Travis Industries Bon-Fyre User manual

Bon-Fyre Log Set Maestro Fireplace
Page 1 of 10 17601980.docx — 4/25/18 © Travis Industries, Inc.
Table of Contents
Unit Sku# Page #
3’x4’,3’x5’,4’x4’ 94401121, 94401122, 94401131, 94401132, Pg. 1
3’x3’ 94401120, 94401130 Pg. 6
Part Numbers, Compatibility, and Packing List – 3’x4’, 3’x5’, 4’x4’
Compatibility Part #
# of Media Trays
#2 Log (see below) #3 Log (see below) #5 Log (see below) #6 Log (see below) #7 Log (see below) #8 Log (see below)
Threaded Rods
Used
Maestro 3’x4’ Single Sided
Maestro 3’x5’ Single Sided 94401122 2 1 1 1 1 1 5
Maestro 4’x4’ Single Sided 94401121 2 1 1 1 1 1 1 6
Maestro 3’x4’ See Through
Maestro 3’x5’ See Through 94401132 3 2 2 1 1 1 7
Maestro 4’x4’ See Through 94401131 3 1 2 2 1 1 1 8
(#2) 250-04516
(#3) 250-04517
(#5) 250-04519
(#6) 250-04520
(#7) 250-04521
(#8) 250-04522

Bon-Fyre Log Set Maestro Fireplace
Page 2 of 10 17601980.docx — 4/25/18 © Travis Industries, Inc.
Log Placement Overview – 3’x4, 3’x5’, 4’x4’
3’x4’ & 3’x5’ Maestro
4x4 Maestro
Top View
FRONT
REAR
5
SEE-THROUGH ONLY



7
Outer Glass
Inner Glass
Third Pane of Glass
Third Pane of Glass
3
68
5
3
REAR
Top View
FRONT
5



7
Outer Glass
Inner Glass
Third Pane of Glass
Third Pane of Glass
3
68
5
3
2
SEE-THROUGH ONLY

Bon-Fyre Log Set Maestro Fireplace
Page 3 of 10 17601980.docx — 4/25/18 © Travis Industries, Inc.
Preparing the Media Trays - – 3’x4, 3’x5’, 4’x4’
1. Remove and discard the stock media trays that come in the fireplace.
-- Single-Sided Units – Remove and discard the front and center media trays.
The rear media tray remains in place.
-- See-Through Units – Remove and discard all three stock media trays.
2. Thread the rods into the placement brackets in the replacement media trays that came with this
kit (see pictures below).
3. Install the Media trays into the fireplace. Make sure to place the media trays correctly (see
“Log Placement Overview” above. The larger tray should have the end with 2 rods on the right
side. The smaller media tray should have the angled rod on the left side (when looking from the
front – it is reversed at the rear of the see-through).

Bon-Fyre Log Set Maestro Fireplace
Page 4 of 10 17601980.docx — 4/25/18 © Travis Industries, Inc.
Installing the Logs - – 3’x4, 3’x5’, 4’x4’
HINT: Each log has a hole in the bottom to accommodate the alignment rod. When installing the log,
place your finger beside the hole to align the log with the threaded rod.
HINT: The alignment rods should support the logs. After the logs are installed you may wish to use the
crushed glass to shim the bottom of the logs to provide additional support.
NOTE: The see-through units have identical logs that are installed at the front and rear of the fireplace.
1. Install the crushed glass on the rear tray (see manual). Then install the outer rear glass (see
manual).
2. Install log 8 and hold it in place. Install log 6 so it props up log 8. Note how log 6 engages log 8
in the crook of a branch (see picture below to the right).
4’x4’ Versions ONLY
Place Log 2 as shown to the right.
Left log engages crook on right log
Support top of log 8 until
log 6 is in place
#8
#6
Hole in the bottom of each log
Log 2

Bon-Fyre Log Set Maestro Fireplace
Page 5 of 10 17601980.docx — 4/25/18 © Travis Industries, Inc.
3. Install log 7 as shown below.
4. Install the crushed glass on the middle tray (see manual). Then install the inner front glass (see
manual).
5. Install logs 3 and 5 as shown below.
NOTE: You may need to rotate the logs for best fit. They can lean up against the glass.
NOTE: When placing the logs make sure to rotate them so the charred side of the log faces the
center of the unit, where the flames will be present during operation.
6. Install the crushed glass on the front tray (see manual). Then install the outer front glass (see
manual).
Log 7 fits into this
notch
Log
7

Bon-Fyre Log Set Maestro Fireplace
Page 6 of 10 17601980.docx — 11/15/21 © Travis Industries, Inc.
Part Numbers, Compatibility, and Packing List – 3’x3’
Compatibility Part Number
# of Media Trays
#1 Log (see below) #2 Log (see below) #3 Log (see below) #4 Log (see below) #5 Log (see below)
Threaded Rods
Maestro 3’x3’ Single Sided 94401120 2 1 1 1 1 1 5
Maestro 3’x3’ See-Through 94401130 3 2 2 1 1 1 7
(#1) 250-04515
(#2) 250-04516
(#3) 250-04157
(#4) 250-04518
(#5) 250-04519

Bon-Fyre Log Set Maestro Fireplace
Page 7 of 10 17601980.docx — 4/25/18 © Travis Industries, Inc.
Log Placement Overview – 3’x3’
Preparing the Media Trays – 3’x3’
1. Remove and discard the stock media trays that come in the fireplace.
-- Single-Sided Units – Remove and discard the front and center media trays.
The rear media tray remains in place.
-- See-Through Units – Remove and discard all three stock media trays.
2. Thread the rods into the placement brackets in the replacement media trays that came with this
kit (see pictures below).
3. Install the Media trays into the fireplace. Make sure to place the media trays correctly (see
“Log Placement Overview” above. The larger tray should have the end with 2 rods on the right
side. The smaller media tray should have the angled rod on the left side (when looking from the
front – it is reversed at the rear of the see-through).
Top View
FRONT
REAR
2
34
5
12
SEE-THROUGH ONLY



1
Outer Glass
Inner Glass
Third Pane of Glass
Third Pane of Glass

Bon-Fyre Log Set Maestro Fireplace
Page 8 of 10 17601980.docx — 4/25/18 © Travis Industries, Inc.
Installing the Logs – 3’x3’
HINT: Each log has a hole in the bottom to accommodate the alignment rod. When installing the log,
place your finger beside the hole to align the log with the threaded rod.
HINT: The alignment rods should support the logs. After the logs are installed you may wish to use the
crushed glass to shim the bottom of the logs to provide additional support.
NOTE: The see-through units have identical logs that are installed at the front and rear of the fireplace.
See-Through Units Only
1. Install the inner rear glass (see manual).
NOTE: On see-through units using an external window, you may wish to install the rear logs from
the front (the images will be reversed – rest the logs against the outer glass).
2. Install logs 1 and 2 as shown below.
NOTE: You may need to rotate the logs for best fit. They can lean against the inner glass.
3. Install the crushed glass on the rear tray (see manual). Then install the outer rear glass (see
manual).
Hole in the bottom of each log

Bon-Fyre Log Set Maestro Fireplace
Page 9 of 10 17601980.docx — 4/25/18 © Travis Industries, Inc.
1. Install log 5 followed by log 3 as shown below.
NOTE: These pictures are shown from the front of the fireplace.
HINT: Support the upper portion of log 5 while installing log 3 (they rest against each other).


2. Install log 4 onto the threaded rod. The top end of log 4 rests in the crook of log 3 (see below)
3. Install the crushed glass on the center tray (see manual).
4. Install the inner front glass (see manual).
Log 3 should rest in
this groove in log 5 Log 3 Log 5
Log 4 threaded rod
Log 4 rests in crook of Log 3

Bon-Fyre Log Set Maestro Fireplace
Page 10 of 10 17601980.docx — 4/25/18 © Travis Industries, Inc.

5. Install logs 1 and 2 at the front of the fireplace as shown below.
NOTE: You may need to rotate the logs for best fit. They can lean against the inner glass.
6. Install the crushed glass on the front tray (see manual). Then install the outer front glass (see
manual).
7. Install the outer layers of glass.
