly or operation.
• Do not allow children to move the lectern.
• Proceed slowly and carefully when moving the lectern.
• For indoor use only. Do not install or store the lectern where it will be exposed
to moisture.
• Do not block the ventilation openings.
• Avoid uneven loading of the equipment into the lectern. Uneven weight
distribution could cause the lectern to tip when the lectern is moving.
• Do not allow anyone to sit, stand, or climb on the lectern.
• Use a damp, soft-cloth, or sponge, with mild soap or detergent solution to clean
dirty surfaces. Do not use harsh solvents or abrasives.
• This lectern is intended for institutional use. It does not have any user-
serviceable parts or user-maintenance requirements. If servicing is necessary,
please contact Spectrum Industries for assistance.
Electrical Safety:
• Do not plug the power cord into an extension cord.
• Inspect power cords for damage before each use. Do not use power cords
that are damaged.
• Unplug power cord from electrical outlet by gripping the cord. Do not unplug
the power cord by pulling only on the cord.
• Do not step on, drive over, drag, or place objects on the power cord.
• For added safety, plug the lectern into a grounded outlet controlled by a GFI
(Ground Fault Interrupter) circuit breaker.
• Electrical devices are not toys. Children are often unaware of the hazards
associated with electrical devices. This lectern must always be used by
adults or with adult supervision.
Warning - Relocating audio and/or video equipment to furniture not speci cally
designed to support audio and/or video equipment may result in death or
serious injury due to the furnishing collapsing or over turning onto a child.
Warning - Death or serious injury may occur when children climb on audio
and/or video equipment furniture. A remote control or toys placed on the
furnishing may encourage a child to climb on the furnishing and as a result the
furnishing may tip over on to the child.
(1) 0113795
long support tube
(1) 0113794
short support tube
(4) 052605
1/4-20 x 15mm JC bolt
(6) 038047
1/4-20 x 50mm JC bolt
Equipment rack items - 55366
stem casters
(2) 0113748 locking
(2) 0113749
(4) 0114470
3/8-16 x 5/8” bell glide
(1) equipment rack
Lectern items - 55368
(2) 0103500
2-1/2” plug
(4) 0114470
3/8-16 x 5/8” bell glide
CAUTION
In order to maintain normal operation, do not exceed 38 lb
(max) of additional weight on the adjustable worksurface.
When routing cords through the side grommets, be sure to
provide enough slack for the worksurface to fully operate
through its range of motion.
(1) 025039
4mm hex wrench
(8) 053310
1/4-20 x 40mm JC bolt
(1) Freedom One Lectern
Important Safety and Care Instructions

Equipment rack assembly / setup
Attach casters or glides
0115923R5 Page 3 of 10
1. Determine if you want casters or glides installed. Figure 1A.
Note: Because the equipment rack needs to be ipped
upside-down to install the casters/glides, Spectrum does
not recommend installing any rack-mount equipment until
the rack has been ipped back upright.
3. For a free-standing equipment rack, install all 4 casters or glides.
Figure 1B.
4. Flip the equipment rack back upright.
Figure 1B Figure 1C
3. If the equipment rack will connect to the Freedom One lectern,
determine which side of the lectern you plan to attach it. The side of
the rack you attach to the lectern will not need (2) casters or glides.
This side of the rack will be supported by the lectern. Figure 1C.
4. Proceed with the unit-to-unit connector kit assembly/setup
instructions on p.5.
(2) non-locking
casters on
audience-side
(2) locking
casters on
instructor side
audience-side audience-side
Free-standing equipment rack
Equipment rack
connected to lectern
Unit-to-unit connector
kit to be attached to
equipment rack and
Freedom One Lectern
(see p.5)
(1) locking
caster on
instructor side
(1) non-locking
caster on
audience-side
equipment
rack
equipment
rack
instructor
side
instructor
side
Figure 1A
Tools Required
11/16” wrench
(for casters)
1/2” wrench
(for glides)
caster glide
2. Carefully ip the equipment rack upside-down.

Figure 2B
locking caster on
instructor side
locking caster on
instructor side
place
blocking
here
place
blocking
here
0115923R5 Page 4 of 10
1. Carefully tip up one side of the lectern using blocking. Figure 2B.
2. Remove the two casters.
3. Install two glides.
4. Repeat this procedure for the remaining two glides.
5. Remove blocking.
Swapping casters for glides (optional)
Lectern assembly / setup
Figure 2C
cable
adjustment
nut
The worksurface extension speed can be adjusted with
the cable adjustment nut located on the release handle.
1. To adjust, tighten or loosen the nut 1/2 turn. Figure 2C.
2. Push down the worksurface, then pull the release handle to check
the worksurface extension speed.
3. Repeat this procedure until the desired extension speed is reached.
Column cylinder adjustment
release handle
Tools Required
11/16” wrench
(for casters)
1/2” wrench
(for glides)
Note: The Freedom One Lectern comes with factory-installed
casters. If a more permanent non-moving lectern is needed, the
casters can easily be replaced with the included glides. Figure 2A.
Figure 2A
caster glide

1. Determine which side of the lectern you want the equipment rack mounted to.
2. Lay the equipment rack down on the oor with the side opposite the lectern down.
Figure 3A shows assembly with the equipment rack on the left-side of the lectern.
3. Be sure two casters or glides are installed on the side of the equipment rack away from
the lectern (outside). See Figure 1C on p.3 for caster/glide installation.
4. Attach the short and long connector tubes with (4) 1/4-20 x 40mm JC bolts each.
Note: The tubes should be pointing upward as shown with the lectern mounting
holes facing away from the casters.
5. Tighten bolts securely.
Figure 3A
long connector tube
(this tube should be attached
with the 8 lectern mounting
holes on this side-facing away
from the casters and oor)
short connector tube
(this tube should be attached
with the 2 lectern mounting holes
facing away from the oor)
1/4-20 x 40mm
JC bolts
(4 per tube)
equipment rack
1. Attach connector kit to equipment rack
Note: The unit can be assembled with the
equipment rack on the left or right-side of
the lectern. These instructions show the
equipment rack assembled on the left-side.
locking caster on
instructor side
4mm hex wrench
(included)
Tools
Required
caster on
audience-side
left-side
right-side
0115923R5 Page 5 of 10
Unit-to-unit connector kit assembly / setup

Figure 3B
place blocking
here
equipment rack
6. Carefully lift and tip up the equipment rack. Be careful not to apply any side load to the
casters while tipping as it could cause damage. Figure 3B.
7. Place blocking under the equipment rack to support and level the assembly.
place blocking
here
these holes
should be
facing up
1. On the lectern, locate the existing lower support brace. Figure 3C.
2. Remove the (4) 1/4-20 x 15mm JC bolts from the lower tray.
3. Remove the (4) 1/4-20 x 50mm JC bolts from the lectern base to take off the support brace.
Note: This support brace is only needed if the lectern is free-standing and unattached to the equipment rack.
2. Remove existing lower support brace
remove the (4) 1/4-20
x 15mm JC bolts in
the lower tray
remove the (2)
1/4-20 x 50mm
JC bolts
remove the (2)
1/4-20 x 50mm
JC bolts
Figure 3C
lower support
brace
lectern base
4mm hex wrench
(included)
Tools
Required
0115923R5 Page 6 of 10

1. Move the lectern over the short and long connector tubes on the equipment rack. Figure 3D.
2. Remove the necessary hole plugs in the lectern base.
3. Align the lectern base mounting holes with the connector tubes.
4. Install (4) 1/4-20 x 15mm JC bolts through the lower tray to secure the long connector tube.
5. Install (6) 1/4-20 x 50mm JC bolts into the lectern base to secure to the connector tubes.
6. Tighten all fasteners securely.
short and long
connector tubes
remove hole plugs
here then install
(2) 1/4-20 x 50mm
JC bolts
Figure 3D
leave hole plugs in
any unused holes
(2) 1/4-20 x
50mm JC bolts
(4) 1/4-20 x 15mm JC
bolts in lower tray
Moving and parking the lectern
lectern base
(2) 1/4-20 x
50mm JC bolts
3. Attach lectern to equipment rack 4mm hex wrench
(included)
Tools
Required
0115923R5 Page 7 of 10
• Before moving, unplug all power cords.
• Close and lock equipment rack door(s).
• Remove any items from the top of the worksurface.
• Unlock the casters.
• Push slowly and carefully. Do not move over uneven or irregular surfaces.
• Do not allow children to move.
• Lock the casters after moving.
• Do not park unit in areas of heavy trafc.
• Do not run power cords across hallways, classrooms, or other areas where they will be walked on.
• Do not leave unit unattended in areas where children have access.
• Keep doors closed and locked whenever unit is unattended or parked.
• Keep casters locked whenever the unit is unattended.
brake lever
Caster operation
1. To lock the caster rotation, press the brake lever. Figure 4.
2. To resume rotation, lift up on the brake lever.
Monitor arms
If a monitor arm is to be used, attach to the equipment rack only.
Spectrum does not recommend attaching monitors to the adjustable
worksurface.
Figure 4

Figure 5B
audience-
side panel
lower
modesty
panel
plastic
stops
3/8”
lower lip
section view
worksurface
audience-
side panel
lectern base
4mm hex wrench
Tools
Required
0115923R5 Page 8 of 10
Lectern lower modesty panel adjustment
1. Push the worksurface down to the lowest position. Figure 5A.
2. Loosen the (7) 1/4-20 x 15mm JC bolts attaching the lower modesty panel to the base.
3. Slide the lower modesty panel toward the audience-side panel in the slots until it makes contact with the plastic stops, then pull
back slightly to create clearance (about 3/8” between the audience-side panel and stops). Figure 5B.
4. When the lower modesty panel is positioned correctly, retighten the (7) screws securely.
Note: If the modesty panels become misaligned and interference
occurs when extending or retracting, follow these steps to adjust.
Figure 5A
1/4-20 x 15mm
JC bolts
(7 required)
lower modesty
panel

0115923R5 Page 9 of 10
Accessories
Cove Power Module Kit
with mounting plate
9’ power cord, 2 AC outlets,
2 USB charge ports
7.5”W x 3.25”D x 4.25”H
99043
Flip-up Shelf
21.1875”W x 30”D
50 lb max capacity
(mounting plate not
available in silver)
68204
Clear Acrylic Locking Door
(can be mounted to be hinged
from the left or right-side)
available in black or silver sparkle
68153B
68153S
Solid Locking Door
(can be mounted to be hinged
from the left or right side)
available in black or silver sparkle
68152B
68152S
Keyboard Tray
22”W x 15.1875”D x 1.1875”H
(14 lb)
55356
Customized modesty panel with logo
for Freedom One Lectern
(must be specied when ordering to get panel
customized-contact Spectrum for details)
YOUR LOGO HERE
Note: Worksurface has predrilled holes to
simplify mounting. See capacity section
for worksurface weight info. (38 lb max
weight on adjustable worksurface)
Unit-to-unit connector kit
for connecting equipment rack to lectern
(available in black or silver sparkle)
55367
Not for use on a stand-
alone equipment racks
See spectrumfurniture.com for the latest
accessories and detailed warranty information.

0115923R5 Page 10 of 10
