Tyger T3 User manual

Clean truck bed thoroughly before installation. Place the assembled cover on the
truck bed against the bulkhead; make sure cover is even on all sides, then
un-buckle the safety straps.
1
Securing Front Clamps
Please refer to supplemental instruction for utility track bracket installation for
Toyota and Nissan models.
1. Pull down front clamps into vertical position. Horizontal position has been set
for optimal fitment, it still can be adjusted if necessary, please refer to Adjusting
Clamp Position section.
2. Hook jaw portion of the clamp under the metal bed rail lip. Clamp pad can be
inserted at the contact point to protect paint.
3. Turn the knob until side Q-seal of the cover is compressed and clamp is snug.
2
IMPORTANT: Clamp must make
solid contact with the metal bed
rail lip for the cover to be secure.
(See Figs 5-7 in Safety Notes)
Securing Rear Clamps and Cover
Unfold the cover all the way to the tailgate; make sure it’s even on both sides.
1. Pull down rear clamps. Horizontal position has been set for optimal fitment, it
still can be adjusted if necessary, please refer to Adjusting Clamp Position section.
2. Hook clamps under the metal bed rail lips. Clamp pad can be inserted at the
contact point to protect paint.
3. Push clamp handle down to vertical position to secure the rear latch; make
sure side Q-seal of the cover is compressed and clamps are snug.
4
Securing Safety Clamps
Turn the knob counterclockwise to loosen the safety clamp with the strap, attach
clamp to the metal bed rail lip on both side, then tighten. Must make sure safety
clamps are in direct contact with the metal part of the bed rail lips.
NOTE: Warranty will be voided if the safety clamps are not secured properly when
vehicle in motion.
3
After rear clamps have been latched securely, close/lock tailgate and cover cannot
be opened from the outside.
NOTE: Cover may not completely cover to the outside edge of the bed rails due to
slight difference in truck bed shape for different year models.
Clamp
Strap
Knob
IMPORTANT: Clamp must make
solid contact with the metal bed
rail lip for the cover to be secure.
(See Figs 5-7 in Safety Notes)
T3 SOFT TRI-FOLD COVER
Please make sure all parts are included in the package.
x1
SP-BC0004
Front Seal Strip
67” x 1.4” x 0.16”
Tool
x1
SP-BC0006
Toyota
x6
SP-BC3003
Nissan
Frontier
x6
SP-BC3005
Nissan
Titan
x6
SP-BC3004
x1
SP-BC0005
Rear Seal Strip
79” x 1.2” x 0.24”
Clamp Pad
x4
SP-BC3002
x1
SP-BC0003
Front Seal Strip
67” x 1” x 0.4”
Bed Cover
x1
DAMAGED or MISSING PARTS?
Contact us directly for replacement
www.TygerAuto.com/contact
V. 20181115

Warranty will be voided if you fail to follow the notes below.
►Check and secure all clamps before driving.
►Do not drive with cover folded open and safety straps un-buckled.
►Do not overload cargo or place sharp objects in contact with cover.
►Safety clamps provide additional security, but they do not replace
front clamps. Front clamps must be securely attached.
►Maximum weight capacity of the cover is 30lbs, weight must be
evenly distributed.
►If the truck is equipped with Over-the-Bedrail bed liner (Fig.5) or
bed side rail cap with plastic lip lower than factory metal bed lip
(Fig.6), small holes of about 2” x 4” will need to be cut on the plastic
liners so the clamps can be fastened securely to the metal part of the
truck bed lips (Fig.7).
6NOTESAFETY NOTES
Fig. 6Fig. 5 Fig. 7
Folding Up the Cover
Open tailgate and release rear latches. Fold up the cover once; secure rear latch
on both sides into the groove with the clamp jaw portion facing down as shown in
Fig.1. Any other incorrect methods shown in Fig.2, Fig.3 & Fig.4 will cause
damage to the vinyl and will void warranty.
When cover is folded all the way at the cab, ensure the safety buckles are properly
secured on both sides.
Adjusting Clamp Position
The factory position has been set for optimal fitment, but if necessary, horizontal
clamp position can be adjusted by releasing the top Phillips Screw and relocating
the clamp to 1 of the 3 available positions for clamping as vertically as possible.
Phillips Screw
2. Leaking
3. Loud apping noise
when driving
4. Driving with the
cover open
5. Maintenance and
care
►Apply the provided seal strips to the gap bet-
ween the cover and truck bed.
►Make sure all 4 sides of the cover are well-
sealed, use seal strips for any exposed gaps. If
more is needed, please contact us.
►It is normal to have flapping noise when driving
at high speed, please check below if noise is too
loud.
►Make sure all clamps are latched onto the me-
tal part of the bed rail lip for a more secure fitting.
(For Over-the-rail bed liners, small 2"x 4" holes
will need to be cut to install the clamps)
►This is not recommend, especially when driving
on the highway which will void warranty.
►Use regular soap and water, avoid using strong
abrasive chemical cleaners.
1. Gap between cover
and truck bed
TROUBLESHOOTING
WARRANTY
TYGER provides hassle free warranty against any manufacturing defects.
►To claim a warranty, please contact us:
www.TygerAuto.com/contact
www.TygerAuto.com
Fig. 1 Fig. 2
Fig. 3 Fig. 4
