SWorkz ZEUS II User manual

2
INSTRUCTION
Congratulations on your purchase of the new SWORKz 1/8th scale ZEUS II o󰀨-road Monster
Truck Pro Kit.
The ZEUS II project is the result of SWORKz passion for improvement. Combining every detail
into a more balanced and improved truck called the "ZEUS II".
The ZEUS II EP Truck incorporates many of the race-inspired features from the S35-T2E and
S35-4E Pro Kits. This Truck provides precise feedback, a nimble and balance feel that will suit
drivers of all levels. The SWORKz design team put their e󰀨orts into proper weight distribution
for the ZEUS II EP Monster Truck. Proper weight distribution proved to be instrumental to the
setup during the testing phase of the ZEUS II EP Monster Truck..
The SWORKz ZEUS II EP Monster Truck comes standard with many high quality parts like a
T7075 aluminum chassis (same S35-4E chassis hard coating process), front and rear shock
towers. It also has S35-T2E Pro Kit's 16mm BBS Racing Shocks, High Performance Crown and
Pinion Gears and oil lled di󰀨erentials provide traction and balance to the truck on di󰀨erent
o󰀨-road surfaces.
The ZEUS II EP Monster Truck uses the S35-T2e newly designed center Motor mount that
makes it possible to easily change the motor or adjust the free play of the gears.
The pivot ball steering system gives the driver sharp and accurate turning feedbacks. The
ZEUS II EP Monster Truck comes with a race inspired base set up that is easy to drive.
1. Quality T7075 Aluminum Main Chassis.
2. Quality T7075 Front and Rear Shock Towers.
3. SWORKz S35-T2e BBS Race Shock System.
4. High Performance CNC machined Crown Gears and Pinion Gears.
5. F/R Full CVA Drive Shafts.
6. Aluminum rear toe in plate is included (SW-330266).
7. Aluminum Adjustable Front and Rear Lower Plastic Insert Toe-In system.
8. Double Protection Bumper Design.
9. Sealed Front and Rear Arms design.
10. Adjustable Front Upper and Lower Suspension Arm System.
11. ZEUS Speed Rhinocero III Pre-Cut EP Body Shell is included.
ZEUS II Kit Features:

3
WARRANTY
Your SWORKz ZEUS II kit warranty covers workmanship and manufacturing
defects of the original and unmodified parts. Warranty claims resulting from
crashes, abuse, improper operation, improper mounting, improper adjustment or
lack of maintenance will not be honored.
Contact your local hobby shop or SWORKz distributor for all claims and
questions. Claims must be well documented. All Claims are subject to expert
examination approval by SWORKz.
Specification
Length: 530mm
Width: 410mm
Height: 230mm
Ground Clearance: 75mm
Wheelbase: 325-330mm
Track: F:355mm / R:355mm
Gear Ratio: C:45-47/15T, F/R 46/10T
Weight: 4470g (Full Equipment)

4
INDEX
This radio controlled racing car is not a toy!
This high-performance R/C model is recommended for ages 14 and older.
INSTRUCTION 2
Warranty 3
Required Equipment for Operation 5
Operation Guide 6
Assembly Steps 7-33
ZEUS II Key No. List 34
ZEUS II Spare Part List 34-35
ZEUS II Option Part List 35
End cover 36

5
Charger and LiPo Battery
Double-sided tape
Paint
Long nose pliers
Modeling knife
Instant cement Thread lock
Included items
Hex wrench
1.5mm
2mm
2.5mm
1.5mm
2mm
2.5mm
Glow plug wrench
Screwdriver
Screwdriver
Radio Gear
Stick Type
ESC system
Wheel & Trigger Type
Receiver
Steering servo
Tools Recommended
Breshless Motor
Side cutter
Curved scissors
Grease
Required Equipment for Operation

6
overturn
Assemble for
4 sets
Assemble for
2 sets
Assemble both left
and right sides
Assemble in the
specied order
Assemble front
and rear
Thread Locking
Compound
Grease Pure Silicone Oil Air lter oil
Operation Guide
Safety Precautions
The SWORKz ZEUS II is a high performance radio controlled model which needs to be
operated with caution and common sense.
The ZEUS II Pro Kit is not intended for children under the age of 14 without adult supervision.
SWORKz shall not be held liable for any loss or damages, whether direct, indirect, act of
nature, arising from the abuse or misuse of this product or any other product required while
operating this model.
- The LiPO Battery can be dangerous is improperly handled.
- Always keep your LiPO Battery in a cool area and never use near flame, sparks, or while
smoking.
- Keep your LiPO Battery, and all other ammables, out of the reach of children.
- After running your car, all parts of the Motor and ESC can become extremely hot. Be careful
not to touch these parts.
- This model is controlled by your radio and that is vulnerable to interference from many
outside sources. This interference can cause a loss of control so it is necessary to operate this
model in an open area to avoid personal, or property damage. Always ensure turning on your
radio rst.
- Keep all the products included in the package out of reach of children.

7
BAG B1
2
330014A
116006R
330015
320003 400002
320004
101004
101004
320004
101004
101004
610002P
210002A
116006R
330502A
330015
320003
400002
330015
Pin M2.2x9.9mm x4
400002
O-ring S5 4.8X1.5 x4
101004
Washer 3.5X10X0.2mm x8
330013
Bevel Gear Shaft x4
Fill the differentials
with oil up to 80%
above the satellite
gears.
Put the SWORKz
Di󰀨. Oil 7000cps
for the front Di󰀨.
and 3000cps for the
rear Di󰀨.
Remember to apply a light coat
of grease to the o-ring, then
slide it over the shaft of the out
drive and seat it in the di󰀨 case.
Insert the pin through the hole
in the di󰀨 case and through the
hole in the shaft of the out drive.
330013
OK! NG!
108003
108003
330014A
108003
M3x10mm FH/ST HEX Screw x4
116006R
Ball Bearing 8x16x5mm (Red Rubber Case) x4

8
4
3
BAG C
108003
320004 330013
610002P
108003
101004
101004
108007
108007
101004
101004
2501469-01 (45T)
2501469-02 (46T)
2501469-03 (47T)
Fill the
di󰀨erentials
with Oil up to
80% full.
Use SWORKz
Di󰀨. Oil
7000cps for
the center
Di󰀨.
320004
116006R
330017
320003 400002
330015 210002A
116006R
330017
330241
330015
320003
400002
Apply a light coat of grease
to the o-ring, then slide it over
the outdrive shaft and place it
in the di󰀨 case.
Insert the pin through the hole
of the out drive.
108003
M3x10mm FH/ST HEX Screw x4
330015
Pin M2.2x9.9mm x2
400002
O-ring S5 4.8X1.5 x2
101004
Washer 3.5X10X0.2mm x4
330013
Bevel Gear Shaft x2
108007
M3x6mm FH/ST HEX Screw x4
116006R
Ball Bearing 8x16x5mm (Red Rubber Case) x2

9
5
BAG D
116006R
116006R
104010
330501A
2501114
2501114
2501529
108001 330227
108001
2501096
2501114
108001
M3x12mm FH/ST HEX Screw x4
101018
SHIM 13x16x0.2mm
101018
x3
106010
Please use the SHIM 13x16x0.2mm
to adjust when the play was bigger
between the crown gear and pinion
gear.
108001
106010
M3x6mm Hex Socket OH/TP Screw x3
106012
M3x35mmHex Soket OH/TP Screw x2
104010
M5x4mm Set Screw (Flat Bottom) x1
116006R
Ball Bearing 8x16x5mm (Red Rubber Case) x2

10
6
7
BAG E1
116006R
116006R
Please use the SHIM 13x16x0.2mm
to adjust when the play was bigger
between the crown gear and pinion
gear.
106008
106008
101018
SHIM 13x16x0.2mm x3
108001
101018
104010
330501A
330830
330227
106010
2501529
2501114
2501121C
330136
106005
106021A
330134
108019
2502037B
2502037B
Left
104010
M5x4mm Set Screw (Flat Bottom) x1
106021A
M4x10mm Hex Socket OH/TP Screw X2
106008
M3x12mm Hex Socket OH/TP Screw x2
108001
M3x12mm FH/ST HEX Screw x2
116006R
Ball Bearing 8x16x5mm (Red Rubber Case) x2
106005
M3x15mm Hex Socket OH/TP Screw x2
108019
M2.6x6mm FH/ST HEX Screw x10

11
8
9
330831
2503260-24.25
2.0mm
330103
Front/Rear Lower Arm HingPin x2
Use a 2mm Hex Wrench and
slowly tighten the Hinge Pins.
108008
108008
M3x35mm FH/ST HEX Screw x2
101020A
3mm Countersunk x2
Washers (GM)
101020A
2503260-24.25
2501100
2501100
330103
2501114
104004
104004
115008
104004
M3x3mm Set Screw x2
Pop in the Stabilizer Guide.
After assembly ensure that both
suspension arms move freely.

12
11
10
104005
104005
105004
104005
M3x4mm Set Screw x2
105004
M2.6x6mm Cap Screw x2
103001
103001
340037
2501096
103001
M3 Nut Lock x2
108003
108003
108003
M3x10mm FH/ST HEX Screw x4

13
12
13
BAG E1
330119
2501099
2501100
108001
M3x12mm FH/ST HEX Screw x4
330119
Front Upper Arm HingPin x2
106002
106002
108001
2501100
106002
M3x10 mm Hex Socket OH/TP Screw x2
2502040-02
2502039B
330815A
2502039B
2501099
330119
2501099
2501099
106005
M3x15mm Hex Socket OH/TP Screw x2
108019
M2.6x6mm FH/ST HEX Screw x12
106021A
2502038B
106005
330136
2501121C
330134
108019
2502038B
106021A
M4x10mm Hex Socket OH/TP Screw X2

14
15
14
2502040-02
108001
108001
330816A
106002
106002
M3x10mm Hex Socket OH/TP Screw x1
330103
330103
108008
2501100
2501100
330266
2502036
2502036
2501099
2501099
330103
Front/Rear Lower Arm HingPin x2
108008
M3x35mm FH/ST HEX Screw x2
Cut away the plastic part as in picture
108001
M3x12mm FH/ST HEX Screw x2
The new rear changeable plastic lower arm plate with 2 inserts can o󰀨er
2.0, 3.0 and 3.5 rear toe-in for your rear lower suspension.
2502036 Rear Changeable Lower Arm Plate
Insert (2.0/3.5 Degree)
2502036 Rear Changeable Lower Arm Plate
Insert (3.0 Degree)
The rear lower arm holder
insert can o󰀨er 1.0, 2.0 and
3.0 rear kick-up for your rear
lower suspension.
2501099 R/F Insert (1 degree)
2501099 R/F Insert (0 degree)

15
16
17
104004
104004
105005
104004
M3x3mm Set Screw x2
104005
104005
105004
104005
M3x4mm Set Screw x2
2501114
Pop in the Stabilizer Guide.
105004
M2.6x6mm Cap Screw x2

16
19
BAG E2 18
116004R
101019
116004R
101019
SHIM 6.0x10.0x0.2mm x1
330113
103001
103001
117003
330251
101021
106007
117003
330251
101021
106007
330135A
115004
116004R
330114A
2501122A
2501667-5
2501122B
116004R
338109
103001
M3 Nut Lock x2
101021
M3x8xT1mm x2
106007
M3x12mm Hex Socket OH/TP Screw(HT) x2
106002
M3x10mm Hex Socket OH/TP Screw x2
106002
116004R
Ball Bearing 6x10x3mm (Red Rubber Case) x2
116004R
Ball Bearing 6x10x3mm (Red Rubber Case) x2

17
20
21
BAG E3
2501100
2501098A
2501098A
2501100
330118A
340035
340035
330118A
330252
330252
Screw and adjust 330118 Knuckle
Pivot Ball Nut so as the pivot ball can
be moved smoothly.
Left
Right
330110
330112
330111
330552
116012
116006R
330124
104010
330121A
330111
Pin M2.5x14.8mm x2
116012
Ball Bearing 15x21x4mm x2
330124
Pin M3.0x16.8mm x2
104010
M5x4mm Set Screw (Flat Bottom) x2
106002
106002
M3x10mm Hex Socket OH/TP Screw x4
116006R
Ball Bearing 8x16x5mm (Red Rubber Case) x2

18
23
22
330121A
330110
330552
330111
116012
330112
116006R
2501095A
2501095A
330124
104010
330111
Pin M2.5x14.8mm x2
116012
Ball Bearing 15x21x4mm x2
Left
Right
330124
Pin M3.0x16.8mm x2
330117A
330117A
Knuckle Pivot Ball Washer x2
104010
M5x4mm Set Screw (Flat Bottom) x2
116006R
Ball Bearing 8x16x5mm (Red Rubber Case) x2

19
24
25
48.1 mm
330401
103001 2501100(3mm)
330401
Rear Hub Carriers Hing Pin with Nut x2
103001
M3 Nut Lock x2
2501100(1mm)
338070B
330125
2501121C
2501121C
330458
330458
S350T Rear Upper Arm Turnbuckle M5x72mm x2

20
26
27
103001
M3 Nut Lock x4
106008
M3x12mm Hex Soket OH/TP Screw x4
106002
105011
103001
105011
M3x23mm Cap Screw x2
106002
M3x10mm Hex Socket OH/TP Screw x2
106008
106003
103001
103001
2501097
2501097
2501097
2501097
2501097
103001
106008
