OWNER’S MANUAL
TRINITY 48” 8-DRAWER ROLLING WORKBENCH
w/ COMBO LOCK
Model # TLSPSB-4803
Everything in its place.®

Your TRINITY 48“ Rolling Workbench should include the following parts. Please inspect box contents to
ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online at
www.trinityii.com (Help & More, Contact Us).
You will need 10mm wrench (for handles) and 14mm wrench (for casters) for assembly (not included).
Parts box and keys are located in the BOTTOM drawer.
PARTS LIST
© 2017 TRINITY - 800.985.5506
1
A
SIDE HANDLE (2)
B C
CASTER BOLT (16)
M10
D
LINER (8)
E
GH
HANDLE BOLT (8)
M6
LOCKING
CASTER (2)
F
NON-LOCKING
CASTER (2)
KEY (1)
WORKBENCH (1)
WASHER (8)
I

ASSEMBLY INSTRUCTIONS
Position SIDE HANDLE (B) over pre-installed nuts
on the side of WORKBENCH (A). Insert HANDLE
BOLTS (C) through the WASHERS (D) first, then
the holes on SIDE HANDLE (B). Use a 10mm
wrench to tighten HANDLE BOLTS (C) to
WORKBENCH (A).
Repeat these instructions to install the other SIDE
HANDLE (B).
© 2017 TRINITY - 800.985.5506 2
STEP 1
STEP 2
10mm
E (2) F (2) G (16)
A (1) B (2) C (8)
Carefully lay WORKBENCH (A) on its backside.
Position LOCKING CASTERS (E) on the same side of the
WORKBENCH (A) and align holes to pre-installed nuts
on the underside of WORKBENCH (A). Use a 14mm
socket wrench to tighten CASTER BOLTS (G) to
WORKBENCH (A).
Repeat above step to install the NON-LOCKING CASTERS
(F) on the other side of the WORKBENCH (A).
Notes:
* For ease of use, place LOCKING CASTERS (E) on the
side you will regularly push or pull.
** If you plan to push the Workbench against a wall,
place LOCKING CASTERS (E) on the front long side for
ease of access.
14mm
D (8)

ASSEMBLY INSTRUCTIONS
Place the LINERS (H) inside each drawer.
© 2017 TRINITY - 800.985.5506
3
STEP 3
H (8)
USAGE INSTRUCTIONS
COMBINATION LOCK
The factory preset combination is 0-0-0-0, even though the Dials may appear with other numbers.
Locked
Position
Unlocked
Position
Dials
Knob
Reset Position
Alignment Line
Before locking the unit, make sure all drawers are fully pushed in and closed.
To lock the unit, turn the knob to line up with the red dot and then turn the dials so that what is
displayed is no longer the 4-digit combination.
Note: If you have difficulty locking the unit, turn the knob towards the Unlocked Position (green dot)
and then slowly turn it counter-clockwise to line up with the Locked Position (red dot). Then turn dials
to lock it.

USAGE INSTRUCTIONS
SET NEW COMBINATION
© 2017 TRINITY - 800.985.5506 4
1. Slowly turn the Knob
to the Unlocked
Position (green dot),
leaving the Dials at the
preset
combination 0-0-0-0.
(Fig. A)
2. Slowly turn the Knob
clockwise 90 degrees to
the Reset Position
(white triangle).
(Fig. B)
3. Set your own
desired 4-digit
combination.
(Fig. C)
4. Slowly turn the Knob
counter-clockwise 90
degrees back to the
Unlocked Position (green
dot). Your combination
lock is now set with the
new combination.
(Fig. D)
FORGOT YOUR COMBINATION
1. The KEY (I) may be used at
any time to unlock the
workbench.
Insert and turn the KEY (I)
clockwise 90 degrees to the
Unlocked Position (green
dot).
(Fig. E)
2. Gently rotate each Dial until
it stops or until you hear a
discernible “click”.
(Fig. F)
Note:
Hold the KEY (I) firmly while you
turn Dials to retrieve your 4-digit
combination
3. Turn the Master Key counter-
clockwise 90 degrees to the Locked
Position (red dot) (Fig. G), then
remove the key.
You can now keep using the
retrieved 4-digit combination or
reset the combination by following
the instructions above.
Fig. A Fig. B Fig. C Fig. D
Fig. E Fig. F Fig. G
NOTE: Always keep your combination a secret and the key in a safe and accessible
place other than the workbench.

USAGE INSTRUCTIONS
DRAWER REMOVAL
DRAWER REPLACEMENT
Pull the drawer out so that it is almost fully extended. On the RIGHT side, push the black release lever
DOWN. On the LEFT side, pull the black release lever UP. While holding the levers as instructed, pull
the drawer forward until released from the slides attached to the Workbench (“Workbench Slides”).
Note: The slides attached to the drawer (“Drawer Slides”) are an integral part of the drawer and must
be removed along with the drawer itself.
To replace the drawer, pull the slides out completely. Insert the brackets on each side of the Drawer
Slides into the corresponding slots on the Workbench Slides, making sure they are properly positioned.
Once the brackets are inserted into the slots, completely close the drawer to set all slides in their
proper positions.
© 2017 TRINITY - 800.985.5506
5

SERVICE PARTS LIST –TLSPSB-4803
Part Number Description Part Number Description
1) AMA-05-019-1400 14” Drawer Handle 12) XBK-22-001-1416 14” Drawer Liner
2) XBK-23-007-2512 End Cap 13) XBK-22-001-2616 26” Drawer Liner
3) ZSV-01-001-0612 Handle Bolt 14) XBK-22-001-4316 43” Drawer Liner
4) ZSV-01-007-0612 Handle Washer 15) ZSV-99-003-5020 Non-locking Caster
5) PSB-05-009-1500 Side Handle 16) PSB-07-007-4403 44” Small Drawer
6) PSB-07-007-1506 15” Drawer 17) AMA-05-019-4300 43” Drawer Handle
7) ZSV-12-010-1575 Slide (workbench side) 18) XXX-10-002-0XXX Key
8) ZSV-12-009-1575 Slide (drawer side) 19) XBK-11-004-0XXX Lock
9) PSB-07-007-4409 44” Large Drawer 20) PSB-07-007-2703 27” Drawer
10) ZSV-01-001-1020 Caster Bolt 21) AMA-05-019-2600 26” Drawer Handle
11) ZSV-99-004-5020 Locking Caster 22) LNA-06-009-4819 Wood Top
TRINITY Customer Service provides the following replacement parts:
7
3
8
5
9
2
6
13
14
17
18
15
12
19
16
20
11
21
22 1
© 2017 TRINITY - 800.985.5506 6
4
10

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
3. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
4. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
5. Do NOT overload the product.
6. Lock the casters when leaving workbench in stationary position.
7. Lock the drawers before moving the workbench.
8. Do NOT open more than one drawer at a time. Tipping can occur.
9. Do NOT step on open drawers.
10. Do NOT let children play near workbench.
CARE AND MAINTENANCE
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Do not use scouring pad for cleaning.
•Keep dry and avoid damp environments.
Weight capacity per drawer 75 lb
Total weight capacity of tool chest 1800 lb
© 2017 TRINITY - 800.985.5506
