SRC H-X-ADV-07-01-AL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
No. Description Quantity Torque * (N-m) Remarks **
1 Mounting Bracket 1
2 GPS Bar 1
3 End Apaptor 2
4 Adaptor - Damper 2
5 Bottom Bracket 1
6 Washer M6 2
7 Screw M6 x 15 2 9 - 10 Use Liquid Thread Locker
8 Nut M6 2 9 - 10 Use Liquid Thread Locker
9 Washer M8 2 24
10 Screw M8 x 20 2 22 - 24 Use Liquid Thread Locker
SRC Design uses Metric System of Measurement and all dimensions are in Millimeters
* Recommended to use the Torque specified in the table
** Denotes Usage of Liquid Thread Locker in specified locations
End Adaptor is Welded and
Integral to the GPS Bar
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: H-X-ADV-07-01-AL / H-X-ADV-07-02-AL
Part Description: GPS Bar –HONDA X-ADV
Applicable to Stainless Steel & Steel Version
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
Step 1:
Remove the Windshield to enable access for fitting the Mounting Bracket (1).
From inside of the Acrylic mount, Insert Washer M6 (6) –2 off, Screw M6 x 15 (7) –2 off, through the mounting
holes, as shown above, and Orient and align the Mounting Bracket (1), in-line from the Front side and slip-in the
Nut M6 (8) –2 off and secure the threads and tighten it to torque, as specified in the BOM table.
Step 2:
The Bottom Bracket (5), is intended to
support the Acrylic Front mount, Stability
and Balance of weight.
Remove the 4 off Mounting Screws
(Original) and Orient and Align the Bottom
Bracket (5) and secure the threads in the 4
mounting points.

Copyright By SRC
Design and Specification are subjected to change
Page 4
After following Step 1 and Step
2, the As Is Mounted Condition,
is a shown in the drawing on the
left-hand side.
Step 3:
Orient and Align the GPS Bar (2) and
Slip-in the Washer M8 (9) and Screw
M8 x 20 (10) –1 off from either end,
and secure the threads on the End
Adaptor (3). The GPS Bar (2) and End
Adaptor (3) are Integral (Welded
together).

Copyright By SRC
Design and Specification are subjected to change
Page 5
Step 4:
Check the Orientation Symmetry and
ensure no fouling with other parts and
tighten the Screws of the GPS Bar, as
per specifications in the BOM table.
The final mounted condition of the GPS
Bar is as shown in the drawing on the
left-hand side.
The removed Windshield can be
mounted back in its position.
