SRC K-VS11-01-01-SL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
No. Description Quantity Torque * (N-m) Remarks **
1 Head Light Guard 1
2 Bracket RH 1
3 Bracket LH 1
4 Washer M5 12
5 Screw M5 x 6 8 5 - 6 Use Liquid Thread Locker
6 Screw M5 x 20 4 5 - 6 Use Liquid Thread Locker
SRC Design uses Metric System of Measurement and all dimensions are in Millimeters
* Recommended to use the Torque specified in the table
** Denotes Usage of Liquid Thread Locker in specified locations
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: K-VS11-01-01-SL / K-VS11-01-02
Part Description: Head Light Guard –KAWASAKI VERSYS650 ( 11 –14 )
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
Step 1:
The 2 off screws as shown in Red colour from
the mounting points, has to be removed from
Right-hand and Left-hand side, and kept
aside.
The Mounting points, will be used for
mounting the Bracket RH and LH with SRC’s
scope of Mounting fasteners, which will be
explained in subsequent steps.
Step 2:
Orient and Align the Bracket RH (2) and
Bracket LH (3), as shown in-line with the
Mounting points in the drawing.
Slip-in Washer M5 (4) –2 off on each side
and Screw M5 x 20 (6) –2 off on each side.

Copyright By SRC
Design and Specification are subjected to change
Page 4
Step 3:
Ensure Symmetry of Orientation of the
Bracket RH & LH and secure the threads in
the Mounting Points and tighten them to
torque, as per specifications in the BOM
table.
Step 4:
Orient and Align the Head Light Guard
(1), as shown, in-line with the 4 off
Mounting holes in the Bracket RH (2)
and Bracket LH (3) and Slide in the
Washer M5 (4) –4 off on each side and
Screw M5 x 6 (5) –4 off on each side.

Copyright By SRC
Design and Specification are subjected to change
Page 5
Step 5:
Ensure Mounting symmetry and tighten the screws to torque as per
specifications in the BOM table.
Final Mounted condition of the Head Light Guard, is as shown in the drawing
above.

Copyright By SRC
Design and Specification are subjected to change
Page 6
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and follow the step-by-
step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the Accessory part to the
Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part and
its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part. It
is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the first 50 kilo meters of ride and
at regular intervals.
7. To the maximum extent possible, our design use the current Mounting/Fitment of the Original
Equipment, so that Installation of these accessories will not affect the Payload or Function of the Vehicle or
the Part on which it is mounted to protect it
8. If any additional modifications are to be done, prior to the fitment of the accessories, it will be explicitly
specified in the instruction sheets
