Instruction Sheet
AMP NE CONNEC * MRJ21*
Cassette Assemblies 1479452-1, 408-8866
LOC B
1 of 2
E 2009 Tyco Electronics Corporation, Harrisburg, PA
All International Rights Reserved
TE logo and Tyco Electronics are trademarks.
*Trademark. Other products, logos, and company names used are the property of their respective owners.
TOOLI G ASSISTA CE CE TER 1-800-722-1111
PRODUCT I FORMATIO 1-800-522-6752 This controlled document is subject to change. For latest revision and Regional Customer Service,
visit our website at www.tycoelectronics.com
13 JA 09 Rev F
1479459-1, 1777082-1, and 1777086-1
Cassette
Assembly
Plunger
(2 Places)
Ports
Patch Panel
1479451-1
MRJ21 Receptacle
Chamfered Corner
(Indicates Port 1)
Rack
Mounting Screw
(4 Places)
1/4-Turn Fastener
(Shielded Cassette
(Only)
Back Cable Manager Kit
1933352-1 (Ref)
1  6 (1 Row With 6 Ports) CASSE E ASSEMBLY 2  6 (2 Rows With 6 Ports) CASSE E ASSEMBLY
Unshielded Shielded Unshielded Shielded
1479452-1 1777086-1 1479459-1 1777082-1
Figure 1
1. IN RODUC ION
MRJ21 cassette assemblies listed in Figure 1 are
designed to be installed into Patch Panel 1479451–1.
Back Cable Manager Kits 1933352–[ ] (shown in
Figure 1) can be used to support the trunk cable. The
patch panel and cable manager kit are designed to be
mounted onto a standard 483–mm [19–in.] Electronic
Industries Alliance (EIA) rack or equipment cabinet.
Read these instructions thoroughly before starting
installation.
Reasons for reissue of this instruction sheet are
provided in Section 5, REVISION SUMMARY.
All umerical values i this i structio sheet are
i metric u its [with U.S. customary u its i
brackets]. Dime sio s are i millimeters [a d
i ches]. Figures are ot draw to scale.
To obtain information on AMP NETCONNECT
products, call PRODUCT INFORMATION at the
AMP ETCO ECT logo is a trademark of Tyco Electronics.
number at the bottom of this page, or visit the
AMP NETCONNECT website at
www.ampnetconnect.com.
2. DESCRIP ION
The front of each cassette assembly features two
plungers used to secure the assembly to the patch
panel and a chamfered corner that indicates Port 1.
The shielded cassette also has a 1/4–turn fastener
used for bonding. The back of each cassette
assembly features an MRJ21 receptacle that accepts
the connector of the trunk cable. See Figure 1.
3. INS ALLA ION
Using the mounting screws, mount the patch panel
and cable manager kit onto the rack, then proceed as
follows:
For i stallatio procedure for the patch pa el,
refer to Figure 1; for the cable ma ager kit, refer
to I structio Sheet 408-10170.
NO E
i
NO E
i

408-8866
MRJ21 Cassette Assemblies 1479452-1, 1479459-1, 1777082-1, and 1777086-1
Rev F2 of 2 Tyco E ectronics Corporation
1. Pull the plungers of the cassette away from the
face of the cassette.
2. Facing the front of the patch panel, align the
cassette with an opening in the patch panel so that
the chamfered corner is on the left (as shown in
Figure 1). This orientation is recommended so that
Port 1 of all cassettes are located at the same
position.
Note that for the shielded cassette, the 1/4–turn
fastener must align with the hole above the
mounting holes in the patch panel.
3. Slide the cassette into the opening of the patch
panel then push the plungers into the holes in the
patch panel. An audible click indicates that the
plungers are fully seated. For the shielded
cassette, using a small cross–recessed tipped
screwdriver, turn the 1/4–turn fastener
clockwise to
the locked position.
4. Plug the connector of the trunk cable into the
receptacle (at the back) of the cassette. Refer to
Figure 2. Make sure to align the keying features of
the connector and receptacle. Ensure that the
connector is fully seated,
then using a small
cross–recessed tipped screwdriver, turn the jack
screws of the receptacle
clockwise and tighten to a
maximum torque of 0.23 Nm [2 lbf–in.].
T av id damage t the receptacle, DO NOT
ver-tighten the jack screws. DO NOT use an
aut matic screwdriver.
5. Using cable ties or similar fasteners, attach the
trunk cable to the tie–down bar. It is recommended
to maintain a minimum bend radius of 50.8 mm
[2 in.] when securing and routing cables. See
Figure 2.
Figure 2
Trunk Cab e Tie-Down
Bar
Connector P ugged
into Receptac e
Cab e
Tie
Front of
Patch Pane
4. TROUBLESHOOTING
For port–to–cable pair cross–reference, refer to
Figure 3. Port numbers are based on the orientation
of the cassette assembly.
Chamfered Corner
Indicates Port 1
357911
46810122
Fr nt f Cassette Assembly
(2  6 Sh wn)
1
Back f Cassette Assembly
(2  6 Sh wn)
Pair 1Pair 3 Pair 2
Pair 4
PORT OF CASSETTE ASSEMBLY
CABLE PAIRS
1  6 2  6
CABLE PAIRS
1
1 1 and 2
1
2 3 and 4
2
3 5 and 6
2
4 7 and 8
3
5 9 and 10
3
6 11 and 12
4
7 13 and 14
4
8 15 and 16
5
9 17 and 18
5
10 19 and 20
6
11 21 and 22
6
12 23 and 24
Figure 3
5. RE ISION SUMMARY
Revisions to this instruction sheet include:
S Corrected part numbers for shielded cassette
assemblies
CAUTION
!
