SRC R-HM18-01-01-SL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: R-HM18-01-01-SL / R-HM18-01-02
Part Description: Head Light Guard –Royal Enfield Himalayan LS410
Applicable to Finished colour versions of Black and Silver
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
Step 1:
The Head Light Guard uses the
Mounting Holes of the Wind
Shield Guard in the Motorbike
and we start mounting the
Bracket RH (2) as shown in the
drawing.
Before Mounting the Bracket RH
(2) and Bracket LH (5), assemble
the Mounting Pin (3) and Screw
M5 x 10 (9), Off-line.
Orient the Bracket RH and slide in
the Delrin (6) - 2 off, Washer M5
(7) - 2 off, and Screw M5 x 25 (8)
–2 off as shown and secure the
threads, but not tighten it fully.

Copyright By SRC
Design and Specification are subjected to change
Page 4
Bracket RH (2) in “As Is Mounted Condition”
Step 2:
Orient the Bracket LH (5) and slide in the Delrin (6) - 2 off,
Washer M5 (7) - 2 off, and Screw M5 x 25 (8) –2 off as
shown and secure the threads, but not tighten it fully.

Copyright By SRC
Design and Specification are subjected to change
Page 5
Bracket RH (5) in “As Is Mounted
Condition”
View Showing the “As Is Mounted
Condition of the Brackets

Copyright By SRC
Design and Specification are subjected to change
Page 6
Step 3:
Orient the Head Light Guard (1) and align it to
the Mounting Pin projecting out of the Brackets
and Slide in the Grommet (5) –2 off on each side
and held using the Mounting Pins

Copyright By SRC
Design and Specification are subjected to change
Page 7
Head Light Guard in “Final Mounted Condition”

Copyright By SRC
Design and Specification are subjected to change
Page 8
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and follow the step-by-
step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the Accessory part to the
Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part and
its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part. It
is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the first 50 kilo meters of ride and
at regular intervals.
7. To the maximum extent possible, our design use the current Mounting/Fitment of the Original
Equipment, so that Installation of these accessories will not affect the Payload or Function of the Vehicle or
the Part on which it is mounted to protect it
8. If any additional modifications are to be done, prior to the fitment of the accessories, it will be explicitly
specified in the instruction sheets
