Toshiba G3 Plus Pack Installation and operating instructions

Date: December, 2007
Project No.: 60459-000
G3+ PACK
ASD OPERATION MANUAL
ADDENDUM
480 Volt Ratings

Manual’s Purpose and Scope
This addendum manual was written by the Toshiba Technical Publications Group. This group is tasked
with providing technical documentation for the G3+ Pack Adjustable Speed Drive. Every effort has
been made to provide accurate and concise information to you, our customer.
This addendum is to be used in conjunction with the G3 ASD Operation Manual. The two manuals
provide information on how to safely install, operate, and maintain your Toshiba power electronics
product. Read both manuals completely before installing, operating, or performing any form of
maintenance on this equipment.
This addendum and the accompanying drawings should be considered a permanent part of the
equipment and should be readily available for reference and review. Dimensions shown are in metric
and/or the English equivalent.
Toshiba International Corporation reserves the right, without prior notice, to update information; make
product changes; or to discontinue any product or service identified in this publication.
Toshiba International Corporation (TIC) shall not be liable for technical or editorial omissions or
mistakes in this manual. Nor shall it be liable for incidental or consequential damages resulting
from the use of information contained in this manual.
This addendum is copyrighted. No part of this addendum may be photocopied or reproduced in any
form without the prior written consent of Toshiba International Corporation.
© Copyright 2007 Toshiba International Corporation.
All rights reserved.
Printed in the U.S.A.
Contacting Toshiba’s Customer Support
Center
The Toshiba Customer Support Center can be contacted to obtain help in resolving any Adjustable
Speed Drive system problem that you may experience or to provide application information.
The center is open from 8 a.m. to 5 p.m. (CST), Monday through Friday. The Customer Support
Center’s toll free number is US [phone]/Fax [phone] — Canada [phone].
You may also contact Toshiba by writing to:
Toshiba International Corporation
13131 West Little York Road
Houston, Texas 77041-9990
Attn: ASD Product Manager.
For further information on Toshiba’s products and services, please visit our website at
www.Toshiba.Com/ind/.

Important Notice
The information contained within this addendum are not intended to cover all details or variations in
equipment types. Nor may it provide for every possible contingency concerning the installation,
operation, or maintenance of this equipment. Should additional information be required contact your
Toshiba representative.
The contents of this addendum shall not become a part of or modify any prior or existing agreement,
commitment, or relationship. The sales contract contains the entire obligation of Toshiba International
Corporation. The warranty contained in the contract between the parties is the sole warranty of Toshiba
International Corporation and any statements contained herein do not create new warranties or modify
the existing warranty.
Any electrical or mechanical modifications to this equipment without prior written consent of
Toshiba International Corporation will void all warranties and may void the UL/CUL listing or
other safety certifications. Unauthorized modifications may also result in a safety hazard or
equipment damage.
TOSHIBA INTERNATIONAL CORPORATION
Adjustable Speed Drive
Please complete the Warranty Card supplied with the ASD and return it to Toshiba by prepaid mail.
This will activate the 12 month warranty from the date of installation; but, shall not exceed 18 months
from the date of purchase.
Complete the following information about the drive and retain it for your records.
Model Number:
Serial Number:
Project Number (if applicable):
Date of Installation:
Inspected By:
Name of Application:
TOSHIBA INTERNATIONAL CORPORATION
Adjustable Speed Drive
Please complete the Warranty Card supplied with the ASD and return it to Toshiba by prepaid mail.
This will activate the 12 month warranty from the date of installation; but, shall not exceed 18 months
from the date of purchase.
Complete the following information about the drive and retain it for your records.
Model Number:
Serial Number:
Project Number (if applicable):
Date of Installation:
Inspected By:
Name of Application:

Table of Contents
G3+ Pack Addendum i
General Safety Information..............................................................................................1
Safety Alert Symbol.....................................................................................................1
Signal Words................................................................................................................1
Special Symbols ...........................................................................................................2
Equipment Warning Labels..........................................................................................2
Qualified Personnel......................................................................................................2
Equipment Inspection...................................................................................................3
Handling and Storage...................................................................................................3
Disposal........................................................................................................................3
Installation Precautions ....................................................................................................4
Location and Ambient Requirements...........................................................................4
Mounting Requirements...............................................................................................4
Conductor Routing and Grounding..............................................................................5
Power Connections.......................................................................................................5
Protection .....................................................................................................................6
System Integration Precautions .......................................................................................7
Personnel Protection.....................................................................................................7
System Setup Requirements.........................................................................................8
Operational and Maintenance Precautions.....................................................................9
Standard Specifications...................................................................................................10
Post-Reset Requirements................................................................................................12
G3+ Pack ASD Typical Wiring Diagram ..................................................................13
Part Numbering Convention..........................................................................................14
Ordering Information .................................................................................................14
Current/Voltage Specifications ......................................................................................15
Specifications for Cables and Terminals.......................................................................16
Dynamic Braking Resistor Wire/Cable Specifications..............................................18
Enclosure Dimensions .....................................................................................................19

G3+ Pack Addendum 1
General Safety Information
DO NOT attempt to install, operate, maintain or dispose of this equipment until you have read and
understood all of the product safety information and directions that are contained in this manual.
Safety Alert Symbol
The Safety Alert Symbol indicates that a potential personal injury hazard exists. The symbol is
comprised of an equilateral triangle enclosing an exclamation mark.
Signal Words
Listed below are the signal words that are used throughout this manual followed by their descriptions
and associated symbols. When the words DANGER, WARNING, and CAUTION are used in this
manual they will be followed by important safety information that must be carefully followed.
The word DANGER preceded by the safety alert symbol indicates that an imminently hazardous
situation exists that, if not avoided, will result in death or serious injury to personnel.
The word WARNING preceded by the safety alert symbol indicates that a potentially hazardous
situation exists that, if not avoided, could result in death or serious injury to personnel.
The word CAUTION preceded by the safety alert symbol indicates that a potentially hazardous
situation exists which, if not avoided, may result in minor or moderate injury.
The word CAUTION without the safety alert symbol indicates a potentially hazardous situation exists
which, if not avoided, may result in equipment and property damage.
DANGER
WARNING
CAUTION
CAUTION

2G3+ Pack Addendum
Special Symbols
To identify special hazards, other symbols may appear in conjunction with the DANGER, WARNING,
and CAUTION signal words. These symbols indicate areas that require special and/or strict adherence
to the procedures to prevent serious injury to personnel or death.
Electrical Hazard Symbol
A symbol which indicates a hazard of injury from electrical
shock or burn. It is comprised of an equilateral triangle
enclosing a lightning bolt.
Explosion Hazard Symbol
A symbol which indicates a hazard of injury from exploding
parts. It is comprised of an equilateral triangle enclosing an
explosion image.
Equipment Warning Labels
DO NOT attempt to install, operate, perform maintenance, or dispose of this equipment until you have
read and understood all of the product labels and user directions that are contained in this manual.
Warning labels that are attached to the equipment will include the exclamation mark within a triangle.
DO NOT remove or cover any of these labels. If the labels are damaged or if additional labels are
required, contact your Toshiba sales representative for additional labels.
Labels attached to the equipment are there to provide useful information or to indicate an imminently
hazardous situation that may result in serious injury, severe property and equipment damage, or death if
safe procedures or methods are not followed as outlined in this manual.
Qualified Personnel
Installation, operation, and maintenance shall be performed by Qualified Personnel Only. A Qualified
Person is one that has the skills and knowledge relating to the construction, installation, operation, and
maintenance of the electrical equipment and has received safety training on the hazards involved (Refer
to the latest edition of NFPA 70E for additional safety requirements).
Qualified Personnel shall:
• Have carefully read the entire manual.
• Be familiar with the construction and function of the ASD, the equipment being driven, and the
hazards involved.
• Be able to recognize and properly address hazards associated with the application of motor-driven
equipment.
• Be trained and authorized to safely energize, de-energize, ground, lockout/tagout circuits and
equipment, and clear faults in accordance with established safety practices.
• Be trained in the proper care and use of protective equipment such as safety shoes, rubber gloves,
hard hats, safety glasses, face shields, flash clothing, etc., in accordance with established safety
practices.
• Be trained in rendering first aid.
For further information on workplace safety visit www.osha.gov.

G3+ Pack Addendum 3
Equipment Inspection
• Upon receipt of the equipment inspect the packaging and equipment for shipping damage.
• Carefully unpack the equipment and check for parts that were damaged during shipping, missing
parts, or concealed damage. If any discrepancies are discovered, it should be noted with the carrier
prior to accepting the shipment, if possible. File a claim with the carrier if necessary and
immediately notify your Toshiba sales representative.
•DO NOT install or energize equipment that has been damaged. Damaged equipment may fail
during operation resulting in equipment damage or personal injury.
• Check to see that the rated capacity and the model number specified on the nameplate conform to
the order specifications.
• Modification of this equipment is dangerous and must not be performed except by factory trained
representatives. When modifications are required contact your Toshiba sales representative.
• Inspections may be required before and after moving installed equipment.
• Keep the equipment in an upright position.
• Contact your Toshiba sales representative to report discrepancies or for assistance if required.
Handling and Storage
• Use proper lifting techniques when moving the ASD; including properly sizing up the load, getting
assistance, and using a forklift if required.
• Store in a well-ventilated covered location and preferably in the original carton if the equipment
will not be used upon receipt.
• Store in a cool, clean, and dry location. Avoid storage locations with extreme temperatures, rapid
temperature changes, high humidity, moisture, dust, corrosive gases, or metal particles.
• The storage temperature range of the ASD is -14° to 104° F (-10° to 40° C).
• Store in an upright position.
Disposal
Contact your state environmental agency for details on disposal of electrical components and packaging
in your area.

4G3+ Pack Addendum
Installation Precautions
Location and Ambient Requirements
• The Toshiba ASD is intended for permanent installations only.
• Installation should conform to the 2005 National Electrical Code — Article 110 (NEC)
(Requirements For Electrical Installations), all regulations of the Occupational Safety and
Health Administration, and any other applicable national, regional, or industry codes and
standards.
• Select a mounting location that is easily accessible, has adequate personnel working space, and
adequate illumination for adjustment, inspection, and maintenance of the equipment (refer to 2005
NEC Article 110-13).
• A noncombustible insulating floor or mat should be provided in the area immediately surrounding
the electrical system.
•DO NOT mount the ASD in alocation that would allow it to be exposed to flammable chemicals or
gases, water, solvents, or other fluids.
• Avoid installation in areas where vibration, heat, humidity, dust, fibers, steel particles, explosive/
corrosive mists or gases, or sources of electrical noise are present.
• The installation location shall not be exposed to direct sunlight.
• Allow proper clearance spaces for installation. Do not obstruct the ventilation openings. Refer to
Figures 1 through 4on pg. 21 for further information on ventilation requirements.
• Except where otherwise specified, the ambient operating temperature range of the ASD is 14° to
122° F (-10° to 50° C).
•SeeTables 4 and 5on pg. 19 for additional information on installing the drive.
Mounting Requirements
• Only Qualified Personnel should install this equipment.
• Install the unit in a secure and upright position in a well-ventilated area.
• A noncombustible insulating floor or mat should be provided in the area immediately surrounding
the electrical system at the place where maintenance operations are to be performed.
• As a minimum, the installation of the equipment should conform to the NEC Article 110
Requirements For Electrical Installations, OSHA, as well as any other applicable national, regional,
or industry codes and standards.
• Installation practices should conform to the latest revision of NFPA 70E Electrical Safety
Requirements for Employee Workplaces.
• It is the responsibility of the person installing the ASD or the electrical maintenance personnel to
ensure that the unit is installed into an enclosure that will protect personnel against electric shock.

G3+ Pack Addendum 5
Conductor Routing and Grounding
• Use separate metal conduits for routing the input power, outputpower, and control circuits and each
shall have its own ground cable.
• A separate ground cable should be run inside the conduit with the input power, output power, and
and control circuits.
•DO NOT connect CC to earth ground.
• Always ground the unit to prevent electrical shock and to help reduce electrical noise.
• It is the responsibility of the person installing the ASD or the electrical maintenance personnel to
provide proper grounding and branch circuit protection in accordance with the 2005 NEC and any
applicable local codes.
The Metal Of Conduit Is Not An Acceptable Ground.
Power Connections
Contact With Energized Wiring Will Cause Severe Injury Or Death.
• Turn off, lockout, and tag out all power sources before proceeding to connect the power wiring to
the equipment.
• Ensure that all power sources are turned off and isolated in accordance with established lockout/tag
out procedures. Then connect the three-phase power source wiring of the correct voltage/frequency
to the correct input terminals and connect the output terminals to a motor of the correct voltage and
type for the application (refer to NEC Article 300 – Wiring Methods and Article 310 – Conductors
For General Wiring). Size the branch circuit conductors in accordance with NEC Table 310.16.
• If multiple conductors are used in parallel for the input or output power and it is necessary to use
separate conduits, each parallel set shall have its own conduit (i.e., place U1, V1, W1, and a ground
wire in one conduit and U2, V2, W2 and a ground wire in another) (refer to NEC Article 300.20
and Article 310.4). National and local electrical codes should be referenced if three or more power
conductors are run in the same conduit (refer to 2005 NEC Article 310 adjustment factors).
• Ensure that the 3-phase input power is Not connected to the output of the ASD. This will damage
the ASD and may cause injury to personnel.
•DO NOT install the ASD if it is damaged or if it is missing any component(s).
• Turn the power on only after attaching and/or securing the front cover.
WARNING
DANGER

6G3+ Pack Addendum
Protection
• Ensure that primary protection exists for the inputwiring to the equipment. This protection must be
able to interrupt the available fault current from the power line. The equipment may or may not be
equipped with an input disconnect (option).
• All cable entry openings must be sealed to reduce the risk of entry by vermin and to allow for
maximum cooling efficiency.
• Follow all warnings and precautions and do not exceed equipment ratings.
• External dynamic braking resistors must be thermally protected.
• It is the responsibility of the person installing the ASD or the electrical maintenance personnel to
setup the Emergency Off braking system of the ASD. The function of the Emergency Off braking
function is to remove output power from the drive in the event of an emergency. A supplemental
braking system may also be engaged in the event of an emergency.
Note: A supplemental emergency stopping system should be used with the ASD. Emergency
stopping should not be a task of the ASD alone.
• Follow all warnings and precautions and do not exceed equipment ratings.

G3+ Pack Addendum 7
System Integration Precautions
The following precautions are provided as general guidelines for the setup of the ASD within the
system.
• The Toshiba ASD is a general-purpose product. It is a system component only and the system
design should take this into consideration. Please contact your Toshiba sales representative for
application-specific information or for training support.
• The Toshiba ASD is part of a larger system and the safe operation of the ASD will depend on
observing certain precautions and performing proper system integration.
• A detailed system analysis and job safety analysis should be performed by the systems designer
and/or systems integrator before the installation of the ASD component. Contactyour Toshiba sales
representative for options availability and for application-specific system integration information if
required.
Personnel Protection
• Installation, operation, and maintenance shall be performed by Qualified Personnel Only.
• A thorough understanding of the ASD will be required before the installation, operation, or
maintenance of the ASD.
• Rotating machinery and live conductors can be hazardous and shall not come into contact with
humans. Personnel should be protected from all rotating machinery and electrical hazards at all
times.
• Insulators, machine guards, and electrical safeguards may fail or be defeated by the purposeful or
inadvertent actions of workers. Insulators, machine guards, and electrical safeguards are to be
inspected (and tested where possible) at installation and periodically after installation for potential
hazardous conditions.
•DO NOT allow personnel nearrotating machinery. Warning signs to this effect shallbe posted at or
near the machinery.
•DO NOT allow personnel near electrical conductors. Human contact with electrical conductors can
be fatal. Warning signs to this effect shall be posted at or near the hazard.
• Personal protection equipment shall be provided and used to protect employees from any hazards
inherent to system operation.
• Follow all warnings and precautions and do not exceed equipment ratings.
WARNING

8G3+ Pack Addendum
System Setup Requirements
• When using the ASD as an integral part of a larger system, it is the responsibility of the ASD
installer or maintenance personnel to ensure that there is a fail-safe in place (i.e., an arrangement
designed to switch the system to a safe condition if there is a fault or failure).
• System safety features should be employed and designed into the integrated system in a manner
such that system operation, even in the event of system failure, will not cause harm or result in
personnel injury or system damage (i.e., E-Off, Auto-Restart settings, System Interlocks, etc.).
• The programming setup and system configuration of the ASD may allow it to start the motor
unexpectedly. A familiarity with the Auto-restart settings is a requirement to use this product.
• Improperly designed or improperly installed system interlocks may render the motor unable to start
or stop on command.
• The failure of external or ancillary components may cause intermittent system operation (i.e., the
system may start the motor without warning).
• There may be thermal or physical properties, or ancillary devices integrated into the overall system
that may allow for the ASD to start the motor without warning. Signs at the equipment installation
must be posted to this effect.
• Power factor improvement capacitors or surge absorbers must not be installed on the output of the
ASD.
• Use of the built-in system protective features is highly recommended (i.e., E-Off, Overload
Protection, etc.).
• The operating controls and system status indicators should be clearly readable and positioned
where the operator can see them without obstruction.
• Additional warnings and notifications shall be posted at the equipment installation location as
deemed required by Qualified Personnel.
• Follow all warnings and precautions and do not exceed equipment ratings.
• If a secondary magnetic contactor (MC) or an ASD output disconnect is used between the ASD and
the load, it should be interlocked to halt the ASD before the secondary contact opens. If the output
contactor is used for bypass operation, it must be interlocked such that commercial power is never
applied to the ASD output terminals (U, V, W).
• When using an ASD output disconnect the ASD and the motor must be stopped before the
disconnect is either opened or closed. Closing the output disconnect while the 3-phase output of the
ASD is active may result in equipment damage or injury to personnel.
CAUTION

G3+ Pack Addendum 9
Operational and Maintenance
Precautions
• Turn off, lockout, and tag out the main power, the control power, and instrumentation connections
before inspecting or servicing the drive, or opening the door of the enclosure.
• Turn off, lockout, and tag out the main power, the control power, and instrumentation connections
before proceeding to disconnect or connect the power wiring to the equipment.
• The capacitors of the ASD maintain a residual charge for a period of time after turning the ASD off.
The required time for each ASD typeform is indicated with a cabinet label and a Charge LED.
Once the ASD power has been turned off, wait for at least the minimum time indicated on the
enclosure-mounted label and ensure that the Charge LED has gone out before opening the door of
the ASD.
• Turn the power on only after attaching (or closing) the front cover and DO NOT remove the front
cover of the ASD when the power is on.
•DO NOT attempt to disassemble, modify, or repair the ASD. Call your Toshiba sales representative
for repair information.
• Do not place any objects inside of the ASD.
• If the ASD should emit smoke or an unusual odor or sound, turn off the power immediately.
• The heat sink and other components may become extremely hot to the touch. Allow the unit to cool
before coming in contact with these items.
• Remove power from the ASD during extended periods of non-use.
• The system should be inspected periodically for damaged or improperly functioning parts,
cleanliness, and to ensure that the connectors are tightened securely.
WARNING

10 G3+ Pack Addendum
Standard Specifications
Parameter Item Name Standard Specification
CONTROL
Control System Sinusoidal PWM control.
Output Voltage Regulation Same as powerline.
Frequency Setting 0.01 to 299 Hz (0.01 to 80 Hz default setting).
Frequency Accuracy Analog Input: ±0.2% of the maximum output frequency at 25° C ±10° C.
Digital Input: ±0.01% at 25° C ±10° C.
Voltage/Frequency
Characteristics
Constant V/f, Variable Torque, Automatic Torque Boost, True Torque
Control, and Automatic Energy Saving Control/Maximum Voltage
Frequency Adjustment (25 to 299 Hz), Torque Boost Adjustment (0 to
30%), Startup Frequency Adjustment (0 to 10 Hz).
PWM Carrier Frequency Adjustable from 0.5 to 3 kHz.
Transistor Type Insulated Gate Bipolar (IGBT).
Output Voltage Regulation ASD output voltage may be programmed to Fixed Maximum Output Voltage, Float With the Input Voltage, or Set Maximum Voltage to Input
Voltage Sensed at Power Down.
Dynamic Braking Optional.
FREQUENCY
Input Signals 1 kΩto 10 kΩ, 0.0 to 10 VDC (Zin = 33 kΩ), ±10 VDC (Zin = 67 kΩ),
±5 VDC (Zin = 34 kΩ), 4 – 20 mADC (Zin = 500Ω).
Setpoint Control (PID) Proportional Gain, Integral Gain, Antihunting Gain, Lag Time-constant,
and PID Error Limit Adjustment.
OPERATING
FUNCTIONS
Accel/Decel Time 0.1 to 6000 Seconds, Accel/Decel time 1 and 2 selection, Accel/Decel
Pattern selection.
Forward or Reverse Run F to CC = Forward Run, R to CC = Reverse Run, F and R to CC =
Reverse Run, ST to CC open = Coast Stop.
Jogging Run Job Run from panel. Jog Run from Terminal Block.
Multispeed Run Set frequency and 15 Preset Speeds by connecting combinations of CC
and S1, S2, S3, and/or S4.
Retry Retry attempts 10 times max. (0 to 10 seconds).
Soft Stall Automatic load reduction during overload (default = Off).
Automatic Restart Coasting motor restart (default = Off).
Pattern Run Four(4) groups of eight(8) patterns. Each pattern may be up to 15 Preset
Speeds. Terminal block control and repetitive run possible.
DC Injection Braking Braking Starting frequency adjustment (0 to 120 Hz), braking current adjustment (0 to 100%), braking time adjustment (0 to 10 seconds),
emergency stop braking function, motor shaft stationary control.

G3+ Pack Addendum 11
OPERATING
FUNCTIONS
Upper/Lower Limit Limits the frequency between set values (0 to max. frequency). Can be
indicated via output contactor.
Frequency Jump Three Jump frequency settings; each with unique band settings.
Edit Function Easy-access user group containing all changed parameters.
Blind Function Select to display parameter groups and parameters.
User-defined Defaults User-set parameters can be saved into a default library. User may then
default drive to Toshiba’s factory settings or the user-stored settings.
DISPLAY
Interface Two-line backlit display, LCD 20 characters per line.
Fault Display
Overcurrent, overvoltage, heatsink overheat, load-side short-circuit,
load-side ground fault, ASD overload, stator overcurrent during start-up,
load-side overcurrent during start-up, EEPROM error, RAM error, ROM
error, communication error, dynamic braking unit overcurrent/
overload, emergency stop, undervoltage, low current, overtorque,
open output phase, motor overload.
Bolded items may be selected or deselected.
Monitor Functions
Terminal input/output status, forward/reverse, frequency setting value,
output frequency, output current, output voltage, input power, output
power, torque current, cumulative run time, past faults, excitation
current, DBR overload ratio, ASD overload ratio, motor overload ratio,
PID feedback value, DC voltage.
Selectable Units Display Scales the frequency display.
Displays current as amps or % and voltage as V or %.
LED Charge Indicator Indicates that the main circuit capacitors are charged (On) or discharged
(Off).
LED Local/Remote Indicator Mounted at the Local/Remote key. Indicates Local (On) or Remote
control (Off).
ASD/MOTOR
Protective Functions
Soft-stall, current limit, overcurrent, overvoltage, short-circuit at load,
load-side ground fault, undervoltage, momentary power failure,
regeneration power ridethrough, electronic thermal overload protection,
main circuit overcurrent at start-up, load-side overcurrent during start-
up, DBR resistor overcurrent/overload, heatsink over heat, emergency
stop, open output phase.
Electronic Thermal
Characteristics
The motor overload protection setting at the ASD may be adjusted for
the motor rated amperage. The motor overload setting has a speed-
sensitivity adjustment, Soft stall feature, and the motor 150% run time is
programmable.
Reset Fault reset via keypad, remote contact closure, or programming drive
retry. Cycling power also resets fault (fault display can be maintained).
Ridethrough Control The G3+ Pack may be configured to use regenerative energy from the
motor to maintain programmable settings during a brownout.
Parameter Item Name Standard Specification

12 G3+ Pack Addendum
Post-Reset Requirements
After a system Reset, the parameters listed below will require that the user return each to the Pre-Reset
settings for normal system operation.
Pre-Reset Settings
• Output Short Circuit Detection Select — Set to 3 (item #169).
• Carrier Frequency — Set to 2.2 kHz (item #42).
• Discrete Input S4 — Set to 10 (EOFF; item #48).
This item is to be set to Normally Closed (SuperUser access required).
See the project drawing for further information on this setting.
OUTPUT SIGNALS
Fault Detection Signals NC/NO form C contact (250 VDC, 2 A).
Low Speed/Reach Signals Dry contacts (250 VDC, 2 A).
Upper/Lower Limit Dry contacts (250 VDC, 2 A).
Programmable Meter Output
Signals
Pre-compensation reference frequency, post-compensation output
frequency, frequency setting value, output current, DC voltage, output
voltage, torque current, excitation current, PID feedback value, motor/
ASD/DBR overload ratio, input/output power.
Pulse Train Frequency Open collector output (max. 24 VDC, 50 mA).
Communications Functions RS232C equipped as standard (modular 6P connector), RS485,
TOSLINE-F10, TOSLINE-F20, RIO, DN, and MB+ are options.
ENCLOSURE
Type NEMA 1 and NEMA 3R.
Cooling Method Forced air cooling. Fan can be automatically stopped when not required
to extend fan life.
Color ANSI gray #61 (indoor) or white (outdoor) polyurethane textured finish.
Service Environment
Indoor ratings — Consult factory for elevations above 1500 m (requires
derate). For example, at 2000 m derate drive FLA by 11%.
Must not be exposed to direct sunlight, corrosive or explosive gases,
mists, fibers, or dusts.
Ambient Temperature 14° F to 122° F (-10° C to 50° C) except where otherwise specified.
Relative Humidity 20% to 95% maximum (non-condensating).
Vibration 5.9 m/s2(0.6 G) maximum (10 to 55 Hz).
Parameter Item Name Standard Specification

G3+ Pack Addendum 13
G3+ Pack ASD Typical Wiring Diagram

14 G3+ Pack Addendum
Part Numbering Convention
The G3+ Pack ASD is a special configuration, large horsepower, G3 ASD. The NEMA 3R version is
designed for outdoor applications and is painted white — the indoor system is painted ANSI 61 gray.
Ordering Information
Use the following part numbering convention when ordering the G3+ ASD.
The 66 KVA, NEMA1, 12-Pulse unit is used as an example below (e.g., P/N G3+B4660CC1).
G3+ B 4 660 CC1
Series Voltage
Rating
ASD Rating
(P/N = Rating) Configuration Options
Revision
4 = 480 VAC 660 = 66 kVA
830 = 83 kVA
11K = 110 kVA
16K = 163 kVA
20K = 200 kVA
26K = 260 kVA
39K = 390 kVA
45K = 454 kVA
*51K40 = 518 kVA
60K = 600 kVA
70K = 700 kVA
81K = 815 kVA
93K = 932 kVA
10L = 1000 kVA
12L = 1200 kVA
*14L40 = 1400 kVA
*15L40 = 1500 kVA
CB — NEMA 3R, 6-Pulse
CC — NEMA 3R, 12-Pulse
CB1 — NEMA 1, 6-Pulse
CC1 — NEMA 1, 12-Pulse
Note: Operating temperature is 50° C unless
otherwise specified.
* Operating temperature is 40° C.
CB = 6-Pulse
CC = 12-Pulse
1 = N1 (N3R if no number)
