TEMPLE & WEBSTER SBSKBTNB User manual

ASSEMBLY INSTRUCTIONS
SBSKBTNB
SBSKBTNN
SBSLBTNB
SBSLBTNN
Ski Leg Oak Dining Bench - 140cm - Natural/Black
Two people required
TEMPLE
WEBSTER
www.templeandwebster.com.au
2021/11/18
Ski Leg Oak Dining Bench - 140cm - Natural/Natural
Ski Leg Oak Dining Bench - 180cm - Natural/Black
Ski Leg Oak Dining Bench - 180cm - Natural/Natural

Keep these instructions for future reference
Assemble the furniture on a soft level surface to avoid damaging the furniture or
your floor.
Parts of the assembly will be easier with 2 people.
We recommend furniture be assembled near where they will be placed, to avoid
moving the product unnecessarily once assembled.
If there is a need to move the furniture, please remove all loose items and have
extra hands to help lift the furniture to the desired location. Dragging the
furniture will damage both the furniture and the floor.
Regularly check and re-tighten (if necessary) all bolts on furniture that you have
assembled yourself.
2
Care and Maintenance of your Furniture
Wipe clean with a damp cloth. Use only water or a gentle detergent.
Wipe dry with a clean cloth.
Maximum user weight is 120kg (per seat).
Do not stand on the Furniture

Tools Required
Parts List
3
DO NOT USE
Bench Top (P1);
Leg Post (P2) x 2;
Leg Post (P3) x 2;
Stretcher (P4) x 2.
Time Required
30 min
People Required
(P1)
(P2)
(P2)
(P3)
(P3)
(P4)
(P4)
Flat Head ScrewdriverMallet

Hardware/Fittings
Wood Dowel x 8
1 2 3 4
8
9 10
7
65
Flat Washer x 12 Spring Washer x 12
4
Long Threaded Rod x 8
Short Threaded Rod x 4 Half Moon Washers x 4 Nut x 12 Spanner x 1
Barrel Nut x 4Felt Foot x 4

2
2
5
1
2 x4 5 x2 10 x2
2 x4 5 x2 10 x2
Insert 1 x Barrel Nut 10 into Leg Post (P2).
If necessary, use a flat head screwdriver to rotate
the Barrel Nut.
Screw 2 x Long Threaded Rod 2 into Barrel Nut10 .
Screw 1 x Short Threaded Rod 5 into Leg Post (P2).
Repeat with the remaining Leg Post (P2).
Insert 1 x Barrel Nut 10 into Leg Post (P3).
If necessary, use a flat head screwdriver to rotate
the Barrel Nut.
Screw 2 x Long Threaded Rod 2 into Barrel Nut 10 .
Screw 1 x Short Threaded Rod 5 into Leg Post (P3).
Repeat with the remaining Leg Post (P3).
2
22
5
2
2
22
5
10
10
10
10
P2 x2
P3 x2

3
4
6
1 x8
7 x4 3 x4 4 x4
Insert 4 x Wood Dowel 1 into Stretcher (P4).
If necessary, gently tap the wood dowels with a mallet.
Repeat with the remaining Stretcher (P4).
1
1
1
1
P4x2
80%
Place the Bench Top (P1) with its underside facing up on a soft covered surface.
Position 1 x Leg Post (P3) onto the corner of Bench Top (P1) as shown.
Loosely attach Leg Post (P3) to Table Top (P1) with 2 x Flat Washers 3 , 2 x Spring Washers
4 and 2 x Nuts 7 .
Repeat with the remaining Leg Post (P2) onto the corner of Bench Top (P1) as shown.
7
34
7
4
3
P2
P3
P1

7
5
7 x4 3 x4 4 x4
80%
Fit Stretcher (P4) onto Leg Post (P3) as shown.
Position Leg Post (P2) onto the other end of Stretcher (P4) and the corner of Bench Top (P1) as
shown.
Loosely attach Leg Post (P2) to Bench (P1) with 2 x Flat Washers 3 , 2 x Spring Washers 4
and 2 x Nuts 7 .
Fit Stretcher (P4) onto Leg Post (P2) as shown.
Position Leg Post (P3) onto the other end of Stretcher (P4) and the corner of Bench Top (P1) as
shown.
Loosely attach Leg Post (P3) to Bench Top (P1) with 2 x Flat Washers 3 , 2 x Spring Washers 4
and 2 x Nuts 7 .
33
447
7
P4
P4
P3
P3
P2
P2
P1

4x
6
8
3 x4 4 x4 8 x1 7 x46 x4
Attach Stretcher (P4) onto Leg Posts (P2) (P3) with 2 x half moon washers 6 , 2 x Flat Washers
3 , 2 x Spring Washers 4 and 2 x Nuts 7 on each leg frame.
Fasten with Spanner8 .
P4
P4
6347
6
3
47
8

Fasten all Nuts 7 with Spanner 8 .
Paste 2 x Felt Feet 9 onto each Stretcher (P4) as shown.
7
8
With help, carefully turn the table over.
Assembly is complete.
9
9 x4 8 x1
4x 100%
9
8
Please dispose of all
packing thoughtfully.
