SRC H-CRF450RL-04-02-AL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
NO. Description Quantity Torque * (N-M) Remarks **
1
2
2
1
1
1
2
8
1
4
4
8
2
5.5
1
1
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Top Rack
Rack RH
Rack LH
Support Top Rack
Bush 18 x 38
Countersunk Washer M8
OilTank 3 Liter
Plastic Knobs
Cap lock
Socket contersunk head Screw M5 x 15
Socket head cap Screw M5 x 15
Socket contersunk head Screw M8 x 25
Socket contersunk head Screw M8 x 60
Washer M5
Use LiquidThread Locker
5.5 Use LiquidThread Locker
23
23 Use LiquidThread Locker
Use LiquidThread Locker
Flank nut
Nut plate
SRCDesign uses MetricSystem of Measurement and all dimensions in Millimeters
*Recommended to use the Torque specified in the table
**Denotes Usage of Liquid Thread Locker in specified Locations
H
H
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: H-CRF300L-04-01-AL / H-CRF450RL-04-02-AL / H-CRF450RL-04-03-AL
Part Description Top Rack–HONDA CRF 450 RL
Applicable to Finished colour versions of Black
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
Step 1:
Before starting to mount the Top
Rack we can remove the original
screw in motorbike (as show)
Step 3:
Orient and Align the Top Rack (1), as shown, Slip-in the Bush Spacer 18 x 38 mm (5) –1
off between the Mounting hole front side and Slip-in Screw M8x 60 (14) –1off and
Taper Ring M8 (11) –1off , Slip-in Screw M8 x 25 (13) –1 off and Taper Ring M8 (11) –
1 off, and slip-in the screw M5 x 15 (12) - 4 off , washer M5 (16) - 4 off ,through the
holes and secure the threads.
Mounting Instruction

Copyright By SRC
Design and Specification are subjected to change
Page 3
Step 4:
Repeat the above step
for the other side to
secure the threads.

Copyright By SRC
Design and Specification are subjected to change
Page 4
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and follow the step-by-
step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the Accessory part to the
Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part and
its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part. It
is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the first 50 kilo meters of ride and
at regular intervals.
7. We are showing here the Scope of Supply/ Installation/Parts list & BOM from SRC
8. To the maximum extent possible, our design use the current Mounting/Fitment of the Original
Equipment, so that Installation of these accessories will not affect the Payload or Function of the Vehicle or
the Part on which it is mounted to protect it
9. If any additional modifications are to be done, prior to the fitment of the accessories, it will be
explicitly specified in the instruction sheets
