Toshiba TOSVERT VF-PS1 User manual

E6581539
TOSVERT VF-PS1 series
Metasys®N2 option unit Instruction Manual
MTS001Z
NOTICE
1. Make sure that this instruction manual is delivered to the end user of Metasys®
N2 option unit.
2. Read this manual before installing or operating the Metasys ® N2 option unit.
Keep it in a safe place for reference.
3. All information contained in this manual are subject to change without notice.
Please confirm the latest information on our web site “www.inverter.co.jp”.

E6581539
- 1 -
Safety precautions
On the inverter and in its instruction manual, important information is contained for preventing
injuries to users, damages to assets, and for proper use of the device.
Read the instruction manual attached to the inverter along with this instruction manual to
completely understand the safety precautions, the symbols and indications shown below. Please
adhere to the contents of these manuals at all times.
Explanation of markings
Marking Meaning of marking
Danger Indicates that errors in operation may lead to death or serious injury.
Warning
Indicates that errors in operation may lead to injury (*1) to people or that these errors may
cause damage to physical property. (*2)
(*1) Such things as injury, burns or shock that will not require hospitalization or long periods of
outpatient treatment.
(*2) Physical property damage refers to wide-ranging damage to assets and materials.
Meanings of symbols
Marking Meaning of marking
Indicates prohibition (Do not do it).
What is prohibited will be described in or near the symbol in either text or picture
form.
Indicates something mandatory (must be done).
What is mandatory will be described in or near the symbol in either text or picture form.
Indicates danger.
What is dangerous will be described in or near the symbol in either text or picture form.
Indicates warning.
What the warning should be applied to will be described in or near the symbol in
either text or picture form.
- 1/13 -

E6581539
- 2 -
Limitation of use
Safety precaution
Never use this unit with any device other than TOSVERT VF-PS1 series inverters. Doing so may
cause an accident.
Handling in general
Danger
Never
Disassemble
Never disassemble, modify or repair the product.
Disassembling the product may cause electric shocks, fire or injuries.
For repairs, call your sales/repair agency.
Prohibited
Do not open the front cover on the inverter while the inverter power is on.
It may lead to electric shocks.
Do not remove this option from VF-PS1 while the power is on.
It may lead to electric shocks.
Do not put or insert foreign objects such as waste cable, bars or wires into the product.
It may lead to electric shocks or fire.
Do not splash water over the product, and do not wipe the body with a wet cloth.
It may lead to electric shocks or fire.
Mandatory
Turn off the power immediately in case of any abnormalities such as smoke, smell or
abnormal noise.
Neglect of these conditions may lead to fire.
For repairs, call your sales/repair agency.
Do not touch the sharp portions (such as leads of parts on the board, the corner of
board, or etc.) on this option.
It may lead to injuries.
Warning
Mandatory
This option is an electrostatic discharge sensitive device. Handle it, where the
environment is protected against electrostatic electricity.
Otherwise, permanent damage to device will result.
Transportation and installation
Danger
Prohibited
Do not apply a dropping shock or other physical shocks.
Otherwise, damage or malfunction will result.
Do not install or operate the inverter if it is damaged or any part of it is missing.
Operating a defective inverter may lead to electric shocks or fire.
For repairs, call your sales/repair agency.
Do not put any flammable material near the product.
It may catch fire due to the product sparking in the case of a malfunction.
Mandatory
Use this product under the environmental conditions prescribed in the instruction
manual.
Usage it under any other conditions may result in malfunction.
An emergency stop device must be installed that fits with system specifications
(e.g. shut off input power then engage mechanical brake).
Operation cannot be stopped immediately by the inverter or this unit alone, thus risking
an accident or injuries.

E6581539
- 3 -
Wiring
Warning
Mandatory
Electrical construction work must be done by a qualified expert.
Connection of input power by someone who does not have expert knowledge may
result in electric shocks or fire.
Turn off input power before wiring.
Wait at least 15 minutes and make sure that the charge lamp (on the inverter unit) is no
longer lit. Otherwise, it may lead to electric shocks.
Operations
Danger
Prohibited
Do not pull on the cable and connector.
It may cause damage or malfunctions.
Mandatory
Use this option under the environment specified in the instruction manual.
Usage under the environment other than them may cause damages or malfunctions or
an accident.
Use an additional safety device with your inverter or system to prevent a serious
accident due to the unit malfunctions.
Usage without an additional safety device may cause an accident.
Warning
Mandatory
Set up “Communication error trip function (see below)” to stop the inverter when the
option unit is deactivated by an unusual event such as an operating error, power
outage, failure, etc.
- Network time-out (f832)
(See the VF-PS1 Metasys®N2 Communication Function Manual for details.)
Deactivated option unit may cause an accident, if the “Communication error trip
function” is not properly set up.
Make sure that the operation signals are STOP before resetting inverter’s fault. The
motor may suddenly start and that may result in injuries.
Disposal
Warning
Mandatory
If you dispose off this unit, have it done by a specialist in industrial waste disposal*.
Improper disposal may result in explosion of capacitors or produce noxious gases,
resulting in injuries.
(*) Persons who specialize in the processing of waste and known as “Industrial Waste
Product Collectors and Transporters” or “Industrial Waste Disposal Persons.” If the
collection, transport and disposal of industrial waste is done by someone who is not
licensed for that job, it is a punishable violation of the law (Laws in regard to cleaning
and processing of waste materials).
Notes on operation
Notes
Avoidinstalling in a place where ambient temperature or/and humidity change sharply.
Keep the transmission cable separate from the power cable of the inverter to prevent the
inverter from malfunctioning due to electromagnetic noise.
Ground of SCR terminal on this option at the grounding terminal separated from those of
inverters and motors. It may cause malfunction due to noise.

E6581539
- 4 -
Preface
Thank you for purchasing the “Metasys®N2 option (MTS001Z)” for TOSVERT VF-PS1 inverter. By
Installing this board into the VF-PS1, data communication can be made with a host computer or
other device via Metasys®N2 network.
Before using this unit, carefully read this instruction manual in order to completely and correctly
utilize excellent performance of this unit. Besides this instruction manual, the “Metasys®N2 option
Function Manual” which includes the contents to install into Metasys®N2 network is prepared. If it is
required, please contact with our branch offices, sales offices or web site “www.inverter.co.jp”.
(“Metasys®N2 option Function Manual”: E6581540)
After reading this instruction manual, please keep it handy for future reference.
* Metasys®N2 is a registered trademark of Johnson Controls Inc.
- Part numbering
MTS 001 Z –0
Revision number
Cable length ( “Z” means “without cable” )
Model number of Metasys®N2 option
Symbol of Metasys®N2 option
- Accessory check list
Metasys®N2 communication option is shipped together with the following accessories. On
opening the packing case, check to see if the following accessories are contained or not.
(1) Metasys®N2 option (MTS001Z) .......1 board
Connector: MSTB2.5/4-STF-5.08
Manufactured by PHOENIX CONTACT
(3) Instruction manual for the VF-PS1 Metasys®N2 option ........ 1 copy
English: E6581539
(This manual)
(4) LED name label .........1 sheet
Manual

E6581539
- 5 -
Table of Contents

1. Overview ···································································································································6
2. Names and functions·················································································································6
2.1. Outline·······························································································································6
2.2. Metasys®N2 Connector····································································································6
2.3. LED indicator·····················································································································7
3. Installing the MTS001Z ·············································································································8
3.1. Network cable connection ·································································································9
3.2. Network configuration········································································································9
4. Parameters······························································································································10
4.1. Communication parameters ····························································································10
4.2. f832: Network Time-Out ··································································································10
4.3. f851: Operation at communication error by disconnection ··············································11
4.4. f852: Preset speed operation selection ···········································································11
5. The Metasys®N2 Local/Remote Operation············································································12
6. Specifications ··························································································································13
7. Warranty··································································································································13


E6581539
- 6 -
1. Overview
The Metasys®N2 interface (MTS001Z) allows the VF-PS1 inverter to be connected into a
Metasys®N2 network.
2. Names and functions
The drawing below shows names and functions of main parts.
2.1. Outline
2.2. Metasys®N2 Connector
Terminal
symbol Function Electrical specifications Internal circuits
B Communication signal (+)
A Communication signal (-)
GND Signal common
SCR
Metasys®N2
communication signal
EIA-485 Shield terminal.
B
A
GND
SCR
47k
47k
4.7k
4.7k
120
SW4
TERM
Don’t use
these connector or switches
Connector to the inverter
Metasys®N2 Connector（See 2.2）
(Terminal connector : MSTB 2,5/4-STF-5.08)
: PHOENIX CONTACT
Termination
Resistor SW
Panel mounting tabs
Earth Plate
Metasys®N2 LED indicato
r
（See 2.3）
Station address switch

E6581539
- 7 -
2.3. LED indicator
The LED shows the present status of the network and error.
Layout of LED
The option has two LEDs. Those function are below table.
State LEDs Comment
A COM LED: OFF
ERR LED: Flashing 5 times in 1 sec Metasys®N2 failure.
B COM LED: OFF
ERR LED: 3 times in 2 sec, Off for 1 sec
Communication loss detected. Confirm the
network condition and connection of the cable.
C COM LED: ON
ERR LED: OFF 0.5 sec, ON 0.5 sec
Invalid configuration detected.
Note: When inverter occurred in e‑23 or e‑24,
the LED becomes this state.
D COM LED: Flashing
ERR LED: OFF Valid message received for this node
E COM LED: OFF
ERR LED: Flashing Invalid message received (any node)
F COM LED: OFF
ERR LED: OFF
No communication
Confirm the network condition and connection
of the cable.
COM
(Green)
ERR
(Red)
2s
OFF
1s
B D
OFF
E
OFF
1s
ON
C
1s
OFF
A F
OFF
OFF
2.2
2.3
2.4
2.5
2.1
COM
ERR

E6581539
- 8 -
3. Installing the MTS001Z
Install the Metasys®N2 option to VF-PS1 as follows.
Please install this option (MTS001Z) on the top of options when you install two options.
Do not install under the another option.
(1) Turn off input power of VF-PS1 and wait for at least 15 minutes and then check that
the CHARGE lamp on VF-PS1 is no longer lit.
(2)Securing the option to the inverter
a) Insert a flat-blade screwdriver in each of the two holes at the upper part of the
front panel, release the panel mounting tab by pushing the screwdriver down and
remove the front panel cover.
b) Install the option in the inverter by fitting the tabs on the lower side the option into
the slots at the lower part of the inverter front panel.
c) Make sure the option is securely attached to the inverter. Then check whether the
plastic bosses on the inverter case have fitted in the holes at the upper and lower
parts of the option.
d) Insert the tabs at the lower part of the front cover into the slots at the lower part of
the inverter to attach the front cover to the inverter.
e) Stuck the enclosed "LED name label" in the option LED display part of a front
cover.
b)
c)
a)
e)
d)
COM
ERR
LED name label

E6581539
- 9 -
3.1. Network cable connection
Connect the Metasys®N2 network cable to communication option as follows.
Title Description
Wire type Shielded twisted cable
Characteristic impedance Between 100 and 130 ohm
Distributed impedance between
conductors Less than 100pF per meter
Distributed impedance between
conductors and shield
Less than 200pF per meter
Foil or braided shield are acceptable.
Length of an MSTP segment 1200 meters with AWG18 (0.8mm2)
Cable sheath should be peeled off by about 7mm.
For wiring work, use a flat blade screwdriver with a 0.6mm thick and
3.5mm width blade.
Tightening torque for the terminal block is 0.5Nm.
* Fix a cable so that a communication connector may be not taken the weight of wire.
3.2. Network configuration
Make up the network as follows.
- Transmission/reception signals (A, B)
Make up the communication path by connecting all transmission/reception data cables.
- Signal common (GND)
GND is the signal common.
- Grounding the shield of cable (SCR)
Connect the all shield lines of network cable. The shield shall be grounded at one end only
prevent currents from being created.
- Termination resistor
A termination resistance of 120 ohms plus or minus 5% shall be connected at each of the two
ends of the segment medium. This option has a termination resistor, so if use, set up the
termination resistor SW. (Refer to 2.1 Outline)
At least one set, and no more than two sets, of network bias resistors shall exist for each segment.
This option has local bias resistors.
Termination B
A
GND
+5
510
510
Node with network
bias resistors
120
B
A
GND
Node without
bias resistors
B
A
GND
+5
47k
Node with local bias resistors
This option board
47k
4.7k
Termination
120
SCR
Communication
cable
Communication
cable
SCRSCR
SW4 TERM
4.7k
N.B.:Do not connect the SCR terminal to the power ground of inverters or other units.
Keep the network cables 20cm or more separate from the power cables to prevent from
malfunctioning due to electromagnetic noise.
7mm

E6581539
- 10 -
4. Parameters
4.1. Communication parameters
Set up the inverter parameters as follows. To update, reset of inverter. If these parameters are not
set to correct value, this unit can not work normally.
Title Function Description
 Network Time-Out 0: No action
Unit: 0.1 sec, Setting range: 1 - 1000 0000 *
f851
Operation at
communication error by
disconnection
0: Inverter stop, communication command,
frequency mode open (by cmod, fmod)
1: None (continued operation)
2: Deceleration stop
3: Coast stop
4: Network error (err8 trip)
5. Preset speed operation command
(Operating at the preset speed operation
frequency set with f852)
0
f852 Preset speed operation
selection
0: None
1 - 15: Preset speed operation 0
f853
Communication option
station address monitor
(Read Only)
Station address (setup by switch) monitor -
Network option
reset setting
0: None
1: Reset option board and inverter 0
*f832 must be set up by a hexadecimal number.
ex.) 100.0 sec = 0x3E8
** When the parameters are changed, the power must be cycled (or set f899 to 1) to the
VF-PS1 for the changes to take effect.
Note) When cmod or fmod is set to “Communication option input”, VF-PS1 drives without
RSCMDMOD (Binary Output Object - 10) or FRCMDMOD (Binary Output
Object - 11) at each Objects.
4.2. f832: Network Time-Out
Set the communication loss action time to f832. The network loss action function starts
from receiving the properly frame message. The action of the network communication
loss is set by f851.

E6581539
- 11 -
4.3. f851: Operation at communication error by disconnection
This parameter sets up the VF-PS1 response to a loss of communications with the
Metasys®N2 network.
0: Stop and Communication release
The inverter decelerates the motor to a stop and gives an alarm (the leftmost LED
flashes). Commands entered through the network are canceled, and the
commands set with parameters cmod and fmod become effective.
When communications are restored, the alarm is turned off.
1: None
The inverter remains in the state where it was when the problem arose, and it gives
an alarm.
2: Deceleration stop
The inverter decelerates the motor to a stop and gives an alarm. Commands
entered through the network are not canceled.
3: Coast stop
The inverter issues a command for a frequency of 0Hz and gives an alarm.
Commands entered through the network are not canceled.
4: Emergency stop
The error message err8 is displayed. Commands entered through the network are
not canceled.
When communications are restored, the inverter is not restored to working order and
the error message err8 does not disappear until the inverter is reset.
5: Preset speed operation command
Refer to Section 4.4.
4.4. f852: Preset speed operation selection
If the communication loss action (parameter f851) is set to 5 (preset speed command),
the VF-PS1 will run at a preset speed as set up by this parameter in the case of a
communication loss (with alarm). Commands entered through the network are not
canceled.
For example,
If the inverter is set as described below,
f851 = 5 (preset speed operation command)
f852 = 8 (preset speed operation frequency 8)
f287 (preset speed operation frequency 8) = 10 (10Hz)
Operation is carried out as follows.
Network Operation of the VF-PS1
Normal conditions ...........Operates according to commands entered through the network.
↓↓
Communications loss......Operates at 10Hz.
↓↓
Restoration......................Operates according to commands entered through the network.

E6581539
- 12 -
5. The Metasys®N2 Local/Remote Operation
The example below shows how to configure the VF-PS1 for local/remote operation.
F terminal.................Operating command
R terminal................The Metasys®N2 local/remote (Terminal in this example) switching
RR/S4 terminal .....Operation frequency command
<Wiring>
VF-PS1
F
R
CC
PP
RR/S4
Variable resistor for adjustmen
t
10k ohm
Metasys®N2 / local Switch
Operation command
SINK
SW1
SOURCE
CCA
<Parameter setting>
cmod(Command mode selection) = 0 (Terminal board)
fmod(Frequency setting mode selection 1) = 2 (RR/S4)
f112(Input terminal selection 2 (R)) = 48 (Metasys®N2/Local control)
<Operation>
R-CC terminal open: VF-PS1 is controlled as a slave device of The Metasys®N2.
R-CC terminal closed:
F-CC terminal short to RUN
F-CC terminal short to STOP
Output frequency is set up by the RR/S4 signal input.
Note) When “local / remote key” (2) is chosen as EASY key selection (f750) and EASY
key lamp of an inverter front panel lights, priority is most given to operation by a
panel. (Refer to the inverter instruction manual for details).
When operation/stop is by the control terminal and only a monitor is by N2, set
the functional number 48 (communication priority release) to the unused control
terminal and turn on or set 48 to the always active function selection (f110, or
f127 or f128).
Note) The local mode of the panel has priority over Metasys®N2 local control.

E6581539
- 13 -
6. Specifications
< Environmental specification >
Item Specification
Model number MTS001Z
Service environment
Indoors, an altitude of 3000m or less, where the product will not be
exposed to direct sunlight, corrosive or explosive gasses, vapor,
coarse particulate including dust, and where there is no grinding or
grinding oil nearby.
Ambient temperature -10 to +60℃
Storage temperature -25 to +65℃
Relative humidity 20 to 93% (No condensation and absence of vapor)
Vibration 5.9m/s2(0.6G) or less (10 to 55 Hz)
(To be complied with JIS C0040.)
Power supply 5VDC supplied from the inverter
<MTS001Z network specification >
Item Specification
Maximum node 255 nodes (32 nodes per segment)
Communication baud rate 9600bps
Bias resistor and termination Local bias resistors are mounted.
Termination resistor (120 ohm) can be select by SW.
Terminal block
Detachable terminal block 4-pole (5.08mm pitch)
Manufacturer: PHOENIX CONTACT
Type-Form : MSTB 2,5/4-STF-5.08
7. Warranty
Any part of Metasys®N2 communication option that is proved to be defective will be repaired free of
charge under the following conditions:
1. This product will be repaired free of charge, if problem/fault occurs under normal handling
within one year of delivery and is caused obviously by a design or manufacturing defect.
2. The warranty applies only to the delivered product.
3. For the following kinds of failure or damage, the repair cost shall be borne by the customer
even within the warranty period.
i) Failure or damage caused by improper or incorrect use or handling, or unauthorized repair
or modification of the inverter.
ii) Failure or damage caused by the unit falling or an accident during transportation after the
purchase.
iii) Failure or damage caused by fire, salty water or wind, corrosive gas, earthquake, storm or
flood, lightning, abnormal voltage supply, or other natural disasters.
iv) Damage due to the use of Metasys®N2 communication option for non-intended purposes.
4. If an additional warranty is provided then those conditions will also apply.
- 13 E -
