Tanco 404 S Service manual

Tanco Autowrap 404 S/M
Operator’s manual
1
TANCO AUTOWRAP
404 S/M MINI BALE WRAPPER
OPERATORS HANDBOOK
WD03-404 S/M
MODELS:
• 404 M – Linkage mounted with cut and start, tipping facility and manual control
• 404 S -- Linkage mounted without cut and start or tipping facility

2
Tanco Autowrap 404 S/M
Operator’s manual
GUARANTEE
Subject to hereunder provided, the sellers undertake to correct either by repair or at their election by replacement
any defect of material or workmanship which occurs in any of its goods within twelve months after delivery of
such goods to first user, with the exception of contractors or commercial users when warranty period is six
months.
In respect of Autowraps the warranty period is for 12 months or 8000 bales, whichever occurs first.
The term goods when used in this document means the article or articles described in invoices as sold by the
sellers but dose not include equipment or proprietary parts or accessories not manufactured by the sellers. The
sellers, however, undertake to pass on so far as they legally can to the first user the benefit of any warranty given
to the sellers by the suppliers of such equipment, parts or accessories.
This understanding shall not apply to:-
(a) Any goods that have been sold by the first user.
(b) Any goods which have been injured by unfair wear and tear, neglect or improper use.
(c) Any goods the identification marks of which have been altered or removed.
(d) Any goods that have not received the basic normal maintenance such as tightening of bolts, nuts,
tines, hose connections and fittings and normal lubrication with the recommended lubricant.
(e) The use of any product on tractors exceeding the recommended horsepower.
(f) Any goods that have been altered or repaired other that on instruction or with the written approval of
the seller or to which any part not manufactured or having written approval by the sellers have been
fixed.
(g) Any second-hand goods or parts thereof.
Any allegedly defective part or parts returned to the seller must be sent carriage paid. No claim for repair or
replacement will be entertained unless upon discovery of the alleged defect written notification is sent to the
Sellers giving, at the same time, the name of the Buyer from whom the goods were purchased and the date of
purchase, together with the full details of the alleged defect and the circumstances involved, also the serial number
of the machine etc.
The sellers shall be under no liability to their Buyers and first or subsequent users of their goods or to any other
person or persons for loss or damage howsoever arising in respect of either personal injuries or for arising out of,
or in any other way connected with or arising from the manufactures sale, handling, repair, maintenance,
replacement or use of its goods or the failure or malfunction of any of its goods.
Representation and/or warranties made by any persons (including Buyers and employees and other representatives
of the Seller) which are inconsistent or conflicting with these conditions are not binding upon the sellers unless
given in writing and signed by a director of sales.
CLAIMS
If you wish to make a claim under the guarantee:
1: Immediately, stop using the machine.
2: Photocopy and fill out the warranty claim form attached to the back of this manual.
List the details of the machine, its serial number and the part number of the damaged
part.
3: Consult with your Tanco dealer (supplier) and have him forward your claim and the
damaged item to Tanco.

3
Tanco Autowrap 404 S/M
Operator’s manual
USER’S MANUAL
MINI WRAP 404 S/M
CHAP. CONTENTS PAGE
1.0 INTRODUCTION 4-5
2.0 SAFETY PRECAUTIONS 6-7
3.0 GENERAL INFORMATION ON BALE WRAPPING 8-9
4.0 SETTING UP / MOUNTING OF THE MACHINE 10
5.0 MOUNTING OF PLASTIC FILM 11-12
6.0 ADJUSTMENTS I USE 13
7.0 OPERATING INSTRUCTION 14
8.0 CONTROLLER MANUAL 15-23
9.0 PERIODIC MAINTENANCE 24
10.0 CHECK POINTS BEFORE TROUBLESHOOTING 25
11.0 TROUBLE SHOOTING 26-27
12.0 HYDRAULIC CHART 27-28
13.0 OPEN AND CLOSED CENTRE CONVENSION 29
14.0 WARRANTY CLAIM FORM 30
15.0 DECLARATION OF CONFORMITY 31

4
Tanco Autowrap 404 S/M
Operator’s manual
Fig 1.- 404 S/M Model
1. Roller
2. Support Roller
3. Tipping Frame
4. Film Dispenser
5. Cut & Start
6. Control Valve

5
Tanco Autowrap 404 S/M
Operator’s manual
1.0 INTRODUCTION.
TANCO AUTOWRAP Ltd. congratulates you with the choice of MINI WRAP bale wrapping
machine. We are certain you will be satisfied with the machine, and that you will have the
pleasure of your investment for many years.
MINI WRAP 404 S/M is hydraulically driven by the tractors hydraulic system, and is easy to
operate with Autostop function and RDS wrap controller.
The MINI WRAP 404 S/M is designed to be a simple and effective bale wrapping machine square
bales.
MINI WRAP 404S/M is estimated for wrapping bales of grass, hay or straw, it can handle bales
from 35cm x 45cm up to 50cm x 50cm. The bales must have a weight of at least 35kg.
This manual is meant to explain how MINI WRAP is prepared, mounted, used and how it works,
and shall together with the spare part’s list be a reference for maintenance and troubleshooting.
So take good care of the books, they are a part of the machine.
Read carefully through this manual, and specially chapter 2.0, safety instructions, before starting
the machine, and follow the instructions thoroughly. If problems should occur, please contact
your MINIWRAP dealer. Ask your dealer for advice before you make the problem worse than it
is. See also chapter 14.0, Warranty claim forms.
Technical Specifications MINI WRAP 404 S/M
Height in working position
Width
Length
Weight
Turntable speed, recommended
Turntable speed, max.
Bale size, max.
Bale weight, min
Pre-stretcher
Hydraulic connection
Oil pressure / amount, mm.
Oil amount, max.
Counter pressure, max.
930 mm
1640 mm
3200 mm
625 kg
22 rev, per minute
27 rev, per minute
500 x 500 x 1150 mm
35kg
500 mm
I single spool outlet + free return
100 bar / 15 liter per minute
30 liter per minute
10 bar
TANCO AUTOWRAP Ltd can change the construction and/or technical specifications without
warning and without rights to changes on already delivered products.
© Copyright. All rights reserved. Any copying and reproduction of this manual is not permitted
without permission from TANCO AUTOWRAP Ltd

6
Tanco Autowrap 404 S/M
Operator’s manual
2.0 SAFETY PRECAUTIONS.
TANCO AUTOWRAP Ltd does not take the responsibility for damages that may occur on
machine, persons or other equipment, because of the machine NOT being used as described in
this manual, or because of the safety precautions NOT being followed.
2.1 SAFETY EQUIPMENT.
Before using the machine, make sure that all guards and covers are securely fitted. The machine
must not be operated if a function does not work as described later in this manual. (See chapter
2.5).
2.2 BECOME FAMILIAR WITH THE OPERATIONS OF THE MACHINE.
If you are unsure how to operate the machine properly, either use of or maintenance to your Mini
Wrap, please contact your Mini Wrap dealer.
2.3 ADJUSTMENTS’ / MAINTENANCE.
Turn off the tractor and discharge the oil pressure before performing any adjustment or
maintenance on the machine. Remember that a well-maintained machine is a safe machine.
2.4 IMPORTANT!
ALWAYS MAKE SURE THAT NOBODY IS INSIDE
THE MACHINE’S WORKING AREA WHEN IT’S IN USE.
SAFETY DISTANCE IS 5 METRES
THE MACHINE MUST NEVER BE OPERATED BY PERSONS WHOM DOES NOT KNOW
ENOUGH ABOUT HOW TO SAFELY OPERATE THE MACHINE, OR BY PERSONS
UNDER 16 YEARS OF AGE.

7
Tanco Autowrap 404 S/M
Operator’s manual
2.5 DANGEROUS AREAS.
TANCO AUTOWRAP Ltd has given the safety to the operator the highest priority, but it is still
impossible to secure oneself of every danger area on the machine. Therefore we will now go
through some of the dangers that can occur when using the Mini Wrap bale wrapper.
1. Be especially aware of the rotating turntable. There is a danger of being squeezed
between the turntable and the main frame.
2. When the wrapping of a bale is complete and tipped off the machine, the turntable
has to be tipped back before wrapping next bale. When the middle frame with
turntable is lowered, there is a squeeze danger between the middle frame and the
main frame on both sides and in the back end of the machine. Keep therefore hands
and feet at a safe distance. (Fig. 2-2).
3. When tipping the turntable, the bale will roll free off the machine. Staying behind the
machine can cause danger for “overrunning” by the bale when it rolls off. Make
therefore sure that nobody is behind the machine when unloading.
2.6 WHILE WRAPPING.
Please keep your hands on the controller during the wrapping prosess.
The machine is to stand horizontally while the wrapping takes place. Make sure that nobody
comes into the working area of the machine.
2.7 TRANSPORTING.
When transported on a public road there are certain safety measures that must be taken:
1. Make sure that the machine does not cover the tractors’ lights. If necessary, mount extra
lights.
2. Always transport the machine with the turntable in transport position. Hydraulic hoses
must be disconnected under transport.
3. Always transport the machine in the lowest possible position.
4. Make sure that at least 20% of the tractor’s total weight is on the steering wheels.

8
Tanco Autowrap 404 S/M
Operator’s manual
3.0 GENERAL INFORMATION ON BALE WRAPPING.
3.1 THE PRINCIPLE.
The advantages of round/square bale silage are many, and include fewer feed units, a flexible
harvesting system, large capacity and the possibility of selling feed units.
In principle, the same fermentation processes occur whether the fodder is placed in a silo or
pressed into bales and packed in plastic, i.e. lactic acid fermentation in anaerobic conditions. The
oxygen in the bale must be exhausted before fermentation begins.
The grass should be dried to approximately 30-40% solid content. The solid content can be
determined by twisting the grass by hand. If drops of liquid are forced out of the grass, the solid
content is less than 25%. Low solid content, (wet grass), can lead to increased butyric acid
fermentation if preservatives are not added to the grass. If the solid content is too high, (over
50%), normal fermentation will not take place and there will be enough oxygen in the bale to
produce mould fungus.
3.2 THE BALER.
It is vital that the baler produces compact, well-formed bales, as misshapen bales can be difficult
to wrap. Wrapping will also often take longer, thereby increasing the amount of plastic used.
3.3 TYPES OF PLASTIC.
A good type of plastic with good adhesive properties, and which is recommended for bale
wrapping, must be used. The thickness of the plastic film should be at least 25 micron.
(25/1,000 mm). In order that the plastic tightens sufficiently around the bale, it is stretched
before being wrapped, so it is somewhat thinner when it is put on the bale. With short-term
storage, (up to eight weeks), it is recommended that bales have a minimum of four layers of
plastic at the thinnest points, with at least 52-53% overlap.
For long-term storage, or when the grass is wet when it is wrapped, the bale should have Six
layers of plastic applied, and the same amount of overlap. If thinner plastic is used, more layers
should be applied. If it is very hot the plastic will be stretched further, and more layers should be
applied. It is better to have slightly too much than too little plastic on the bale.
From experience, light coloured plastic produces slightly lower temperatures within the bale, and
tends to improve feed quality.
3.4 STORAGE LOCATION.
Care should be taken in finding a suitable location for the storage of bales. The storage location
should preferably be prepared before the bales are laid out. An elevation close to well-drained
roads is recommended. If the wrapped bales are simply placed on stubble there is a danger of the
plastic being pierced. A tarpaulin or a thin layer of sand should therefore be laid where the bales
are to be stored over the winter.
Bales should be stored in the shade as far as possible. This reduces the danger of air leakage in
the bales. A bale that is stored in sunlight and which therefore undergoes greater swings in
temperature “pumps ins’ a great deal of air in comparison to a bale which is stored in the shade.
According to ~‘Teknik for Lantbruket” [Technology for Agriculture] in Sweden, a bale which is
stored in the shade has only 40% of the air leakage of a bale which is stored in sunlight.
3.5 STACKING I PROTECTION.
If bales are hard and well formed, they can be stacked vertically, but loose and misshapen bales
with low solid content should not be stacked higher than one layer, as this could easily cause
deformity and the danger of runoff will be increased.
Bales can also be stored on their sides. The layer of plastic is thicker here, providing greater
protection against piercing.
Bales should be covered with a tarpaulin or a fine-mesh net to protect against birds and small

9
Tanco Autowrap 404 S/M
Operator’s manual
rodents. If the plastic is pierced, it must be sealed with weatherproof, hard-wearing tape,
preferably under the outermost layer of plastic. Ensure that the hole is adequately sealed.
3.6 The best wrapping results are obtained by...
1. . . . Harvesting the grass early.
2. ...Drying it out to 30-40% solid content. If there is a danger of rain, bale and wrap the
grass anyway.
3. ...Taking care not to mix any earth in with the grass.
4. ...Using a baler which produces even, firm bales.
5. ...Wrapping the bales soon after baling, never later than two hours afterwards.
6. . . .Using a good type of plastic and six layers of plastic. This removes the need to use
preservatives.
7. ...Storing bales in the shade to reduce the danger of air leakage.

10
Tanco Autowrap 404 S/M
Operator’s manual
4.0 SETTING UP / MOUNTING OF THE MACHINE.
4.1 Mounting the Lower link pins.
Attach the lower link pins to the machine and tighten the nuts.
4.3 Mount the Film Dispenser.
Adjust the height on the Dispenser so that the middle of the plastic meets with the bale’s center.
4.4 Mount the safety arm to the Chassis
4.5 Lubricate the machine.
4.6 Check that all the bolts and nuts are tightened.
4.8 Connect the machine to the tractors three point linkage.
4.9 HYDRAULIC CONNECTION.
The hydraulic hoses between machine and tractor are equipped with 1/2’ ISO male quick-
couplers. Discharge the oil pressure before you connect the oil hoses. Use the tractors’ hydraulic
lever. Connect the hoses so that the turntable rotates counterclockwise.
To make sure that the bale wrapper works properly, the tractors’ oil pressure has to be at least
100 bar. If you are unsure of what oil pressure the tractor gives, or what oil pressure the bale
wrapper receives, please contact your machinery dealer.
NB! When connected to a tractor with closed center (e.g. JOHN DEERE) a special, closed centers,
plug must be fitted to the valve to prevent the oil over heating (See section 13.0 and consult your
dealer ).
4.10 CHECK LIST.
Before using the machine it is recommended to follow this check list:
1. Make it a habit to discharge the oil-pressure before connection or disconnection of the
hydraulic hoses. (Use the tractors hydraulic control lever).
2. Hose with BLUE CAP = RETURN OIL.
3. Hose with RED CAP = PRESSURE.
4. Tie up loose hoses so that no squeeze damages occur.
5. Start the tractor and try out the functions. (It should rotate counterclockwise).
6. Check all connections, hoses and couplings. If there is any oil-leakage, it should be
rectified immediately.
Your MINI WRAP bale wrapper has been tested in practical operation in approx. 2 hours
at the factory.

11
Tanco Autowrap 404 S/M
Operator’s manual
5.0 MOUNTING OF THE PLASTIC FILM
5.1 When loading a plastic roll, first push back the Stretch rollers (3) until held in position by
locking catch (4). Then loosen locking bolt (1) and raise top cone (2) and lock in raised position.
5.2 Place a roll of film on to the Dispenser. Drop the top cone down and apply pressure to the top of
the shaft to compress the spring and allow the locking bolt to close one of the grooves in the
shaft.
5.3 Pull the film between the rollers on the pre-stretcher in the direction of the arrow. (See fig. 5-2).
(See also the sticker on the dispenser).
5.4 Release the locking catch and allow the rollers to lie against the roll of film. Pull the film from
the roll and tie it to the bale.
5.5 HEIGHT ADJUSTMENT OF DISPENSER/ PLASTIC FILM.
It is important that the plastic film is applied to the center of the bale, and therefore it can be
necessary to adjust the height of the Dispenser. The Dispenser may be adjusted to different
heights. Disconnect the locking bolt, and adjust the dispenser so that the plastic hits in the
middle of the bale. Replace the locking bolt and the splint.
The Tanco film Dispenser supplied with all 404 machine is capable of using several different
sizes of film rolls. 500 mm, 360 mm and 250 mm plastic film can all be used but care must be
taken that the correct level of overlap is used as you need turntable roller speeds for different
films. (see also 6.4 Overlap)

12
Tanco Autowrap 404 S/M
Operator’s manual
5.6 Tanco Dual stretch Film Dispenser
Some Tanco Autowrap machines can optionally be fitted with a patented dual stretch gear
system.
This system enables a quick change of stretch levels on the Film Dispenser.
If the bolt (1) is fitted in position 2, the bottom set of gears provide the stretch (70%).
By removing the bolt from position 2 and fitting it in position 3, the top set of gears become the
stretch gears giving 32% (for prestretched film) or optionally 55% (for use in hotter climates or
with square bales).
Tanco Dispenser Gear Combinations
Inner Gear Outer Gear % Stretch
60 Tooth 35 Tooth 70%
58 Tooth 37 Tooth 55%
54 Tooth 41Tooth 32%

13
Tanco Autowrap 404 S/M
Operator’s manual

14
Tanco Autowrap 404 S/M
Operator’s manual
6.0 ADJUSTMENT / OPERATING.
6.1 SUPPORT ROLLERS.
Place the bale you want to wrap on top of the rollers. Move the support rollers as tight to the bale
as possible. Make sure that the bale is in center of the rollers.
6.2 HEIGHT ADJUSTMENT OF DISPENSER.
The Dispenser can be placed in different positions. Disconnect the locking bolt, and adjust the
pre-stretcher so that the plastic hits in the middle of the bale. Replace the locking bolt and the
splint.
6.3 Operating the RDS control box
See chapter 8
6.4 REVOLUTION SPEED OF TURNTABLE.
Start the machine by operating the lever inside the tractor. All 404’s are equipped with an
adjustable valve on the outlet from the main valve block to the motor. Screw in to reduce
turntable speed. Adjust this until the turntable speed is approx. 22 revolutions per minute (Just
below 3 seconds per revolution) and lock the knob in position by tightening the allen-headed
screw on the knob.
6.5 OVERLAP.
To control the overlap, stop the machine after a few turns. Use a marker to mark a line on the
middle of the film wrapped on the bale. By the next turn this line should just be covered. It is now
possible to use ether the 500mm, 360mm or 250mm film on the MINI WRAP 404EH. The
machine is generally delivered set up for use with the 360mm film. Tanco recommend this size
of film for best results.
If using 250mm or 500 mm film, a special set of sprockets need to be fitted to the turntable
(inside the large chain guard) to maintain correct bale indexing speed. See parts books or contact
your dealer for advice. The chains from the turntable’s main shaft must be lengthened or
shortened as required to ensure correct chain tension. Note that these are twin sprockets. Fit
chain to larger sprocket for 250 mm film and on smaller for 500 mm film.

15
Tanco Autowrap 404 S/M
Operator’s manual
7.0 OPERATING INSTRUCTION.
We shall now go through a complete wrapping process, from loading to storage place, and
explain the practical use of the MINI WRAP 404.
7.1 LOADING.
On the 404 M/S machine the Bale must be placed manually on the turntable.
7.2 HEIGHT ADJUSTMENT OF DISPENSER.
The height of the pre-stretcher has to be adjusted so that the plastic film is always hitting the
middle of the bale. (See more about this in chapter 5.5 and 6.2).
7.3 TIPS ON WRAPPING SQUARE BALES.
The MINI WRAP 404EH is assembled for delivery with the rollers in the outer position. If the
bales to be wrapped are in some degree smaller than mean measure then the rollers must be
moved. (Optimally the film should meet the bale being wrapped in the middle.) The chain cover
must be removed, and the Rocking roller assembly moved either in or out. The chain length
must be adjusted so ensure the chain-tension is tightened before finally the bolts are replaced.
Remember that a hard and well packed bale will give the best result when wrapping.
7.4 START.
Remember that the plastic film end must be tied to the bale. This is normally only necessary on
the first bale. Operate the hydraulic lever carefully to make a gently start. To quick start can rip
off the plastic film, and then it has to be tied again.
The 404 M/S models are equipped with an AutoStop function, which enables semi-automatic
operation of the machine. Once the turntable has made one revolution the spool lever is held in
position by the bale counter until the preset number of rev.s has been achieved. The lever is then
automatically released and the turntable stops in the correct “Off-Loading” position.
7.5 OVERLAP.
Control that the overlap is correct. If not, see chapter 6.4.
7.6 HOW MANY LAYERS OF PLASTIC FILM?
When the bale is completely covered with film, read the counter that displays the number of
revolutions done by the turntable. If you don’t have a counter, you have to count the revolutions
yourself, (or you can measure the time it takes). This number has to be multiplied by 2 or 3,
depending on how many layers of film you want to have.
* 4 layers - multiply by 2.
* 6 layers - multiply by 3.
7.7 STOP / UNLOADING.
On an S machine the Film must be cut by hand and the Bale lifted off the machine.
On an M machine, tip up the tipping frame until the film is lying in the cut and start jaws.
Energize cut and start close until the film is gripped and cut. Continue tipping up until the bale
falls off the table.
7.8 NEW BALE.
Lower the turntable down again. Then place a new bale on top of the rollers, and attach the film
to the bale (404 S only), and start wrapping. Now the plastic film from the last should be cut off.
Fasten the film end, if necessary, with some weatherproof tape.

16
Tanco Autowrap 404 S/M
Operator’s manual
8. Controller Manual
8.1. Introduction
What can it do?
8.2. The control switches
8.3. Using the instrument
8.3.1. Channel 1 - Current/Target Wraps display
3.1.1 Manually reset Current Wraps to zero
3.1.2 Program Target Wraps
3.1.3 Program Early Warning Alarm
8.3.2. Channel 2 - Store Totals
3.2.1 Display a Store Total
3.2.2 Select a Store Total
3.2.3 Reset a Store Total
8.3.3. Channel 3 - Part total
3.3.1 Display Part Total
3.3.2 Reset Part Total
8.3.4. Channel 4 - Grand Total
3.4.1 Display Grand Total10
8.3.5. Channel 5 - Bale Wrapping Rate
3.5.1 Display Bale Wrapping Rate
3.5.2 Reset the Timing Period
8.3.6. Channel 6 - Bale Wrapping Speed
3.6.1 Display Bale Wrapping Speed
3.6.2 Programme the Overspeed Alarm
8.3.7. Film Break Alarm
8.3.8. Total Reset
8.3.9. Other CAL Mode settings
Cut and Start Release duration
Film Break Sensor – On/Off

17
Tanco Autowrap 404 S/M
Operator’s manual
8.1. Introduction
The instrument has 6 channel functions with an illuminated 4 digit LCD display, 5 switches to control
all functions and an internal alarm. An external alarm is optional.
The instrument is normally powered on via the vehicle ignition circuit and recalls the function displayed
when the instrument was last used.
What can it do ?
• Continuously displays the current number of wraps around the bale alongside the desired (Target)
number of wraps preset by the operator.
• Sounds an alarm at a preset number of wraps before the target number is reached.
• Automatically senses when the bale wrap sequence ends and records it to each of these memory
registers:
(i) Grand Total
(ii) Part Total
(iii) One of eight selectable Store Totals
• Displays the number of bales wrapped per hour, within any desired time period.
• Displays bale wrapping speed in rpm, and sounds an alarm when a preset speed is exceeded.
• Film break alarm and automatic stop.
8.2. The Control Switches
• Adjustable turntable stop position.
There are five switches on the front panel used individually or in combination to programme, set/reset or select a
function.
Current No. of
wraps
Channel
Pro
g
ramme
Select Channel
Retard the
turntable
stop Channel
position
Tar
g
et No. of
Advance the
turntable stop
position
Set Target Wraps
Set Alarm Threshold
Reset Totals
Channel 1 ‘Normal’ display (Current/Target no. of Wraps)
Channel 2 Store Totals (A - H)
Channel 3 Part Total
Channel 4 Grand Total
Channel 5 Bale Wrapping Rate

18
Tanco Autowrap 404 S/M
Operator’s manual
Channel 6 Bale Wrapping Speed
8.3. Usin
g
the Instrument
8.3.1 Channel 1 - Current/Target Wraps Display
Press to select .
The left-hand section shows the current number of wraps and the right hand section shows the target number.
When the current number = Target number, the alarm will sound for 2 seconds and the display will flash. (If set,
the early warning alarm sounds beforehand).
Automatic reset of current number to zero normally occurs 5 seconds after the Target number is reached. If
additional wraps are added after the Target number is reached, the current number will continue to advance.
8.3.1.1 Manually reset Current No. of Wraps to Zero
Press to select .
Press and hold.

19
Tanco Autowrap 404 S/M
Operator’s manual
8.3.1.2 Programme the Target Wraps
Press to select .
Hold continuously.
The third digit flashes.
Hold to cycle to the required digit then release, otherwise press once…
The fourth digit flashes.
Hold to cycle to the required digit.
Release all.
8.3.1.3 Programme Early Warning Alarm
An early warning alarm can be programmed to sound from 1 to 9 wraps before the target number is reached.
Depending on the setting, the alarm will sound long beeps for up to 8 wraps, short beeps for the final wrap, and
then a continuous beep for three seconds.
For example, if the bale requires 22 wraps and you want an alarm at 20 wraps, then set the number to 2.
To effectively disable the alarm, set the number to 0.
Press to select .
Hold continuously.
The fourth digit flashes.
Hold to cycle to the required digit.
Release all.

20
Tanco Autowrap 404 S/M
Operator’s manual
8.3.2 Channel 2 - Store Totals
When bale wrap is complete, one of eight pre-selected memory store totals A, b, C, d, E, F, G, or H, is
automatically advanced by 1. Store totals can be reset individually.
8.3.2.1 Display a Store Total
Press to select .
The fourth digit displays the current store designation for 2 seconds.
The current total for that store then displays for five seconds, then defaults
to channel 1.
8.3.2.2 Select a Store Total
Press to select .
Select the desired store total (A – H).
This is now the default store, and subsequent bale counts are stored there
until another store is selected.
8.3.2.3 Reset a Store Total
Press to select .
Select the desired store total (A – H).
Press and hold.
