Travis Industries DVS EG Firebacks User manual

DVS/DVL EG Firebacks
Page 1 of 4 17602176 - 9/14/20 Travis Industries, Inc.
SKU Numbers
DVS Firebacks DVL Firebacks
Straight Brick/Herringbone sku# 96100473 Straight Brick/Herringbone sku# 96100483
Handmade Brick/Graystone sku# 96100474 Handmade Brick/Graystone sku# 96100484
Black Glass sku# 96100475 Black Glass sku# 96100485
Ledgestone sku# 96100476 Ledgestone sku# 96100486
Compatibility Tools Needed
DVS EmberGlo™ Inserts – (starting 2020) ¼” Nut Driver
DVL EmberGlo™ Inserts – (starting 2020)
Packing List
(1) Rear Fireback
(2) Side Firebacks
(2) Short - Top Fireback Clips (For Glass Firebacks ONLY)
(2) Long -Bottom Fireback Clips (For Glass Firebacks ONLY)
Installation
WARNING Turn off gas to the appliance and make sure it has fully cooled prior to conducting service.
GLASS FIREBACK WARNINGS
HANDLING THE FIREBACKS: The glass firebacks are fragile – especially the edges. Take care to prevent
contacting/scraping the glass against metal or rough surfaces. You may wish to lay out a blanket during
installation in case you need to set the firebacks down.
We recommend the use of gloves and safety glasses during the installation of the glass firebacks.
GLASS FIREBACK CLEANING
These firebacks require periodic cleaning. Do not use ammonia-based cleaners (this may cloud the glass). We
recommend ammonia-free glass cleaner (i.e. vinegar and water) to clean the fireback.
CERAMIC FIREBACK WARNINGS
The rear fireback is rectangular and must be placed right side up. Lay the firebacks on a flat
surface prior to installing to verify the texture (brick, ledgestones) are aligned.
The firebacks are fragile, especially after being exposed to heat. Take care to prevent contacting/scraping the
firebacks against metal or rough surfaces.
NOTE On two-sided firebacks make sure the rear and sides patterns match.
NOTE On rear firebacks that have brick texture make sure the edge with the full brick is at the top.
1. Access the firebox (see Owner’s Manual).
2. There are (2) fireback clips in the
firebox ceiling for DVS (1) on each
side and (3) for DVL– (1) on each
side and (1) in the back. Use a ¼” nut
driver to loosen the screws just
enough to allow the fireback clip to
move. The clip has a “keyhole” slot
on it. Slide the clip forward until it can
move freely over the head of the
screw. Tighten the screws so they do
not obstruct the installation of the
fireback panels in a later step.
Fireback Clip
Loosen Screw
TIghten Screw

DVS/DVL EG Firebacks
Page 2 of 4 17602176 - 9/14/20 Travis Industries, Inc.
3. Use a ¼” nut driver to
loosen the screws (1
each side) that secure
the burner side covers
to the burner. There is
a “keyhole” slot in the
cover so removal of the
screw is not necessary.
Push the burner side
cover toward the center
of the insert until the
hole in the cover lines
up with the head of the
screw. Lift up slightly
and remove the cover
from the firebox.
Repeat for other cover.
Set the covers aside
for reinstallation.
4. Place the rear fireback
into position and support
it with your hand until
you install the rear
fireback clip in the next
step.
1/4" Nutdriver
NOTE: the fireback
NOTE: Install the rear
rests on the ledge at
fireback bottom first. Then
the back of the firebox
tilt the top into place.

DVS/DVL EG Firebacks
Page 3 of 4 17602176 - 9/14/20 Travis Industries, Inc.
BLACK GLASS FIREBACKS ONLY – For all other firebacks skip to step 6
5. Prepare the side firebacks for
installation. Each side uses (1)
large clip on the bottom of the panel
and (1) small clip on the top of the
panel (just after the mitered corner.
Place the clips as shown below and
bend the small tabs (1 on the top
and 3 on the bottom) to secure the
clips to the glass.
NOTE: You may want to pre-bend
the tabs before placing the clip on
the glass.
6. Make sure the rear
fireback is centered in
the insert.
(DVL ONLY) Replace
the rear fireback clip to
secure the rear fireback
in place.
(DVS ONLY) The rear
fireback will be held in
place by the side
firebacks in the next
step. Support the rear
fireback with your hand
until at least one side
fireback is in place
(next step).

DVS/DVL EG Firebacks
Page 4 of 4 17602176 - 9/14/20 Travis Industries, Inc.
7. Install one of the side
panels into the firebox
as shown below. The
side fireback rests on
a shelf located to the
side of the burner.
NOTE: Push the side
fireback backward
until it contacts the
rear fireback.
8. Install a fireback clip
(removed in step 2) over the
screw. Slide the clip against
the fireback (the fireback will
be sandwiched between the
clip and the side of the
firebox). Tighten the screws
to lock the glass in place (see
below).
9. Repeat steps 6 and 7 for the opposite side fireback.
10. Reinstall the burner side covers removed in step 3.
NOTE: Slide the side burner covers toward the sides of the unit until they contact the side firebacks. Tighten the
screws to hold them in place.
Hold the side firebacks at an angle
and place them into position.
Replace the fireback
clip to secure the
fireback in place.
(see step #8).
NOTE: Mitered
corners should face
the front of the insert.
