SRC T-S1200-14-01-SL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
NO. Description Quantity Torque * (N-M) Remarks ** Check List
4
4
4
9 - 10
1
1
1
1
2
3
4
5
6
Bottom Plate
Top Plate
Middle Plate
Use LiquidThread Locker
Nut M6
Spacer
SRCDesign uses MetricSystem of Measurement and all dimensions in Millimeters
*Recommended to use the Torque specified in the table
**Denotes Usage of Liquid Thread Locker in specified Locations
Countersink Screw M6 X 20
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: T-S1200-14-01-SL
Part Description: Large Side Stand –Triumph Scrambler 1200
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
Step 1:
During Mounting the Large Side
Stand, let the Motorbike firmly
rest on the floor, using the Centre
Stand.
The side stand can be brought
forward (position as shown in the
drawing) to have access to the
Mounting/ Assembly of the SRC
Large Side Stand.
Step 2:
Slide-in the Middle Plate (2), as
shown. Its inner walls, closely hugs
the outer walls of the Side stand.
Slide-in the Spacer (4), as shown and
orient the mounting holes in-line with
the 4 Projecting screws.
Orient and Align the Bottom Plate (3),
in-line with the Mounting holes of the
Middle Plate.
Slip-in the Countersink Screw M6 x 20
(5) –4 off, from the bottom side, as
shown.

Copyright By SRC
Design and Specification are subjected to change
Page 4
“As is Mounted condition “after
Insertion of the M6 Screws from the
Bottom side, and flushing the
countersink contours of the screws and
the Bottom plate.
Step 3:
Slide-in the Top Plate (1), as shown
and orient the mounting holes in-line
with the 4 Projecting screws.
Secure the threads on the screw using
M6 Nut (6), as shown.
As shown in the left, is the Final
Mounted condition of the Side Stand

Copyright By SRC
Design and Specification are subjected to change
Page 5
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and
follow the step-by-step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the
Accessory part to the Vehicle. We have prepared this based on our experience and
knowledge, related to the Vehicle, Part and its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s
accessory part. It is advised to the User, to inspect and ensure the original state of all other
Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour
and/or the stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will
help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all
functions of the Vehicle. It is always advised to check loosening of the fasteners after the first
50 kilo meters of ride and at regular intervals.
7. We are showing here the Scope of Supply/ Installation/Parts list & BOM from SRC
8. To the maximum extent possible, our design use the current Mounting/Fitment of the
Original Equipment, so that Installation of these accessories will not affect the Payload or
Function of the Vehicle or the Part on which it is mounted to protect it
9. If any additional modifications are to be done, prior to the fitment of the accessories, it
will be explicitly specified in the instruction sheets.
