Travis Industries DVL GSR User manual

DVL GSR / 33 DVI SS/Enamel Firebacks
SKU # 96100155 Black Enamel 96100158 Stainless Steel
Page 1 of 2 17601617 - 8/12/11 Travis Industries, Inc.
Packing List
Rear Fireback
(2) Side Firebacks
STAINLESS STEEL WARNINGS
HANDLING THE FIREBACKS: The stainless steel firebacks are shipped in vinyl to prevent marring the surface
of the stainless steel. Remove the vinyl prior to installation. Wear clean gloves when installing the firebacks
to prevent fingerprints on the surface (or use a rag or paper towel to handle the firebacks).
COLORATION AND CLEANING: These stainless steel firebacks will obtain a slight “patina” (brown tint) after
use. Do not clean the firebacks. This patina becomes consistent. Any cleaning may lead to unequal coloring.
If soot forms on the fireback, we recommend brushing it off with a soft cloth or brush.
Cleaning Enamel Firebacks
We recommend cleaning the enamel surface with glass cleaner and a soft cloth.
Installation
WARNING Turn off gas to the appliance and make sure it has fully cooled prior to conducting service.
1 Remove the glass frame and logs (see the manual for details). Add the burner.
2 On the DVL GSR, bend the accent light down. On the 33 DVI, remove the back air shield (see “LP
Conversion Instructions” in the manual for details) – replace the back air shield after firebacks are in place.
3 Install the rear fireback (see the directions below).




Slide the top of the fireback
behind the baffle and pivot into
place. It rests on the shelf at the
back of the firebox.












































































4 On the DVL GSR, return the accent light to the correct configuration.

DVL GSR / 33 DVI SS/Enamel Firebacks
SKU # 96100155 Black Enamel 96100158 Stainless Steel
Page 2 of 2 17601617 - 8/12/11 Travis Industries, Inc.
5 Install the side firebacks
following the directions
to the right.
6 Replace the burner and
restore the appliance to
the correct configuration.




Hold the side firebacks at a slight angle
and place them into position (both
sides).














































































































Remove this clip
attached to the firebox
ceiling (both sides).






Replace the clip to
secure the side
fireback (both sides).



























































































































































































