U-Line H-86 User manual

PAGE 1 OF 4 0315 IH-86
πH-86, H-87, H-89
FOOT-OPERATED
IMPULSE SEALERS
1-800-295-5510
uline.com
PARTS
Replacement Parts Included:
Heating Elements
Heating Element Fuse
2PCS
Transformer
Sealing
Light
Fuse
Holder Power
Switch
Power Supply
Cord
Standing Tube
Pedal Base
Foot
Pedal
Pressing
Lip
Pressing Plate For
Refractory Cloth
Operating
Board
Working Plate
Fixed Bracket
Adjustable
Tension Rod
Timer Setting
Knob
Sealing Press
Plate
Sealer
Body

PAGE 2 OF 4 0315 IH-86
ASSEMBLY INSTRUCTIONS
1. Insert Standing Tube into Pedal Base and connect with short screw.
(See Figure 1)
2. With four long screws, connect Body to Standing Tube. (See Figure 2)
3. Attach Tension Rod to Puller located under Base. Attach to Foot
Pedal. (See Figure 3)
4. Connect Working Plate Fixed Bracket to Body. (See Figure 4)
5. Attach Operating Board to Bracket using two screws. (See Figure 4)
NOTE: When attaching Working Plate Bracket, leave enough
space between Body and top of screws so Operating Board
can be attached easily.
Figure 2
Figure 1
Figure 3
Figure 4

PAGE 3 OF 4 0315 IH-86
MODEL H-86 H-87 H-89
REPAIR KIT H-204 H -173 H -174
REPLACING TEFLON ROLL
1. Turn off power and unplug sealer.
2. Remove pressing plate and loosen teflon clips.
(See Figure 6)
3. Cut off a new section of teflon tape. Replace
pressing plate and tape.
4. Adjust teflon screw to tighten teflon roll. (See Figure 7)
5. Tighten teflon clips.
REPLACING HEATING ELEMENT
1. Turn off power and unplug sealer. Release teflon clips.
2. Remove screws to release heating element.
3. Remove old heating element and replace with the
new one.
4. Reattach and tighten the teflon tape.
OPERATING INSTRUCTIONS
1. Plug in the sealer. Set the power switch to "on".
2. Adjust the timer to the minimum setting necessary for poly bag thickness.
3. Insert poly bag between pressing lips. Press the foot pedal to begin
sealing. (See Figure 5)
4. When the light turns off, sealing is complete. Wait 1 to 2 seconds to allow
the seal to cool, then release the foot pedal.
NOTE: The sealing time is automatically controlled by the timer.
You can leave the unit plugged in and turned on between seals.
Power is only used during sealing.
Figure 5
SPECIFICATIONS
MODEL H-86 H-87 H-89
Impulse Power 520 W 380 W 454 W
Seal Width 2 mm 2 mm 2 mm
Max. Seal Length 24"/600 mm 12"/300 mm 18"/450 mm
Max. Seal Thickness 16 Mil 16 Mil 16 Mil
Heat Time ~0.2–1.7 sec. ~0.2–1.7 sec. ~0.2–1.7 sec.
Weight 75 lbs. 51 lbs. 62 lbs.
Dimensions 27.75 x 15.75 x 35.5" 15 x 13.75 x 35.5" 21.25 x 15 x 35.5"
REPLACEMENT PARTS
Figure 6
Teflon
Clips
Pressing
Plate
Figure 7
Teflon
Screw
Pressing
Plate
Teflon
Tape
Heating
Element
Teflon
Clip

PAGE 4 OF 4 0315 IH-86
ADDITIONAL INFORMATION
• Always keep the sealing platform clean. Remove
any residue (typically overheated plastic) from the
teflon barrier tape.
• Clean the sealing platform with a dry cloth. Do not
use water or solvents.
• A short circuit will occur if the bottom teflon tape
strip wears out. Each time you replace the heating
element or the top teflon tape, check the bottom
teflon tape for wear or damage.
• Only use Uline replacement parts.
• A worn rubber pressure pad (under the handle) will
influence the quality of the seal. The rubber pad
should be periodically checked for uneven wear.
• Information regarding potential risks of fire, electric
shock, or injury to persons that are capable of
occurring due to use of the product. The instructions
shall caution the user to place the product and
connected cord so that it is not likely that the
product will be overturned.
• Information regarding the potential risks of electric
shock due to overfilling, the replacement of a lamp,
or cleaning the product without disconnecting the
power-supply cord.
• Instructions regarding the cleaning of the product,
including any necessity for disassembly and
reassembly.
• Close supervision is required when this product is
used near children.
