E6580719
Introduction
Thank you for purchasing the "Parameter Writer" forthe Toshiba high-performance inverterTOSVERT
VF-AS.
This Parameter Writer has the following functions.
1)
Copy function handy for setting data
in
multiple inverters.
2)
Compare function to confirm the copy results.
3)
Edit function to edit the parameters.
Always read this manual before using the "Parameter Writer" to ensure correct use
of
this Parameter
Writer's outstanding functions.
This manual must
be
kept by the "Parameter Writer" user, and used for future maintenance and
inspections.
[Explanation
of
Parameter Writertype]
PWAS -
001
L
L_
Cable length
1.
5 meters (Only this type is available for the VF-A5.)
......__
____
VF-A5 Parameter Writer
[Precautions
for
using
Parameter Writer]
1)
Copying to differing invertertypes (capacities)
When using this ParameterWriterfordifferent invertertypes, some specific parameters will not
be
copied. This Parameter Writer can
be
used with inverter versions (
c.-ut:
Lie
PU) u :
:o
(version 110) and above. Only the C0 P
=:
function can
be
used with versions u : : 0 and
below.
If
the compare function or edit function is used with versions u : : 0 and below 0L d
will appear, and the function will
be
inhibited. (Refer to Chapter 4
on
page 13.)
2)
Holding power during parameter copying
If
the inverter's power is turned OFF or
if
the Parameter Writer's cable is disconnected while
copying the parameters, the data will not
be
written
in
correctly to the end.
Do
not turn the power
OFF or disconnect the cable when the Parameter Writer display (LED) is changing.
3)
Prohibition
of
use during inverter operation
Do
not connect the Parameter Writer's cable while the inverter
is
running. The inverter will stop
once, etc. Operation
of
the Parameter Writer while the inverter is running
is
prohibited, and
is
indicated with the error display (
.-
U
.-.
E
).
Thus, always use the Parameter Writer while the
inverter
is
stopped.
4)
Cautions against impacts (dropping)
If
external impact (dropping, etc.)
is
applied
on
this Parameter Writer, a contact defect, etc., may
occur
in
the operation panel connector. Take special care when handling.
5)
Guaranteed limit
on
data saving
This Parameter Writer uses
an
EEPROM to save the data. Thus, the guaranteed limit for writing
data to the Parameter Writer's memory with the copy function ( C0 P
=:)
is
10,000 times. The
data
can
be
saved for up to ten years.
