SRC K-VS1000-07-01-SL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
No. Description Quantity Torque * (N-m) Remarks **
1 Bracket RH 1
2 End Adaptor 2
3 GPS Bar 1
4 Washer M8 2
5 Screw M8 x 16 2 9 - 10 Use Liquid Thread Locker
6 Bracket LH 1
SRC Design uses Metric System of Measurement and all dimensions are in Millimeters
* Recommended to use the Torque specified in the table
** Denotes Usage of Liquid Thread Locker in specified locations
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: K-VS1000-07-01-SL / K-VS1000-07-02
Part Description: GPS Bar –KAWASAKI VERSYS1000 2015-2018
Applicable to Stainless Steel & Steel Version
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
Step 1:
First step, while mounting the SRC-GPS Bar is to
remove the Wind-Shield screen, as shown.
The 2 sets of Screws/Washers and Nuts from each
side has to be removed and to be used for
mounting the brackets of the GPS Bar.
Step 2:
Orient and Align the Bracket RH (1) and Bracket LH (6), as
shown in the drawing and Slip-in the 2 sets of
Screws/Washers and Nuts, through the Mounting holes in
the side flap of the brackets, as shown.

Copyright By SRC
Design and Specification are subjected to change
Page 4
Step 3:
Secure the Nuts and tighten them fully and ensure
the brackets are seated squarely on the
Windshield brackets.
Step 4:
Mounting of the GPS Bar
The GPS Bar (3) has 2 Threaded
End Adaptors integral to it.
Slip in the Washer M8 (4) –1 off
from either sides, and Screw M8 x
16 (5) –1 off from either sides,
through the hole in the Brackets
and secure the threads to the End
Adaptor and tighten them to
torque as per specifications in the
BOM table.

Copyright By SRC
Design and Specification are subjected to change
Page 5
GPS Bar in Final Mounted condition is as shown above.

Copyright By SRC
Design and Specification are subjected to change
Page 6
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and follow the step-by-
step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the Accessory part to the
Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part and
its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part. It
is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the first 50 kilo meters of ride and
at regular intervals.
7. To the maximum extent possible, our design use the current Mounting/Fitment of the Original
Equipment, so that Installation of these accessories will not affect the Payload or Function of the Vehicle or
the Part on which it is mounted to protect it
8. If any additional modifications are to be done, prior to the fitment of the accessories, it will be explicitly
specified in the instruction sheets
