Toshiba TOSVERT VF-P7 User manual

 Ｅ６５８０９７１③
INVERTER INSTRUCTION MANUAL
VF-P7 200V class
VF-P7 400V class
NOTICE
1. Make sure that this Instruction Manual is delivered to the end user of the
inverter unit.
2. Keep this manual before installing or operating the inverter unit, and
store it in a safe place for reference.
© Toshiba Schneider Inverter Corporation 2001
All rights reserved.
Compliance with CE Marking and
UL Standard

 Ｅ６５８０９７１③
- 1 -
１．Compliance with CE Marking ・・・・・・・・・・・・・・・Ｐ２
１．１．Abstract ・・・・・・・・・・・・・・・・・・・・Ｐ２
１．２．EMC directive ・・・・・・・・・・・・・・・・・Ｐ３
１．３．Compliance with EMC directive ・・・・・・・・・・・Ｐ４
１．４．Low Voltage directive ・・・・・・・・・・・・・・・・Ｐ７
１．５．Compliance with Low Voltage directive ・・・・・・・・・Ｐ８
２．Compliance with UL Standard ・・・・・・・・・・・・・・ Ｐ９
２．１．Compliance with Installation ・・・・・・・・・・・・Ｐ９
２．２．Compliance with Connection ・・・・・・・・・・・Ｐ９
２．３．Compliance with Peripheral devices ・・・・・・・・・Ｐ９
２．４．Compliance with Motor overload protection ・・・・・・・・Ｐ１１
INDEX

 Ｅ６５８０９７１③
- 2 -
１．Compliance with CE Marking
1.1. Abstract
In Europe, EMC directive is enforced starting 1st Jan. of 1996, and Low Voltage Directive
starting 1st Jan. of 1997. The display of CE mark that demonstrates that products imported to
European Union conform to these directives is required. Inverter itself cannot function alone, but
is de-signed as a component in order to control machines or equipment which includes that
inverter installed in a cubicle. Therefore the conformance to EMC directive is not required on
inverter it-self. But since the object of the Low Voltage directive is equipment that is designed to
be used with rated voltage of 50 to 1,000 VAC or 75 to 1,500 VDC, CE should be marked on
inverter as to the Low Voltage directive.
But CE has to be marked on the final product installing inverters, that conforms to the EMC
directive and the Low Voltage directive. And the product also may conform to Machine directive.
The user that makes the final products have to take the responsibility for Marking of CE. For that
reason, we recommend installation for Low Voltage directive and measurement for EMC
directive, so that the products including our inverter should conform to the EMC and Low
Voltage directive.
We carried out Approval testing and confirmation testing on representative models under the
circumstances based on installation and measurement so that our products should conform to
each directive. But we cannot confirm the conformance of the user’s products to the EMC
directive. Since EMC environment changes according to the construction of the cubicle and the
relation of other installed electric equipment and the condition of wiring and installation, please
confirm the conformance to the EMC directive for the final products on your side.

 Ｅ６５８０９７１③
- 3 -
1.2. EMC directive
An inverter itself is not an object of CE marking.
A machine which consists of an inverter and a motor is an object of CE marking.
The EMC directive includes the emission section and the immunity section. VF-P7 can conform
to EMC directive by means of installing the recommended EMI noise filter to the input side, and
wiring properly.
→Emission: Emission of electromagnetic wave and electromagnetic interference
→Immunity: Resistance to electromagnetic interference
[EMC directive]
89/336/EEC
Table 1 Relative standard
Noise type Test item Standard Applicable standards
Conducted Emission EN55011 Group 1 class A
Emission Radiated Emission EN55011 Group 1 class A
Electrostatic Discharge IEC61000-4-2
Radiated Electromagnetic field IEC61000-4-3
Electrical Fast Transient/Burst IEC61000-4-4
Immunity
Surge Immunity
EN61800-3
IEC61000-4-5
Conducted Disturbances IEC61000-4-6
Voltage dips, short interruptions
and voltage variations
IEC61000-4-11

 Ｅ６５８０９７１③
- 4 -
1.3. Compliance with EMC directive
(1) Recommended EMI noise filters(refer to Table 2) should be installed to the input. These
can reduce the conducted and radiated noise.
Table 2. Recommended EMI filter selection
《3-phase 200V class》《3-phase 400V class》
Type form Filter type Type form Filter type (NOTE)
VFP7-2185P FN258-100/35 or
FN3258-100/35
VFP7-4185P FN258-42/07 or
FN3258-42/47
VFP7-2220P FN258-100/35 or
FN3258-100/35
VFP7-4220P FN258-55/07 or
FN3258-55/52
VFP7-2300P FN258-130/35 or
FN3258-130/35
VFP7-4300P FN258-75/34 or
FN3258-75/32
VFP7-2370P FN258-180/07 or
FN3258-180/40
VFP7-4370P FN3258-75/52 or
FS5992-72/52
VFP7-2450P FN258-130/35×2P or
FN258-250/07 or
FN3359-250/28
VFP7-4450P FN258-100/35 or
FN3258-100/35
VFP7-2550P FN258-130/35×2P or
FN258-250/07 or
FN3359-250/28
VFP7-4550P FN3258-130/35 or
FS5992-130/35
VFP7-2750P FN359-300/99 or
FN3359-320/99
VFP7-4750P FN258-180/07 or
FN3258-180/40
VFP7-2900P FN359-400/99 or
FN3359-400/99
VFP7-4900P FN3359
(
HV
)
-250/28
VFP7-2110KP FN359-500/99
FN3359-500/99
VFP7-4110KP FN359
(
H
)
-250
/
99 or
FN3359
(
HV
)
-250/28
−−VFP7-4132KP FN359
(
H
)
-300
/
99 or
FN3359
(
HV
)
-320/99
−−VFP7-4160KP FN359
(
H
)
-400/99 or
FN3359
(
HV
)
-400/99
−−VFP7-4200KP FN359
(
H
)
-500/99 or
FN3359
(
HV
)
-500/99
−−VFP7-4220KP FN359
(
H
)
-500/99 or
FN3359
(
HV
)
-500/99
−−VFP7-4280KP FN359
(
H
)
-600/99 or
FN3359
(
HV
)
-600/99
−−VFP7-4315KP FN359
(
H
)
-900/99 or
FN3359
(
HV
)
-1000/99
Note) FN258,3258 480V or less
FN359 400V or less, FN359H 520V or less
FN3359 500V or less, FN3359HV 690V or less
(2) The main cables such as input to the EMI filter and output of the inverter and the signal
cables should be shielded, then cable length should be wired as short as possible. The main
input cable should be separated from the main output cable, and cables for control signal
also should be separated from main cables, not wiring parallel and not bundling, cross the
wires where necessary.
(3) Install EMI filter and inverter on the same metal back plate in an inverter panel. The metal
back plate or the cubicle must be grounded absolutely, by using short thick wires, separated
from the main cables.
(4) Please separate input cable to EMI filter from output cable as much as possible.
(5) Shielded cables should be grounded on the metal back plate in order to reduce the radiated
noise from the other cables. It is an effective measure that shielded cables are grounded
close to the inverter or/and operation panel or/and EMI filter(less than 10cm).
(6) Installation of the zero-phase and/or the ferrite core can also effectively reduce the radiated
noise further.(Input or/and output of inverter)

 Ｅ６５８０９７１③
- 5 -
【Ex. Countermeasure – main circuit wiring】
Fig. 1
Inverter
panel
(metal)
RSTUVWE
E
IM
L1L2L3E
EL1L2L3
Note 1)
Refer to P.6.
Separate input and
outputs cables. Do not
run input cables along-
side output cables.
Do not bundle input
and output cables.
Shieldedcable
EMI
FILTER

 Ｅ６５８０９７１③
- 6 -
Note 1)
Process as shown below.
Shielded cable
Fig. 2
【Operating with external signals】
To operate with external signals, process as following figures.
Fig. 3
【Accessories for countermeasure】
- Ferrite core 1 : Chomerics
Type form/HBFE-1004-AS
(or TDK co. ltd. Type form/ ZCAT3035-1330)
- Note2) Shield : SUMITOMO 3M Co. Ltd. Electro-magnetic guard shielded sleeve
Typeform/DS-5,7,10,14
- EMI filter : SCHAFFNER ELEKTRONIK AG
Type form/ FN258/FN3258/FN359/FN3359/FS5992
- Zero-phase reactor : Soshin Electric Co. Ltd.
Type form/ RC5078 or RC9129
Strip the coating of the cable and fix the shielded
part to the metal plate using a metal fitting.
PP
RR
CC
F
R
Control
circuit
terminal
Ferrite core 1
Shielded cable or Note 2)
Potentiometer
Forward
Reverse
Note 1)

 Ｅ６５８０９７１③
- 7 -
1.4. Low voltage directive
Inverter itself is an object of the CE marking.
The Low Voltage Directive defines the safety of the electric equipment. VF-P7 series conform
to the Low Voltage directive based on EN50178.
Normative standard : EN50178/Electronic equipment for use in power installation
Pollution degree :2(5.2.15.2)
Over-voltage category : 3 200V class 3.0 mm (5.2.16.1)
400V class 5.5 mm (5.2.16.1)
EN50178 provides that for electronic equipment used in power installations. The main intention is
to stipulate minimum requirements for the design and manufacture of electronic equipment, for
protection against electric shock, for testing and for the integration into systems for power
installations.

 Ｅ６５８０９７１③
- 8 -
1.5. Compliance with Low voltage directive
Please carry out the below mentioned countermeasures for the Low Voltage Directive in case
of using VF-P7 as components of your products.
(1) Inverter should be installed in a panel. Pay attention to wiring openings, so that it should
prevent someone from touching live parts through the opening in case of maintenance.
2) No more than 1 cable should be connected to one earth terminal of the main terminal board. In
this case, other cables for ground should be grounded on the metal back plate and/or in the
cubicle (Refer to Fig. 4).
Refer the size of grounding cable to Table. 4.
(3) MCCB should be connected to the input side of the EMI filter.
Metal back plate
Fig. 4
Inverter Make other terminal for
grounding
Grounding
terminal

 Ｅ６５８０９７１③
- 9 -
２．Compliance with UL Standard
The VF-P7 models conform to the UL Standard have the UL/CUL mark on the nameplate.
2.1. Compliance with Installation
The VF-P7 Inverter must be installed in a panel, and used within the maximum surrounding air
temperature 50 degrees.
2.2. Compliance with Connection
Use the UL listed cables, 75 degree copper wire only, with the UL listed closed -loop
terminal connector at field wiring connection to the inverter input terminals, R/L1, S/L2,
T/L3, output terminals, U/T1, V/T2, W/T3, and other main terminals.
Refer the wire gauge, the type of closed-loop terminals and crimping tools to Table.4
and Table.5.
2.3. Compliance with Peripheral devices
Use the UL listed MCCB or fuses at connecting to power supply.
(The fuses should be used CLASS CC/J.)
Refer to the instruction manual about selecting the rating of them.
Short circuit test is performed under the condition of the power supply
short-circuit currents in Table. 3.
These currents depend on the applicable motor capacities.
Table.3 Power supply short-circuit current and maximum input voltage
Input voltage
(v)
Applicable motor
( kW )
power supply shout-circuit current and maximum input voltage
18.5 ～ 37 Suitable for use on a circuit capable of delivering not more than
5,000 rms symmetrical amperes in below,240 volts maximum.
200
45 ～ 110 Suitable for use on a circuit capable of delivering not more than
10,000 rms symmetrical amperes in below,240 volts maximum.
18.5 ～ 37 Suitable for use on a circuit capable of delivering not more than
5,000 rms symmetrical amperes in below,480 volts maximum.
45 ～ 132 Suitable for use on a circuit capable of delivering not more than
10,000 rms symmetrical amperes in below,480 volts maximum.
160 ～ 280 Suitable for use on a circuit capable of delivering not more than
18,000 rms symmetrical amperes in below,480 volts maximum.
400
315 Suitable for use on a circuit capable of delivering not more than
30,000 rms symmetrical amperes in below,480 volts maximum.

 Ｅ６５８０９７１③
- 10 -
Table.4 Wire gauge
Wire gauge AWG （ｍｍ2）
Inverter
type-form Input/output
terminals
Control power
supply terminals
Grounding terminal
VFP7-2185P 4 (21.2) 14 (2.1) 4 (21.2)
VFP7-2220P 2 (33.6) 14 (2.1) 4 (21.2)
VFP7-2300P 2/0 （67.4）14 (2.1) 2 (33.6)
VFP7-2370P 2/0 （67.4）14 (2.1) 2 (33.6)
VFP7-2450P 4/0 (107.2) 14 (2.1) 2/0 （67.4）
VFP7-2550P 4/0 (107.2) 14 (2.1) 2/0 （67.4）
VFP7-2750P 300 (152) 14 (2.1) 4/0 (107.2)
VFP7-2900P 300 (152) 14 (2.1) 4/0 (107.2)
VFP7-2100KP 400 (203) 14 (2.1) 4/0 (107.2)
VFP7-4185P 8 (8.4) 14 (2.1) 8 (8.4)
VFP7-4220P 6 (13.3) 14 (2.1) 6 (13.3)
VFP7-4300P 6 (13.3) 14 (2.1) 6 (13.3)
VFP7-4370P 4 (21.2) 14 (2.1) 4 (21.2)
VFP7-4450P 2 (33.6) 14 (2.1) 4 (21.2)
VFP7-4550P 2 (33.6) 14 (2.1) 4 (21.2)
VFP7-4750P 2/0 （67.4）14 (2.1) 2 (33.6)
VFP7-4900P 4/0 (107.2) 14 (2.1) 2/0 (67.4)
VFP7-4110KP 4/0 (107.2) 14 (2.1) 2/0 (67.4)
VFP7-4132KP 4/0 (107.2) 14 (2.1) 2/0 (67.4)
VFP7-4160KP 300 (152) 14 (2.1) 4/0 (107.2)
VFP7-4200KP 400 (203) 14 (2.1) 4/0 (107.2)
VFP7-4220KP 400 (203) 14 (2.1) 4/0 (107.2)
VFP7-4280KP 300*2 (152*2) 14 (2.1) 300 (152)
VFP7-4315KP 300*2 (152*2) 14 (2.1) 300 (152)

 Ｅ６５８０９７１③
- 11 -
Table. 5 Type-form of closed-loop terminals and crimping tools
Type-form of closed-loop terminal Crimping tools
AWG
(mm2) M3
screw
M4
screw
M5
screw
M6
screw
M8
screw
M10
screw
M12
screw
Hand
Tools
Air-
pressure
tools
Hydraulic
tools
14 (2.1) 2-3 R2-4 ---- ---- ---- ---- ---- YHT-
2210 YA-4 BCT-
0514
8 (8.4) ---- ---- R8-5 R8-6 R8-8 ---- ---- YHT-
8S
6 (13.3) ---- ---- R14-5 R14-6 R14-8 R14-10 ---- ----
YA-4,
YA-5
4 (21.2) ---- ---- ---- R22-6 R22-8 R22-10 R22-12 ----
2 (33.6) ---- ---- ---- ---- R38-8 R38-10 R38-12 ---- YA-5
2/0 (67.4) ---- ---- ---- ---- 70-8 70-10 70-12 ---- ----
4/0
(107.2) ---- ---- ---- ---- ---- R100-
10
R100-
12 ---- ----
300 (152) ---- ---- ---- ---- ---- R150-
10
R150-
12 ---- ----
YPT-150-
1,
BCT-
8150
（body）
YF-1
（head）
YET-150-
1
400 (203) ---- ---- ---- ---- ---- ---- R200-
12 ---- ----
(body)
YF-1
(head)
YET-300-
1
（Note）The closed-loop terminal and crimping tools in Table. 5 are manufactured
byJSTMfg.Co,.Ltd.
2.4. Compliance with Motor overload protection
The electronic thermal protection level and characteristic must be adjusted to fit the motor
rated current and specification.
Refer the detail of electronic thermal protection to the instruction manual.
Installing external overload relay to each motor between inverter and motors when driving
several motors simultaneously.
