FormNo.3416-266RevA
RearRemoteHydraulicKit
SandPro®/IneldPro®3040and5040TractionUnit
ModelNo.08781—SerialNo.315000001andUp
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCalifornia
tocausecancer,birthdefects,orreproductiveharm.
WARNING
Hydraulicuidescapingunderpressurecan
penetrateskinandcauseinjury.
•Makesurethatallhydraulicuidhoses
andlinesareingoodconditionandall
hydraulicconnectionsandttingsaretight
beforeapplyingpressuretothehydraulic
system.
•Keepyourbodyandhandsawayfrom
pin-holeleaksornozzlesthateject
high-pressurehydraulicuid.
•Usecardboardorpapertondhydraulic
leaks.
•Safelyrelieveallpressureinthehydraulic
systembeforeperforminganyworkonthe
hydraulicsystem.
•Seekimmediatemedicalattentionifuid
isinjectedintoskin.
Wheneveryouneedservice,genuineT oroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
g220043
Figure1
1.Locationofthemodelandserialnumbers
ModelNo.
SerialNo.
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
©2017—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3416-266*A

Safety
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal110-1303
110-1303
1.Pressure3.Highpressureuid,
injectionintobody
hazard—stoptheengine,
stoptheimplement,
anddisconnectthe
quick-connectports.
2.Tank4.Tank
2

LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Preparethemachine.
2Nopartsrequired–Removetheaircleaner.
3Nopartsrequired–Removethehydraulicreservoirand
shrouds.
Small90-degreeteewithbarb1
Large90-degreeelbow(threadedboth
ends)1
4Strainer1
Installttingstothehydraulictank.
Retainerbracket1
Muferclamp2
Hose-retainerbracket1
5Couplerbracket1
Installthecouplerbrackettotherear
frame.
Valve1
Valveplate1
Bolt(1/4x1-3/4inches)2
Nut(1/4inch)2
Small90-degreeelbow1
Teetting1
Thread-formingscrew(9/32x3/4inch)2
Teeadapter1
Relay1
6
Cap1
Installthemanifoldandbracket.
Hydrauliccap1
Hydrauliclinenumber11
Hydrauliclinenumber21
7Hydraulicline(hose)number51
Installthehydrauliclines.
Hydraulicpump1
45-degreetting(maleends)1
Hubassembly1
Squarekey(1/4x1inch)1
Setscrew(5/16x3/4inch)4
Pumpbracket1
Bolt(withthread-lockingcompound)
(5/16x3/4inch)2
Washer(3/8inch)2
8
Large90-degreeelbow(withhose
barbedend)1
Installthehydraulicpump.
Hydrauliclinenumber31
9Hydrauliclinenumber41Installthehydrauliclines.
3

ProcedureDescriptionQty.Use
Largehydraulichose1
Hydraulichosewithttings1
Largehoseclamp2
Smallhoseclamp2
Smallmoldedhydraulichose1
R-clamp1
Bolt(5/16x7/8inch)1
10
Flangenut(5/16inch)1
Installthehydraulichoses.
11Nopartsrequired–Tightenallconnections.
Harness1
Switch1
12Fuse1
Installtheswitchandharness.
Dipstick1
13Hydraulicuid
25.5L
(6-3/4US
gallons)
Installthehydraulicuidandcheckfor
leaks.
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface.
2.Lowertheattachments.
3.Engagetheparkingbrake.
4.Shutofftheengineandremovethekey.
5.Thoroughlycleanthemachine.Removeall
debristoensurethatthemountingbracketswill
tproperlyandthatnodirtordebrisgetsinto
thehydraulicsystem.
2
RemovingtheAirCleaner
NoPartsRequired
Procedure
1.Thoroughlycleantheareaaroundtheair
cleaner.
2.Loosentheradiatorclamparoundthehoseand
lowertheclampontothehose.
3.Removetheinsideboltholdingtheaircleaner
inplace.
4.Removetheair-cleanercoverandlter(Figure
2).
g003574
Figure2
1.Air-cleanercanister3.Canistercover
2.Airlter
5.Removethehosefromtheair-cleanercanister.
6.Spreadtheair-cleanerstrapopenandpullit
overtheendofthecanisterwherethelterwas
takenout(Figure3).
4

g003580
Figure3
1.Bolt4.Cap
2.Air-cleanerstrap5.Air-cleanercanister
3.Machineframe
7.Coverthehoseorinsertaragintoitsothatno
dirtordebrisgetsintoitwhileinstallingthiskit.
8.Removetheoppositeboltholdingtheair-cleaner
straptothemachineframe.
3
RemovingtheHydraulic
ReservoirandShrouds
NoPartsRequired
Procedure
1.Drainthehydraulictank.Refertothemachine
Operator'sManual.
2.Raisetherearofthemachineofftheground
andblockuptherearofthemachine.Referto
themachineOperator'sManualunderRaising
theMachine.
WARNING
Mechanicalorhydraulicjacksmayfailto
supportthemachineandcauseserious
injury.
Usejackstandswhensupportingthe
machine.
3.Removetheleftreartire.
4.Removethe4ange-headscrewssecuring
theleftwheelshroudtotheframe(Figure4).
Removeandretaintheshroud.
g003581
Figure4
1.Leftwheelshroud3.Tire
2.Flange-headscrews4.Nut
5.Removethe2ange-headscrewssecuring
theleftfrontscreentotheframe.Removeand
retainthescreen.
g003836
Figure5
1.Flange-headscrews3.Leftfrontscreen
2.Frame
6.Removethe3boltssecuringtherearhitch
shieldtotheframe.
5

g003838
Figure6
1.Bolt2.Rearhitchshield
7.Removethe2screwssecuringthecenter
shroudtotheframe(Figure7).Removeand
retaintheshroud.
g003617
Figure7
1.Centershroud3.Seat
2.Screws
8.Disconnectthehydrauliclinesgoingtothetank.
9.Removethetophydraulictankbracketfromthe
machineframeandloosenthe2bracketsonthe
sideoftheframe(Figure8).Removethetank
andretainthehardware.
g003575
Figure8
1.Hydraulictank4.Nut
2.Bolt5.Sidebracket
3.Topbracket6.Washer
4
InstallingFittingstothe
HydraulicTank
Partsneededforthisprocedure:
1Small90-degreeteewithbarb
1Large90-degreeelbow(threadedbothends)
1Strainer
Procedure
Note:MakesurethatallO-ringsarelubricatedand
properlypositionedonallttingsbeforeinstallation.
Note:Installallttingsandhydrauliclineslooselyrst
andthentightenthemwheneverythingisinstalled.
Installthettingsattheanglesshowninthegures.
1.Removethe2hydraulictankplugsfromtheside
ofthetank.
2.Installthestrainerintothehydraulictankwhere
thelargeplugwasremoved.
3.Installthelarge90-degreeelbowintothe
strainer.
4.Installthesmall90-degreeteewithbarbwhere
thesmallplugwasremoved(Figure9).
6

g015917
Figure9
1.Large90-degreeelbow
(installatangleshown)
5.Small90-degreetee
(installatangleshown)
2.Strainer6.Removethesmallplug.
3.Removethelargeplug.7.45degrees
4.Hydraulictank
5
InstallingtheCoupler
BrackettotheRearFrame
Partsneededforthisprocedure:
1Retainerbracket
2Muferclamp
1Hose-retainerbracket
1Couplerbracket
Procedure
Note:Installallhydrauliclineslooselyrstandthen
tightenthemwheneverythingisinstalled.
1.Positiontheclampsaroundtheroundtubeof
therearframe.
2.Installthehose-retainerbracketandthecoupler
brackettothemuferclamps.
Note:Donottightenthenutsatthistime.The
couplerbracketneedstobeloosetoinstallthe
hydrauliclines(Figure10).
g003578
Figure10
1.Mufeclamp4.Retainerbracket
2.Muferbracket5.Nut
3.Couplerbracket6.Rearframeroundtube
3.Temporarilypositionthecouplerbracketonthe
roundframetube;refertoFigure11.
Note:Placethecouplerbracketwherethetube
beginstobend.
g003837
Figure11
1.Roundframetube3.Couplerbracket
2.Temporarypositionforthe
couplerbracket
7

6
InstallingtheValve
Partsneededforthisprocedure:
1Valve
1Valveplate
2Bolt(1/4x1-3/4inches)
2Nut(1/4inch)
1Small90-degreeelbow
1Teetting
2Thread-formingscrew(9/32x3/4inch)
1Teeadapter
1Relay
1Cap
Procedure
Note:MakesurethatallO-ringsarelubricatedand
properlypositionedonallttingsbeforeinstallation.
Note:Installallttingsandhydrauliclineslooselyrst
andthentightenthemwheneverythingisinstalled.
Installthettingsattheanglesshowninthegures.
1.Installthettingsattheanglesshowninthe
gures.Installtheteettingtothesideofthe
valve.RefertoFigure12forthecorrecttee
tting.
2.Installasmall90-degreeelbowtothetopofthe
valve(Figure12).
3.Installtheteeadaptertothe90-degreeelbow.
RefertoFigure12forthecorrectteetting.
4.Installthecapontotheteeadapter(Figure12).
5.Installtherelaytothevalvebracketatthesame
timethevalveisinstalledtothevalvebracket.
6.Installthevalvetothevalvebracketwith2bolts
(1/4x1-3/4inches)and2nuts(1/4inch);refer
toFigure12.
g003576
Figure12
1.Teeadapter6.Valvebracket
2.Small90-degreeelbow7.Relay
3.Nut8.Bolt(1/4x1-3/4inches)
4.Valve9.Cap
5.Teetting
7.Installthevalvebrackettothemachineframe
with2thread-formingscrews(9/32x3/4inch);
refertoFigure13.
g003577
Figure13
1.Thread-formingscrew
(9/32x3/4inch)
2.Valveassembly
8

7
InstallingHydraulicLines
1,2,and5
Partsneededforthisprocedure:
1Hydrauliccap
1Hydrauliclinenumber1
1Hydrauliclinenumber2
1Hydraulicline(hose)number5
Procedure
UseFigure14foridentifyingthecorrecthydraulic
lines.
g015920
Figure14
1.Hydrauliclinenumber14.Hydrauliclinenumber4
2.Hydrauliclinenumber25.Hydraulicline(hose)
number5
3.Hydrauliclinenumber3
Note:Installallhydrauliclineslooselyrstandthen
tightenthemwheneverythingisinstalled.
1.Installthehydrauliccapontohydraulicline
number1,port1b.
2.Positionhydrauliclinenumber1intothe
machineasshowninFigure15.
3.Installhydrauliclinenumber1totheteetting
assembledtothesideofthevalve(Figure15).
4.Installthehydrauliclinenumber1totheupper
malecoupler(Figure15).
g003608
Figure15
1.Teettingonthesideof
thevalve
4.Uppermalecoupler
2.Valve5.Couplerbracket
3.Hydrauliclinenumber1
5.Positionhydrauliclinenumber2intothe
machineasshowninFigure16.
6.Installhydrauliclinenumber2totheteetting
assembledtothe90-degreeelbowandthetop
ofthevalve(Figure16).
7.Installhydrauliclinenumber2totheupper
femalecoupler(Figure16).
g003607
Figure16
1.Valve4.Upperfemalecoupler
2.Teettingassembledto
the90-degreeelbow
5.Couplerbracket
3.Hydrauliclinenumber2
8.Looselyinstallhydraulicline(hose)number5to
thelowermalecoupler(Figure17).
Note:Theotherendofthishosewillbe
installedinProcedure10.
9

g015919
Figure17
1.Hydrauliclinenumber14.Hydraulicline(hose)
number5
2.Couplerbracket5.Hydrauliccap
3.Lowermalecoupler
8
InstallingtheHydraulic
Pump
Partsneededforthisprocedure:
1Hydraulicpump
145-degreetting(maleends)
1Hubassembly
1Squarekey(1/4x1inch)
4Setscrew(5/16x3/4inch)
1Pumpbracket
2Bolt(withthread-lockingcompound)(5/16x3/4inch)
2Washer(3/8inch)
1Large90-degreeelbow(withhosebarbedend)
Procedure
1.Installthelargesquare90-degreeelbowtothe
sideofthehydraulicpump.
2.Installthe45-degreeelbowtothesideofthe
hydraulicpump(Figure18).
g003611
Figure18
1.45-degreeelbow4.Maleend
2.Hydraulicpump5.Femaleend
3.Large90-degreeelbow
(withhosebarbedend)
3.RemovetheexistingcoverovertheenginePTO
(powertakeoff).
4.Installthepumpbrackettotheenginewith2
bolts(5/16x3/4inch)and2washers(3/8inch).
RefertoFigure19forthecorrectpositionto
installthepumpbracket.
g003818
Figure19
1.Engine4.Washer(3/8inch)
2.EnginePTOshaft5.Bolt(5/16x3/4inch)
3.Pumpbracket
5.Applyanti-seizecompoundtotheenginePTO
(powertakeoff)shaftandthehydraulicmotor
shaft.
6.Installthesquarekey(1/4x1inch)intotheslot
intheenginePTOshaft(Figure20).
10

7.Alignthehubassemblywiththesquarekeyand
installitontotheenginePTO(powertakeoff)
shaft(Figure20).
Note:Makesurethatthehubassemblyis
totallybottomedoutontheshaft.
8.Applyremovablethread-lockingcompoundto
the2setscrews(5/16x3/4inch)andinstall
themintothehubassemblytosecureittothe
PTOshaft(Figure20).
g003610
Figure20
1.Pumpbracket4.Setscrew(5/16x3/4inch)
2.EnginePTOshaft5.Hubassembly
3.Squarekey(1/4x1inch)
9.Installthepumpplatestudintothepumpbracket
whileinstallingthehydraulicpumpshaftintothe
hubassembly.
Note:Thehydraulicpumpshaftwilltouchthe
endoftheenginePTOshaft(Figure21).
g003612
Figure21
1.Pumpbracket4.Hubassembly
2.Pumpplatestud5.Hydraulicpumpshaft
3.Pumpplate6.Setscrew(5/16x3/4inch)
10.Thehubassemblyneedstobetotallyseated
ontheshaft.
Note:Verifythatthereisagapbetweenthe
pumpplateandthehubassembly.Ifthereis
nogap,thenthehubassemblyisnotinstalled
correctlyandneedstobeseatedcorrectly
(Figure22).
g003606
Figure22
1.Pumpplate3.1.0to3.1mm(0.040to
0.122inch)gapbetween
hubassemblyandpump
plate
2.Hubassembly
11

11.Applyremovablethread-lockingcompoundto
the2setscrews(5/16x3/4inch)andinstallthem
intothehubassemblytosecurethehydraulic
pumpshaft(Figure21).
9
InstallingHydraulicLines3
and4
Partsneededforthisprocedure:
1Hydrauliclinenumber3
1Hydrauliclinenumber4
Procedure
Note:Installallhydrauliclineslooselyrstandthen
tightenthemwhenalleverythingisinstalled.
UseFigure23asakeyforidentifyingthecorrect
hydrauliclines.
g015920
Figure23
1.Hydrauliclinenumber14.Hydrauliclinenumber4
2.Hydrauliclinenumber25.Hydrauliclinenumber5
3.Hydrauliclinenumber3
1.Installtheexistinghosesbackontothehydraulic
tank.
2.Installthehydraulictanktotheframeandsecure
itwiththe3bracketspreviouslyremovedand
loosened(Figure24).
g003575
Figure24
1.Hydraulictank4.Nut
2.Bolt5.Sidebracket
3.Topbracket6.Washer
3.Installhydrauliclinenumber4totheteetting
assembledtothesideofthevalve(Figure25).
g016164
Figure25
1.Small90-degreeteewith
barbinhydraulictank
4.Teetting
2.Hydrauliclinenumber45.Hydraulictank
3.Valve
4.Positionhydrauliclinenumber3intothe
machineasshowninFigure26.
5.Installhydrauliclinenumber3tothelarge
90-degreeelbowinstalledtothestrainerand
hydraulictank(Figure26andFigure31).
12

g003582
Figure26
1.Hydraulictank4.Hydrauliclinenumber3
2.Couplerbracket5.Machineframe
3.Large90-degreeelbow
installedintank
10
InstallingtheHydraulic
Hoses
Partsneededforthisprocedure:
1Largehydraulichose
1Hydraulichosewithttings
2Largehoseclamp
2Smallhoseclamp
1Smallmoldedhydraulichose
1R-clamp
1Bolt(5/16x7/8inch)
1Flangenut(5/16inch)
Procedure
Note:Makesurethatnothingrubsagainstanyhoses.
1.Slidethe2largehoseclampsontothelarge
hydraulichose.
2.Installthelargehydraulichosetothe90-degree
elbowinstalledtothesideofthehydraulicpump
(Figure27andFigure31).
3.Tightenahoseclamparoundthehoseand
elbow(Figure27).
4.Installthelargehydraulichosetohydraulicline
number3(Figure27).
5.Tightenthehoseclamparoundthehoseand
hydrauliclinenumber3(Figure27).
g003614
Figure27
1.Hydrauliclinenumber34.Hydraulicpump
2.Hoseclamp5.90-degreeelbow
3.Largehydraulichose6.Hoseclamp
6.InstallanR-clampontothelargehydraulichose
asshowninFigure28.
g003615
Figure28
1.Nut(3/8inch)3.Bolt(3/8x3/4inch)
2.R-clamp4.Retainerbracket
7.InstalltheR-clamptotheretainerbracketwitha
bolt(5/16x7/8inch)andanut(5/16inch);refer
toFigure28.
13

8.Installthehydraulichosewithttingstothe
ttingonhydrauliclinenumber2asshownin
Figure29.
g219889
Figure29
1.Valve3.Hydraulichosewithttings
2.Fittingonhydraulicline
number2
9.Installthehydraulichosewithttingstothe
45-degreeelbowattachedtothehydraulicpump
(Figure30andFigure31).
Note:Itwillbebelowthehydrauliccylinder.
g003613
Figure30
1.Fittingonhydraulicline
number2
3.45-degreeelbow
2.Hydraulichosewithttings4.Hydraulicpump
10.RefertoFigure31forthecorrectlocationsofthe
hosesandhydrauliclinestothehydraulicpump.
g003840
Figure31
1.Hydrauliclinenumber34.Largehydraulichose
2.Hydraulichosewithttings5.Hydraulicpump
3.Machineframetube6.Couplerbracket
11.Slidethe2smallhoseclampsontothesmall
moldedhydraulichose(Figure32).
12.Installthelonglegofthemoldedhoseontothe
90-degreeteeinthehydraulictank(Figure32).
13.Installtheshortlegofthemoldedhoseontothe
barbendofhydrauliclinenumber4(Figure32).
14.Tightenthetwosmallhoseclampsoneachend
ofthemoldedhose.
15.Looselyinstallthehydraulicline(hose)number
5tothesmall90-degreetee(Figure32).
14

g018784
Figure32
1.Small90-degreeteewith
barbinhydraulictank
4.Hydrauliclinenumber4
2.Smallhoseclamp5.Hydraulicline(hose)
number5
3.Smallmoldedhose
11
TighteningAllConnections
NoPartsRequired
Procedure
Note:Makesurethatthehosesandhydrauliclines
areroutedawayfromandtodonotrubagainstany
sharp,hot,ormovingcomponents.
1.Whenallhydrauliclinesandhosesareinstalled,
tightenalloftheconnections.
Note:Useabackupwrenchonalltankttings.
2.Positionthecouplerbracketasclosetotheleft
tireaspossibleandtightentheclamps.
12
InstallingtheSwitchand
Harness
Partsneededforthisprocedure:
1Harness
1Switch
1Fuse
Procedure
1.Removethecontrolpanelfromthemachine.
2.Removetheplasticplugfromthepaneland
installtheswitchtothepanel(Figure35).
3.Routetheharnessalongtheseathingefromthe
switchandtotherelaypreviouslyinstalledto
thevalve(Figure33).
g003649
Figure33
1.Smallconnector5.Mainharnessconnector
2.Squareconnector6.Switchconnector
3.Seathinges7.Cabletie
4.Fuseblock
4.Installtheharnesstotheswitchinthecontrol
panel(Figure35).
5.Removethejumperwirefromthemainharness
underthecontrolpanel(Figure34).
15

g005083
Figure34
1.Mainharnessconnector2.Jumperwire
6.Installthemainharnessconnectortothemain
harness(Figure35).
7.Installthecontrolpaneltothemachine.
g003648
Figure35
1.Switch4.Switchconnector
2.Screw5.Mainharnessconnector
3.Controlpanel
Installthefuseintorightslotinthefuseblock
(Figure33).
8.Installthesquareconnectortotherelayinstalled
nextwiththevalve(Figure36).
9.Installthesmallconnectortothevalve(Figure
36).
10.Fastenthewireharnesstothevalvewitha
cabletie.
g003620
Figure36
1.Valve4.Cabletie
2.Smallconnector5.Relay
3.Diode6.Squareconnector
13
InstallingtheHydraulic
FluidandCheckingfor
Leaks
Partsneededforthisprocedure:
1Dipstick
25.5L
(6-3/4
US
gallons)
Hydraulicuid
Procedure
Thehydraulicsystemcapacityisnow25.5L(6-3/4
USgallons).
RefertotheOperator'sManualforthecorrectuid
touse.
1.Removetheolddipstickfromthehydraulictank
anddiscard.
2.Slowlypourapproximately80%ofthespecied
uidintothetank.
16

3.Insertthenewdipstickandcheckthelevelof
thehydraulicuid(Figure37).
4.Slowlyaddtheadditionaluidtobringittothe
Fullmark.
g003618
Figure37
1.Hydraulic-tankcap3.Hydraulictank
2.Dipstick
5.Startthemachineandletitrunfor5minutes.
6.Checkforanyleaksinthesystemwithapiece
ofcardboard.
WARNING
Hydraulicuidescapingunderpressure
canpenetrateskinandcauseinjury.
Ifhydraulicuidisinjectedintotheskin
itmustbesurgicallyremovedwithina
fewhoursbyadoctorfamiliarwiththis
typeofinjury.Gangrenemayresultif
thisisnotdone.
•Keepbodyandhandsawayfrom
pin-holeleaksornozzlesthateject
high-pressurehydraulicuid.
•Usecardboardorpapertond
hydraulicleaks.
•Safelyrelieveallpressureinthe
hydraulicsystembeforeperforming
anyworkonthehydraulicsystem.
•Makesurethatallhydraulic-uid
hosesandlinesareingoodcondition
andthatallhydraulicconnections
andttingsaretightbeforeapplying
pressuretothehydraulicsystem.
7.Installtheleftfrontscreentotheframe.
8.Installthefrontshroudtotheframewith4
ange-headscrews.
9.Installthe4ange-headscrewssecuringtheleft
wheelshroudtotheframe(Figure38).
10.Installtheleftreartire(Figure38).
g003581
Figure38
1.Leftwheelshroud3.Lefttire
2.Flange-headscrews4.Nut
11.Lowerthemachineontotheground.
12.Installtherearhitchshield.
13.Installtheair-cleanerassembly.
17

DeclarationofIncorporation
TheT oroCompany,8111LyndaleAve.South,Bloomington,MN,USAdeclaresthatthefollowingunit(s)
conform(s)tothedirectiveslisted,wheninstalledinaccordancewiththeaccompanyinginstructionsontocertain
ToromodelsasindicatedontherelevantDeclarationsofConformity.
ModelNo.SerialNo.ProductDescriptionInvoiceDescriptionGeneralDescriptionDirective
08781315000001andUpRearRemoteHydraulicKitREARREMOTE
HYDRAULICSScarier2006/42/EC
RelevanttechnicaldocumentationhasbeencompiledasrequiredperPartBofAnnexVIIof2006/42/EC.
Wewillundertaketotransmit,inresponsetorequestsbynationalauthorities,relevantinformationonthispartly
completedmachinery.Themethodoftransmissionshallbeelectronictransmittal.
ThismachineryshallnotbeputintoserviceuntilincorporatedintoapprovedToromodelsasindicatedonthe
associatedDeclarationofConformityandinaccordancewithallinstructions,wherebyitcanbedeclaredin
conformitywithallrelevantDirectives.
Certied:AuthorizedRepresentative:
MarcelDutrieux
ManagerEuropeanProductIntegrity
ToroEuropeNV
Nijverheidsstraat5
2260Oevel
Belgium
JohnHeckel
Sr.EngineeringManagerTel.+3216386659
8111LyndaleAve.South
Bloomington,MN55420,USA
June19,2017

EuropeanPrivacyNotice
TheInformationT oroCollects
ToroWarrantyCompany(T oro)respectsyourprivacy.Inordertoprocessyourwarrantyclaimandcontactyouintheeventofaproductrecall,weaskyou
tosharecertainpersonalinformationwithus,eitherdirectlyorthroughyourlocalTorocompanyordealer.
TheT orowarrantysystemishostedonserverslocatedwithintheUnitedStateswhereprivacylawmaynotprovidethesameprotectionasapplies
inyourcountry.
BYSHARINGYOURPERSONALINFORMATIONWITHUS,YOUARECONSENTINGTOTHEPROCESSINGOFYOURPERSONALINFORMATION
ASDESCRIBEDINTHISPRIVACYNOTICE.
TheWayT oroUsesInformation
Toromayuseyourpersonalinformationtoprocesswarrantyclaims,tocontactyouintheeventofaproductrecallandforanyotherpurposewhichwetell
youabout.ToromayshareyourinformationwithToro'safliates,dealersorotherbusinesspartnersinconnectionwithanyoftheseactivities.Wewillnot
sellyourpersonalinformationtoanyothercompany.Wereservetherighttodisclosepersonalinformationinordertocomplywithapplicablelawsand
withrequestsbytheappropriateauthorities,tooperateoursystemsproperlyorforourownprotectionorthatofotherusers.
RetentionofyourPersonalInformation
Wewillkeepyourpersonalinformationaslongasweneeditforthepurposesforwhichitwasoriginallycollectedorforotherlegitimatepurposes
(suchasregulatorycompliance),orasrequiredbyapplicablelaw.
Toro'sCommitmenttoSecurityofY ourPersonalInformation
Wetakereasonableprecautionsinordertoprotectthesecurityofyourpersonalinformation.Wealsotakestepstomaintaintheaccuracyandcurrent
statusofpersonalinformation.
AccessandCorrectionofyourPersonalInformation
Ifyouwouldliketorevieworcorrectyourpersonalinformation,pleasecontactusbyemailat[email protected].
AustralianConsumerLaw
AustraliancustomerswillnddetailsrelatingtotheAustralianConsumerLaweitherinsidetheboxoratyourlocalT oroDealer.
374-0282RevC

TheToroWarranty
ATwo-YearLimitedWarranty
ConditionsandProductsCovered
TheToroCompanyanditsafliate,T oroWarrantyCompany,pursuant
toanagreementbetweenthem,jointlywarrantyourT oroCommercial
product(“Product”)tobefreefromdefectsinmaterialsorworkmanship
fortwoyearsor1500operationalhours*,whicheveroccursrst.This
warrantyisapplicabletoallproductswiththeexceptionofAerators
(refertoseparatewarrantystatementsfortheseproducts).Wherea
warrantableconditionexists,wewillrepairtheProductatnocosttoyou
includingdiagnostics,labor,parts,andtransportation.Thiswarranty
beginsonthedatetheProductisdeliveredtotheoriginalretailpurchaser.
*Productequippedwithanhourmeter.
InstructionsforObtainingWarrantyService
YouareresponsiblefornotifyingtheCommercialProductsDistributoror
AuthorizedCommercialProductsDealerfromwhomyoupurchasedthe
Productassoonasyoubelieveawarrantableconditionexists.Ifyouneed
helplocatingaCommercialProductsDistributororAuthorizedDealer,or
ifyouhavequestionsregardingyourwarrantyrightsorresponsibilities,
youmaycontactusat:
ToroCommercialProductsServiceDepartment
ToroWarrantyCompany
8111LyndaleAvenueSouth
Bloomington,MN55420-1196
952–888–8801or800–952–2740
E-mail:[email protected]
OwnerResponsibilities
AstheProductowner,youareresponsibleforrequiredmaintenanceand
adjustmentsstatedinyourOperator'sManual.Failuretoperformrequired
maintenanceandadjustmentscanbegroundsfordisallowingawarranty
claim.
ItemsandConditionsNotCovered
Notallproductfailuresormalfunctionsthatoccurduringthewarranty
periodaredefectsinmaterialsorworkmanship.Thiswarrantydoesnot
coverthefollowing:
•Productfailureswhichresultfromtheuseofnon-Tororeplacement
parts,orfrominstallationanduseofadd-on,ormodiednon-T oro
brandedaccessoriesandproducts.Aseparatewarrantymaybe
providedbythemanufactureroftheseitems.
•Productfailureswhichresultfromfailuretoperformrecommended
maintenanceand/oradjustments.Failuretoproperlymaintainyour
ToroproductpertheRecommendedMaintenancelistedinthe
Operator’sManualcanresultinclaimsforwarrantybeingdenied.
•ProductfailureswhichresultfromoperatingtheProductinanabusive,
negligent,orrecklessmanner.
•Partssubjecttoconsumptionthroughuseunlessfoundtobedefective.
Examplesofpartswhichareconsumed,orusedup,duringnormal
Productoperationinclude,butarenotlimitedto,brakepadsand
linings,clutchlinings,blades,reels,rollersandbearings(sealedor
greasable),bedknives,sparkplugs,castorwheelsandbearings,tires,
lters,belts,andcertainsprayercomponentssuchasdiaphragms,
nozzles,andcheckvalves,etc.
•Failurescausedbyoutsideinuence.Conditionsconsideredtobe
outsideinuenceinclude,butarenotlimitedto,weather,storage
practices,contamination,useofunapprovedfuels,coolants,lubricants,
additives,fertilizers,water,orchemicals,etc.
•Failureorperformanceissuesduetotheuseoffuels(e.g.gasoline,
diesel,orbiodiesel)thatdonotconformtotheirrespectiveindustry
standards.
•Normalnoise,vibration,wearandtear,anddeterioration.
•Normal“wearandtear”includes,butisnotlimitedto,damagetoseats
duetowearorabrasion,wornpaintedsurfaces,scratcheddecalsor
windows,etc.
Parts
Partsscheduledforreplacementasrequiredmaintenancearewarranted
fortheperiodoftimeuptothescheduledreplacementtimeforthatpart.
Partsreplacedunderthiswarrantyarecoveredforthedurationofthe
originalproductwarrantyandbecomethepropertyofToro.Torowillmake
thenaldecisionwhethertorepairanyexistingpartorassemblyorreplace
it.Toromayuseremanufacturedpartsforwarrantyrepairs.
DeepCycleandLithium-IonBatteryWarranty:
DeepcycleandLithium-Ionbatterieshaveaspeciedtotalnumberof
kilowatt-hourstheycandeliverduringtheirlifetime.Operating,recharging,
andmaintenancetechniquescanextendorreducetotalbatterylife.Asthe
batteriesinthisproductareconsumed,theamountofusefulworkbetween
chargingintervalswillslowlydecreaseuntilthebatteryiscompletelyworn
out.Replacementofwornoutbatteries,duetonormalconsumption,
istheresponsibilityoftheproductowner.Batteryreplacementmaybe
requiredduringthenormalproductwarrantyperiodatowner’sexpense.
Note:(Lithium-Ionbatteryonly):ALithium-Ionbatteryhasapartonly
proratedwarrantybeginningyear3throughyear5basedonthetime
inserviceandkilowatthoursused.RefertotheOperator'sManualfor
additionalinformation.
MaintenanceisatOwner’sExpense
Enginetune-up,lubrication,cleaningandpolishing,replacementoflters,
coolant,andcompletingrecommendedmaintenancearesomeofthe
normalservicesT oroproductsrequirethatareattheowner’sexpense.
GeneralConditions
RepairbyanAuthorizedT oroDistributororDealerisyoursoleremedy
underthiswarranty.
NeitherTheToroCompanynorToroWarrantyCompanyisliablefor
indirect,incidentalorconsequentialdamagesinconnectionwiththe
useoftheToroProductscoveredbythiswarranty,includingany
costorexpenseofprovidingsubstituteequipmentorserviceduring
reasonableperiodsofmalfunctionornon-usependingcompletion
ofrepairsunderthiswarranty.ExceptfortheEmissionswarranty
referencedbelow,ifapplicable,thereisnootherexpresswarranty.All
impliedwarrantiesofmerchantabilityandtnessforusearelimitedto
thedurationofthisexpresswarranty.
Somestatesdonotallowexclusionsofincidentalorconsequential
damages,orlimitationsonhowlonganimpliedwarrantylasts,sotheabove
exclusionsandlimitationsmaynotapplytoyou.Thiswarrantygivesyou
speciclegalrights,andyoumayalsohaveotherrightswhichvaryfrom
statetostate.
Noteregardingenginewarranty:
TheEmissionsControlSystemonyourProductmaybecoveredby
aseparatewarrantymeetingrequirementsestablishedbytheU.S.
EnvironmentalProtectionAgency(EPA)and/ortheCaliforniaAirResources
Board(CARB).Thehourlimitationssetforthabovedonotapplytothe
EmissionsControlSystemWarranty.RefertotheEngineEmissionControl
WarrantyStatementsuppliedwithyourproductorcontainedintheengine
manufacturer’sdocumentationfordetails
CountriesOtherthantheUnitedStatesorCanada
CustomerswhohavepurchasedToroproductsexportedfromtheUnitedStatesorCanadashouldcontacttheirT oroDistributor(Dealer)toobtain
guaranteepoliciesforyourcountry,province,orstate.IfforanyreasonyouaredissatisedwithyourDistributor'sserviceorhavedifcultyobtaining
guaranteeinformation,contacttheToroimporter.374-0253RevD
