Toshiba CANVIO AEROMOBILE User manual

GMAA00469014
594111-A3
12/15
English/Español/Français
TOSHIBA
Canvio AeroMobile™
Wireless Solid State
Drive User's Manual

Important notice for security
English
Please be sure to change the default Wi-Fi password and the
default Admin password immediately upon rst usage of the
product. To set your unique password, please refer to this user
manual on your applicable regional support site.
The default password is automatically set upon shipping of the
product. Even if the default password is changed to your unique
password, your unique password may be reset to a default
password in the following situation:
In case the product is reset by depressing the Reset button to
accomplish a reset of the product.
Aviso importante de seguridad
Español
Asegúrese de cambiar la contraseña predeterminada de Wi-
Fi y la contraseña predeterminada de administrador de forma
inmediata cuando use el producto por primera vez. Para
congurar la contraseña personal, consulte este manual del
usuario en su correspondiente sitio de soporte regional.
La contraseña predeterminada se congura automáticamente
cuando se envía el producto. Aun si cambia la contraseña
predeterminada a su contraseña personal, su contraseña personal
se puede volver a congurar a la contraseña predeterminada en
la siguiente situación:
Si se reinicia el producto presionando el botón Reiniciar para reiniciar
el producto.
Remarque importante
concernant la sécurité
Français
Veuillez vous assurer de changer le mot de passe Wi-Fi par défaut
et le mot de passe Admin par défaut dès la première utilisation du
produit. Pour dénir votre mot de passe unique, veuillez consulter ce
manuel d’utilisation sur votre site de support régional.
Le mot de passe par défaut est automatiquement déni lors de
l’expédition du produit. Même si vous changé votre mot de passe par
défaut par votre mot de passe unique, celui-ci peut être réinitialisé à
un mot de passe par défaut dans la situation suivante:
Lorsque le produit est réinitialisé en appuyant sur le bouton Reset
pour effectuer une réinitialisation du produit.

2
California Prop 65 Warning
This product contains chemicals, including lead, known to
the State of California to cause cancer and birth defects or
other reproductive harm. Wash hands after handling.
For the state of California only.
Safety information and Rules and
Regulations for wireless LAN
Do not use the Wireless LAN functionality near a microwave
oven or in areas subject to radio interference or magnetic
fields. Interference from a microwave oven or other source
can disrupt Wireless LAN operation.
The transmission speed over the wireless LAN, and the
distance over which the wireless LAN can reach, may vary
depending on surrounding electromagnetic environment,
obstacles, access point design and configuration, client
design and software/hardware configurations. The
transmission rate described is the theoretical maximum
speed as specified under the appropriate standard – the
actual transmission speed will be lower than the theoretical
maximum speed.
Federal Communications Commission
(FCC) Notice (USA)
Complies with FCC RF Exposure requirements.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
❖Reorient or relocate the receiving antenna.
NOTE
NOTE

3
❖Increase the separation between the equipment and the receiver.
❖Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
❖Consult the dealer or an experienced radio or television technician
for help.
Changes or modifications to this equipment not expressly approved by
Toshiba or parties authorized by Toshiba could void the user's authority to
operate this equipment.
Declaration of Conformity for Products
Marked with the FCC Logo (USA)
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including
interference that may cause undesired operation.
SAR information
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps
qu’aucune autre antenne ou émetteur.
Canadian Notice
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit
pas produire de brouillage; (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.

4
To comply with the Canadian RF exposure compliance
requirements, this device and its antenna must not be co-
located or operating in conjunction with any other antenna or
transmitter.
Pour être conforme aux exigences canadiennes en matière
d’exposition aux fréquences radio, l’appareil et son antenne
ne doivent pas être situés au même endroit qu’une autre
antenne ou un autre émetteur ni fonctionner en même
temps.
Copyright
This manual may not be reproduced in any form without the prior written
permission of Toshiba. No liability is assumed with respect to the use of the
information contained herein.
© 2015 by Toshiba America Information Systems, Inc. All rights reserved.
Notice
The information contained in this manual, including but not limited to any
product specifications, is subject to change without notice.
TOSHIBA CORPORATION AND TOSHIBA AMERICA INFORMATION
SYSTEMS, INC. “TOSHIBA” PROVIDE NO WARRANTY WITH REGARD
TO THIS MANUAL OR ANY OTHER INFORMATION CONTAINED
HEREIN AND HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY
PARTICULAR PURPOSE WITH REGARD TO ANY OF THE FOREGOING.
TOSHIBA ASSUMES NO LIABILITY FOR ANY DAMAGES INCURRED
DIRECTLY OR INDIRECTLY FROM ANY TECHNICAL OR
TYPOGRAPHICAL ERRORS OR OMISSIONS CONTAINED HEREIN OR
FOR DISCREPANCIES BETWEEN THE PRODUCT AND THE MANUAL.
IN NO EVENT SHALL TOSHIBA BE LIABLE FOR ANY INCIDENTAL,
CONSEQUENTIAL, SPECIAL, OR EXEMPLARY DAMAGES, WHETHER
BASED ON TORT, CONTRACT OR OTHERWISE, ARISING OUT OF OR
IN CONNECTION WITH THIS MANUAL OR ANY OTHER INFORMATION
CONTAINED HEREIN OR THE USE THEREOF.

5
GNU General Public License (“GPL”)
Firmware incorporated into this product may include third party copyrighted
software licensed under the GPL or Lesser General Public License (“LGPL”)
(collectively, “GPL Software”) and not Toshiba's End User License Agreement.
A copy of that license may be obtained at http://www.gnu.org, and http://
support.toshiba.com. You may obtain, for a period of three years after the date
of purchase, the complete Corresponding Source code from us by
downloading at no charge from http://support.toshiba.com or by calling
Toshiba Customer Support. With respect solely to the GPL Software, no
warranty is provided, to the extent permitted by applicable law. Modification of
or tampering with the Software is solely at your own risk and will void the
product warranty. Toshiba is not responsible for any such modification or
tampering. Toshiba will not support any product in which you have or have
attempted to modify the Software supplied by Toshiba.
Third party services and other Internet services are not provided by Toshiba,
may change or be discontinued at any time and may be subject to internet
service provider restrictions. Toshiba makes no warranties, representations, or
assurances about the content, availability, compatibility or functionality of
third-party content or services. Use of third party Internet services may require
the creation of a separate account and payment of one-time and/or recurring
charges.
Protection of stored data
For your important data, please make periodic back-up copies of all the data
stored on the hard disk or other storage devices as a precaution against
possible failures, alteration, or loss of the data. IF YOUR DATA IS ALTERED
OR LOST DUE TO ANY TROUBLE, FAILURE OR MALFUNCTION OF
THE STORAGE DEVICES AND THE DATA CANNOT BE RECOVERED,
TOSHIBA SHALL NOT BE LIABLE FOR ANY DAMAGE OR LOSS OF
DATA, OR ANY OTHER DAMAGE RESULTING THEREFROM. WHEN
COPYING OR TRANSFERRING YOUR DATA, PLEASE BE SURE TO
CONFIRM WHETHER THE DATA HAS BEEN SUCCESSFULLY COPIED
OR TRANSFERRED. TOSHIBA DISCLAIMS ANY LIABILITY FOR THE
FAILURE TO COPY OR TRANSFER THE DATA CORRECTLY.

6
Critical Applications
This product you have purchased is not designed for any “critical
applications.” “Critical applications” means life support systems, medical
applications, connections to implanted medical devices, commercial
transportation, nuclear facilities or systems or any other applications where
product failure could lead to injury to persons or loss of life or catastrophic
property damage. ACCORDINGLY, TOSHIBA, ITS AFFILIATES AND
SUPPLIERS DISCLAIM ANY AND ALL LIABILITY ARISING OUT OF THE
USE OF THE COMPUTER PRODUCTS IN ANY CRITICAL
APPLICATIONS. IF YOU USE THE PRODUCT IN A CRITICAL
APPLICATION, YOU, AND NOT TOSHIBA, ASSUME FULL
RESPONSIBILITY FOR SUCH USE.
Trademarks
Canvio and Canvio AeroMobile are trademarks of Toshiba America Information
Systems, Inc.
Android and Google Play are trademarks of Google Inc.
DLNA is a trademark or a registered trademark of the Digital Living Network
Alliance.
Facebook is a registered trademark of Facebook, Inc.
iOS is a registered trademark or trademark of Cisco Systems, Inc. and/or its
affiliates in the United States and certain other countries.
Mac, Mac OS, iPad, iPhone, OS X, and Time Machine are trademarks of Apple
Inc., registered in the U.S. and other countries. App Store is a service mark of
Apple Inc.
SD, SDHC, and SDXC are trademarks of SD-3C, LLC.
Twitter is a registered trademark of Twitter, Inc.
Wi-Fi®is a registered trademark of the Wi-Fi Alliance®.
Windows is either a registered trademark or trademark of Microsoft
Corporation in the United States and other countries.
All other brand and product names are trademarks or registered trademarks of
their respective companies.

7
Safety icons
This manual contains safety instructions that must be observed to
avoid potential hazards that could result in personal injuries, damage
to your equipment, or loss of data. These safety cautions have been
classified according to the seriousness of the risk, and icons
highlight these instructions as follows:
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if
not avoided, may result in property damage.
Provides important information.
Safety precautions
Do not immerse the device (with the internal battery
in it) in liquid such as water, beverages, or other
fluids.
The battery (including protection circuit) may catch
on fire, smoke, explode, or cause heat generation
by unexpected electrical load.
Do not use device in a wet location. Do not
connect/disconnect a power plug/cord with wet
hands.
Keep the device (with the internal battery in it) away from
heat and fire. Heat will damage the battery and may
cause it to generate heat, smoke, catch fire, or explode.
NOTE

8
Do not disassemble, modify, tamper with, or repair
your device and/or the internal battery. Disassembly or
modification of the device and/or battery may damage
the protection circuit. This may cause the battery to
generate heat, smoke, catch fire, or explode.
Do not leave parts such as plastic covers, battery,
and electrical plug within the reach of children and
pets. Misuse of the part including, without limitation,
accidental swallowing the part may cause choking
and suffocation resulting in death or serious injury. If
you suspect a part has been swallowed, immediately
take appropriate emergency action and consult a
doctor.
Stop charging if the charging process cannot be finished.
If the battery can not finish the charging process
within the specified time, halt the charging process.
The battery may generate heat, smoke, catch fire, or
explode.
Discard this device in accordance with applicable laws
and regulations. For disposal, reuse or recycling
information, please contact your local government.
Always immediately turn the power off and
disconnect the power cable/cord plug from the plug
socket and stop using the device if you observe any
of the following conditions: Offensive or unusual
odor/Excessive heat/Discoloration/Deformation,
crack, or leaks/Smoke/Other unusual event during
use, such as abnormal sound. Do not turn on the
device’s power again. Continued use could cause a
fire or rupture possibly resulting in serious injury or
drive failure, including but not limited to, the loss of
data.
If the device is leaking or its case is cracked, put on
protective gloves to handle it.

9
Only operate the device and/or charge the battery in
temperatures between 5 to 35º C (41 to 95º F).
Operating and/or charging the device outside of this
temperature range may result in the loss of data or
damage to the drive. Charging the device outside of
this temperature range may cause the battery to leak,
generate heat, or result in serious damage. It may
also cause the battery's performance and life to
deteriorate.
Actual battery life may vary depending on settings,
application usage, features or tasks selected, network
configuration, operating temperature and many other
factors. Recharge time varies depending on usage. The
battery may not charge while the drive is consuming full
power. After a period of time, the battery will lose its
ability to perform at maximum capacity. This is normal for
all batteries.
Additional Safety Precautions
Failure to observe any of the following instructions may result in risk
of fire, electric shock, serious bodily injury and/or damage to your
device.
Service Provider
Disconnect device from the electrical outlet and
take device to an authorized Toshiba service
provider if:
❖AC adapter or power cable/cord is damaged.
❖Liquid has spilled into device or an object (such
as a screw, staple or paper clip) has entered
device.
❖Device has been dropped, subject to shock or
impact and/or damaged in some way.
❖Noticeable signs of overheating, smoke,
deformation, cracks, leaks or unusual odor occur.
❖Service is needed on component inside
compartments requiring opening or removal of
covers.
NOTE

10
❖Always use power cables/cords and power
sources that comply with the voltage and
frequency specifications and requirements of the
country of use.
❖Be careful if you use a multiple connector as an
overload of one socket could cause a fire or
electric shock, possibly resulting in serious injury.
❖Always confirm that the power plug (and
extension cable plug if used) has been fully
inserted into the socket, to ensure a secure
electrical connection.
❖Always make sure the drive and AC adapter have
adequate ventilation and are protected from
overheating when the AC adapter is connected to
a power outlet. Do not cover the drive during
operation. Inadequate ventilation may cause the
drive and AC adapter to overheat resulting in a
fire or electric shock and serious injury.
❖If dust gets on the power plug connectors or
connector base, turn the power off and
disconnect the power plug. Then clean the
connector and/or connector base with a dry soft
cloth.
❖Avoid extended contact between the drive and
your skin. The drive may become hot! Avoid
prolonged contact to prevent skin irritation and/or
heat injury.
❖Never pull on a power cord/cable to remove a
plug from a socket. Always grasp the plug
directly.
❖Do not place the drive on a shaky table, uneven,
tilted surface or other unstable location. The drive
may fall, causing damage to the drive or possible
injury.

11
❖Do not disconnect the USB cable or the AC
adapter while operating, as it may result in loss of
data or damage to the drive.
❖Do not bump, drop or jar the drive, as it may
result in loss of data or damage to the drive.
❖Do not use the drive during a thunderstorm. If you
see lightning or hear thunder, immediately turn off
the devices to which this drive is connected,
computer and peripherals, and disconnect the
power cord from the outlet, and disconnect the
USB cable from the computer. An electric surge
caused by the lightning may result in loss of data
or damage to the drive.

12
Contents
Introduction.......................................................14
Overview .............................................................. 14
Components .................................................. 14
Hardware specifications ................................ 15
Software specifications.................................. 15
Chapter 1: Getting Started......................................17
Features ............................................................... 17
Charging the Canvio AeroMobile Wireless
Solid State Drive ........................................... 20
Connect to Canvio AeroMobile Wireless
Solid State Drive ............................................ 21
Connect with USB ......................................... 21
Connect wirelessly ......................................... 22
Chapter 2: Canvio AeroMobile Wireless Solid
State Drive Software Utility.................23
Wireless SSD for Toshiba System login .............. 23
Connect wirelessly to a PC/Mac.................... 23
Web browser login ......................................... 24
Client login for iPhone or iPad ...................... 24
Client login for Android .................................. 25
Wireless SSD for Toshiba main interface ............ 27

13
Contents
Web main interface ........................................ 28
Wireless SSD for Toshiba App main
interface ................................................... 28
Pictures Management interface........................... 30
Picture Viewer interface ................................. 31
Videos Management interface ............................. 32
Video Playback interface
(iPhone, iPad, and Android device
only).......................................................... 34
Music Management interface .............................. 35
Music Player interface
(iPhone, iPad, and Android device
only).......................................................... 37
Documents Management interface...................... 38
Document Viewer interface
(iPhone, iPad, and Android device
only).......................................................... 39
File/Folder Management interface ....................... 40
Transferring files............................................. 42
Chapter 3: Backup Management............................44
Using the Backup Management feature .............. 44
Manual backup .............................................. 44
Automatic backup.......................................... 45
Unmount the SD Card ......................................... 46
Chapter 4: Settings Management...........................47
Using the Settings Management ......................... 47
Configurations................................................ 48
DHCP Settings (Web browser only)..................... 57
User image and name management.................... 58
Cache (App only).................................................. 59
Language (App only) ............................................ 59
Logout.................................................................. 59
Contacting Toshiba.............................................. 59
Call Toshiba Customer Support Center......... 59
Index .................................................................60

14
Introduction
Overview
The Toshiba Canvio AeroMobile Wireless Solid State Drive allows
you to wirelessly access your music, videos, pictures, and data,
streaming it to your iPad, iPhone, tablets, smartphones, and
notebooks, no longer requiring you to tangle with cords or cables.
With the internal SSD storage, there is no need to worry about
running out of space on your mobile devices and the built-in USB 3.0
port makes file transfer fast and easy.
Components
The Canvio AeroMobile Wireless Solid State Drive includes the
following components:
❖AC adapter
❖USB 3.0 cable
❖Quick Start guide
❖Storage pouch
❖Standard Limited Warranty information

15
Introduction
Overview
Hardware specifications
Software specifications
Product dimension: 123.5 mm (L) x 63.0 mm (W) x 12.5 mm (H)
[4.9 in (L) x 2.5 in (W) x 0.5 in (H)]
Weight: Approximately 4.23 oz
Battery: 3100mAh Li-ion type
Charging time: 3 hours maximum
Environmental requirements:
Wireless LAN
Standard: 802.11 b/g/n
Frequency: 2.4 GHZ
Speed: 1T1R up to 150 Mbps
Temperature
Operating: 5 to 35º C (41 to 95º F)
Storage: -20 to 60º C (-4 to 140º F)
Humidity
Operating: 20-80%
Storage: 8-90%
Compatible file types:
Videos: mp4, 3gp, m4v, mov, avi
Music: mp3, m4a, aac, wav
Pictures: jpg, bmp, png, gif, tif
Documents: pdf, doc, docx, ppt, pptx, xls, xlsx, txt, rtf
Others: Opens in external software
System requirements:
Operating system
Windows®: Windows 7, Windows 8, Windows 8.1, Windows 10
Mac OS: OS X 10.7, 10.8
Android™, iPhone, or iPad: Android smartphones and tablets, iPhone, and iPads
are supported. Visit the “Wireless SSD for Toshiba”
app Web site for the supported versions.

16 Introduction
Overview
This drive is formatted in NTFS for Windows. When
using this drive with both Windows PC and Mac, you
can read and write data to both Windows PC and
Mac only if the “Tuxera NTFS for Mac” is installed on
the Mac. Under these conditions the Time Machine
function of the OS X is disabled.
NOTE

17
Chapter 1
Getting Started
Features
❖Built-in 128 GB SSD with NTFS format.
❖Access and stream your music, videos, pictures and data
using the free Wireless SSD for Toshiba app available for
iPhone, iPad, and Android.
❖Four user profiles available to help keep your files organized.
❖Connect wirelessly or using a USB 3.0 cable.
❖Enjoy up to 8 hours of continuous battery life in video
streaming condition (actual battery life may differ depending
on user conditions).
❖Quickly locate and access your files using the Search
function.
❖Access the Internet via wireless, supporting 802.11 b/g/n.
❖Supports SD™/SDHC™/SDXC™ memory card, Class 10
compatible.

18 Getting Started
Features
(Sample Illustration) Canvio AeroMobile Wireless Solid State
Drive features
On/Off button:
❖Press and hold for 2 seconds, (Wireless LAN mode turns
ON).
❖Press and hold for 2 seconds again, (Wireless LAN mode
turns OFF).
The Canvio AeroMobile Wireless Solid State Drive cannot
be turned on if the battery is too low. The battery
indicator will blink orange for 6 seconds, and then off.
Reset button:
❖In Wireless LAN mode, press and hold for 5 seconds. The
system will restore to its factory settings.
USB 3.0 port:
❖Compatible with USB 3.0 and USB 2.0.
❖Allows you to transfer data between a computer and the
Canvio AeroMobile Wireless Solid State Drive when
connected.
❖Allows you to charge the product battery when connected to
the AC adapter.
SD Card indicator light
Wi-Fi
®
/SSD indicator light
Battery indicator light
On/Off button
Reset button
USB 3.0 port
SD Card slot
NOTE

19
Getting Started
Features
SD Card slot:
❖Supports SD/SDHC/SDXC memory card, Class 10
compatible. Visit the “Wireless SSD for Toshiba” or the
“Wireless SSD for Toshiba Ver2” app Web site for the SDXC
Card supported versions.
❖You can access the SD Card in Wireless LAN mode.
Battery indicator light:
❖Green: There is 30% or more battery power.
❖Yellow: Between 30%-10% battery power remaining.
❖Orange (blinking fast): The product is out of battery power or
the operating temperature is too high. The product will shut
down after 30 seconds.
❖Green or Yellow (blinking slowly): The battery is charging.
❖Green (not blinking): Finished charging.
❖Green or Yellow (blinking fast): The product is shutting down
or turning ON.
❖LED Off: The device is powered OFF.
Wi-Fi/SSD indicator:
❖Wireless LAN Mode
❖Blue: Wireless LAN is ON (no data currently transmitting).
❖Blue (blinking): Wireless LAN is ON (storage access
available).
❖Blue (turned off): Wireless LAN is OFF.
❖USB Mode
❖White: No data currently transmitting.
❖White (blinking): Data access available.
❖White (turned off): The device is in Sleep or Standby
mode. It is safe to disconnect the device.
SD Card indicator:
❖Only glows in Wireless LAN Mode
❖Violet: No SD Card access.
❖Violet (blinking): SD Card access available.
❖Violet (turned off): SD Card enters into Standby.
