General
Description
The Series TY-B, 80 and 115 K-factor,
Conventional Sprinklers described in
this data sheet are special response -
standard coverage, decorative 4 mm
glass bulb sprinklers designed for use
in accordance with the installation
rules recognized by the applicable Ap-
proval agency (e.g.. VdS).These sprin-
klers are intended to be installed either
pendent or upright, and in either posi-
tion, they produce a spherical water
discharge pattern with approximately
50% of the discharge directed up-
wards and approximately 50% of the
discharge directed downwards.
WARNINGS
The Series TY-B Sprinklers described
herein must be installed and main-
tained in compliance with this docu-
ment, as well as with the applicable
standards recognized by the Approval
agency, in addition to the standards of
any other authorities having jurisdic-
tion. Failure to do so may impair the
performance of these devices.
The owner is responsible for maintain-
ing their fire protection system and de-
vices in proper operating condition.
The installing contractor or sprinkler
manufacturer should be contacted
with any questions.
Model/Sprinkler
Identification
Numbers
TY3641 - Conventional 80K
TY4641 - Conventional 115K
Technical
Data
Approvals
VdS Approved (CEA 4001)
Maximum Working Pressure
12,1 bar
Discharge Coefficient
K = 80 LPM/bar1/2
K=115LPM/bar
1/2
Temperature Ratings
57°C, 68°C, 79°C, 93°C, 141°C, and
182°C
Finishes
Natural Brass, Chrome Plated, and
Polyester Coated
Physical Characteristics
Frame .............Bronze
Button .........Brass/Copper
SealingAssembly...........
. . . . . . Beryllium Nickel w/Teflon*
Bulb .............. Glass
Compression Screw . . . . . Bronze
Deflector........... Copper
* DuPont Registered Trademark
Operation
The glass Bulb contains a fluid which
expands when exposed to heat. When
the rated temperature is reached, the
fluid expands sufficiently to shatter the
glass Bulb, allowing the sprinkler to
activate and water to flow.
Installation
The Series TY-B Sprinklers must be
installed in accordance with the follow-
ing instructions:
NOTES
Do not install any bulb type sprinkler if
the bulb is cracked or there is a loss of
liquid from the bulb. With the sprinkler
held horizontally, a small air bubble
should be present. The diameter of the
air bubble is approximately 1,6 mm for
the 57°C to 2,4 mm for the 182°C tem-
perature ratings.
A leak tight 1/2 inch NPT sprinkler joint
should be obtained with a torque of 9
to 19 Nm. A maximum of 28 Nm of
torque may be used to install sprin-
klers with 1/2 NPT connections. A leak
tight 3/4 inch NPT sprinkler joint
should be obtained with a torque of 13
Series TY-B — 80 and 115 K-factor
Conventional Sprinklers
Special Response, Standard Coverage
Page 1 of 4 TFP663
JULY, 2004
Technical Services: Tel: [phone] / Fax: [phone]
IMPORTANT
Always refer to Technical Data
Sheet TFP700 for the “INSTALLER
WARNING” that provides cautions
with respect to handling and instal-
lation of sprinkler systems and com-
ponents. Improper handling and in-
stallation can permanently damage
a sprinkler system or its compo-
nents and cause the sprinkler to fail
to operate in a fire situation or cause
it to operate prematurely.

to 27 Nm. A maximum of 40 Nm of
torque is to be used to install sprinklers
with 3/4 NPT connections. Higher lev-
els of torque may distort the sprinkler
inlet and cause leakage or impairment
of the sprinkler.
Do not attempt to make-up for insuffi-
cient adjustment in the escutcheon
plate by under- or over-tightening the
sprinkler. Readjust the position of the
sprinkler fitting to suit.
The Series TY-B Conventional
Sprinklers must be installed in ac-
cordance with the following instruc-
tions.
Step 1. With pipe thread sealant ap-
plied to the pipe threads, hand tighten
the sprinkler into the sprinkler fitting.
Step 2. Tighten the sprinkler into the
sprinkler fitting using only the W-Type
6 Sprinkler Wrench (Ref. Figure 2) or
W-Type 7 Sprinkler Wrench (Ref. Fig-
ure 3). With reference to Figure 1, the
W-Type 6 or W-Type 7 Sprinkler
Wrench is to be applied to the wrench
flats.
Care and
Maintenance
The Series TY-B Sprinklers must be
maintained and serviced in accord-
ance with the following instructions:
NOTE
Before closing a fire protection system
main control valve for maintenance
work on the fire protection system that
it controls, permission to shut down the
affected fire protection system must be
obtained from the proper authorities
and all personnel who may be affected
by this action must be notified.
Sprinklers that are found to be leaking
or exhibiting visible signs of corrosion
must be replaced.
Automatic sprinklers must never be
painted, plated, coated or otherwise
altered after leaving the factory. Modi-
fied sprinklers must be replaced.
Sprinklers that have been exposed to
corrosive products of combustion, but
have not operated, should be replaced
if they cannot be completely cleaned
by wiping the sprinkler with a cloth or
by brushing it with a soft bristle brush.
Care must be exercised to avoid dam-
age to the sprinklers - before, during,
and after installation. Sprinklers dam-
aged by dropping, striking, wrench
twist/slippage, or the like, must be re-
placed. Also, replace any sprinkler that
has a cracked bulb or that has lost
Page2of4 TFP663
FIGURE 1, SPECIAL RESPONSE SERIES TY-B CONVENTIONAL SPRINKLERS
1-Frame
2-Button
3 - Sealing
Assembly
4-Bulb
5-Compression
Screw
6 - Deflector *Temperature rating is indicated on deflector or adjacent to
orifice seat on frame.
**Pipe thread connections per ISO 7/1 can be provided on
special request.
TY3641 WITH 1/2 INCH NPT TY4641 WITH 3/4 INCH NPT
2
4
5
6
56 mm 57 mm
38 mm
11 mm
NOMINAL
MAKE-IN
FLATS
WRENCH
1
33
1
2
5
4
6
**
13 mm
MAKE-IN
NOMINAL
3/4"
FLATS
WRENCH
NPT**
NPT
1/2" **
PENDENT SHOWN UPRIGHT
CROSS SECTION
PENDENT
CROSS SECTION
SHOWN UPRIGHT
SHOWN SHOWN
38 mm
TY3641 WITH 1/2 INCH NPT
FIGURE 2
W-TYPE 6 SPRINKLER
WRENCH
WRENCH RECESS
(END "A" USED FOR
1/2" NPT MODELS)
WRENCH RECESS
(END "B" USED FOR
3/4" NPT MODELS)
FIGURE 3
W-TYPE 7 SPRINKLER
WRENCH
RECESS
WREN
C
H
WITH SPRINKLER
ENGAGEMENT
IN TO ENSURE
WREN
C
HIN
G
AREA
PUSH WRENCH

liquid from its bulb. (Ref. Installation
Section).
The owner is responsible for the in-
spection, testing, and maintenance of
their fire protection system and de-
vices in compliance with this docu-
ment, as well as with the applicable
standards of the National Fire Protec-
tion Association (e.g., NFPA 25), in
addition to the standards of any other
authorities having jurisdiction. The in-
stalling contractor or sprinkler manu-
facturer should be contacted relative to
any questions.
It is recommended that automatic
sprinkler systems be inspected,
tested, and maintained by a qualified
Inspection Service in accordance with
local requirements and/or national
codes.
Limited
Warranty
Products manufactured by Tyco Fire
Products are warranted solely to the
original Buyer for ten (10) years
against defects in material and work-
manship when paid for and properly
installed and maintained under normal
use and service. This warranty will ex-
pire ten (10) years from date of ship-
ment by Tyco Fire Products. No war-
ranty is given for products or
components manufactured by compa-
nies not affiliated by ownership with
Tyco Fire Products or for products and
components which have been subject
to misuse, improper installation, corro-
sion, or which have not been installed,
maintained, modified or repaired in ac-
cordance with applicable Standards of
the National Fire Protection Associa-
tion, and/or the standards of any other
Authorities Having Jurisdiction. Mate-
rials found by Tyco Fire Products to be
defective shall be either repaired or
replaced, at Tyco Fire Products’ sole
option. Tyco Fire Products neither as-
sumes, nor authorizes any person to
assume for it, any other obligation in
connection with the sale of products or
parts of products. Tyco Fire Products
shall not be responsible for sprinkler
system design errors or inaccurate or
incomplete information supplied by
Buyer or Buyer’s representatives.
IN NO EVENT SHALL TYCO FIRE
PRODUCTS BE LIABLE, IN CON-
TRACT, TORT, STRICT LIABILITY OR
UNDER ANY OTHER LEGAL THE-
ORY, FOR INCIDENTAL, INDIRECT,
SPECIAL OR CONSEQUENTIAL
DAMAGES, INCLUDING BUT NOT
LIMITED TO LABOR CHARGES, RE-
GARDLESS OF WHETHER TYCO
FIRE PRODUCTS WAS INFORMED
ABOUT THE POSSIBILITY OF SUCH
DAMAGES,ANDINNOEVENT
SHALL TYCO FIRE PRODUCTS’ LI-
ABILITY EXCEED AN AMOUNT
EQUAL TO THE SALES PRICE.
THE FOREGOING WARRANTY IS
MADE IN LIEU OF ANY AND ALL
OTHER WARRANTIES EXPRESS OR
IMPLIED, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FIT-
NESS FOR A PARTICULAR PUR-
POSE.
Ordering
Procedure
When placing an order, indicate the full
product name. Refer to the Price List
for complete listing of Part Numbers.
Contact your local distributor for avail-
ability.
Sprinkler Assemblies:
Specify: (Specify Model/SIN), Special
Response, (specify K-factor), (specify
temperature rating), Series TY-B Con-
ventional Sprinkler with (specify type
of finish ), P/N (specify from Table A).
Sprinkler Wrench:
Specify: W-Type 6 Sprinkler Wrench,
P/N 56-000-6-387, or
W-Type 7 Sprinkler Wrench,
P/N 56-850-4-001.
TFP663 Page 3 of 4
P/N 57 — XXX — X — XXX
182°C
68°C
360
155
TEMPERATURE
RATING
57°C135
1
SPRINKLER
TABLE B
PART NUMBER SELECTION
SERIES TY-B SPECIAL RESPONSE CONVENTIONAL SPRINKLERS
79°C
286
93°C200
141°C
175WHITE POLYESTER
NATURAL BRASS
9
4
MODEL/SIN
CHROME PLATED
473 80K CONVENTIONAL (1/2" NPT)
493 115K CONVENTIONAL (3/4" NPT)
TY3641
TY4641
3WHITE (RAL9010)*
* Eastern Hemisphere sales only.

Page4of4 TFP663
