Turnstone A la carte TS 301A Series User manual

Page 1 of 3
TS301A Rev F
TS 301A
a la carteTM Task Chairs
R
©2001 Steelcase Inc.
Grand Rapids, MI 49501 U.S.A.
Printed in U.S.A.
1. Insert the shafts of the casters
into their corresponding sockets
of the base. Push in firmly. Stand
the base upright.
2. Insert cylinder into base
With base resting on floor, insert
cylinder as shown.
TS30101 TS30102 TS30105 TS30106
TS30103

Page 2 of 3
TS301A Rev F
3.  Assemble cylinder cover
Slide cylinder (A) up through cylinder (B)
(see fig 1). With cylinder (A) engaged with
cylinder (B), slide cylinder (C) down over
cylinders (A and B) (see fig 2). Refer to
fig. 3 for completed assembly.
For installation of optional stool kit
insert the gas cylinder into the
foot ring and tighten (fig 1).
Push the gas cylinder into the
base (fig 2).
4. Place cover over the cylinder in base (fig. 2) 5. Attach seat to cylinder
Line up hole over cylinder, and place seat
down. By grabbing the seat, firmly push
the entire chair towards the floor to properly
lock the tapers on the cylinder into the seat
and the base.
fig. 1 fig. 2 fig. 3
A
B
C
Fig. 2
Fig. 2
6.  Attach back to control
Remove the bolt from the
control (Fig. 1). Tighten
the seat bolt, as shown (Fig. 2).
Fig. 1 Fig. 2
A
B
C
A
B
A
B
C
Fig. 1

Page 3 of 3
TS301A Rev F
Optional Arm Installation
Height and Width Adjustable Arms
1. Remove knob from arm.
2. Push arm into arm bracket.
3. Replace knob and tighten.
Fixed Arms
1. Attach arms with four (4) phillips
head screws.
Seat front
Seat front
