TEMPLE & WEBSTER Baxter FJBBSCHB User manual

A
8 PCS 8 PCS 8 PCS 1 PC 1 PC 1 PC 1 PC 2 PCS
1
32
4
5
6
6
9
8
11
12
13
10

B C D E F G H
J K L
S T
M N O P
I
10 PCS 10 PCS
2 PCS
1 PC 1 PC 1 PC 1 PC 4 PCS 4 PCS
Q R
1 PCS 6 PCS 8 PCS
7
7
7
CAUTION:
Only tighten bolts to 80% at first. Once all parts have
been assembled, fully tighten all hardware. To
prevent damage to threads, do not use a power tool
and do not over tighten bolts.
Use two people to lift and turn the product when
assembling.
Do not attempt with only one person and do not roll
on to legs. Keep all hardware and small parts away
from children.
Read these instructions and follow steps carefully to
ensure you assemble the product correctly and avoid
damages. Check that all parts hardware have been
provided before assembling the products. Place all
contents on a clean, soft-flat surface to avoid scratching
the product.

3
3
3
4
4
4
3
1
1
2
4
5
Step 1:
CL
CR
J
K
J
J
J
J
J
J
B
B
B
C
C
C
A
A
A
A
A
S
S
S
S
A
A
B
J
L
L
K
Attach 4 x Cam Bolts (B) into Top Panel (1) using a Phillips head screwdriver. Insert 4 x Dowels (A)
into Side Panels (3, 4). Insert 4 x Cam Nuts (C) into the holes of Side Panels (3) and (4). Rotate the cam
nuts so the arrows point towards the incoming cam bolts. Attach Top Panel (1) and tighten the cam nuts.
Insert Back Panel (5) into the groove of Side Panels (3, 4). Attach Bottom Panel (2)
to Side Panels (3, 4) with 4 x Long Screws (S).
Step 2:
Step 3:
Attach 1 x CL Runner Track (K) to Left Side Panel (3) with 3 x Small Screws (J).
Attach 1x CR Runner Track (L) to Right Side Panel (4) with 3 x Small Screws (J).

Step 4:
2
Step 5:
Step 6:
6
6
6
6
6
6
7
77
8
Attach Panels (6) to Panels (7) with 6 x Bolts (R).
Attach Panels (6) to Panel (2) with 6 x Screws (I).
Attach Panel (8) to Panels (6) with 4 x Screws (I).
R
R
R
R
R
R
I
I
I
I
I
I
I
I
I
I

Step 7:
B
B
9
9
10
10
10
10
11
11
11
11
B
B
C
C
S
S
C
T
T
Q
C
13
12
S
S
9
Step 8:
Step 9:
Attach 1 x DL Runner (M) to Left Drawer Side (10) and 1 x DR Runner (N) to Right Drawer Side (11)
with 4 x Small Screws (J). Attach 1 x Handle (Q) to Drawer Front Panel (9) with 2 x Small Screws (T).
Attach 4 x Cam Bolts (B) to Drawer Front (9) as shown. Insert 4 x Cam Nuts (C) into the holes of
Drawer Sides (10, 11). Rotate the cam nuts so the arrows point towards the incoming cam bolts.
Push Drawer Sides (10, 11) into place and tighten the cam nuts.
Slide Drawer Base (13) into the groove in Drawer Sides (10) and (11). Attach Drawer Back (12) to
Drawer Sides (10, 11) with 4 x Screws (S). Make sure that the groove lines up the whole way
around the drawer.
N
M
J
J
J
J

Step 10:
9
Step 11:
Step 12:
1
H
D
E
O
P
H
D
E
5
1
Fasten the safety strap to your wall using appropriate fixings for your wall type. If you
are unsure, please seek professional advice on how to attach this safety strap to your specific wall.
Recommended step for
wall securing
Put the drawers into the chest.
Secure Back Panel (5) in place with 4 x Wedges (O) using 4 x Medium Screws (P). Attach Safety
Strap (D) to the Top Panel (1) using 1 x Screw (E) and 1 x Washer (H).
H
F
G
H
G
F

WARNING
It is STRONGLY RECOMMENDED that you ANCHOR this product.
Toppling furniture can cause serious injuries and death.
This product has been provided with an anchor strap. To prevent your
furniture from tipping forward it is strongly recommended that you
securely attach this product to a wall or other solid surface, using the
anchor strap provided and appropriate fixings.
IMPORTANT:
Regularly check that anchors are securely maintained.
Stability of tall items may be affected by thick pile carpet or uneven
floors.
CAUTION:
For your safety when attaching the anchor fixings, please note
the following:
Check for any electrical wires or plumbing inside the wall before
drilling any holes (if you are unsure please seek professional
advice from a qualified tradesperson)
Walls are constructed from different materials, for example,
masonry (solid brick) or plasterboard lined cavity walls (hollow).
It is important that you use the appropriate
wall fixings for your wall type.
Your local hardware store will have the necessary drills and
fixings and can offer advice if needed. If in doubt, engage the
services of a qualified tradesperson to install and anchor
the product.
