Instruction Sheet
AMP NETCONNECT* MRJ21* 48-Port
10/100/1000BASE-T Angled Pat h Panels 408-8963
LOC B
1 of 2
E 2007 Tyco Electronics Corporation, Harrisburg, A
All International Rights Reserved
TE logo and Tyco Electronics are trademarks.
*Trademark. Other products, logos, and company names used are the property of their respective owners.
TOOLING ASSISTANCE CENTER 1-800-722-1111
RODUCT INFORMATION 1-800-522-6752 This controlled document is subject to change. For latest revision and Regional Customer Service,
visit our website at www.ty oele troni s. om
19 JUN 08 Rev D
1777052-1 and 1777053-1
AM NETCONNECT* AM TRAC*
rinted Circuit ( C) Board Subassembly
(2 laces) (AM TRAC atch anel Only)
EIA Rack
(Ref)
Front of Patch Panel
Back of Patch Panel
12-24 Screw
(4 laces)
HD -22 Connector
(2 laces) (AM TRAC
atch anel Only)
MRJ21 Receptacle
(8 laces)
ort Identification
(16 laces)
ort Identification
(8 laces)
2  6 RJ45 Connector
Assembly (4 laces)
Right Side AM TRAC
ort Identification (AM TRAC
atch anel Only)
Left Side AM TRAC
ort Identification (AM TRAC
atch anel Only)
Standard Pat h Panel AMPTRAC Pat h Panel
1777052-1 1777053-1
Figure 1
1. INTRODUCTION
MRJ21 48–Port 10/100/1000BASE–T angled patch
panels are designed to be mounted onto a standard
483–mm [19–in.] Electronic Industries Alliance (EIA)
rack or equipment cabinet as shown in Figure 1.
The AMPTRAC patch panel is designed for use with
the AMP NETCONNECT AMPTRAC system. Read
these instructions thoroughly before starting
installation.
All numerical values in this instruction sheet are
in metric units [with U.S. customary units in
brackets]. Dimensions are in millimeters [and
inches]. Figures are not drawn to scale.
For the AMPTRAC patch panel, these
instructions assume that the reader understands
the operation of e uipment and software used
with the AMPTRAC system.
AMPTRAC Retrofit Kit 1479853–1 can be installed
onto the standard patch panel to enable the patch
panel to be connected to the AMP NETCONNECT
AMPTRAC system. Back Cable Manager Kits
1933352–[ ] or Wiring Distribution Bracket Kit
557548–1 must be used to support the cable.
To obtain information on AMP NETCONNECT
products, call PRODUCT INFORMATION at the
number at the bottom of this page, or visit the
AMP NETCONNECT website at
www.ampnetconnect.com.
Reasons for reissue of this instruction sheet are
provided in Section 6, REVISION SUMMARY.
2. DESCRIPTION
Each patch panel contains eight MRJ21 receptacles
(two per 2  6 RJ45 connector assembly). The ports
are identified by numbers printed on the front and
back of the patch panel. Four 12–24 screws are
included to mount the patch panel to the rack.
In addition, the AMPTRAC patch panel has two pc
board subassemblies and two HDP–22 connectors
to enable the patch panel to connect to the
AMP NETCONNECT AMPTRAC system.
NOTE
i
NOTE
i

408-8963
M J21 48-Port 10/100/1000BASE-T Angled Patch Panels 1777052-1 and 1777053-1
Rev D2 of 2 yco Electronics Corporation
3. INSTALLATION
1. Using the screws, mount the patch panel onto
the rack. Refer to Figure 1.
2. Plug a connector (from the trunk cable) into
each MRJ21 receptacle (at the back of the patch
panel). Refer to Figure 2. Make sure to align the
keying features of the connector and receptacle.
Ensure that the connector is fully seated,
then
using a small cross–recessed tipped screwdriver,
turn the jack screws of the connector
clockwise
and tighten to a maximum torque of
0.23 Nm [2 lbf–in.].
To avoid damage to the connector, DO NOT
over-tighten the jack screws. DO NOT use an
automatic screwdriver.
3. For the AMPTRAC patch panel, plug the
connector of an I/O cable assembly
(PN 1499507–[ ]) from the analyzer into each
HDP–22 connector (at the back of the patch
panel). See Figure 2.
4. Install the bracket onto the rack. Using cable
ties or similar fasteners, attach the cables to the
bracket. It is recommended to maintain a minimum
bend radius of 50.8 mm [2 in.] when securing and
routing cables. See Figure 2.
For installation procedure for the wiring
distri ution racket, refer to Figure 2; for the
ack ca le manager, refer to Instruction Sheet
408-10170.
4. T OUBLESHOOTING
For port–to–cable pair cross–reference, refer to
Figure 3.
Figure 2
runk
Cable
Bracket
(Ref)
Connector Plugged
into MRJ21 Connector
(8 Places)
Cable
ie
Front of
Patch Panel
Connector of I/O Cable
Plugged into HDP-22
Connector (2 Places)
(AMP RAC Patch Panel Only)
EIA Rack
(Ref)
357911
46810122
2  6 RJ45 Connector Assem lies
(Front of Patch Panel)
1
MRJ21 Receptacle
(Back of Patch Panel)
Pair 1Pair 3
Pair 2
Pair 4
15 17 19 21 23
16 18 20 22 2414
13
27 29 31 33 35
28 30 32 34 3626
25 39 41 43 45 47
40 42 44 46 4838
37
Left Side
Right Side
351
462
Note: For Reference, Ports Labeled1-6AreShown
Pair 6 Pair 5Pair 8Pair 7
PO T CABLE PAI S
(4 Pairs Per Port)
1 13 25 37 1, 2, 3, 4
2 14 26 38 5, 6, 7, 8
3 15 27 39 9, 10, 11, 12
4 16 28 40 13, 14, 15, 16
5 17 29 41 17, 18, 19, 20
6 18 30 42 21, 22, 23, 24
7 19 31 43 1, 2, 3, 4
8 20 32 44 5, 6, 7, 8
9 21 33 45 9, 10, 11, 12
10 22 34 46 13, 14, 15, 16
11 23 35 47 17, 18, 19, 20
12 24 36 48 21, 22, 23, 24
Figure 3
5. EPLACEMENT AND EPAI
Patch panels are not repairable. DO NOT use a patch
panel with damaged or defective connectors.
6. EVISION SUMMA Y
Revisions to this instruction sheet include:
S Added text to Steps 2 and 4 and CAUTION of
Section 3
