SRC H-X-ADV17-01-01-SL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
No. Description Quantity Torque * (N-m) Remarks **
1 Head Light Guard 1
2 Mounting Plate 1
3 Grommet 6
4 Pin for Mounting 6
5 Bottom Plate 1
6 Adaptor for Rubber Mount 2
7 Rubber Mount 2
8 Washer M6 3
9 Washer M5 4
10 Screw M6 x 20 1 9-10 Use Liquid Thread Locker
11 Screw M5 x 10 4 5-6 Use Liquid Thread Locker
12 Nut M6 3 9-10 Use Liquid Thread Locker
13 Screw M6 x 16 2 9-10 Use Liquid Thread Locker
SRC Design uses Metric System of Measurement and all dimensions are in Millimeters
* Recommended to use the Torque specified in the table
** Denotes Usage of Liquid Thread Locker in specified locations
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: H-X-ADV17-01-01-SL / H-X-ADV17-01-02
Part Description: Head Light Guard –HONDA X-ADV
Applicable to Finished colour versions of Black and Silver
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
Step 1:
Step 1:
Orient and Align the Mounting
Plate (2), as shown in the
drawing, with the Top two
mounting holes in line with the
Mounting Holes in the
Motorbike (under the
Windshield bracket).
Slip-in the Washer M6 (8) –2
off, Screw M6 x 16 (13) –2 off
from the rear side and pass it
through the Mounting holes in
the Windshield bracket and
Mounting Plate and secure
using the M6 Nut (12) –2 off
and tighten it.
Step 2:
Orient the Bottom Plate (5), as
shown in the drawing, and slip-in
the M6 x 16 Screw (13) –1 off from
the Top side of the Motorbike
Bracket, and hold it from the
bottom side using Washer M6 (8) –
1 off and M6 Nut (12) –1 off and
tighten the threads.

Copyright By SRC
Design and Specification are subjected to change
Page 4
Step 3:
Mount/Fit the Pin for Mounting
(6) –4 off on the Mounting Plate
(2) and 2 off on the Bottom Plate
(5), as shown.
The Pins for Mounting Head Light
Guard, can be assembled Off-line
too.
Off-line Assembly of Washer M5
(9) –4 off, Screw M5 x 10 (11) –4
off, is done to secure the “Pin for
Mounting” (6) to the Mounting
Plate (2), as shown from the rear
side.
Similarly, Off-line Assembly of
Adaptor for Rubber mount (6) –2
off and Rubber Mount (7) –2 off,
is done to secure the 2 off Pin for
Mounting (6), at the lower side of
the Plate for Mounting (6).

Copyright By SRC
Design and Specification are subjected to change
Page 5
Final Mounted condition of Head
Light Guard, is as shown in the
drawing.
Step 4:
Orient the Head Light Guard (1), as shown. Assemble the Grommet (3) –6 off,
hugging and flush, with the outer surfaces of the Head Light Guard and holding
on to the Mounting Pins, projecting out of the Plate for Mounting / Lower
Plate, as shown in the drawing.

Copyright By SRC
Design and Specification are subjected to change
Page 6
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and follow the step-by-
step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the Accessory part to the
Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part and
its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part. It
is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the first 50 kilo meters of ride and
at regular intervals.
7. To the maximum extent possible, our design use the current Mounting/Fitment of the Original
Equipment, so that Installation of these accessories will not affect the Payload or Function of the Vehicle or
the Part on which it is mounted to protect it
8. If any additional modifications are to be done, prior to the fitment of the accessories, it will be explicitly
specified in the instruction sheets
