Turnstone Tour Counter User manual

R
© 2008 Steelcase Inc.
Grand Rapids, MI 49501 U.S.A.
Printed in U.S.A.
T-27
1
2
1
SCREW IS PRE-ASSEMBLED
TO END OF FRAME ASSEMBLY
OPTIONAL INFILL
SHOWN THIS END
#2 SQUARE
DRIVE
SCREW TO BE
INSTALLED
1. Position tour counter end
frame assembly at each end of tour
counter. Slide pre-assembled
screws into keyholes.
2. Position four (4) 1/4-20 x 1/2"
screws. Two (2) each end. Tighten
four (4) screw each end to 4-5 ft-lb.
Tour™ Counter Assembly
Page 1 of 6
939500285 Rev D

Page 2 of 6
939500285 Rev D
GROMMET
GROMMET
GROMMET
STEEL PANEL
LAMINATE
PANEL
GROMMET
TOUR STEEL
CENTER PANEL
TOUR LAMINATE
CENTER PANEL
SCREW
3b
3b
3a
4
4
3a
3. Position center panel (3a)
into the grommets located at each
end of the counter support
assembly (3b).
4. Position and tighten screws
holding the center panel to the
counter support assembly (6
screws for laminate, 3 screws for
steel.)

Page 3 of 6
939500285 Rev D
5. Lower crossbar onto center
panel.
5
5
TOUR STEEL
CENTER PANEL
TOUR STEEL
CENTER PANEL
SIDE VIEW
(for steel center panel only)
LOWER
CROSSBAR
TOUR LAMINATE
CENTER PANEL

Page 4 of 6
939500285 Rev D
6. Attach lower crossbar to
counter end frames.
7. Using two (2) people, flip unit over.
8. Assemble end trims.
9. At each end of the counter, push
down to ensure the counter tray is
resting on the screws (9a). Place end
trims into each end of counter (9b)
making sure tab is engaged (9c).
1/4-20 x 1-1/2"
FLATHEAD SCREW
T-27 TORX DRIVE
TIGHTEN TO
4-5 FT/LBS.
TOUR COUNTER END
FRAME ASSEMBLY
LOWER CROSSBAR
8
END TRIM
TOUR COUNTER
COVER END TRIM
TAB SNAPS
INTO PLACE
9b
9c
6
TOUR COUNTER
9a
9a

Page 5 of 6
939500285 Rev D
Installing Electrical
Components (Optional)
1. Position powerway in counter with receptacles facing
downward (1a). Ensure receptacles protrude thru opening (1b).
NOTE: All power assembly and use must meet all code
requirements applicable to the location of use.
2. Use one (1) counter duplex spring bracket at each receptacle
location, (4 total). Hook one end of bracket into slot at an
angle (2a) and then push down until the other side
of the bracket engages into slot (2b).
NOTE: Bracket deforms over receptacle.
1a
1b
EACH RECEPTACLE
PROTRUDES SLIGHTLY
THROUGH OPENING
NOTE: Faces of the
receptacles are
marked I for ciruit 1
and II for circuit 2.
POWERWAY 2a
2b
TOUR COUNTER
DUPLEX SPRING
BRACKET

Page 6 of 6
939500285 Rev D
Mounting Counters
End-to-End
1. Install counter to counter tie
plate using four (4) screws. Repeat
for other side.
2. Install two-way lower frame
bracket around glides as shown
(2a). Tap lightly with rubber mallet
(2b). Repeat for other side.
1
COUNTER TO
COUNTER TIE PLATE
TWO WAY
LOWER FRAME
BRACKET
GLIDE
SCREW
2a
2b
