Travis Industries 250-02736 User manual

SIT Pilot Ground Upgrade Kit (E-Clip)
(250-02736)
Page 1 of 3 17601773 - 12/18/12 © Travis Industries, Inc.
Overview
This kit contains an “E” clip, grounding wire, and screws designed to improve the grounding performance of
your gas appliance. This update provides a significant improvement in grounding of the pilot, resulting in
improved pilot spark and pilot rectification.
NOTE: This kit is for Travis Industries, Inc. products only.
Items Required
•1/4” and 5/16” Nutdrivers
•Pliers
Packing List
•E-Clip
•Grounding Wire (used only on certain models – see page 3)
•(2) 10-24 x 3/8” Thread-Forming Screws (used only on certain models – see page 3)
Installation
1 Access the firebox and remove the burner (see
installation/owner’s manual for details).
2 Remove the pilot hood and place it aside.
3 Remove and discard the pilot hood clip. Needle-
nose pliers work well for this.
4 Replace the pilot hood.

SIT Pilot Ground Upgrade Kit (E-Clip)
(250-02736)
Page 2 of 3 17601773 - 12/18/12 © Travis Industries, Inc.
5 Install the “E” clip as shown to the right.
NOTE: The pilot hood should not wiggle when in place.
Make sure the “E” clip is fully inserted. The
middle tab will rest against the pilot base (apex
of hexagon) as shown to the right.
If the clip is fully inserted and the hood is not
fully secure, remove the clip and use pliers to
compress the clip slightly then re-install and
verify the hood is tight.
If the clip does not insert into the slots on the
pilot base, use pliers to carefully compress the
clip while it is in place.

SIT Pilot Ground Upgrade Kit (E-Clip)
(250-02736)
Page 3 of 3 17601773 - 12/18/12 © Travis Industries, Inc.
Install the Grounding Wire on the Following Units with Pilot Assemblies Attached by Screws:
•DVS Insert
•31 DVI Insert
•564 HO Fireplace
•Tree of Life Stove
•DVL Insert
•33 DVI Insert
•Berkshire Stove
The above units may be identified by the use of a gasket underneath the pilot assembly. If you have
one of these units, follow the directions below. All other units may disregard the steps below.
NOTE: If you have a newer version of these units, and the pilot is held in place with press-studs and
nuts, you may disregard the steps below.
Instructions:
Remove the stock screws on the pilot assembly (see illustration below). Secure the grounding wire
using the included 10-24 screws. The included screws have a larger thread designed to purchase the
metal with a larger contact area. You may need to use some torque to secure these screws.
1/4" Nutdriver 5/16" Nutdriver
Grounding Wire
Use the 10-24 screws included
with the new pilot assembly
Route the grounding wire to any of the four screws that secure the gas control valve bracket to the
valve tray. Remove the screw and secure the wire (see illustration below). Make sure the wire is
routed away from the air shutter and in a location where it will not interfere with burner installation.
Grounding
Wire
