TEMPLE & WEBSTER SBMECTOK User manual

ASSEMBLY INSTRUCTIONS
www.templeandwebster.com.au
SBMECTOK
SBMECTWH
Memo Chest of 3 Drawers

Keep these instructions for future reference
Read these instructions and follow steps carefully to ensure you assemble the product
correctly and avoid damages. Check that all parts and hardware have been provided
before assembling the product. Place all contents on a clean, soft-flat surface to avoid
scratching the product.
CAUTION:
Only Tighten bolts to 80% at first. Once all parts have been assembled, fully tighten all
hardware. To prevent damage to threads, do not use a power tool and do not overtighten
bolts. Use two people to lift and turn the product when assembling. Do not attempt with
only one person and do not roll on to legs. Keep all hardware and small parts away from
children.
We recommend furniture be assembled near where they will be placed, to avoid moving
the product unnecessarily once assembled.
If there is a need to move the furniture, please remove all loose items and have extra
hands to help lift the furniture to the desired location. Dragging the furniture will damage
both the furniture and the floor.
Regularly check and re-tighten (if necessary) all bolts on furniture that you have
assembled yourself.
Wipe clean with a damp cloth. Use only water or a gentle detergent.
Wipe dry with a clean cloth.
Care and Maintenance of your Furniture
2
WARNING:
Do not stand on the Chest of Drawers !

3
WARNING：
- Walls are constructed from different materials, for example, masonry (solid brick) or
plasterboard lined cavity walls (hollow). It is important that you use the appropriate
wall fixings for your wall type. If unsure, please seek professional advice on how to
attach this safety strap to your specific wall.
- Your local hardware store will have the necessary drills and fixings and can offer
advice if needed. If in doubt, engage the services of a qualified tradesperson to install
and anchor the product.
It is STRONGLY RECOMMENDED that you ANCHOR this product.
Toppling furniture can cause serious injuries and death.
This product has been s with a strap. To prevent your furniture from tipping
forward it is strongly recommended that you securely attach this product to a wall or
other solid surface, using the straps provided and appropriate fixings.
IMPORTANT:
Regularly check that anchors are securely maintained.
Use safety drawer locks to prevent children climbing.
Stability of tall items may be affected by thick pile carpet or uneven floors.
Do not place unanchored televisions on furniture.
CAUTION:
For your safety when attaching the anchor fixings, please note the following:
- Check for any electrical wires or plumbing inside the wall before drilling any holes (if
you are unsure, please seek professional advice from a qualified tradesperson)

Tools Required
Parts List
DO NOT USE
Time Required
30 min
(P1). Top panel, x1
(P2). Left side panel, x1
(P3). Right side panel, x1
(P4). Top support rail, x1
(P5). Middle support rail, x2
(P6). Bottom support rail, x1
(P7). Back top support rail , x1
(P8). Back middle support rail, x1
(P9). Back bottom support rail, x1
(P10). Back panel, x2
(P11). Bottom support rail , x1
(P12). Drawer front, x3
(P13). Left drawer side, x3
(P14). Right drawer side, x3
(P15). Drawer back, x3
(P16). Drawer bottom, x3
(P17). Drawer bottom support rail, x3
4
(P1)
(P2)
(P3)
(P4)
(P5)
(P5)
(P6)
(P7)
(P8)
(P9)
(P11)
(P10)
(P10)
(P12)
(P13)
(P14)
(P15)
(P16)
(P17)

T
wall
5
2pcs
8sets
59pcs 59pcs 3sets
30pcs 18pcs
1 2 3 4
8765
9 10

1
6
Screw 28 x Cam bolts (1) into Left side panel (P2) and Right side panel (P3) using a screwdriver as shown.
Fix 3 x Slide Tracks (4 CL) onto Left side panel (P2) with 9 x Screws (5) using a screwdriver.
Fix 3 x Slide Tracks (4 CR) onto Right side panel (P3) with 9 x Screws (5) using a screwdriver.
X28 X18 X6
1 54
(P2)
(P3)
154(CL)
1
5
4(CR)
4

2
3
7
Position Top support rail (P4), 2x Middle support rails (P5), Bottom support rail (P11) and Back support rails (P7), (P8)
and (P9) onto Left side panel (P2).
Insert 14 x Cam nuts (2) into Top support rail (P4), 2x Middle support rails (P5) and Back support rails (P7), (P8) and (P9).
Use a screwdriver to turn clockwise to lock.
This is how a cam nut works........
The head of the cam
bolt goes into the open
mouth of the cam nut.
You then turn the cam
nut so it tightens over
the bolt.
Insert 2x Back panels (P10) into the grooves of Left side panel (P2) and Back support rails (P7), (P8) and (P9).
14
2
2
(P2)
(P4)
(P5)
(P5)
(P11)
(P7)
(P8)
(P9)
(P2)
(P7)
(P10)
(P10)
(P8)
(P9)

4
5
8
Position Right side panel (P3) onto Top support rail (P4),
Middle supports (P5), Bottom support rail (P11) and Back support rails
(P7), (P8) and (P9) as shown.
Insert 14 x Cam nuts (2) into Top support rail (P4), Middle support rails (P5),
Bottom support rail (P11) and Back support rails (P7), (P8) and (P9).
Use a screwdriver to turn clockwise to lock.
Screw 4 x Cam bolts (1) into Bottom support rail (P6) using
a screwdriver as shown.
Position Bottom support rail (P6) onto Left side panel (P2) and Right side panel (P3).
Insert 4 x Cam nuts (2) into Side panels (P2) and (P3).
Use a screwdriver to turn clockwise to lock.
14
2
2
(P3)
(P7)
(P8)
(P9)
(P11)
(P4)
(P5)
(P5)
12
1
2
(P3)
(P2)
(P6)
(P6)

6
7
9
Insert 2 x Dowels (3) into Left side panel (P2) and Right side panel (P3) as shown.
Position Top panel (P1) onto the assembled frame.
Insert 9 x Cam nuts (2) into Left side panel (P2), Right side panel (P3), Top support rail (P4) and Back top
support rail (P7).
Use a screwdriver to turn clockwise to lock.
Screw 9 x Cam bolts (1) into Top panel (P1) using a screwdriver as shown.
Fix the Wall strap (8) with 1 x Screw (10) and 1 x Washer (9) to the Top panel (P1) as shown.
(P1)
18 9 10
1
8
10
9
23
(P1)
(P2)
(P3)
(P4)
(P7)
3
2

8
9
10
Fix Drawer back panel (P15) onto Left drawer side (P13) and Right drawer side (P14) with 4 x Screws (6) using a
screwdriver as shown.
Repeat with the remaining panels.
6
Fix Drawer bottom support rail (P17) onto Drawer back panel (P15) with 2 x Screws (6) using a screwdriver.
Repeat with the remaining panels.
6
6(P13)
(P15)
(P14)
6
6
(P15)
(P17)

10
11
11
Slide Drawer bottom (P16) into the grooves of Left drawer side (P13), Right drawer side (P14) and Drawer back
panel (P15) as shown.
Repeat with the remaining panels.
Screw 6 x Cam bolts (1) into Drawer front (P12) using a screwdriver as shown.
Position Drawer front (P12) onto Drawer sides (P13) and (P14).
Insert 6 x Cam nuts (2) into Drawer sides (P13), (P14) and Drawer bottom support rail (P17).
Use a screwdriver to turn clockwise to lock.
Repeat with the remaining panels.
(P15)
(P16)
(P13)
(P14)
(P12)
(P12)
(P13)
(P14)
12
1
2
2

12
12
Fix Slider runner (4 DL) onto the Left drawer side (P13) with 2 x Screws (5) using a screwdriver.
Fix Slider runner (4 DR) onto the Right drawer side (P14) with 2 x Screws (5) using a screwdriver as shown.
Repeat with the remaining drawers.
(P14)
4
4(DL)
4(DR)
54
5

13
14
13
Fix 8 x Back panel holders (7) to assembled unit with 8 x Screws using a screwdriver.
Slide the three drawers onto the track as shown.
7
7

15
wall
Move the chest of drawers into position against a wall.
Mark a suitable position for the wall fixing.
Follow instructions to install the wall fixing onto the wall.
Reposition the bedside table and fix the Wall strap (8) and 1 x Washer (9) to the wall with wall fixing.
Assembly is complete.
14
