TE35A
TE50A

OWNER’S MANUAL
CONTENTS
1. NOTE
2. PASSPORT DATA
3. LIMITED WARRANTY
4. SAFETY AND GENERAL INFORMATION
SAFETY
FORESEEN USE OF THE MACHINE
CORRECT USE OF THE MACHINE
PIECE CLAMPING]
TOOL FIXING
CHIPS DURING MACHINE
5. TEST REPORT
6. MAIN SPECIFICATIONS
7. TRANSPORT
8. INSPECTION
9. FOUNDATION DIAGRAM
10. CLEANING
11. GENERAL DESCRIPTION
12. FILLING WITH OIL
13. LUBRICATION
14. SPEED SELECTOR
15. AUTOMATIC TOOL EJECTOR
16. RETURN SPRING
17. TORQUE LIMITER
18. OPERATION PANEL
19. WIRING DIAGRAM
20. ELECTRICAL COMPONENTS
21. DRILL PROTECTION GUARD
22. MACHINE CARE AND MAINTENANCE
23. BASE
24. SPEED BOX
25. HEADSTOCK
26. FEED BOX

OWNER’S MANUAL
PASSPORT DATA
MODEL:
SERIAL NO.:
MANUAFACTURING YEAR:
MAIN EL. POWER:
NOTE
This manual has been prepared for the owner and operators of
this machine. Its purpose, aside from machine operation, is to
promote safety through the use of accepted correct operation
and maintenance procedures. Completely read the safety and
maintenance instructions before operation or serv
icing the
machine.
To obtain maximum life and efficiency form your
machine, and to aid in using the machine safety, read this
manual.
Since we continually strive to incorporate latest developments
in the construction of the machine, it is quite possible at time,
due to printing and shipping requirements, some data may not
correspond to the machine in the question。

OWNER’S MANUAL
LIMITED WARRANTY
We makes every effort to assure that our products meet high quality
and durability standards and warrants to the original retail
consumer/purchaser of our products that each product be free from
defects in materials and workmanship as follow: ONE YEAR LIMITED
WARRANTY ON ALL PRODUCTS UNLESS SPECIFIED OTHERWISE.
This warranty dose mot apply to defects due directly or indirectly to
misuse, abuse ,negligence or accidents, normal wear and tear or
alterations outside our facilities, or to a lack of maintenance.
We shall in no event be liable for death, injuries to persons of for
incidental, contingent, special, or consequential damages arising
from the use of our products.
To take advantage of this warranty, the product or part must be
returned to for examination, postage prepaid. Proof of purchase date
and an explanation of the complaint must accompany the
merchandise. If our inspection discloses a defect, we will either or
replace the product, or refund the purchases price if we cannot
readily and quickly provide a repair or replacement, if you are willing
to accept a refund. We will return repaired product or replacement at
our expense, but if it is determined there in no defect, or that the
defect resulted from causes not within the scope of our warranty,
then the user must bear the cost of storing and returning the product.

OWNER’S MANUAL
SAFETY AND GENERAL INFORMATION
1. SAFETY
A drilling machine, due to its purpose, is considered an “open
machine” Therefore, some safety measures have to be taken to
avoid accidents.
Bear in mind the following safety instructions:
The machine must always be operated for the purpose for which
was designed.
Do not ever stand under a hanging machine or nearby, when it is
been loaded for transportation.
Connect the machine to an exclusive electric connection, which
includes differential switch of protection. Plug in first the
green-yellow protection wire and then the others.
The piece must always be fastened with suitable devices. Do not
ever handhold the pieces.
Sharpened tools in good condition must always be used.
Appropriate tools must always be used, Do not ever adapt a tool
for a use for which it was not designed.
Use the correct speeds and feeds for the material being machined
as well as for the tool being used.
Use glasses to prevent small chips from getting in the eyes.
Insert the tools correctly in the tool holder cone.
Fix the piece fastening devices to the machine table.
Do not wear baggy clothes, loose gloves, etc, which can be
caught by the tool while drilling.
Keep the working place clean.
Gather the chips with suitable instruments (brush, gloves, etc.)
Before carrying out any operation which is not strictly drilling,
tapping etc. (like lubricating, changing of tools, etc,) turn the

OWNER’S MANUAL
main switch to the “0”position.
Before changing speeds, stop the machine and wait until all
moving elements are completely brought to a halt.
Do not ever leave the machine on without supervision. When
leaving the machine, check that the general switch is in the
“0”position and that moving elements are stopped.
Check periodically the correct operating of all security controls
and elements of the machine.
Before pressing the starting pushbutton, set the drill protector
guard in the working position.
Consider work area environment. Don’t use electric power driven
tools in damp or wet locations. Keep work area well lit. Don’t use
electric power tools in presence of flammable liquids or gases.
Keep children away.
Use only such accessories and attachments as are
recommended in the operating instructions or the catalogue for
the power tool concerned.
2. FORESEEN USE OF THE MACHINE
The drilling machine was designed to be used with specific tools and
for certain machining operations.
The most common machining operation is the drilling of holes with
helicoidal drills. The drilling of hole is carried out by the combination
of a drill turning movement and a feed movement in the turning
spindle direction.
Besides the helicoidal drill, other tools can be used to drill holes.
There is a great variety of drill types and shapes in the market which
can be used on this machine, provided that they are designed for
such a purpose and that can be fixed in the spindle taper. They will
usually be the Morse taper or ISO type. The drill shanks should have
the corresponding taper to the spindle in which they are to be fitted,

OWNER’S MANUAL
or parallel shank if they are going to be fitted by means of a tool
holder. Contact the tool manufacturer for any further information. Do
not ever use tools which were not designed to be used in a drilling
machine and that have been adapted.
A drilling machine can also perform other machining operations a
part from the drilling, such as tapping, reaming, chamfering, punch
marking, countersinking, spot facing, to perform such operations, it
is necessary to have appropriate tools, specially designed for this
sort of jobs. In the tapping case, besides using correct tool, the
machine has to be provided with such a device that verses the turning
direction of the tool when it reaches the depth previously fixed.
3. CORRECT USE OF THE MACHINE
Not exceeding its working capacity.
Operating the machine by qualified and trained staff and
according to the points mentioned in the instruction book.
Working under the safety systems provided with the machine,
checking them and keeping them.
Watching the safely measures mentioned in the instruction book
and notices on the machine.
Wearing clothes which provide personal as mentioned in the
instruction book.
Watching the safely measures which may affect work in the
machine and that can be lawfully expected, as well as those
demanded in the workshops.
4. PIECE CLAMPING.
Tangential cutting forces and axial forces in the feed direction of the
tool are mainly produced during the drilling process. The tangential
forces produce a moment of forces which make the piece being
drilled turn. Therefore, the pieces to be drilled (or to be machined by

OWNER’S MANUAL
one of the operations mentioned above) must be clamped in an
appropriate device such as a drill chuck and the drill chuck must be
correctly clamped to the machine table. For this reason the machine
tables are provided with “T”slots.
The pieces must be clamped conveniently by some clamping device.
The clamping devices in turn must be clamped to the machine table.
The machine table is provided with “T”slots for such purpose.
5. TOOL FIXING
The tools generally used in this machine will have parallel or taper
shanks. Drill holders are normally used to fix to the main spindle of
the machine the parallel shank tools. This fixing device is used for
small drill diameters (max. up to dia.16mm). Bigger diameter drills,
usually have taper shank of Morse taper (the ones of smaller
diameters to 16mm can have taper shanks).
The housing in the main spindle to insert the tool is of Morse taper
type. It is very important to insert the tool taper correctly in the main
spindle taper to avoid the tool falling from its housing when turning
and provoke and accident. The coupling system itself of the tool
male taper in the female taper of the main spindle is auto-locking,
but for it the surfaces of the tool taper and spindle taper must be in
contact. To get the best possible contact, the surfaces of the tool
taper as well as the spindle taper should be in good conditions.
Therefore, it is advisable to handle the tool as well as the spindle of
the machine carefully.
6. CHIPS DURING MACHINE
The machining process removes material from the piece. This
material is released in chips, which can be of different shapes
depending on the material itself. The most common ones are of three
types: fragmented chips in small bits, short helicoidal chips and long

OWNER’S MANUAL
helicoidal chips.
The chips fragmented in small bits can be rejected from the
machining area and can be dangerous if they reach the eyes of the
operator. To avoid this, it is advisable to wear safety glasses.
The long helicoidal chips tend to roll up the tool and gain
considerable volume before breaking, which is dangerous if they
reach the operator as they may produce injuries.
The reached volume may also displace the dill protector from its
security position, increasing the risk of an accident. It is advisable to
use chip breaking tools to machine materials which produce such
chips. For further information contact the tool manufacturer.

OWNER’S MANUAL
TEST REPORT
No. Checking items Inspection item Tolerance Data
G1 Flatness of table and
base
0.12
G2 Spindle taper run out
a. At the end of spindle
nose
b. At the end of
200mm test bar
a.0.03
b.0.06
G3 Verticality of spindle
center line to table
a. Transverse direction
b. Longitudinal
direction
a.0.10/300
(α≤90°)
b.0.10/300
G4 Verticality of spindle
sleeve vertical travel to
table
a. Transverse direction
a.0.10/150
(α≤90°)
b.0.10/150

OWNER’S MANUAL
MAIN SPECIFICATIONS
b. Longitudinal
direction
Max.drilling capacity 40 mm
Threading in steel & last iron 22/24 mm
Distance spindle center to column surface 350 mm
Max.distance spindle nose to worktable 770 mm
Distance spindle nose to base 1320 mm
Spindle taper MT4
Spindle travel 180 mm
Spindle power feed range 0.1mm 0.2mm
Spindle speeds range（option）
50-1450 rpm
Worktable size 560×560 mm
Dimensions of base 735×510mm
Width of T-slot 18mm
Distance of T-slot of working table 125mm
Distance of T-slot of base 100mm
Cooling pump 75W
Motor
1.5kW
Packing size(L×W×H)mm 2270×690×1100mm
N.W/G.W 540/600Kg

OWNER’S MANUAL
Transport
Insert an iron bar through the transversal hole in the machine head
which with the aid of a rope, will be used for lifting the machine.

OWNER’S MANUAL
INSPECTION
The machine should be carefully examined on arrival, to check that it
is complete and in good order, so that claims can be made , if
necessary.
FOUNDATION DIAGRAM
CLEANING
Remove all anti-rust compounds. Clean and lubricate all movable

OWNER’S MANUAL
parts.
GENERAL DESCRIPTION
1. driving motor
2. speed plate
3. speed selectors
4. operation panel
6. oil draining plug
7. oil level window
8. rapid manual feed
control
9. oil filling opening
10. deep stop
11. oil level window
12. oil draining plug

OWNER’S MANUAL
13. oil pump control
sight gage
14. oil filling opening
15. spiral spring housing
16. tool ejector
17. feed selector
FILLING WITH OIL
4.5L 0.5L Empty
The speed box incorporates an oil
pump to lubricate the gears.
Attention! The machine is supplied
without oil for transport reasons.
Please, follow the following
instructions for filling the machine with
oil:

OWNER’S MANUAL
Remove upper plug Fill oil by using a funnel. Stop filling oil when
oil level reaches the red mark on level window. This red mark
must be never exceeded; as otherwise, the oil will overflow out
the machine.
If this occurs, remove plug and drain oil until oil level goes down
to red mark on level window.
LUBRICATION
A Quill spindle daily lubricate with oil the greaser located next the
spiral spring cover.
B Quill gearing shaft daily lubricate with oil the lubrication port on
the spiral spring cover.
C Quill Clean and lubricate with grease the rack for upward and
downward displacement of quill-spindle.
D Column Clean and grease with oil every 50 hours.
E Speed box Fill the box with oil until reaching the indicated level.
Change oil every 2000 hours.
F Feed box Fill the box with oil until reaching the indicated level.
Change oil every 2000 hours.
G Rack clean and lubricate with grease every 50 hours.
H Table daily lubricates with oil the two lubrication points.
SPEED SELECTOR
By means of levers spindle speeds are selected. Right lever
selects a spindle speed value. For moving these levers, slightly
pull them and the rotate.
Feeds selector
To select the feed speed, turn the side selector until the required
point(value).
AUTOMATIC TOOL EJECTOR

OWNER’S MANUAL
To remove tool from the spindle, perform the following
operations:
1. Lower the spindle from the reels a little bit and introduce the
extractor bolt.
2. Raise the spindle from the reels.
3. Hold the tool with the hand when raising the spindle or it will
fall on to the table
ATTENTION: Do not leave the extractor bolt introduced.
RETURN SPRING
To tauten the return spring in model extract the quill until the
teeth of the working gear can move freely. Then move the reels in
the arrow direction and introduce the quill again.
Unfasten the screws in the plastic cover and turn this cover in
positive direction, once it is tautened, fasten the screws again.
AUTOMATIC FEED
Models incorporate mechanical automatic feed.
The way to proceed is the following:
1.-Regulate the stroke at the depth top.
2.-Select the feed
3.-Place the lever of the automatic feed.
At the end of the stroke, the depth top displaces the lever of the
automatic feed.
The lever can also be displaced manually.
TORQUE LIMITER
The gearbox is fitted with a stopping device which works in the
event of overload.
If the feed stops during drilling and the tool continue to revolve, it
is a sign that it is overloaded.

OWNER’S MANUAL
When the load is reduced, the feed starts up again.
If for any reason, such as due to wear of the limiter discs or the
need for a higher working load, it is required to readjust it, we
recommend the following action.
---From the inspection hole and guided by the limiter assembly
shown on FEEDBOX tighten the nut (No.10)
This mechanism has been adjusted in our works, by measuring
the maximum admissible axial load, with a tens meter. Therefore,
do not tighten the nut too much, so as to avoid risk of breaking
the mechanism.
OPERATION PANEL

OWNER’S MANUAL
WIRING DIAGRAM

OWNER’S MANUAL
ELECTRICAL COMPONENTS LIST
Code Name Model Specification Qty
QF1 Circuit breaker 3VU13400MJ00 2.5-4A
QF2 Circuit breaker DZ47-60 D1 2P
QF3 Circuit breaker DZ47-60 C3 1P 1
KM1-2 Contactor 3TB41-22 Coil voltage 24V 1
KM3 Relay 3TH8031 Coil voltage 24V 1
SA1 Main switch JCH13-20/3 1
SA2 Switch LW8PS-20 1
SA3,SA4 Knob switch LAY3-11X/2 Black 2
SA5 Knob switch BJA-D2B22S Black 1
SB1 Mushroom button LA38-11MXS/209B Red 1
SB2(HL1) Stop Button + pilot lamp BJA-ER0124L Red 1
SB3(HL2) Start button + pilot lamp BJA-ER0124L Green 1
SB4 Return button BJA-AY11 Yellow 1
KA Relay 3TH8031 AC24V 1
SQ1,2 Top, bottom Limit switch LWW5-11N1 2
SQ3 Chuck cover switch LXW16-5/1C2 1
TC Transformer JBK5-63 1
EL Working lamp SC-108E 24V,35W 1
M1 Main motor YD100L-8/4 0.85/1.5KW 1
M2 Coolant pump DB12 1
